PLANET ECLIPSE ETHA3 User manual

etha3
01
SUB TITLE
Planet eclipse: etha3
User manual: english .68cal

Etha3 etha3
02 !
SUB TITLE I PORTANT SAFETY NOTICES
Etha3 etha3
! !
I PORTANT SAFETY NOTICES I PORTANT SAFETY NOTICES
PLANET ECLIPSE PAINTBALL EQUIPMENT IS NOT A TOY.
PAINTBALL SAFETY RULES MUST BE FOLLOWED AT ALL
TIMES.
Careless or improper use of the marker and/or parts, including
failure to follow instructions and warnings within this User Manual
could cause serious injury or even death.
Do not remove or deface any warnings attached to the marker.
Paintball industry standard eye/face/ear and head protection
designed specically to stop paintballs and meeting ASTM
standard F1776 (USA) or CE standard (Europe) must be worn by
the user and any person within range. Proper protection must be
worn during assembly, cleaning and maintenance.
Hearing protection should be worn.
Never shoot at a person who is not wearing proper protection.
Never look directly into the barrel of the marker. Accidental
discharge into the eyes may cause permanent injury or even
death. Never look into the barrel or breech area of the marker
whilst the marker is switched on and able to re.
Keep the marker switched off until ready to shoot.
Treat every marker as if it is loaded and ready to re.
The electronic On/Off button or mechanical Safety switch is the
marker’s disabling device. Always switch the marker off when not
in use.
Always t a barrel-blocking device to the marker when not in use.
Always remove paintballs from the marker when not in use.
Do not eld strip or remove any parts while the marker is
pressurised.
Do not pressurise the marker without all the components of the
marker correctly installed, as high-pressure gas may be emitted.
Do not re the marker without the bolt correctly installed.
Never put your nger or any foreign objects into the paintball
feed tube of the marker.
Never allow pressurised gas to come into contact with any part of
your body.
Always remove the rst stage regulator and relieve all residual
gas pressure from the marker before disassembly.
Always remove the rst stage regulator and relieve all residual
gas pressure from the marker for transport and storage.
Always follow guidelines given with your rst stage regulator for
safe transportation and storage.
Always store the marker in a secure place.
Observe all local and national laws, regulations and guidelines.
Persons under 18 years of age must have adult supervision when
using or handling the marker.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Only use professional paintball elds where codes of safety are
strictly enforced.
Use compressed air/nitrogen only. Do not use any other
compressed gas or pressurised liquid including CO2.
Always follow instructions, warnings and guidelines given with any
rst stage regulator you use with the marker.
Use 0.68 inch calibre paintballs only.
Always measure your marker’s velocity before playing paintball,
using a suitable chronograph.
Never shoot at velocities in excess of 300 feet (91.44 metres) per
second, or at velocities greater than local or national laws allow.
Any installations, modications or repairs should be carried out by
a qualied individual at a licensed and insured paintball facility.
This User Manual is in English.
It contains important safety guidelines and
instructions. Should you be unsure at any
stage, or unable to understand the contents of
this manual you must seek expert advice.
Le mode d’emploi est en Anglais.
Il contient des instructions et mesures de
sécurité importantes. En cas de doute, ou s’il
vous est impossible de comprendre le
contenu du monde d’emploi, demandez
conseil à un expert.
Este manual de usuarios (operarios)
Usarios está en Inglés.Contiene importantes
normas de seguridad e instrucciones. Si no
está seguro de algùn punto o no entiende los
contenidos de este manual debe consultar con
un experto.
Diese Bedienungs - und Benutzeranleitung
ist in Englisch.
Sie enthaelt wichtige Sicherheitsrichtlinen und
- bestimmungen. Solten Sie sich in irgendeiner
Weise unsicher sein, oder den Inhalte dies
Heftes nicht verstehen, lassen Sie sich bitte von
einen Experten beraten.
Warning !
This user manual must accompany the product in the event of resale or new
ownership. Should you be unsure at any stage you must seek expert advice.

Etha3 etha3
04 05
SUB TITLE WELCO E TO PLANET ECLIPSE
Etha3 etha3
04 05
contents
WELCO E TO THE N3XTL3V3L
SUPPORT
As an Eclipse customer you will have access to
our worldwide technical support network that will
help you with any technical problems from
localised service centres to on-site* tech support.
WARRANTY *
All Eclipse Markers have 24 months limited
warranty from the date of manufacture, or a
minimum of 12 months with proof of purchase.
Meaning we got your back from day one.
QUALITY
All Eclipse products undergo meticulous checks
by experienced specialists who care about the
product that arrives at your door. Precision
materials + high standards = a quality product.
STANDARD
Your Eclipse marker is awesome and requires no
after market parts however, for genuine Eclipse
accessories and support please consult your local
Eclipse Dealer for upgrade options.
* Conditions apply, see online policies for full
details at planeteclipse.com/warranty
05 Welcome to Planet Eclipse
06 Setting Up
08 Switching The ETHA3 On/Off
09 LED Status Indicator
10 Velocity Adjustment
11 Trigger Adjustment
12 Unloading The Marker
14 Storage And Transportation
15 We Got Your Back
16 The Set-Up Mode
17 Presets
20 Fault Finding Tables
24 Parts List
26 Inline Regulator
27 Solenoid Assembly
28 Gamma Core Bolt Assembly (68cal)
29 Frame Assembly
30 Clamping Feed Neck Assembly
31 Two-Piece Grips
32 Push On Purge System (POPS) Assembly
33 Tournament Lock Button
34 ETHA3 Circuit Board
35 Glossary Of Terms

Etha3 etha3
06 07
SUB TITLE SETTING UP
Etha3 etha3
06 07
SETTING UP
Warning !
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or used
incorrectly.
Only attach an air system certied for use within the country of use.
Never add lubricants or grease into the ll adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you feel
condent with your ability to handle the marker safely and responsibly.
A
I
H
G
F
E
B B C
D
Fig.1 FIG.1
ASwitch the marker OFF before you begin.
This ensures the marker will not re when the trigger is pulled.
BAttach the barrel.
Rotate the barrel tip counter-clockwise into the back section.
Rotate the barrel back clockwise into the marker body.
CAttach a barrel blocking device for safety.
DAttach the preset air system.
Rotate the air system clockwise into the ASA body.
ELoosen the clamping feed neck.
Open the feed neck lever away from the feed neck.
Rotate the feed neck lever screw counter-clockwise.
FAttach the loader.
Loosen the clamping feed neck if it’s too tight.
GSecure the loader.
Close the feed neck lever to secure.
Rotate the feed neck lever screw clockwise to tighten.
HGas the marker.
Push the POPS switch towards the POPS body until it engages.
ISwitch the marker ON when you are ready to play.
The marker will now re when the trigger is pulled.
!IMPORTANT! To switch the marker ON/OFF see page 8.
!DO NOT over-tighten the barrel.
!ALWAYS ensure marker is de-gassed when setting up.
!NEVER use CO2. Only use compressed air or Nitrogen.

Etha3 etha3
08 09
SUB TITLE LED STATUS INDICATOR
Etha3 etha3
08 09
SWITCHING THE ETHA3 ON/OFF PUSH BUTTON SAFETY
The frame Ahouses the On/Off button Band
the status indicator C. Use the On/Off button
to switch the marker On/Off.
FIG-1
SWITCHING THE ETHA3 ON
Press and hold the On/Off button. Release the
On/Off button when the status indicator lights
up.
On power up, if the marker is unable to load
its previous settings it will restore the factory
settings. If this happens, the LED will ash
RED (error), then BLUE factory reset).
See pages 16-17 for settings.
SWITCHING THE ETHA3 OFF
Press and hold the On/Off button. Release the
On/Off button when the status indicator turns
RED. The marker will now switch off.
FIRING THE ETHA3
Pull the trigger to re the marker. If the marker
is ON and able to re then it will do so. warning!
If the On/Off button does not work contact your local Eclipse Dealer immediately and
do not use the marker.
When the marker is On, the marker is live and will re with every pull of the trigger, if
an air system is tted.
Fig.1
Fig.1
FIG-1
The status indicator is visible on each side of the marker and is used to
indicate a number of different things.
BREECH SENSOR STATUS
After power up the status indicator Cwill display the status of the
breech sensor (BS). The breech sensor (BS) is used to detect paintballs
in the breech of the marker.
The table below shows each LED colour and its relevant BS status.
BATTERY STATUS
1Tap the On/Off button Bwhen the marker is On.
2The status indicator Cwill indicate the status of the battery for
2 seconds (see the table below for battery status colour
information).
The status indicator also indicates the various marker parameter
settings. See pages 16-17.
A
Led colour Breech sensor (BS) status
Flashing Yellow BS enabled. NO paintball detected. Marker WILL NOT re.
Flashing Light Blue BS enabled. Paintball detected. Marker WILL re.
Flashing Purple (Slow) BS disabled. Marker WILL re.
Flashing Purple (Fast) Blockage detected. BS disabled. Marker WILL re.
Red Replace battery! Marker may or may not re.
Led colour Battery status
Green Battery level is good.
Yellow Battery level is low.
Red Replace the battery!
Flashing Red Insufcient energy. Replace the battery immediately!
C
B
B
C

Etha3 etha3
10 11
SUB TITLE TRIGGER ADJUST ENT
Etha3 etha3
10 11
VELOCITY ADJUST ENT DETENTS
WARNING!
DO NOT exceed 300FPS.
ALWAYS wear correct protective equipment when ring your marker.
NEVER point your marker in the direction of other people when not on the eld.
ALWAYS be aware of where the barrel is facing when adjusting the velocity.
FIG-1
The pre-travel screw Aadjusts the distance
the trigger travels before the microswitch is
actuated. Clockwise reduces the amount of
travel (shortening the trigger), counter-
clockwise increases the trigger pre-travel
distance.
The trigger spring screw Badjusts the spring
strength of the trigger return. Clockwise
increases the spring strength, counter-
clockwise reduces the spring strength.
The post-travel screw Cadjusts the distance
the trigger travels once the microswitch has
been actuated. Clockwise reduces the
amount of travel (shortening the trigger),
counter-clockwise increases the trigger post-
travel distance.
B
C
Fig.1
warning!
Do not wind the screws in too far as this may prevent
the marker from ring or even damage the marker.
If the pre-travel screw is wound in too far this could
cause the marker to re unintentionally.
FIG.1
Insert a 1/8” hex key Ainto the velocity adjuster screw Bto alter the
velocity of the marker.
ADJUSTING THE VELOCITY:
ATurn the hex key clockwise to reduce velocity.
BTurn the hex key counter-clockwise to increase velocity.
!Fire two clearing shots after each velocity adjustment for an
accurate velocity reading.
!DO NOT turn the adjuster screw in too far.
This will prevent the marker from ring.
B
Fig.1
1/16”
1/8”
A
A

Etha3 etha3
12 13
SUB TITLE UNLOADING THE ARKER
Etha3 etha3
12 13
UNLOADING THE ARKER UNLOADING THE ARKER
Warning !
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or used
incorrectly.
Only attach an air system certied for use within the country of use.
Never add lubricants or grease into the ll adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you feel
condent with your ability to handle the marker safely and responsibly.
FIG.1
ASwitch the marker OFF before you begin.
This ensures the marker will not re when the trigger is pulled.
BAttach a barrel blocking device for safety.
CDe-gas the marker.
Push and hold the POPS button then pull the POPS switch
away from the POPS body.
DRemove the preset air system.
Rotate the air system counter-clockwise from the ASA body.
ELoosen the clamping feed neck.
Open the feed neck lever away from the feed neck.
Rotate the feed neck lever screw counter-clockwise.
FRemove the loader.
If the feed neck is too tight, loosen the clamping feed neck
more.
GRemove the barrel.
Rotate the barrel counter-clockwise from the marker body.
HSeparate the barrel sections.
Rotate the barrel tip clockwise from the barrel back.
!IMPORTANT! To switch the marker ON/OFF see page 8.
!ALWAYS attach a barrel blocking device to avoid injury.
!ALWAYS remove air system before unloading.
!ALWAYS remove any paintballs from the breech of the marker
once the loader has been removed.
Fig.1
A
C
F
E
G H B
D

Etha3 etha3
14 15
SUB TITLE WE GOT YOUR BACK
Etha3 etha3
14 15
STORAGE AND TRANSPORTATION ECLIPSE TECH SUPPORT
From our live tech services, instructional video
guidance and ongoing warranty support
you’ll quickly discover that our reputation for
industry-leading after-sales care goes way
beyond anything you’ve experienced before.
So pat yourself on the back for making the
right choice and welcome to the family.
#WEGOTYOURBACK
!Your marker must be clear of all paint and propellant during
transportation or storage.
!Make sure the marker is switched OFF.
!Remove the barrel from the marker.
!Make sure the marker is clean of any paint residue, dirt and
moisture.
!Store your marker in a clean, cool, dry place.
!Keep your marker away from any unauthorised or unsafe users.
!Protect your marker from excessive heat during transportation.
!When transporting a paintball marker by air, check with the
airline regarding their policies on transporting paintball
equipment as hold luggage before arriving at the airport.
!Observe and obey all local and national laws concerning the
transportation of paintball markers.
!Use the box in which the marker was originally supplied to
protect the marker against rough handling during transport.
tech
support
scan to access our live tech support hub.
tech
videos
scan to watch in-depth technical guidance videos.
warranty
registration
scan to check warranty support eligibility.
WARNING!
Never carry your marker un-cased when not on a playing eld. The non-playing public and law enforcement personnel may not be able to distinguish between a paintball marker and a real
rearm. For your own safety, and to protect the image of paintball, always carry the paintball marker in a suitable marker case, such as the one in which it was supplied.

Etha3 etha3
16 17
SUB TITLE PRESETS
To modify the control parameters you must access the set-up mode:
1Fully depress and hold the trigger.
2Switch on the marker.
3The status indicator should ash WHITE.
4Release the trigger.
If the status indicator ashes RED then access to set-up is denied
because the tournament lock is still on. Turn off the tournament lock
(page 33) and try again.
Once in set-up mode, use the trigger to cycle through the parameters,
indicated by the colour of the status indicator (see table below).
Quickly press the On/Off button to display the current parameter value.
A long LED ash indicates the unit, whilst a short LED ash indicates the
tenth. E.g. 5 long ashes and 3 short ashes would indicate 5.3.
MODIFYING A PARAMETER
1Enter the set-up mode.
2Select a parameter using the trigger.
3Push and hold On/Off button for 1 second to select.
4The LED will go off.
5Increase the unit value using the trigger, one pull per unit.
6Push the On/Off button to switch to tenths values.
7Increase the tenths value using the trigger, one pull per tenth.
Do not pull the trigger if the value should be 0.
8Push the On/Off button to conrm. The status indicator will
ash 3 times: GREEN if the value is accepted, RED if the value
is invalid. If the status indicator was red then try again.
9Push and hold the On/Off button until the status indicator turns
BLUE to exit set-up mode.
To reset all of the parameters to their factory-set default values press
and hold the tournament lock button for 2 seconds while in set-up
mode. The status indicator will ash BLUE when the parameters have
been reset.
1The settings will return to their previous saved values if you do
not pull the trigger for 5 seconds.
2If a parameter does not support tenths, this will be skipped.
Etha3 etha3
16 17
THE SET-UP ODE FAULT FINDING TABLES
Led colour parameter range
Red Preset 1 to 4
Green Maximum ROF with BS on
(capped modes only) 4.0 to 15.0 bps
Blue Maximum ROF with BS off 4.0 to 15.0 bps
Purple Dwell 18 to 28
Light Blue Debounce 1 to 10
The Preset parameter is used to quickly set up the marker to operate
within the rules of the most common paintball leagues. Simply set the
Preset parameter to the required value as shown in the table below.
The rate of re caps used by the presets are safe values to allow for
variations in rate of re measuring equipment.
To change the rate of re, rst set the preset parameter and then set
the two maximum ROF parameters (GREEN and BLUE).
value mode description
1 SEMI ∞ Uncapped Semi-Automatic: one shot per trigger pull with no rate of re cap.
2 SEMI 15.0 Capped Semi-Automatic: one shot per trigger pull with 15.0 bps rate of re cap.
3 NXL NXL compliant ramping with a 10.2 bps rate of re cap.
4 PSP PSP compliant ramping with a 10.2 bps cap and 1.0 ms restart.

Etha3 etha3
18 19
FACTORY RESET INSTALLING A 9V BATTERY
It is important that the marker is set-up as per factory standards before
use.To restore to factory settings follow these steps.
FIG-1
1Enter set-up mode (see page 16). Reset all of the parameters to
their factory-set default values by pressing and holding the
tournament lock button for 2 seconds (see page 33).The status
indicator will ash BLUE when the parameters have been reset.
2Using the 1/8” hex key Aturn the inline regulator screw B4
turns clockwise from it’s fully screwed-out position.
!DO NOT turn the adjuster screw in too far.
This will prevent the marker from ring.
The lock n’ load battery system is located in the foregrip and makes
changing your battery easy.
FIG-1
1Pull out the bottom locking tab A.
2Pinch and hold the side locking tabs B.
3With the side locking tabs held rmly, pull the battery base C
out of the bottom of the foregrip and remove.
4The battery base has a positional diagram Dto show the
correct orientation of the battery and terminals.
5Install your battery ensuring the terminal position is correct E.
6Replace the battery base C, ensuring the side tabs click and
lock into place.
7Push the bottom locking tab Aback in place to lock the unit.
!DO NOT use rechargeable batteries.
!DO NOT use poor quality batteries.
Fig.1
A
B
C
E
B
Fig.1
1/8”
A
D

Etha3 etha3
20 21
FAULT FINDING TABLES FAULT FINDING TABLES
SY PTO POSSIBLE CAUSE SOLUTION
Although a fresh battery has been tted, the marker will
not switch on.
The battery has insufcient power. Replace the battery.
The battery has been tted the wrong way. Remove the battery and check that the terminal indicators and the
battery orientation are correct.
The battery does not last very long. The battery is low quality. Replace with a good quality alkaline or lithium battery.
Do not use a low quality or rechargeable battery.
The marker leaks from the solenoid.
The following items may be damaged or dirty:
Solenoid gasket, air transfer pipe o-ring,
solenoid plate gasket.
Ensure the gaskets are seated correctly.
Replace the gaskets if damaged (using your parts kit).
Check condition of the #010 NBR70 air transfer pipe o-ring
Solenoid valve is over-pressurised.
Check and adjust the inline regulator output pressure.
Clean and inspect the inline regulator assembly, especially the
piston tip and regulator seal.
Replace damaged components where necessary.
Damaged or incorrect seals on the solenoid spool. Replace and/or lubricate solenoid spool seals.
Damaged SMC solenoid pilot valve. Replace the SMC solenoid pilot valve.
The marker leaks down the barrel.
Dirty or damaged can o-rings. Clean, lubricate or replace the #020 NBR70 and #017 NBR70 o-
rings on the front of the can.
Dirty or damaged spool o-rings. Clean, lubricate or replace the #011 NBR70 and #012 NBR70 o-
rings on the main spool.
Dirty or damaged bolt o-rings. Clean, lubricate or replace the 14x2 NBR70 o-ring on the back of
the bolt.
Dirty or damaged rear bolt guide o-ring. Clean, lubricate or replace the 14x2 NBR70 o-ring towards the back
of the bolt guide.
SY PTO POSSIBLE CAUSE SOLUTION
Low rate of re or not reaching the ROF cap.
The loader’s force setting is too low (where applicable). Increase the loader’s force feed setting.
The breech sensor is defaulting and reducing the ROF. Check the position and condition of both breech sensors.
Clean or replace the breech sensor light pipes if required.
The marker is breaking paintballs in the barrel or breech.
The ball detents are damaged or missing. Replace the ball detents.
The loader’s force setting is too high (where applicable). Reduce the loader’s force feed setting.
The paintballs are poor quality. Try a higher grade of paint.
The breech sensor is switched off. Switch on the breech sensor.
The bolt and/or breech sensor is dirty. Cleane the bolt and breech sensor/light pipes.
The marker velocity is set too high. Check and adjust the velocity accordingly.
The marker does not re.
The marker is not switched on. Power up the marker using the ON/OFF button.
The POPS is not fully engaged. Push in the POPS switch until it engages.
The battery quality or charge level is very low. Install a new high quality alkaline or lithium battery.
The battery is at. Replace the battery.
The DWELL parameter is set too low. Increase the DWELL parameter.
The trigger is set-up incorrectly. Adjust trigger to fully open and close the microswitch.
The solenoid is not plugged into the PCB. Plug the solenoid wire into the PCB port.
The breech sensor is enabled but no paint in the breech. Fill loader with paint. Ensure loader is feeding correctly.
The PCB is damaged. Replace the PCB.
The solenoid valve is damaged. Replace the solenoid pilot valve.

Etha3 etha3
22 23
FAULT FINDING TABLES FAULT FINDING TABLES
SY PTO POSSIBLE CAUSE SOLUTION
Low constant velocity. The inline regulator output pressure set too low. Increase the output pressure of the inline regulator.
High velocity rst shot. The inline regulator is creeping. Strip and clean the inline regulator, replacing the regulator seal.
Velocity drop-off during rapid re.
The battery quality or charge level is low. Install a new high quality alkaline or lithium battery.
Air system regulator does not have high enough ow. Try another air system and get your current one checked out
Dirty/partially blocked inline regulator. Strip, clean, lubricate and rebuild the inline regulator.
The trigger is very ‘bouncy’.
Incorrect lter settings. Check that the DEBOUNCE settings suit your trigger set-up.
The trigger pull is too short and return strength too low. Refer to the manual’s Trigger Adjustment page to rene.
The breech sensor is not reading correctly.
The breech sensor light pipes are dirty. Keep the breech sensor light pipes clean for correct readings.
Breech sensor cover(s) are not tted correctly. Check, remove and re-t the covers correctly.
Breech sensors are damaged or bent on the PCB. Check that the breech sensors are pointing outwards.
Make sure the sensor legs are not broken.
The breech sensor turns itself off after ring and the
display shows a breech sensor fauly.
The sensors or light pipes are dirty. Clean the breech sensors and light pipes.
The sensors are faulty. Replace the main circuit board.
The sensors are out of place. Make sure the breech sensors are pointing outwards.
SY PTO POSSIBLE CAUSE SOLUTION
Two or more paintballs are being fed into the breech.
Worn, damaged or missing ball detents. Change the rubber ball detent(s).
The loader’s force setting is too high (where applicable). Reduce the loader’s force feed setting.
The marker is inconsistent.
The inline regulator is dirty. Strip and clean the inline regulator, replace seal accordingly.
The DWELL is too low. Increase the DWELL setting.
Using poor quality paintballs. Use higher grade paintballs.
Poor paintball size to barrel bore match. Find a better barrel bore size.
Inconsistent air supply from the air system. Service the air system.
The marker is inefcient. Poor paintball size to barrel bore match. Find a better barrel bore size.
Powering up, the status indicator shows WHITE or RED.
The trigger is being pulled. Release the trigger before powering up the marker.
Microswitch is permanently depressed by an incorrectly
set-up trigger. Adjust the trigger so that it’s not being activated at rest.

Etha3 etha3
24 25
SUB TITLE PARTS LIST
Etha3 etha3
24 25
PARTS LIST PARTS LIST
FIG.1
AClamping Feed Tube Assembly
BMarker Body Shell
CQuick-Release Back Cap
DGamma Core Bolt Assembly
ERubber Detent
FOn/Off button (left side only)
GSolenoid Assembly
HRear Frame Screw
IFront Frame Screw
JFrame Assembly
KTrigger Assembly
LGrip Retaining Clip
MRegulator Assembly
NLock N’ Load Battery Assembly
OPOPS Assembly
PBarrel O-Ring
#016 NBR70
Q9V Battery
RLight Pipe
SBreech Sensor
IS H
GK
A
EEE EEP
EEQ
EEM
EEN
EEO
C
J
L
B D
F
R
Fig.1

Etha3 etha3
26 27
SUB TITLE SOLENOID ASSE BLY
Etha3 etha3
26 27
INLINE REGULATOR FL 3-WAY VALVE
FIG.1
ASolenoid Body Gasket
BSolenoid Body
C#6 seal - Custom
DSolenoid Spool
E6 x 1 NBR70
FSolenoid Gasket
GSolenoid Plate
HM1.6 x 5 Machine Screws
ISolenoid Pilot
JSolenoid Plug
KM2 x 16 Cross Pan head Screws
FIG.1
ARegulator Body
B#015 NBR70 O-Rings
CAdjuster Bottom
D#011 NBR70 O-Ring
EPurge Poppet Spring
FPurge Poppet
GRegulator Seal
HAdjuster Top
I#008 NBR70 Internal O-Ring
J#011 NBR70 External O-Ring
KRegulator Spring
LRegulator Piston
M14x2 NBR70 O-Ring
NRegulator Cap
D
E
G
J
M
A
F
H
K
L
N
C
I
B
Fig.1
B
D
E
J
K
A
C
F
G
H
I
Fig.1

Etha3 etha3
28 29
SUB TITLE PUSH ON PURGE SYSTE (POPS) ASSE BLY
Etha3 etha3
28 29
GA A CORE BOLT ASSE BLY (68CAL) BOLT ASSE BLY-50CAL
FIG.1
AQuick Release Back Cap
B#020 NBR70 O-Ring
CValve Chamber
D#010 NBR70
EPlunger
FSwitch
G#016 NBR70 O-Ring
HSpring Guide
ISpool Spring
JSpool
K#012 NBR70 O-Ring
L#011 NBR70 O-Ring
M#008 NBR70 O-Ring
NBolt Guide
O#014 NBR70 O-Ring
P14 x 2 NBR70 O-Ring
Q#013 NBR70 O-Ring
RBolt
S14 x 2 NBR70 O-Ring
T#015 NBR90 O-Ring
U#013 NBR70 O-Ring
VCan
W#020 NBR70 External O-Ring
X#017 NBR70 Internal O-Ring
C
E
F
K
P
Q
D
J
N
O
EEA
B
L
M
T
U
R
S
V
W
X
I
H
G
Fig.1 FIG.1
APOPS Bonnet
BPOPS Body
CLatch Spring
DLatch Button
EPush Rod
F#004 NBR70
G#004 NBR70
H#005 NBR90 (Internal O-Ring)
I#007 NBR70 (External O-Ring)
JPOPS Insert
KPOPS Pin
G
D
C
B
I
K
F
Fig.1
E
A
H
J

Etha3 etha3
30 31
SUB TITLE TWO-PIECE GRIPS
Etha3 etha3
30 31
CLA PING FEED NECK ASSE BLY TWO-PIECE GRIPS
FIG.1
AClamping Feed Nut O-Ring
#004 NBR70
BClamping Feed Nut
CShort Clamping Feed Screw
10-32 UNF x 1/2”
DFeed Tube
EMachined Clamping Feed Screw
FFeed Insert
GFeed Lever
HFeed Swivel
IFeed Swivel O-Ring
#006 NBR70
Fig.1
C
E F G
I
H
D
A B
The tool-less two-piece grip system makes it
incredibly easy to remove and clean the grips
after a big day out in the eld.
FIG-1
ALocate and pull back the rear grip
locking tab.
BUse the nger recess to help release
the rear grip section.
COnce released, pull to fully remove
the rear grip section from the frame.
DThe front grip section can now be
released and removed.
EYou can now easily access the frame
and separate grip pieces for thorough
cleaning.
Repeat the steps in reverse order to reattach
the grips to the frame.
warning!
When cleaning the frame, there are exposed
operational elements that may be affected if wet.
Fig.1
A
C
A
B
D
E

Etha3 etha3
32 33
BREECH SENSOR ACCESS TOURNA ENT LOCK BUTTON
The tournament lock button Bsits behind the
breech sensor cover Aon the left hand side
of the marker.
FIG-1
To lock/unlock the marker press the
tournament lock button Bonce and you will
be able to alter/lock the marker settings.
See pages 16-17 for parameter settings and
status indicator.
Fig.1
B
A
FIG.1 (ACCESS)
Use a 5/64” hex key to remove the breech
cover screw Aby rotating counter-clockwise.
Then release the breech cover B.
FIG.2 (DETAILS)
ABreech Cover Screw
6-32UNC x 5/16
Countersunk socket screws
BBreech Cover
CLight Pipe
DRubber Detent
EDetent Recess
FTournament Lock Button
GBreech Sensor
Fig.1
Fig.2
5/64”
C
G
E
A
A
B
B D
F

Etha3 etha3
34 35
ETHA3 CIRCUIT BOARD FRA E ASSE BLY
FIG-1
CIRCUIT BOARD: TOP
ACircuit Board
BTournament Lock Button
CBreech Sensors
DSolenoid Connector
FIG-2
CIRCUIT BOARD: BOTTOM
A9V Battery Terminals
BPush Button Switch
CLED Unit
DMicroswitch
C
C
AD
B
D
B
A
Fig.1
Fig.2
C
Q
M
L
R
D
A
B
I
F
C
G
H
I
Fig.1
E
J
P
O
N
S
K

Etha3 etha3
36 37
GLOSSARY OF TER S GLOSSARY OF TER S
Air System 07, 09, 13, 22–23
Barrel 02, 07, 10, 13–14, 20–21, 23, 25
Battery 09, 19–22, 25, 34–35
BLUE 08–09, 16–18
Breech Sensor 09, 21–22, 25, 32–34
Circuit Board 04, 22, 34–35
Detent 11, 21, 23, 25, 32
Feed Lever 30
Feed Neck 04, 07, 13, 30
Frame 04, 08, 25, 31, 35
Gamma Core 04, 25, 28
GREEN 09, 16–17
Grip 04, 25, 31
LED 04, 08–09, 16, 34
LIGHT BLUE 09
Light Pipe 22, 25, 32
Lock N’ Load 19, 25
Microswitch 21, 34
On/Off 02, 04, 07–09, 13, 16, 21, 25
Parameters 09, 16–18, 21, 33
POPS 04, 07, 13, 21, 25, 29
PSP 17
PURPLE 09, 16
Rate Of Fire 17, 21
RED 08–09, 16, 23
Regulator 02–04, 07, 13, 18, 20, 22–23, 25–26, 35
Reset 08, 16, 18–19
Semi 17
Set-Up 04, 16, 18, 21
Solenoid 04, 20–21, 25, 27, 34–35
Spool 20, 27–28
Status Indicator 04, 08–09, 16, 18, 23, 33
Tech Support 05, 15
Tournament Lock 04, 16, 18, 32–34
Trigger 04, 07–09, 11, 13, 16, 21–23, 25, 35
Velocity 03–04, 10, 21–22
Warning 03, 07, 09–11, 13–14, 31
Warranty 05, 15
YELLOW 09

Etha3
38 SUB TITLE
Get more
Planeteclipse.com
get
more
scan to access
everything that
is planet eclipse.
THIS PRODUCT IS COVERED BY AND/OR LICENSED UNDER ONE OR MORE OF THE
FOLLOWING PATENTS:
G.B. PATENTS:
2,342,710; 2,345,953; 2,352,022; 2,391,292; 2,391,063;
U.S. PATENTS:
7,836,873; 7,603,995; 7,073,284; 8,104,463; 7,509,953; 7,921,839; 7,089,697; 7,866,307;
8,082,912; 7,076,906; 7,607,424; 7,980,238; 8,960,175; 8,528,877; 8,201,547; 8,397,706;
8,210,160; 7,073,284; 6,311,682; 6,748,938; 6,860,259; 6,941,693; 6,973,748; 5,881,707;
5,967,133; 6,035,843; 6,474,326; 6,637,421; 6,644,295; 6,810,871; 6,901,923; 7,121,272;
7,100,593; 7,610,908; 7,603,997; 7,946,285; 6,349,711; 7,044,119; 7,185,646; 7,461,646;
7,556,032; 7,591,262; 7,617,819; 7,617,820; 7,640,925; 7,640,926; 7,866,308;
APPLICATION NUMBERS:
12/256,832; 12/613,958; 12/493,777; 11/654,721; 11/747,107; 12/503,504; 11/781,821;
60/832,548; 11/965,886; 10/280,115
Additional U.S. and International Patents may be pending.
UK
Unit 14 Premier Park, Acheson Way
Trafford Park Road, Trafford Park
Manchester, M17 1GA, England
T: [phone]
planeteclipse.com/contact
USA
130 Franklin Street
Building L4 & L5
Warren, RI, 02885, USA
T: [phone]
planeteclipse.com/contact
EUROPE
PE-Paintball.De Gmbh
Langenberger Str. 9 Tor 5 & 6
Düsseldorf 40233, Germany
T: [phone]
planeteclipse.com/contact
© Planet Eclipse Ltd.
5069__EN_ETHA3-Manual-V1
