Important information concerning Product
Liability.
According to the laws governing product liability, the manufacturer and dealer are obliged to hand the
operating manual to the customer at the time of sale, and to instruct them in the recommended operating,
safety, and maintenance regulations. Confirmation is necessary to prove that the machine and operating
manual have been handed over accordingly.
For this purpose,
- document A is to be signed and sent to Pöttinger,
- document B remains with the dealer supplying the machine,
- and the customer receives document C.
In accordance with the laws of product liability, every farmer is an entrepreneur.
According to the laws of product liability, property damage is damage caused by a machine and not to
it. An excess of Euro 500 is provided for such a liabilioty.
In accordance with the laws of product liability, entrepreneurial property damages are excluded from
the liability.
Attention! Should the customer resell the machine at a later date, the operating manual must be given
to the new owner who must then be instructed in the recommended regulations referred to herein.
GB Dear Farmer
You have just made an excellent choice. Naturally we are very happy
and wish to congratulate you for having chosen Pöttinger. As your
agricultural partner, we offer you quality and efficiency combined with
reliable servicing.
In order to assess the spare-parts demand for our agricultural machines
and to take these demands into consideration when developing new
machines, we would ask you to provide us with some details.
Furthermore, we will also be able to inform you of new developments.

Dokument D
GB-0600 Dokum D Servo - 3 -
PÖTTINGER Landtechnik GmbH
Industriegelände 1
A-4710 Grieskirchen
Tel. 07248 / 600 -0
Telefax 07248 / 600-2511
❑Check SERVO Turnover Plough as per the delivery docket. Check that delivery is complete.
All safety equipment and operating devices at hand.
❑Using the operating manual explain and go over the operation, initial start and maintenance of the machine or
implement with the customer.
❑Fitting to the tractor has been carried out.
❑Check that hydraulic connections to the tractor have been made and that they are correct.
❑Hydraulic functions (turnover, cutting width adjustment) have been demonstrated and explained.
❑Plough is set correctly to the tractor (cutting width of 1st component, drawing point).
❑Transport and working positions have been explained.
❑Information about optional and additional equipment has been given.
❑It has been pointed out that to read the operating manual is imperative.
Cross where applicable. X
In accordance with Product Liability obligations, we would ask you to please check the following points.
GB
INSTRUCTIONS FOR
PRODUCT DELIVERY
In order to prove that the machine and the operating manual have been properly delivered, a confirmation is necessary.
For this purpose please do the following:
- sign the document A and send it to the company Pöttinger or via the internet to www.poettinger.at
- document B stays with the specialist factory delivering the machine.
document C stays with the customer.

GB
#/.4%.43
- 4 -
'"! ).(!,4
Contents
Meaning of warning signs .....................................................................................................................................................................................5
Preparations on the tractor ...................................................................................................................................................................................6
Hydraulic control on the lifting gear ......................................................................................................................................................................6
Hydraulic connection ............................................................................................................................................................................................7
Preparations on the plough...................................................................................................................................................................................7
Attaching to the tractor ......................................................................................................................................................................................... 8
Removal from tractor.............................................................................................................................................................................................8
Garaging, cleaning and winter storage of the implement .....................................................................................................................................8
Before driving to the field ......................................................................................................................................................................................9
Setting the plough to the tractor using "Servomatic" .........................................................................................................................................10
Turning the plough over.......................................................................................................................................................................................11
Hydraulic cylinder (22) to swing the plough in ....................................................................................................................................................11
Setting the plough gradient (11) .......................................................................................................................................................................... 11
Ploughing with control hydraulic .........................................................................................................................................................................12
Hydraulic cutting width adjustment (SERVO PLUS)............................................................................................................................................12
Shear bolts ..........................................................................................................................................................................................................13
Fully automatic „Nonstop“ overload safety.........................................................................................................................................................14
Setting range .......................................................................................................................................................................................................14
Table ....................................................................................................................................................................................................................14
Gas accumulator (43): .........................................................................................................................................................................................15
Altering pressure in the gas accumulator............................................................................................................................................................15
Take note ............................................................................................................................................................................................................. 15
General maintenance advice...............................................................................................................................................................................16
Cleaning the machine parts ................................................................................................................................................................................16
Hydraulic unit ......................................................................................................................................................................................................16
Setting the ploughing component tilt .................................................................................................................................................................. 17
Basic setting of the ploughing component .........................................................................................................................................................17
Setting the disk coulter (* ....................................................................................................................................................................................18
Spring loaded disk coulter (* ...............................................................................................................................................................................18
Pre-ploughing implements: .................................................................................................................................................................................19
Double feeler wheel.............................................................................................................................................................................................20
COMBI-wheel (Feeler and transport wheel) ........................................................................................................................................................21
Changing to working position .............................................................................................................................................................................21
Changing to transport position ...........................................................................................................................................................................21
Transport-Feeler wheel........................................................................................................................................................................................22
Changing to working position .............................................................................................................................................................................22
Changing to transport position ...........................................................................................................................................................................22
Extension arm with hydraulic releasing device for packer and trailing implements............................................................................................23
Working with a trailing implement .......................................................................................................................................................................23
Disconnect the arm .............................................................................................................................................................................................24
Adjusting the amortisation effect ........................................................................................................................................................................24
Defined use of the plough according to the manufacturer’s instructions ...........................................................................................................25
Vehicle Identification Plate ..................................................................................................................................................................................25
Technical data .....................................................................................................................................................................................................26
Optional Equipment.............................................................................................................................................................................................27
Plough body forms..............................................................................................................................................................................................28
SERVO model......................................................................................................................................................................................................29
SERVO NOVA model ...........................................................................................................................................................................................29
SERVO PLUS model ...........................................................................................................................................................................................29
SERVO NOVA PLUS model.................................................................................................................................................................................29
Combination of tractor and mounted implement ................................................................................................................................................35
Important! Additional Information........................................................................................................................................................................ 35

7!2.).' 3)'.3 GB
- 5-
 '" !:"
CE sign
The CE sign, which is affixed by the manufacturer, indicates outwardly that this machine conforms
to the engineering guideline regulations and the other relevant EU guidelines.
EU Declaration of Conformity (see supplement)
By signing the EU Declaration of Conformity, the manufacturer declares that the machine being
brought into service complies with all relevant safety and health requirements.
Meaning of warning signs
Stay clear of swinging area of
implements
Never reach into the crushing danger area
as long as parts may move.

'" !."!5?
GB
!44!#().' 4/ 4(% 42!#4/2
- 6 -
Preparations on the tractor
General
Please observe the power range limits of the tractor being used.
Wheels
- Air pressure in the tractor’s rear tyres when ploughing should be 0.8
bar.
- Under difficult operating conditions additional wheel weights can be
advantageous. See the tractor manufacturer’s operating manual also.
Ballast weight
• Sufficient ballast weights are to be stacked on the front
of the tractor in order to guarantee steering and braking
capabilities.
• At least 20% of the tractor’s tare weight on the front axle.
Lifting gear
- Left and right lifting struts (4) must be of equal length.
Adjust using adjusting device (3).
- If the lifting struts on the lower link can be pinned variously, then select
the back position (H). In so doing the tractor’s hydraulic unit will not be
heavily loaded.
- Position (2) the upper link (1) according to the tractor manufacturer’s
information.
Setting-up for transportation
- Fix the lower link with the struts (5) so that the attached implement cannot
swing out during transportation.
- The hydraulic’s operating lever must be secured against lowering.
- Do not transport in the „ON-LAND“ position
Setting-up for ploughing
- Set the struts (5) so that the greatest possible sideways swing range
exists.
Hydraulic control on the lifting gear
Control position:
For mounting and dismounting the implement and for transportation.
The control position is the normal setting for the lifting gear hydraulics.
The mounted implement remains at the height (= position) set by the servo-
valve (ST).
Pull control, mix control:
Ploughing occurs with of one of the two operating modes. See chapter
„OPERATION“ for description.

'" !."!5?
GB
!44!#().' 4/ 4(% 42!#4/2
- 7 -
Hydraulic connection
•If the tractor has a single-action servo-valve only, it is absolutely
necessary to have an oil return line (T) professionally installed.
- Connecting pressure line (1) and oil return line (2).
1 Single-action control unit
Type SERVO, SERVO NOVA
or
1 Double-action control unit
Type SERVO, SERVO NOVA
+ 1 Double-action control unit
Type SERVO PLUS, SERVO NOVA PLUS
SERVO PLUS = with hydraulic cutting width adjustment
Preparations on the plough
Mounting axle (965 mm / 825 mm)
• Use the correct mounting axle
- see also spare parts list.
Fit mounting axle
• 965 mm mounting axle
- Secure plates to the outside (pos.1).
• 825 mm mounting axle
- secure plates to the inside (pos. 2).
Upper link pins
Position upper link pins (6) as per diagram
- secure with linch pin (K).

'" !."!5?
GB
!44!#().' 4/ 4(% 42!#4/2
- 8 -
TD65/92/27
1P1
P2
Important advice:
Supportstand in the working position
• Insert pin only in the first hole (pos. 1).
• Do not use holes in pos. 2 - 8
- otherwise support stand will be damaged when turning
plough
Lighting and Warning equipment
When travelling in fog, half-light or at night, protruding parts are to
be clearly indicated. Advice on the application of warning signs,
reflective film or paint and lighting units
can be found in the instructions for
ancillary equipment in supplement C.
PôTTINGER can supply lighting units
and warning signs upon request.
Always observe the statutory
regulations
.
Removal from tractor
Hinweis: Die Scharspitzen sind gehärtet; beim Aufsetzen auf hartem
Untergrund (Stein, Beton usw.) besteht Bruchgefahr. Daher die
Scharspitzen auf eine geeignete Unterlage (Holzbrett) absetzen!
- Pflugrahmen in
Arbeitsstellung drehen und
Gerät auf tragfähigem und
ebenem Boden abstellen.
- Move the control lever (ST)
back and forth several times
to reduce pressure in the
hydraulic lines.
- Switch tractor’s hydraulics
to control position.
- Disconnect hydraulic hoses from tractor.
- Swing support stand down and secure with pins.
- Detach upper and lower links from implement.
Garaging, cleaning and winter
storage of the implement
• Observe the points in the chapter „MAINTENANCE AND
SERVICE“!
Attaching to the tractor
Safety advice:
See supplement A1, Pt. 8a-h
- Switch tractor’s hydraulics to control position.
- Attach implement to lower link and secure with linch pin.
Note
The attaching frame can be positioned horizontally by turning the
tilt spindle (11).
Doing this enables an easier coupling to the lower link.
Then turn the tilt spindle (11) back. See chapter „OPERATION“
also.
Pin upper link (1)
- Pin upper link (1) so that the attachment point (P1) on the plough
during operation is somewhat higher than the attachment point (P2)
on the tractor.
Securing lower link
If the tractor’s hydraulic control
is to be steered over the lower
link, then the upper link should be
positioned in the slot (LL) on the
attaching frame.
Securing upper link
If the tractor’s hydraulic control is to be triggered over the upper
link, then both the (RL) borings on the attaching frame are to be
used.
- Couple hydraulic hoses to the tractor.

(955) 0700-GB VOREINSTELLUNG
GB
PRESETTING THE PLOUGH
- 9 -
Before driving to the field
Set furrow width
Five furrow widths can be selected on the standard model (SERVO). The
furrow width is set by swivelling the anchoring console.
- Loosen both hexagonal screw (SK).
- Remove rear hexagonal screw.
- Swivel anchoring console until the required furrow width is obtained and
the hexagonal screw fits into one of the borings (1, 2, 3, 4, 5).
- Retighten hexagonal screws.
Setting both the spindles (ZP, VF)
Drawing point (ZP)
Backfurrow (VF)
• Setting depends upon the inside distance between the tractor wheels (RA)
and the set furrow width (1, 2, 3, 4, 5).
- Further Information on the drawing point and backfurrow in chapter
"OPERATION".
SERVO PLUS
SERVO NOVA PLUS
1. Carry out basic setting according to
table B, with average cutting width
position.
2. Carry out a more accurate setting
when in use.
** With a component gap of 90 cm
1. Carry out basic setting according to
table B, with average furrow width
position.
2. Carry out a more accurate setting
when in use.
Cutting width 1 2 3 4 5
30 cm 35 cm 40 cm 45 cm 50 cm
RA VF ZP VF ZP VF ZP VF ZP VF ZP
(mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
1200 445 443 435 458 425 472 416 485 406 498
1300 440 430 431 445 421 459 411 472 401 485
1400 436 418 427 432 417 446 407 459 397 472
1500 432 405 423 419 413 433 403 447 393 460
1600 428 392 418 406 408 420 398 434 388 447
Table-A
for
SERVO
standard plough
with component
gap 100 cm *
SERVO NOVA
1. Carry out basic setting according to table
A.
2. Carry out a more accurate setting when in
use.
SERVO
Setting according to table A
* With a component gap of 90 cm
1. Carry out basic setting according to table A.
2. Carry out a more accurate setting when in use.
Table-B
RA VF ZP
(mm) (mm) (mm)
1000 452 525
1100 447 509
1200 443 494
1300 438 478
1400 434 461
1500 431 445
1600 427 428
1700 424 410
RA
TD65/92/35
SERVO PLUS
SERVO NOVA PLUS
component gap 100 cm **
RA VF ZP
(mm) (mm) (mm)
1200 452 525
1300 447 510
1400 443 494
1500 438 478
1600 434 462
1700 431 445
1800 427 428
1900 424 411
2000 420 393
SERVO PLUS SERVO NOVA PLUS
TD 329-07-02
VF
ZP
1
3
4 5
SK
2
TD126/98/07
VF
ZP

 '" %).3!4:
GB
/0%2!4)/.
- 10 -
Setting the plough to the tractor
using "SERVOMATIC"
„SERVOMATIC“ enables the optimum adaption of plough to tractor.
The following setting controls should be carried out in order.
• Never reach into the area where danger of crushing
exists as long as parts are still moving.
• Do not stand in the swinging range of the implement.
1. Set furrow width
- See chapter 02%3%44).' 4(% 0,/5'(
2. Furrow width setting of the first ploughing component
(backfurrow)
The cutting width (S2) of the first ploughing component is set by turning
the spindle (VF).
Furrow width (S1) to narrow
- turn spindle (VF) longer
Furrow width (S2) to wide
- turn spindle (VF) shorter
Furrow width (S2) correct
- Spindle is correctly set according to table.
See chapter 02%3%44).' 4(% 0,/5'(h
Hydraulic cylinder (optional)
Hydraulic furrow width adjustment (SERVO PLUS)
However an additional double-action control unit is necessary on
the tractor.
Incorrect setting
The drawing line does not run through the mid-point of the tractor’s rear
axle. Tractor is drawn into already ploughed area during ploughing. This
can only be compensated by steering in the opposite direction.
- Turn spindle (ZP) longer
See chapter 02%3%44).' 4(% 0,/5'(h
3. Setting the drawing point (Z)
Correct setting
The drawing line (ZL) runs through the mid-point (M) of the tractor’s
rear axle. No side pull arises from the tractor.
The plough is easy to pull.
- Spindle (ZP) is set correctly.
See chapter 02%3%44).' 4(% 0,/5'(h

 '" %).3!4:
GB
/0%2!4)/.
- 11 -
Turning the plough over
Beware!
Nobody is to stand within the swinging range during
turning.
Turning procedure is only to be actuated from the
tractor cabin.
The plough must be completely raised to turn.
The turning unit is equipped with a double-action cylinder and
intergrated automatic reversing gear.
The automatic reversing gear enables the whole turning procedure
to be carried out through only one single switch position on the
control unit (ST).
Turning procedure
The turning procedure is carried out in the same way for both the
single-action and the double-action control unit.
A return line is necessary on the tractor for a single-action control
unit.
- Switch control unit (ST) to lift (h).
The plough is turned 180¯.
- Switch control unit (ST) to neutral (O).
After some 5 seconds another turning procedure can be effected.
Special fitting for 4 and 5 blade ploughs
Hydraulic cylinder (22) to swing the plough in
The hydraulic cylinder (22) swings the plough frame to the tractor
centre before turning over. This enables 4 and 5 blade ploughs to
be turned without problem. After turning is completed the hydraulic
cylinder (22) swings the plough back into the working position.
Only one double-action or one single-action control unit with return
line is necessary on the tractor. This control unit simultaneously
accommodates the hydraulic cylinder (22) and the cylinder in the
turning unit.
4$ 
s
h
0
ST
TD 65/92/25
90o
Setting the plough gradient (11)
The plough should sit as vertical (90°) as possible to the
ground during ploughing. This position is obtained by
turning both spindles (11) as described below.
- Lift plough 5 - 10 cm
- Actuate control unit (ST) briefly.
The plough turns slightly away from the stop
spindle (11).
- Set the gradient using the spindle (11).
- Turn plough back to stop again.
- Proceed with ploughing and check whether the
plough sits more vertically (90°) to the ground through
the new setting.

 '" %).3!4:
GB
/0%2!4)/.
- 12 -
Ploughing with control hydraulic
So that the hydraulic control functions properly, the following must
be observed.
- Position upper link (1) so that the attachment point (P1) on the plough
during operation is somewhat higher than the attachment point (P2)
on the tractor.
Pinning the upper link
LL, RL = Pinning position for securing
lower link
RL =
Pinning position for securing upper link
See chapter „ATTACHING TO THE TRACTOR“ also.
- During operation the plough should lie lengthwise as parallel as possible to the ground
surface.
- The working depth is set with the lifting gear via the servo-valve firstly.
Depending upon the hydraulic control model, varying ground resistance when ploughing
is passed on to the control servo-valve via the upper link (1) or both the lower links. The
relevant impulse is then converted causing the lifting gear to lift or lower.
An example: Securing upper link
The plough penetrates deeper into the ground.
This causes the pressure on the control servo-valve via the upper link to become greater.
As a consequence, the control valve remains switched to lift until the set working depth is reached again.
Note:
Follow the tractor manufacturer’s operating manual also.
Optional equipment:
Hydraulic cutting width adjustment (SERVO PLUS)
A hydraulic cylinder actuates the adjusting unit. Therefore an additional double-action control unit is necessary on the tractor.
Limitless cutting width adjustment can be carried out during ploughing. The drawing line position is not influenced by this (see "Setting the
drawing point (Z)").
Advantages:
- accurate ploughing along boundaries.
- ploughing around obstacles (masts, trees, etc.).
TD65/92/27
1P1
P2

  '" 3)#(%25.'
GB
/6%2,/!$ 3!&%49
- 13 -
Shear bolts
The ploughing components are fastened with shear bolts.
When overloaded the shear bolts break (30) and the ploughing component swings away and up.
- Remove the rest of the shear bolt.
- Loosen hexagonal bolt (31).
- Swing ploughing component back into the working position.
- Insert new shear screws and retighten both bolts.
Take note!
Only use genuine shear bolts (see spare parts list) with the corresponding dimension and quality. Under no circumstances
use bolts with greater or lesser strength.

 '" ./6!
GB
3%26/ ./6!
- 14 -
Fully automatic „Nonstop“ overload safety
The fully automatic overload safety is recommended for soils
which are difficult to plough e.g. soil with stones or other foreign
bodies.
Every ploughing component is hydromechanically safeguarded
against damage on the
SERVO-NOVA plough.
When driving over an
obstacle the ploughing
body swings out to either
side and then swings
automatically back into
the working position. There
is no need to stop the
tractor.
Along with the fully automatic „Nonstop“ overload safety, all
component carriers have a shear bolt as additional protection. See
chapter /6%2,/!$ 3!&%49h for a description.
Setting range
• The overload safety release force can be adapted to the various
soil types.
.ORMAL SETTING
- Pressure in the hydraulic cylinders (40) must be approx. 10 bar
greater than the nitrogen pressure in the gas accumulator (43).
4$ 
40
43
Nitrogen pressure in the gas accumulator (43) (Factory
set)
80 bar
Pressure adjustment area of the hydraulic cylinder (40)
90 to 155 bar
Should practice show that the overload safety reacts too often,
the pressure(* in the hydraulic cylinders can be increased with the
accompanying top-up device (42).
Table
pressure(* release force
( bar ) ( kp )
90 1270
100 1390
110 1510
120 1630
130 1750
140 1870
150 1990
155 2050
Increasing the pressure in the hydraulic cylinders:
- Shut-off valve in position A.
- Remove sealing cap (41) from shut-off valve and screw on top-up
line.
- Depressurize servo-valve on the tractor.
- Connect plug-in coupling (42) to the tractor.
- Open shut-off valve (position E). The hydraulic pressure drops.
- Actuate servo-valve on tractor until the manometer shows the
desired pressure. Then close the shut-off valve (position A).
Take note!
The shut-off valve must always be closed (position A)
when ploughing.
- Depressurize top-up line using servo-valve.
- Remove top-up line and screw sealing cap (41) back on.

 '" ./6!
GB
3%26/ ./6!
- 15 -
Gas accumulator (43):
Pressure in the gas accumulator can also be altered.
A reduction or increase of gas pressure in the accumulator depends upon the various soil
types.
• With very light soil the gas pressure can be somewhat reduced.
Important!
• No welding, soldering or mechanical work of any kind may be carried out on the
accumulator.
Altering pressure in the gas accumulator
This work must be carried out only by our Customer Service or by a specialist work shop.
A special filling and testing device is required to reduce or increase the preload pressure in the gas accu-
mulator.
1. Reduce pressure:
a) Remove plastic cap.
Remove the lead mould plug (if it exists) in the gas filling plug (44) with a pointed tool.
b) Slightly loosen the gas filling plug (44).
c) Screw on filling and testing device.
d) Slightly open the outlet valve on the filling device.
Slowly let the nitrogen out (N) until the mamometer shows the desired pressure has been
reached.
e) Close outlet valve, remove filling device, tighten gas filling plug and knock the lead mould plug
(if it exists) back in.
2. Increase pressure:
• Only use nitrogen (N) to fill the accumulator, do not use oxygen
(danger of explosion).
f) Connect filling device to nitrogen bottle.
g) Remove plastic cap.
Remove the lead mould plug (if it exists) in the gas filling plug (44) with a pointed tool.
Slightly loosen the gas filling plug (44).
Screw on filling and testing device.
h) Screw testing device onto nitrogen bottle.
i) Slightly open the outlet valve on the filling device and fill with nitrogen until the mamometer shows the required pressure has been
reached.
k) Close outlet valve, remove filling device, tighten gas filling plug and knock the lead mould plug (if it exists) back in.
Take note
All gas accumulators show a slight pressure drop after a certain period of time, according to "HYDAC" factory specifications.
The gas loss amounts to approx. 2-3 % pa.
It is recommended that the accumulator pressure be checked and, if necessary, regulated after 4-5 years.
4$ 
40
43

 '" 7!245.'
GB
-!).4%.!.#% !.$ 3%26)#%
- 16 -
General maintenance advice
In order to keep the implement in good condition even after a long
service life, please observe the following points:
- After the first hours of operation retighten all screws.
During the operating season
- Check all screws occasionally and retighten if necessary.
- Grease the four greasing points on both of the swing bolts weekly.
- Grease all other greasing points at least twice per season.
At the same time oil joints and adjusting spindles also.
Expendable parts
- Replace worn out expendable parts in time to prevent all stress-
bearing parts from becoming damaged.
Tyre pressure
- Pay attention to the correct tyre pressure!
Check tyre pressure regularly!
• Danger of bursting exist when inflating or when tyre
pressure is too great!
Cleaning the machine parts
Take note!
Do not use a high pressure cleaner to clean bearings or hydraulic
parts.
- Danger of rust formation!
- Lubricate the machine after cleaning and carry out a short trial
run.
- Cleaning with too much pressure can damage the paintwork.
Parking in the open
When parking in the open for
longer periods, clean plunger
rods and then grease.
Winter storage
- Thoroughly clean the machine
before storing.
- Store the machine where it is
weather protected.
- Protect exposed parts against rusting.
- Grease all greasing points
Hydraulic unit
- Check hydraulic hoses regularly for damage.
Immediately replace porous or damaged hydraulic hoses.
FETT
Beware: Danger of infection!
• Where there are dfects in the
hydraulicunit, do nottouchareas
of leakage.
Before working on the hydraulic unit
- lower implement to the ground.
- When carrying out maintenance work on
a raised implement always make it secure
with a suitable support.
- Depressurize the hydraulic unit and turn
the motor off.

 '" 7!245.'
GB
-!).4%.!.#% !.$ 3%26)#%
- 17 -
Basic setting of the ploughing component
Checks must be made in the following order after replacing worn out parts:
1. Stand the plough on even ground.
2. The gap (A) between plough and blade cutting edege must be the same for all ploughing components.
3. Check the gap (B1) on the last ploughing component.
B1 = 0 - 5 mm for ploughing components* of the type W, UWS
10 - 20 mm for ploughing components* of the type UW, UWS, WSS
4. Set the same measurement for gap (B) as for B1.
 4HE TYPE OF PLOUGHING COMPONENT IS SHOWN CLEARLY ON THE MANUFACTURERS PLATE
Setting the ploughing component tilt
If the plough is not penetrating the ground correctly, an improvement
can be obtained by turning the eccentric bush.
• The blade point in the area „S“ is set either higher or lower depending
upon the position of the eccentric bush (A or B).
• Retighten screws after resetting.
On some models a catch plate is fitted instead of an eccentric bush.
See "ASIC SETTING OF THE PLOUGHING COMPONENT also.

 '" :534:%
GB
!$$)4)/.!, $%6)#%3
- 18 -
(* Beware! Danger of injury on the cutting edges.
Setting the disk coulter (*
• Set the cutting depth of the disk coulter at a gap of 5 cm to the
ploughing blade tip.
• The lengthwise fitting position is preselected by moving the carrier
on the console.
Further fitting positions arise by swivelling the eccentric (50)
180°.
• The lateral gap to the ploughing blade tip should be 2 - 3 cm. It is
set by swiveling the eccentric (50).
Spring loaded disk coulter (*

 '" :534:%
GB
!$$)4)/.!, $%6)#%3
- 19 -
(* Beware! Danger of injury on the cutting edges.
Pre-ploughing implements:
Maize skimmer, Manure skimmer
These implements are designed to incorporate surface trash
straw or manure in the soil.
• Set the working depth to 1/3 of the total working depth.
• The lengthwise fitting position should lie over or behind the ploughing
blade tip. Where there is a lot of surface growth, or when ploughing
in straw, the pre-ploughing implements should be set back as far
as possible.
Leg deflector (60)
Leg deflector, which are fitted to the ploughing component, serve
to bend the stalks less when ploughing in straw enabling them to
slide off better.
Trashboards (61)
For ploughing in manure or other fertilizers.
• Trashboards for ploughing components of the type UW, W, WSS.
These implements can be used instead of manure mulchers (see
above) but are not very effective with shallow working depths.
Knife coulter (62) (*
This implement can be used instead of a disk coulter (see above)
however it is not adjustable.

 '" $/00%,4!342!$
GB
&%%,%2 7(%%,3
- 20 -
Double feeler wheel
• The double feeler wheel is fitted to the last ploughing component.
• The working depth is set via the spindle (70) using the accompanying
ratchet.
• When ploughing with a 4 blade plough the
double feeler wheel can be fitted to the
second last ploughing component. This
has the advantage that when ploughing
along the boundary the feeler wheel does
not greatly project over the last ploughing
component.
Double feeler wheel fitted to the second last ploughing
component.
