VIP-351PT
PLANET continues to bring innovation to the Voice over IP communications
market with cutting edge products and Internet telephony manufacturing
experience. PLANET now introduces the latest member of mainstream
enterprise series 4-line desktop PoE IP phone family: the VIP-351PT.
The standard features of the VIP-351PT includes 4-line, dual 10/100
switched Ethernet ports and integrated IEEE power over Ethernet (802.3af)
circuitry for offering a choice of powering and cabling options to help
reduce cabling expenses and cord clutter.
To give most flexibility to users, the VIP-351PT platform contains a 128 x
64 pixels graphic LCD with Back light, 4 Line keys, 4 soft-buttons, 5 speed
dials, 7 fixed function keys and a navigation key. The PLANET VIP-351PT
desktop phone is engineered to make Easy-to-install communications, cost-
effective to deploy, self-contained, service-integrated, intelligent phone
features offering and powerful voice processing power as possible.
The VIP-351PT can effortlessly deliver toll voice quality equivalent to
the regular VoIP / IP PBX connections utilizing cutting-edge 802.1p QoS
(Quality of Service) capabilities to encompass, 802.1q VLAN tagging, echo
cancellation, comfort noise generation (CNG) and voice compensation
technology. Meanwhile, the dual Ethernet interfaces on the IP phone allow
users to install in an existing network location without interfering with
connections of desktop PC networks.
The VIP-351PT has streamlined wired IP telephone that provides additional
features such as built-in PPPoE / DHCP clients, password-protected
machine management, call hold, forwarding, mute, transfer, waiting,
pickup, caller ID, speed-dial, 3-way conference, last number redial,
incoming message indicator, multiple call appearances and user-intuitive
web administration system.
Data Sheet
1
Key Features
PRODUCT FEATURES
IEEE 802.3af Power-over-Ethernet•
Full-Featured enterprise SIP Desktop Phone•
802.1p (QoS) / 802.1q (VLAN)•
Full duplex speakerphone (mic and speaker)•
Pixel-based monochrome LCD (128 x 64) with backlight•
Efficient installation deployment of IP PBX solution•
Reversible base stand / wall mount•
VOIP FEATURES
SIP 2.0 (RFC3261) compliant•
Supports up to 4 service domains•
Interoperability with leading PLANET IP PBX platforms•
Voice codec support: G.711(A-Law, u-Law), G.723.1, G.729 A/B•
In-band, out-of-band DTMF Relay (RFC 2833) and SIP INFO•
Three-way Conference / Caller ID / Speed Dial•
Call Hold / Mute / Forward / Transfer / Waiting•
Voice processing: VAD, CNG, AEC, Adaptive Jitter Buffer•
Management
Enterprise PoE IP Phone
Applications
VIP-351PT Enterprise PoE IP Phone Solution for IP PBX
Deployments
IPX-2000
IP PBX
FGSW-2620PVS
PoE Switch
VIP-351PT
Internet
PSTN
PC
PC
PC
PC
PC
PC
PC
PC
PC
RJ-45
RJ-45(PoE)
RJ-11

PLANET reserves the right to change specications without prior notice. All brand names and trademarks are property of
their respective owners. Copyright © 2008 PLANET Technology Corp. All rights reserved.
PLANET Technology Corporation
11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
Email: [email protected] www.planet.com.tw
VoIP Gateway: vip.planet.com.tw
VIP-351PT
Data Sheet
2
Specification
Product Enterprise PoE IP Phone
Model VIP-351PT
Hardware
WAN 1 x 10/100 Base-TX RJ-45 port (802.3af support)
PC 1 x 10/100 Base-TX RJ-45 port
Display 128 * 64-pixels LCD with Back Light
Function Keys
4 x Line Buttons (Green LED)
4 x Soft Buttons
2 x Navigation Buttons
2 x Volume Buttons
5 x Hot Line Buttons
7 x Fixed Function Buttons (DND, MENU, SELECT, MESSAGE (Green LED), MUTE (RED LED),
SPEAKER (Green LED)
Protocols and Standard
Standard
SIP 2.0 (RFC 3261)
RTP(RFC 2833)
STUN (RFC 3481)
UPnP (TBD)
SNTP (RFC 2030)
TCP/IP, UDP, HTTP, ICMP, DNS, NTP
STUN (RFC 3481)
UPnP (TBD)
Outbound Proxy
Voice Code G.711(A-law /μ-law), G.729 A/B, G.723.1 (6.3 Kbps / 5.3Kbps)
Voice Standard
Auto negotiation
Acoustic echo cancellation for integrated speakerphone operations
Voice activity detection
Silence suppression
Comfort noise generation
Dynamic Jitter buffer
Call Progress Tone Generation
DTMF Support: In-band / Out-of-band DTMF (RFC 2833) / Out-of-band DTMF (SIP Info)
Security
802.1p (QoS)
802.1q (VLAN)
Class of Service (VLAN tag or TOS)
Full Range VLAN ID Support
Features
Call Features
Caller ID display
Address Book (50)
Missed Calls (10)
Received Calls (10)
Placed Calls (10)
Date / Time Display
Speed dial configuration (mapped to 5 speed dial key)
Network Setting
Time Zone Setting
Call Flash (via Soft Key)
SIP port configurable
RTP port configurable
Call Forward: Busy Forward / No Answer Forward / Unconditional Forward
Call Waiting
Call Transfer
Call Hold
3-way Conference
DND (Do Not Disturb)
Multi-line Appearance / Registration (up to 4)
Selectable Ring Tone
Distinctive Ring by Group Name
NTP Support
LCM Contrast Adjustment
XML Configuration

VIP-351PT
Data Sheet
3
Ordering Information
VIP-351PT Enterprise PoE IP Phone
05-08 C-VIP351PT
PLANET reserves the right to change specications without prior notice. All brand names and trademarks are property of
their respective owners. Copyright © 2008 PLANET Technology Corp. All rights reserved.
PLANET Technology Corporation
11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
Email: [email protected] www.planet.com.tw
VoIP Gateway: vip.planet.com.tw
Network and Configuration
Internet Connection Type Fixed IP, DHCP, PPPoE
Management
LCD / Keypad UI
Web (HTTP)
Remote Software Upgrade (TFP/FTP)
Auto Provision (TFTP)
Dimension (W x D x H) 218 mm x 195 mm x 80 mm
Operating Environment 0~45 degree C, 0~95% humidity
Power Requirement 5 V DC
EMC/EMI CE, FCC
