Planet WSG-401 User manual

Hot Spot
Wireless Subscriber Gateway
WSG-401
User s Manual

WSG-401 UserManual
2
Copyright
Copyright (C) 2004 PLANETTechnology Corp. Allrights reserved.
The productsand programsdescribed inthisUsersManual arelicensedproductsofPLANET
Technology,This User sManual contains proprietary information protected by copyright, and this Users
Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of thisUser sManual maybe copied, photocopied,reproduced, translated,or reduced to any
electronicmediumor machine-readable formby any means by electronicor mechanical.Including
photocopying, recording, or information storageand retrievalsystems, forany purposeotherthanthe
purchaser's personaluse, and without theprior express written permission of PLANET Technology.
Disclaimer
PLANETTechnology does not warrant that thehardware will work properly inall environmentsand
applications, and makesnowarranty and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or fitness fora particular purpose.
PLANEThasmade every effort to ensure that thisUsersManual is accurate;PLANETdisclaims
liability for any inaccuracies or omissions that may have occurred.
Information in this UsersManual is subject to change without notice and doesnot represent a
commitment on the part of PLANET. PLANETassumesno responsibility for any inaccuracies that may
be contained inthis User sManual. PLANETmakesnocommitment to updateorkeepcurrent the
informationinthis User sManual, and reserves theright tomakeimprovementstothisUsersManual
and/or to the products described in this Users Manual, at any time without notice.
If you find information in thismanual that isincorrect, misleading, orincomplete, wewould appreciate
your comments and suggestions.
CE mark Warning
The is a class B device,In a domestic environment, this product maycauseradio interference, in which
casethe user may be required totake adequate measures.
Trademarks
The PLANETlogo isatrademark of PLANETTechnology.Thisdocumentationmayrefer to numerous
hardware and software productsbytheirtradenames. Inmost, if not allcases, thesedesignationsare
claimedas trademarks or registered trademarks by their respective companies.
Revision
User s Manual for PLANETHot Spot WSG-401:
Model: WSG-401
Rev: 1.0 (Dec. 2003)
Part No. EM-WSG401V1

WSG-401 User Manual
3
Table of Contents
1. Introduction.....................................................................................................................................4
1.1 Package Contents..................................................................................................................4
1.2 Features.................................................................................................................................4
1.3 WSG-401 Outlook..................................................................................................................6
1.4 TechnicalSpecifications.........................................................................................................8
2. Installation.....................................................................................................................................12
2-1 Wall-Mounting......................................................................................................................12
2.2 Connecting theAntennas.....................................................................................................12
2.3 Installation Requirements.....................................................................................................13
2-4 GettingStart.........................................................................................................................14
3. Configuring the WSG-401.............................................................................................................16
3-1 Setting Wizard......................................................................................................................16
3-2 Advanced Setup...................................................................................................................38
3-3 System Status....................................................................................................................116
3-4 SystemTools......................................................................................................................122
AppendixA RJ-45 Connector Description........................................................................................131

WSG-401 UserManual
4
1. Introduction
Inheritingtheconvenienceof Plug-n-Play Internetaccess, the PLANETWSG-401 istheidealsolution
for establishing Hot Spot Internet service applications. Via built-in billing mechanismand integrated with
receipt printing capabilitiesmakesthe PLANETWSG-401 suitablefor providing Internet access of
businesses and public areas applications, suchas hotel, cyber café,train stations, schoollibraries and
airports.
The PLANETWSG-401 comprises802.11b+, wireless access point, interface, a4-port auto-sensing,
auto-MDI/MDI-X10/100Mbpsswitch,andastandard 10/100Base-TXWANport providing superior
Internet access for wired, and wireless subscribers. Internet subscriber gateway WSG-401 combines
all thefunctionalitiesinasingle, tiny box,WSG-401 can work independently,no enormousRADIUS
system integration, and no muchcomputer expertise required, this benefit customerto deploy their Hot
Spot business faster and easier than ever.WSG-ACG,acompact thermal printer allowing machine
operators, clerks and cashiers to print out billinginformation.
1.1 Package Contents
Pleaseinspect your package. The following items should beincluded:
l One WSG-401
l Two antennas
l One AC Power Adapter for WSG-401
l One CD containing User s Manual
l One Quick Installation Guide
l Two screws for wall-mount
l One UTPEthernet/Fast Ethernet cable (Cat.5Twisted-pair)
If any of the above items are damaged or missing, please contact your dealer immediately.
1.2 Features
l Ideal Hot Spot solution
Viatheintegrated 802.11b wireless interface, mobile users canestablishhighspeed Internet
access without any configuration.
l Zero configuration (Plug-n-Play) Internet access
WSG-401 translates proper IP address information for Internet access, allIP configurations,
DHCP,Private IP or StaticIP information will be turned into Internet-ready configurations.
Subscribers won't feel the difference, and no need to face to the inconvenience ofIP
reconfigurations.
l Built-inproprietary AAAmechanism and billing system
PLANETWSG-401 integratesWeb-based Authentication (including subscriber SSL logon page),

WSG-401 User Manual
5
selective Web-basedAccounting,and proprietary billingmechanism, which can helpyou
prepare abilling mechanism inavery short time, andbilling systeminWSG-401 works without
RADIUS system, andbring most convenience, theleast efforts for billing applications.
l Exclusive Printer Accounting
Machine operators may customizethe printout information for different billing application.
l Securityand Firewall
With built-in 64/128/256-bit RC4 WEP Encryption, VLAN Security for Wireless, subscriber SSL
Login Page /Admin Page, VPN (IPSec/PPTP) Pass through.....various security features,
PLANET WSG-401 bringyou anease-f-useand most comfort safeInternet access environment.
l Ease-of-Use and Management
The built-inweb management interfacein WSG-401 bringsmost conveniencetosystem
administrators or machineoperators while configuring machine or setting up subscriber
privileges in movements. With time increments, clerks or machine operators may print out, billing
and other user information with time increments are convenientlyprinted on the button-operated
printer includedwith thePLANETWSG-401. Timeincrements may be compiled simplyby
pressingtheprinter button multiple times. Nocomputersorcomplexback-end subscriber
management systems are required for deployment.
Note: The "PnP" Functiononly can be usedwithTCP/IP-based Network.

WSG-401 UserManual
6
1.3 WSG-401 Outlook
Figure 1-1 WSG-401 Outlook
1-3-1 Top Panel
The top panelof the WSG-401 is shown below.
Figure 1-2 WSG-401Top Panel

WSG-401 User Manual
7
LEDs Indication
LED State Description
Off WSG-401 is not receivingelectrical power. Power
Green WSG-401 is receiving electrical power.
Green The WAN port is usedtoconnect your xDSLor Cable modem. WAN
Green (Blinking) Data is intransmitting andreceiving on WAN port.
Green Aport has established avalid 10/100Mbps network connection.
Green (Blinking) 10/100Mbps traffic is traversing the port.
LAN (1-4)
Off Port has not established any network connection.
Green The WSG-401 has establisheda valid wireless connection.
Wireless
Green (Blinking)
The Wireless connection is active.
Off The WSG-401 status is defective.
Green (Solid) WSG-401 status is complete.
Status
Green (Blinking) During firmware upgrades, this status LED will blink.
1-3-2 Rear Panel
Rear panel of PLANET WSG-401 is shown below.
Figure 1-3 WSG-401 Rear Panel
1. Power Jack:
Used toconnect the external power supply with PLANET WSG-401 device.
2. LAN Port:
WSG-401 supports four auto-sensing RJ-45 portsand all portscanbe auto-switched to MDI-II
connections. The LANports usedfor linkinghosts or other networking device.
3. WAN Port:
One RJ-45 port usedfor linkingxDSLorCable Mode
4. Device Port
Used toconnect theThermalPrinter WSG-ACG.
1-3-3 Left SidePanel
The left side panelof the WSG-401 is shown below.

WSG-401 UserManual
8
1. Reset Button:
WSG-401 integrates areset buttonat the left side panelof thedevice. Under somecircumstances you
might needto reset thedevice.
Figure 1-4 WSG-401 Left Side Panel
1.4 TechnicalSpecifications
1-4-1 Hardware Specifications
Network Specification
IEE802.3 10BaseT Ethernet
IEE802.3u 100BaseTXFast Ethernet
IEE802.11b Wireless LAN
ANSI/IEEE 802.3 NWayauto-negotiation
Wi-Fi Compatible
Connectors
Four LAN Ports (10BaseT/100BaseTXAuto cross-over)
One WANPort (10BaseT/100BaseT)
One Device Port (1DB25 male RS232 for external device application)
Wireless Operation Range
Open Space: 100~300m
Indoors: 35~100m
Wireless Data Rate
22 Mbps, 11 Mbps, 5.5 Mbps, 2 Mbps, 1Mbps
Encryption
64/128/256-bit RC4

WSG-401 User Manual
9
External Antenna Type
2dBi (Max) Dual detachable diversity antenna with reverse SMA
Power Requirement
External Power Adapter
Input: 100-240 VAC, 50/60 Hz
Output: 5V, min 1.4A
LED Indicators
One POWER LED
One WANLink/Activity LED
Four LAN Link/Activity LEDs
One Wireless Link/Activity LED
One Status LED
Dimension
Size: 200(L) x130(W) x44(H) mm
Weight:About 400g (Net)

WSG-401 UserManual
10
Environment Conditions
Operating Temperature: 0 to50°C
Operating Humidity: 10~90% non-condensing
Certifications
FCC part 15 Class B, CE, Class B, UL,
CE , C-Tick
Mounting
Desktop, Wallmounted
1-4-2 SoftwareSpecifications
Networking
• IEEE802.310BaseTEthernet
• IEEE802.3u100BaseTXFast Ethernet
• Supports 100 Simultaneous Users
• IPPlugand Play (iPnP)
• HTTPProxy Support
• WEPData Encryption
• SMTP Server Redirection
• DHCP Server
• DHCP Relay
• Static IP WANClient
• DHCP WAN Client
• PPPoE WANClient
• PPTP WANClient
• NAT
• IPRouting
• NTP (Network Time Protocol) Support
• IPMulticast support
Marketing Cooperation
• Advertisement URLlink
• Walled garden
• CustomizeLogin Page
• Portal Page

WSG-401 User Manual
11
AAA/ Billing
• Built-inAuthentication
• Web-basedLogin Page Authentication
• Exclusive Printer Accounting without PCoperating
• Web-basedAccounting
• Flexible Billing Profiles andPrice Plan
• Flexible Billing Mechanism (Pre-Paid and Post-Paid)
• Flexible TimeMechanism (TimetoFinish andAccumulation)
• Credit Card Support (Authorize.net and iTable)
• External PS/2Keypad Support
Security
• Layer 2 Isolation
• SSLLogin Page
• SSL Administration
• VPN Pass through (IPSec/PPTP/L2TP)
• CustomizeSSLCertificate
• Pass through DestinationIP/URL
• Pass through SourceIP/MAC
• Restricted Destination FilteringIP/URL
• Share LAN Resources
Management
• Administrator/Super Subscriber/Account Manager ManagementAccess
• Remote Browser-based Configuration and management
• Authorized remotemanagement (Access Control List)
• Firmware Upgrade via HTTP/TFTP
• Scheduled Firmware Upgrade
• Backup/Restore/Factory Default Setting
• LAN Device Management
• Dynamic DNS
• System Information Table
• Real-time Current User List / DHCP Clients List / SessionList /Account List
• Syslog
• Status Report (Daily/Monthly/System/Network)

WSG-401 UserManual
12
2. Installation
Following sessions are physical installation stepsof WSG-401. Please refer to the illustration and follow
the steps belowto complete theinstallation of your device.
2.1 Wall-Mounting
The WSG-401 can bewall-mounted on a wall by applying thetwo mounting brackets onscrews.
Figure 2-1 Wall-Mounting Bracket - Bottom of WSG-401
Pleaserefer tothefollowing instructions for mounting a WSG-401 ona wall or other surface.
1. Install two screws on awall according to the relative positions shown below.
Figure 2-2
2. Hang WSG-401 on the wall by sliding thetwo screws in themounting brackets.
Note:If the screws arenot properly anchored, the strainof thecables connected to the WSG-401 rear
panel connectors couldpull out the WSG-401 from the wall.
2.2 Connecting the Antennas
PLANET WSG-401 provides two antenna connectors on the rear of the unit for wireless subscribers.

WSG-401 User Manual
13
2.3 Installation Requirements
Before installing the WSG-401, make sure your network meets the following requirements.
System Requirements
The WSG-401 requires one of the following types of software:
l Windows 98 SecondEdition/NT/2000/XP
l Red Hat Linux7.3 or later version
l MAC OS X10.2.4or laterversion
l Any TCP/IP-enabled systems like Mac OS and UNIX(TCP/IPprotocol installed)
l Standard phone linefor xDSLmodem
Or Coaxial cable for Cablemodem
l Web Browser Software (Microsoft I.E 5.0or later version or Netscape Navigator 5.0 orlater
version)
l One computer with an installed 10Mbps, 100Mbps or 10/100Mbps Ethernet card
l UTP network Cable with a RJ-45connection (Package contents)
Note: Prepare twisted-pair cables with RJ-45plugs. Use Cat.5 cable for all connections. Make sure
each cable not exceed 328feet (Approximately 100 meters).
ISPRequirements
Verify whether your ISPusefixed or dynamicIP. If it is afixed IP, be sure toget the IPfrom your ISP.
For dynamic IP, which is mostly used, thePC will get the IPautomatically whenever it hooks upon
the modem.
DynamicIP
l Dynamic IPSetting

WSG-401 UserManual
14
Fixed IP
l Your fixed IP address for the WSG-401
l Your subnet mask for the WSG-401
l Your default gateway IPaddress
l Your DNS IP address
PPPoE
l Your username fromyour ISP
l Your password fromyour ISP
PPTP
l PPTP Server IPAddress from your ISP
l PPTP LocalIP address from your ISP.
l PPTP LocalIP subnet mask from your ISP.
l Your username fromyour ISP
l Your password fromyour ISP
Your PC Requirements
The Static IP settings forthe PC
l Your PCs fixed IP address
l Your PCs subnet mask
l Your PCs default gateway IPaddress
l Your PCs primary DNS IP address
Note:
1. Thegateways default IPaddress setting is “192.168.0.1”.
2. Thegateways default subnet mask settingis “255.0.0.0”.
The DynamicIPsettings forthe PC
We recommend that you leave your IP settings as automatically assigned. Bydefault, WSG-401is a
DHCP server, and it will give your PC thenecessary IPsettings.
2.4 Getting Start
1. Placethe WSG-401 and Miniaccount generator printer on aflat work surface.
2. Connect theDB25connector of printer cableintothe device port on the rear of the WSG-401.
3. Plugtheotherend oftheprinter cable intotheRJ11port of the miniaccount generatorprinter. Check
that the account generator printerstatus LED lights.
4. Ensure that your modemandcomputer are bothswitched on.
5. Usethesuppliedcableto connect theWSG-401's WANport tothemodem. Check that the
Cable/xDSL Status LED lights.
6. Connect your computer to one of the 10/100 LAN ports on the WSG-401.Check that the LAN Port

WSG-401 User Manual
15
Status LED lights.
7. Configure the further parameters via aweb browser.
Figure 2-1 WSG-401 Connection

WSG-401 UserManual
16
3. Configuring the WSG-401
3.1 Setting Wizard
Step 1: Start your browser, and then enter thefactory default IP address 192.168.0.1 in your browser s
locationbox. Press Enter.
Step 2: The WSG-401 configuration tools menu will appear. In the Username and Password field, type
the factory defaultusername(admin)andpassword (password)and click “Getting
Started”.If you are first time settingthe system, the wizard setup screen will appear.You will
be guided, step-by-step, through a basic setupprocedure.
Figure 3-1 ConfigurationTools Menu
Username:
admin
Password: password

WSG-401 User Manual
17
Note:
FIf you would liketochange the password please see Step10.
FUsername and Passwordcanconsist of up to 20 alphanumeric characters and are casesensitive.
FIf for some reason your password is lost or you cannot gain access to theWSG-401 Configuration
Program, please press thereset button to load the device to manufacturer defaults.
FIf the WSG-401 doesnt send packet in5 minutes (default), the WSG-401 wills logout automatically.
FProxy needs to set disable first when administrator accesses admin UI.
Step 3: Internet Connection Setting
Select the appropriate Internet connection type toconnect toyour ISP.
lDHCP Client
Figure 3-2 Internet Connection Setting Screen—DHCP Client Setting
The devicecanwork as aDHCPclient. Thisallowsthedevicetoobtain the IP address and other
TCP/IP settingsfromyour ISP.If your xDSL/Cable comes with thisfeature, please enable Use DHCP
Client.

WSG-401 UserManual
18
l Static IPSetting
If “Static IP”is selected, then this screen will appear. Enter theIP address information provided by your
ISP.
Figure 3-3 Internet Connection Setting Screen—Static IPSetting
Item Default Description
IPAddress 0.0.0.0 Enter the IPaddress provided by your ISP.
Subnet Mask 0.0.0.0 Enter the subnet mask provided by your ISP.
Gateway IP
Address
0.0.0.0 Enter the Gateway IPAddress provided by your ISP.
Primary DNS
Server
Empty Enterthe
primary DNSserver IPaddress forthexDSL/Cable
connection (provided by your ISP).
Secondary DNS
Server
Empty Enter thesec
ondary DNS server IPaddress for the xDSL/Cable
connection (provided by your ISP). If the primary
DNS Server IP were
not available, meanwhile, Secondary DNS Server IP would startinthe
same time.

WSG-401 User Manual
19
l PPPoE (Point-to-PointProtocol over Ethernet)
If “PPPoE”is selected, then this screen will appear. Enter the username, password and other major
fields.
Figure 3-4 Internet Connection Setting Screen—PPPoE Setting
Item Default Description
UsernameEmpty
Enter the user nameprovided by your ISP.Th
euser name
can consist of up to 80alphanumericcharacters and is
casesensitive.
Password Empty
Enter the user password provided by your ISP
.The
password canconsist of upto80alphanumeric
characters and is case sensitive.
PPP MTU Setting 1492 MTU (
MaximumTransferUnit) specifies maximum
transmission unit size.
TCP MSS Setting 1452
MSS (MaximumSegmentSize) specifiesmaximum
segment size.
Service nameEmpty Your ISP will provide the servicename.

WSG-401 UserManual
20
Item Default Description
Connect on Demand and MaxIdle Time
Connect on Demand Enable
MaxIdle Time10 Minutes
You can configure your WSG-401
to cutyour connection
with your ISP after aspecified period of time(Max
Idle
Time). If you have beendisconnecteddue to inactivity,
Connect onDemandenables your WSG-401
to
automatically re-establish your connection
assoon as you
attemptto access the Internet again. If you wish to
activate
Connect on Demand,click the check box.If you
want your Internet connectiontoremain,click the
check
boxof keep alive. The MaxIdle Timemaximumvalue
is
65535 minutes.
Keep alive and RedialPeriod
Keep alive Disable
Redial Period 30 Seconds
This option keeps your PPPoE enabled
Internet access
connectedindefinitely, even when it sits idle. The
Redial
Period maximum value is 65535 seconds.
