Power Electronics SD 500 Series Parts list manual

SD500 ACCESORIES
GETTING STARTED MANUAL
PROFINET BOARD
www.power-electronics.com

A C C E S O R I E S
Profinet Module
Accessories Manual
Edition: October 2017
SD50MA01AI

POWER ELECTRONICS
SD500 –PROFINET
3
ABOUT
PURPOSE
This manual contains important instructions for the installation and
maintenance of the optional Profinet communication module for Power
Electronics SD500 variable speed drives.
AUDIENCE
This manual is intended for qualified customers who will install, operate and
maintain Power Electronics SD500 variable speed drives.
Only trained electricians approved by the installation company may install and
commission the drives. The instructions assume that the installer is familiar
with electrical installation rules and regulations.
REFERENCE MANUALS
The following reference guide is available for the SD500 variable speed drives:
•Hardware and Installation Manual
•Programming and Software Manual
POWER ELECTRONICS CONTACT INFORMATION
Power Electronics, S.A.
C/ Leonardo da Vinci, 24 –26
46980 –PATERNA
SPAIN
Tel. [phone] (Spain) • Tel. [phone] • Fax [phone]
Email: [e-mail]
Website: www.power-electronics.com

SD500 –PROFINET
POWER ELECTRONICS
4
REVISIONS
CONTROL OF REVISIONS
DATE
REVISION
DESCRIPTION
25 / 10 / 2017
A
First edition
The equipment and technical documentation are periodically updated. Power
Electronics reserves the right to modify all or part of the contents of this manual without
previous notice. To consult the most updated information of this product, you may
access through our website www.power-electronics.com, where the latest version of this
manual can be downloaded. The reproduction or distribution of the present manual is
strictly forbidden, unless express authorization from Power Electronics.

POWER ELECTRONICS
SD500 –PROFINET
TABLE OF CONTENTS
5
TABLE OF CONTENTS
1. INTRODUCTION .....................................................................................15
Description of Profinet Communication Module .....................................15
Components............................................................................................15
2. PROFINET COMMUNICATION MODULE FEATURES.........................16
Common Features ..................................................................................16
GSDML File.............................................................................................16
3. PART NAMES AND INSTALLATION.....................................................17
Installation ...............................................................................................17
Profinet communication module..............................................................18
24V External Power Input .......................................................................20
4. NETWORK CONNECTIONS...................................................................22
Network Cable Contacts .........................................................................22
Communication Cable Connector...........................................................22
Network Cable Specification...................................................................22
5. PARAMETERS CONFIGURATION........................................................23
6. PROFIDRIVE STATUS DIAGRAM .........................................................31
7. SUPPORTED PROFIDRIVE CYCLIC TELEGRAM ...............................34
Standard telegram (Mode:0)...................................................................34
Vendor Specific Telegram (Mode: 1)......................................................34
Control word (STW1)..........................................................................35
Status Word (ZSW1)...........................................................................37
Setpoint Value.....................................................................................39
Current Speed Value ..........................................................................39
Alarm Information................................................................................39
Torque ...........................................................................................40
Current ...........................................................................................40
Dummy ...........................................................................................40
8. SUPPORTED PROFIDRIVE PARAMETERS.........................................41
Parameters..............................................................................................41
9. FAULT MESSAGE COUNTER (PNU[944]) AND FAULT NUMBER
(PNU[947]) .....................................................................................................43

SD500 –PROFINET
POWER ELECTRONICS
6
TABLE OF CONTENTS
10. ACCESSING THE COMMON PARAMETERS USING THE
PROFIDRIVE PARAMETERS........................................................................47
11. ACCESSING PARAMETERS USING THE PROFINET RECORD DATA
OBJECT..........................................................................................................50
12. PROCESSING THE ALARMS ................................................................51
13. TROUBLESHOOTING ............................................................................52

POWER ELECTRONICS
SD500 –PROFINET
SAFETY SYMBOLS
7
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards
from occurring.
In this manual, safety messages are classified as follows:
The following CAUTION symbols can be used in this manual and they
symbolize:
WARNING
Identifies potentially hazardous situations where
dangerous voltage may be present, which if not avoided,
could result in minor personal injury, serious injury or
death.
Be extremely careful and follow the instructions to avoid
the risk of electrical shocks.
CAUTION
Identifies potentially hazardous situations, which if not
avoided, could result in product damage, or minor or
moderate personal injury.
Read the message and follow the instructions carefully.
NOTICE
Identifies important measures to take in order to prevent
damage equipment and warranty lost, as well as
encouraging good use and environmental practices
Hot surface. Be careful and follow the instructions to
avoid burns and personal injuries.
Risk of fire. Be careful and follow the instructions to
prevent causing an unintentional fire.
Caution, risk of electric shock. Energy storage timed
discharge. Wait for the indicated time to avoid electrical
hazards.

SD500 –PROFINET
POWER ELECTRONICS
8
SAFETY SYMBOLS
Caution, risk of hearing damage. Wear hearing
protection.

POWER ELECTRONICS
SD500 –PROFINET
SAFETY INSTRUCTIONS
9
SAFETY INSTRUCTIONS
IMPORTANT
Read carefully this manual to maximize the performance of the product and to
ensure its safe use.
In order to appropriately use the drive, please, follow all instructions described
in the installation manual which refer to transportation, installation, electrical
connection and commissioning of the equipment.
Power Electronics accepts no responsibility or liability for partial or total
damages resulting from incorrect use of equipment.
WARNING
Be cautious when handling the CMOS components of the
communication board. Static may lead to product malfunctioning.
Turn the drive power off before changing the communication cable.
Otherwise, you may damage the module or a communication error may
occur.
Make sure to insert precisely the communication module connector
to the drive. Otherwise, you may damage the module or a communication
error may occur.
Check the parameter unit before setting up the parameters.
Otherwise, a communication error may occur.
Do not remove the cover while the power is applied or the unit is in
operation. Otherwise, electric shock could occur.
Do not remove the cover while power supply is connected or the drive
is operating. Otherwise, you may get an electric shock.

SD500 –PROFINET
POWER ELECTRONICS
10
SAFETY INSTRUCTIONS
Do not run the drive with the front cover removed.
Otherwise, you may get an electric shock.
The drive does not remove the voltage from the input terminals.
Before working on the drive, isolate the whole drive from the supply.
If you do not remove the power supply, you may get an electric shock.
Do not remove the cover except for periodic inspections or wiring,
even if the input power is not applied. Otherwise, you get an electric
shock.
Operate the drive with dry hands.
Otherwise, you may get an electric shock.
Do not use cables with damaged insulation.
Otherwise, you may get an electric shock.
Do not subject the cables to abrasions, excessive stress, heavy loads
or pinching. Otherwise, you may get an electric shock.

POWER ELECTRONICS
SD500 –PROFINET
SAFETY INSTRUCTIONS
11
CAUTION
Install the drive on a non-flammable surface. Do not place
flammable material nearby. Otherwise, a fire could occur.
Disconnect the input power if the drive is damaged.
Otherwise, it could result in a secondary accident or fire.
Do not allow lint, paper, wood chips, dust, metallic chips or other
foreign matter into the drive.
Otherwise, a fire or an accident could occur.
The drive becomes hot during operation. Wait until it cools down
before performing any actions.
Touching hot parts may result in skin burns.
Do not apply power to a damaged drive or to a drive with parts
missing, even if the installation is complete.
Otherwise, you may get an electric shock.
NOTICE
RECEPTION
•The SD500 are carefully tested and perfectly packed before delivering.
•In the event of transport damage, please ensure to notify the transport
agency and POWER ELECTRONICS: 902 40 20 70 (International +34 96
136 65 57), or your nearest agent, within 24hrs from receiving the goods.
UNPACKING
•Make sure model and serial number of the variable speed drive are the same
on the box, delivery note and unit.
•Each variable speed drive is delivered with Hardware and Software technical
manuals.

SD500 –PROFINET
POWER ELECTRONICS
12
SAFETY INSTRUCTIONS
RECYCLING
Equipment packaging must be recycled. Separate all different materials (plastic,
paper, cardboard, wood…) and place them in the corresponding containers.
Ensure waste collection is properly managed with a Non-Hazardous Waste
Agent. To guarantee health and natural environmental sources protection,
the European Union has adopted the WEEE directive concerning
discarded electric and electronic equipment (SEEA).
Waste of electrical and electronic equipment (WEEE) must be
collected selectively for proper environmental management.
Our products contain electronic cards, capacitors and other
electronic devices that should be separated when they are no
longer functional. These WEEEs should be managed accordingly
with a Hazardous Waste Agent.
Power Electronics promotes good environmental practices and
recommends that all its products sold outside of the European
Union, once they reach the end of their life, are separated and the
WEEE managed according to the particular country applicable
legislation (especially: electronic cards, capacitors and other
electronic devices)
If you have any questions about the electric and electronic
equipment waste, please contact Power Electronics.
CYBER SECURITY DISCLAIMER
This product is designed to be connected to and to communicate information
and data via a network interface. The customer is the sole responsible for
providing and continuously ensuring a secure connection between the product
and customer network or any other network (as the case may be). Customer
shall establish and maintain any appropriate measures (such as, but not limited
to, the installation of firewalls, application of authentication measures,
encryption of data, installation of antivirus programs, etc.) to protect the product,
the network, its system and the interface against any kind of security breaches,
unauthorized access, interference, intrusion, leakage and/or theft of data or
information.
Power Electronics and its affiliates are not liable for damages and/or losses
related to such security breaches, any unauthorized access, interference,
intrusion, leakage and/or theft of data or information.

POWER ELECTRONICS
SD500 –PROFINET
SAFETY INSTRUCTIONS
13
ELECTROMAGNETIC COMPATIBILITY (EMC)
•The drive is intended to be used in industrial environments (Second
Environment). It achieves compliance with C3 category defined in IEC/EN
61800-3 standard when the installation recommendation within this manual
are followed.
•Select communication and control system according to the drive EMC
environment. Otherwise, systems could suffer from interferences due to a
low EMS level.
SAFETY
Before operating the drive, read this manual thoroughly to gain an
understanding of the unit. If any doubt exists, please contact POWER
ELECTRONICS, (902 40 20 70 / [phone]) or your nearest agent.
•Wear safety glasses when operating the drive with power applied or for
when the front cover is removed.
•Handle and transport the drive following the recommendations within
this manual.
•Install the drive according to the instructions within this manual and local
regulations.
•Do not place heavy objects on the drive.
•Ensure that the drive is mounted vertically and keeping the minimum
clearance distances.
•Do not drop the drive or subject it to impact.
•The SD500 drives contain static sensitive printed circuits boards. Use
static safety procedures when handling these boards.
Avoid installing the drive under conditions that differ from those described in
the Environmental Ratings section.
CONNECTION PRECAUTIONS
•To ensure a correct operation of the drive, it is recommended to use a
SCREENED CABLE for the control wiring.
•The motor cable should comply with the requirements within this manual. Due
to increased leakage capacitance between conductors, the external ground
fault protection threshold value should be adjusted ad hoc.
•Do not disconnect motor cables if the input power supply remains connected.
•The internal circuits of the SD500 Series will be damaged if the incoming
power is connected and applied to the output terminals (U, V, W).

SD500 –PROFINET
POWER ELECTRONICS
14
SAFETY INSTRUCTIONS
•Do not use power factor correction capacitor banks, surge suppressors, or
RFI filters on the output side of the drive. Doing so may damage these
components.
•Before wiring the terminals, make sure that the drive keypad display is turned
off and the front cover is off as well. The drive may hold a high voltage electric
charge long after the power supply has been turned off.
EARTH CONNECTION
•Ground the drive and adjoining cabinets to ensure a safe operation and to
reduce electromagnetic emission.
•Connect the input PE terminal only to the dedicated PE terminal of the drive.
Do not use the case, nor chassis screws for grounding.
•Ground the drive chassis through the labelled terminals. Use appropriate
conductors to comply with local regulations. The ground conductor should be
connected first and removed last.
•Motor ground cable must be connected to the PE output terminal of the drive
and not to the installation’s ground. We recommend that the section of the
ground conductor (PE) is equal or greater than the active conductor (U, V, W).
TRIAL RUN
•Verify all parameters before operating the drive. Alteration of parameters may
be required depending on application and load.
•Always apply voltage and current signals to each terminal that are within the
levels indicated in this manual. Otherwise, damage to the drive may occur.
CAPACITORS DEPLETION
If the drive has not been operated for a long time, capacitors lose their charging
characteristics and are depleted. To prevent depletion, once a year run the
device under no-load conditions during 30-60 minutes. For further information,
please contact Power Electronics.

POWER ELECTRONICS
SD500 –PROFINET
INTRODUCTION
15
1. INTRODUCTION
Description of Profinet Communication Module
The SD500 Profinet communication module provides Profinet network
communication for the SD500 drive. Profinet is a communication protocol
compliant with IEC 61158 Type 10. The Profinet communication module
provides full-duplex data transfer which enables real-time communication
without transmission collisions. Using a Profinet connection, the SD500 drive
can be controlled and monitored via a PLC sequence program or any master
PLC module. In addition, Profinet is easy to connect, enabling faster
installation and easier maintenance.
Components
The Profinet module kit contains the following parts:
•1 Profinet communication card
•1 Profinet module manual
•2 Mounting screws
1

SD500 –PROFINET
POWER ELECTRONICS
16
PROFINET COMMUNICATION MODULE FEATURES
2. PROFINET COMMUNICATION
MODULE FEATURES
Common Features
Communication protocol
Profinet IO CC-A
Communication speed
100 Mbps
Communication type
Full Duplex
Max. number of nodes
64
Distance
100m (Twisted Pair)
Service
Profidrive Class 1
Topology
Line, Tree, Star topology
GSDML File
The GSDML file contains information about the Profinet communication
module installed in a drive. When you configure the Profinet network, the
network configuration software requires the GSDML file.
** For downloading the file, please contact Power Electronics.
2

POWER ELECTRONICS
SD500 –PROFINET
PART NAMES AND INSTALLATION
17
3. PART NAMES AND
INSTALLATION
Installation
WARNING
Turn the power supply off before connecting a communication network.
If the Profinet communication module is removed or installed, the power
supply should be switched off.
Otherwise, the SD500 drive may get damaged and warranty will be voided.
Install or remove the Profinet communication module when the drive
capacitor is fully discharged.
When installing the Profinet communication module, ensure that the
connectors of the drive body and the communication module are correctly
aligned.
To install the Profinet communication module, please follow these steps:
Remove the front cover
Connect the Profinet communication module by inserting it into the
connector on the drive body.
Secure the Profinet communication module with the two mounting
screws.
Replace the cover
3

SD500 –PROFINET
POWER ELECTRONICS
18
PART NAMES AND INSTALLATION
Profinet communication module
