Pixapro Daylite4 Simple manual

(1)
Manual Instructions
Please read these instructions carefully before using your device for the
first time. It includes everything you need to know to avoid physical
injuries and damages.
Please pay attention to all safety notes in this instruction manual.
Please keep this manual safe. In case of selling or leaving the device to
other persons, please don’t forget to hand this manual over as well.

A) Features .............................................................................................. 3
B) Safety precautions ................................................................................ 3/4
C) Panel Diagram ................................................................................... 4/5
D) Instructions ...................................................................................... 5/6/7
Switching the device on and off
Cooling procedures
Change micro-fuse
Change of bulb
Fixing stand to the head unit
Adjust the angle and position of each light
Softbox assembling
Transportation and storage
Cleaning
E)E) Trouble shooting .................................................................................... 8
Glossary
Page
Important Information
PLEASE READ
(2)

A) Features
These units offer a convenient yet economical method of modern studio These units offer a convenient yet economical method of modern studio
lighting, suitable for use with conventional still digital or video cameras. They
provide a soft uniform diffused light. Ideal for portraits in a confided area or
web based product photography, and can be combined with a light pod
or pop up light tent. You will find the versatility of the kit useful for most types
and styles of photography, as the flicker free lamps are color balanced to
5500k enabling them to be used with many other studio lighting products.
All light bulbs are energy efficient and CE and ROHS certified. These types
of bulb are called CFL which has less heat generation than the normal
bulb. It further reduces the effect of overheating by its cool light features.
Each bulb can be operated individually on the control panel. So you can
have complete control the light power.
Here are the combination kits you can find from our shop:
B) Safety precautions
i. DO NOT attempt to repair your lighting equipment yourself.
ii. DO NOT expose the equipment to sunlight, moisture, dust, any exposure
to chemical solutions, gasoline, grease, oil, paint, or detergents can result in
permanent damage to your equipment.
iii. DO NOT insert any metal objects into your lighting equipment.
(3)

iv. DO NOT place it in close distance to the eyes of persons or animals.
Please ensure that the distance between persons and animals is at least
1m.
v. DO NOT dismantle the head unit unless it is carried out by a qualified
electrician.
vi.vi. Ensure the device is cooled down approximately 30 minutes before
starting any mounting or maintenance arrangements.
vii. Ensure the device is cooled down approximately 15 minutes for every
hour of use.
viii. ENSURE that the device is always positioned tilt and skid resistant and
stored securely.
ix.ix. ENSURE the device is disconnected the power supply when the light is
not in use and before mounting and maintenances.
x. Please ENSURE the original cables are used.
xi. In case of falling-off, please ENSURE the device is checked by qualified
electrician before switching on again.
xii. ENSURE all the inflammable materials are kept away from the devices.
xiii. Please ENSURE bulbs are handled with care to avoid bursting.
xiv.xiv. Please ENSURE the power supply is either AC220-240V 50HZ or
AV110-120V 60HZ to ensure the light is working safely.
xv. AVOID touching bulbs when mounting or charging accessories.
xvi. AVOID holding lamp sockets while attaching the softbox
C) Panel Diagram
(4)

D) Instructions
Switch the device on and off
Turn on the device by pressing down the power button to each bulb. The
POWER ON light will turn red light. It will take 30 -60 seconds until the bulb
reach its maximum output.
Cooling procedures
Cooling procedures must be taken place when the device has undergone:
- 15 minutes cooling down period for every hour of use.
1. The device shall be cooled down for at least 15 minutes.
2. During cooling procedures, you MUST ENSURE the lamp has been
switched off.
Change of micro-fuse
Danger of electric shock and fire through short circuit. A 5A 220V micro-fuse
shall be used.
1. Switch off device (see Switch on and off of device)
2. Disconnect from power supply by unplugging power cord.
3.3. Unscrew the fuse hold and pull it out with your hands completely out of
the slot
4. Take out the old micro-fuse.
(5)

5. Take the new micro-fuse out of the spare slot and insert it in the centre of
the holder.
6. Screw the fuse holder carefully into the slot as far as it goes.
(6)
Change of bulbs
Please use CE bulbs.
Posterior danger of bursting of bulbs. Don’t touch the flash tube with bare
hands and you shall wear cotton gloves or use clean and dry cloth.
1. Switch off the main switch and follow by unplugging the power cord.
2. Cool down device for at least 15 minutes.
3.3. Remove old bulbs:
- Remove the outer and inner diffuser
- Screw out the old bulb
4. Attach the new bulb:
- Screw in the new bulb.
- Put the outer and inner diffuser back into position.
5. Then switch on the device.
Note: Change of bulb does not require dismantling the head unit. This action Note: Change of bulb does not require dismantling the head unit. This action
is DANGEROUS and it is prohibited.
Note: DO NOT USE BULBS more than 105W. We always recommend using
bulbs 105W or below.
Fixing Stand to Head Unit
Firstly, unscrew the star shape knob at bottom corner of the head unit
completely, then sit the light unit on the stand, and then screw it back on to
lock it
Adjust the angle and position of each head unit
Unscrew the knob (clock wise) to loosen the unit and adjust to required
angle/position and then screw the knob (anti-clock wise) to secure its angle/position and then screw the knob (anti-clock wise) to secure its
position.

(7)
Softbox Assembling
Care should be taken when a soft box is assembled for the first time, due to
the canvas not yet being stretched. You will find that assembly will become
easier after a few times. (It does take a little strength to initially erect- the rods
are powerfully sprung so care should be taken and we advise that protective
eyewear should be worn.)
1)1) Remove the Canvas and rods from the carry case; also remove any
packaging from the continuous Light Head.
2) Spread out the Canvas on a clean surface with the silver foil side visible
and place the speedring in to the center, you may need to align the holes of
the speedring to the corners of the softbox.
3) Insert the tip of the Rods in to the hole of the canvas material corner pock-
ets.
4) Insert the larger tip of the rods in to the speedring. You may need to push
down on the rods to the place them in the speedring holes, slightly bending
the rods.
5) Repeat the above method on the corner opposite the 1st rod you have
placed in.
6)6) On the Internal light diffuser there are small clips on each of the four cor-
ners , use these to secure the light diffuser inside the softbox, you will find a
loop they connect on to approximately half way down the rod
7) Finally take the External light diffuser and stretch over the four corners. Use
the velcro edges down the sides to secure the diffuser in place.
Do not hold onto lamp sockets whilst installing the softbox.

(8)
Transportation and storage
1. Switch off device (see Switch on and off device) and disconnect the
power supply by unplugging power cord.
2. Cool down the device completely.
Fire hazard due to hot parts.
3. Screw out the bulbs.
4.4. Clean the device as necessary.
5. Put the device and all demounted elements into the anti-shock packing
and carry and store them at cool and dry place.
Cleaning
Posterior danger of bursting of bulb, so you MUST ENSURE not to touch
the bulb with bare hands accidentally.
Danger of electric shock, so you MUST ensure the power supply is discon-
nected during cleaning and you MUST AVOID contact with moisture and
water.
E) Trouble Shooting
