Power Electronics SD 500 Series User manual

Ethernet Communication
Communication Network

Communication Network
Ethernet Communication
Edition: November 2016
SD50BC03BI Rev. B

SD500 –ETHERNET
POWER ELECTRONICS
2

POWER ELECTRONICS
SD500 –ETHERNET
SAFETY SYMBOLS
3
E
N
G
L
I
S
H
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards
from occurring.
In this manual, safety messages are classified as follows:
Other symbols used in this manual for CAUTION messages are the following:
WARNING
Identifies potentially hazardous situations where
dangerous voltage may be present which if not
avoided could result in minor personal injury,
serious injury or death
Be extremely careful and follow the instructions
to avoid the risk of electrical shocks.
CAUTION
Identifies potentially hazardous situations which
if not avoided could result in product damage or
minor or moderate personal injury.
Read the message and follow the instructions
carefully.
NOTICE
Identifies important measures to take in order to
prevent damage equipment and warranty lost, as
well as encouraging good use and environmental
practices.
Hot surface. Be careful and follow the instructions to avoid burns
and personal injuries.
Risk of fire. Be careful and follow the instructions to prevent
causing an unintentional fire.

SD500 –ETHERNET
POWER ELECTRONICS
4
Revisions
Date Revision Description
02 / 05 / 2012 A First edition
17 / 11 / 2016 B Misprints and contents update.
The equipment and technical documentation are periodically updated. Power Electronics
reserves the right to modify all or part of the contents of this manual without previous
notice. To consult the most updated information of this product, you may access through
our website www.power-electronics.us where the latest version of this manual can be
downloaded.

POWER ELECTRONICS
SD500 –ETHERNET
TABLE OF CONTENTS
5
E
N
G
L
I
S
H
TABLE OF CONTENTS
SAFETY INSTRUCTIONS................................................................................7
PART I: ETHERNET BOARD........................................................................ 13
1. INTRODUCTION .................................................................................... 15
1.1. Ethernet Networks........................................................................... 15
1.1.1. Introduction.............................................................................. 15
1.1.2. Types of Ethernet Networks.................................................... 16
1.2. Description of the Ethernet Board................................................... 17
2. TECHNICAL CHARACTERISTICS ....................................................... 18
2.1. General Information......................................................................... 18
2.1.1. Contents of the Ethernet Board Kit ......................................... 18
2.1.2. Specifications of Ethernet Board............................................. 18
2.1.3. Local Indicators ....................................................................... 19
2.1.4. Requirements.......................................................................... 19
3. INSTALLATION AND CONNECTION ................................................... 20
3.1. Installation of Ethernet Board.......................................................... 20
3.2. Connections of the Ethernet Board................................................. 21
3.2.1. Connectors description............................................................ 21
3.2.2. Switches Description............................................................... 22
3.2.3. Leds Description...................................................................... 23
4. ETHERNET BOARD CONFIGURATION............................................... 25
4.1. Ethernet Parameters Setting........................................................... 25
4.1.1. Group 3: References............................................................... 25
4.1.2. Subgroup 4.1 –G4.1: Digital Inputs........................................ 26
4.1.3. Subgroup 21.1 –G21.1: GENERAL ....................................... 27
4.1.4. Subgroup 21.2 –S21.2: Modbus TCP/IP................................ 28
4.1.5. Subgroup 21.3 –S21.3: ETHERNET IP ................................. 29
4.2. Lost Command Mode...................................................................... 31

SD500 –ETHERNET
POWER ELECTRONICS
6
TABLE OF CONTENTS
PART II: Modbus TCP/IP PROTOCOL........................................................ 33
1. INTRODUCTION .................................................................................... 35
1.1. Modbus TCP/IP Protocol................................................................. 35
1.1.1. Modbus Protocol TCP/IP Architecture .................................... 35
1.2. Modbus TCP/IP ............................................................................... 37
1.2.1. Modbus TCP/IP Protocol Description ..................................... 38
1.2.2. Modbus TCP/IP Protocol Architecture .................................... 39
2. MODBUS TCP PARAMETERS SETTING............................................. 40
2.1. Modbus Frame composition............................................................ 40
2.2. Function Code description............................................................... 41
2.2.1. Read holding registers ............................................................ 41
2.2.2. Read input registers ................................................................ 41
2.2.3. Write multiple register.............................................................. 42
2.3. Except frame.................................................................................... 42
3. MODBUS ADDRESS LIST .................................................................... 44
3.1. Common Area.................................................................................. 44
PART III: ETHERNET/IP PROTOCOL.......................................................... 49
1. INTRODUCTION .................................................................................... 51
1.1. Ethernet/IP Protocol ........................................................................ 51
1.1.1. Ethernet/IP Technology........................................................... 52
1.2. CIP Protocol..................................................................................... 53
1.2.1. CIP Protocol to Ethernet/IP..................................................... 55
2. CIP OBJECTS........................................................................................ 56
2.1. Identity Object.................................................................................. 56
2.2. Motor Data Object ........................................................................... 58
2.3. Control Supervisor Object ............................................................... 59
2.4. AC Drive Object............................................................................... 61
3. Parameter object instances................................................................. 63
3.1. Input Instance.................................................................................. 63
3.2. Output Instance ............................................................................... 66

POWER ELECTRONICS
SD500 –ETHERNET
SAFETY INSTRUCTIONS
7
E
N
G
L
I
S
H
SAFETY INSTRUCTIONS
IMPORTANT!
Read carefully this manual to maximize the performance of the
product and to ensure its safe use.
In order to use appropriately the drive, please, follow all instructions
described in the installation manual referred to transport, installation,
electrical connection and commissioning of the equipment.
Power Electronics accepts no responsibility or liability for partial or
total damages resulting from inappropriate equipment use.
Please, pay careful attention to the following recommendations:
WARNING
Make sure to take ESD (Electrostatic Discharge) protection measures
when you touch the board.
Otherwise, the optional board may get damaged due to static charges.
Implement wiring change on the optional board after checking that the
power supply is off.
Otherwise, there is a danger of connecting error and damage to the
board.
Be sure to connect correctly the optional board to the inverter.
Otherwise, there is a danger of connecting error and damage to the
board.
Do not remove the cover while the power is applied or the unit is in
operation.
Otherwise, electric shock could occur.
Do not run the inverter with the front cover removed.
Otherwise, you may get an electric shock due to the high voltage
terminals or exposure of charged capacitors.
Do not remove the cover except for periodic inspections or wiring,
even if the input power is not applied.
Otherwise, you may access the charged circuits and get an electric shock.

SD500 –ETHERNET
POWER ELECTRONICS
8
SAFETY INSTRUCTIONS
Wiring and periodic inspections should be performed at least 10
minutes after disconnecting the input power and after checking the
DC Link voltage is discharged with a meter (below 30VDC).
Otherwise, you may get an electric shock.
Operate the switches with dry hands.
Otherwise, you may get an electric shock.
Do not use cables with damaged insulation.
Otherwise, you may get an electric shock.
Do not subject the cables to the abrasions, excessive stress, heavy
loads or pinching.
Otherwise, you may get an electric shock.
CAUTION
Install the drive on a non-flammable surface. Do not place
flammable material nearby. Otherwise, a fire could occur.
Disconnect the input power if the drive gets damaged.
Otherwise, it could result in a secondary accident or fire.
Do not allow lint, paper, wood chips, dust, metallic chips or
other foreign matter into the drive. Otherwise, a fire or
accident could occur.
The inverter becomes hot during operation. Wait until it
cools down before performing any actions.
Touching hot parts may result in skin burns.
Do not apply power to a damaged drive or to a drive with
parts missing, even if the installation is complete.
Otherwise, you may get an electric shock.

POWER ELECTRONICS
SD500 –ETHERNET
SAFETY INSTRUCTIONS
9
E
N
G
L
I
S
H
NOTICE
RECEPTION
Material of Power Electronics is carefully tested and perfectly packed
before leaving the factory.
In the event of transport damage, please ensure that you notify the
transport agency and POWER ELECTRONICS: 902 40 20 70
(International [phone]) or your nearest agent, within 24hrs
from receipt of the goods.
UNPACKING
Make sure received merchandise corresponds with delivery note,
models and serial numbers.
Each board is supplied with a technical manual.
RECYCLING
Packing of the equipment should be recycled. For this, it is necessary
to separate the different included materials (plastic, paper, cardboard,
wood, …) and deposit them in corresponding containers.
Waste products of electric and electronic devices should be
selectively collected for their correct environmental management.
SAFETY
Before operating the inverter, read this manual thoroughly to gain and
understanding of the unit. If any doubt exists then please contact POWER
ELECTRONICS, (902 40 20 70 / [phone]) or your nearest
agent.
Wear safety glasses when operating the inverter with power applied or
the front cover is removed.
Handle the inverter with care according to its weight.
Install the inverter according to the instructions within this manual.
Do not place heavy objects on the inverter.
Ensure that the mounting orientation is correct.
Do not drop the inverter or subject it to impact.
The SD500 drives contain static sensitive printed circuits boards. Use
static safety procedures when handling these boards.

SD500 –ETHERNET
POWER ELECTRONICS
10
SAFETY INSTRUCTIONS
CONNECTION PRECAUTIONS
To ensure correct operation of the inverter it is recommended to use a
SCREENED CABLE for the control wiring.
For EMERGENCY STOP, make sure supply circuitry is open.
Do not disconnect motor cables if input power supply remains
connected. The internal circuits of the drive will be damaged if the
incoming power is connected and applied to output terminals (U, V,
W).
It is not recommended to use a 3-wire cable for long distances. Due to
increased leakage capacitance between conductors, over-current
protective feature may operate malfunction.
Do not use power factor correction capacitors, surge suppressors, or
RFI filters on the output side of the inverter. Doing so may damage
these components.
Always check whether the DC Link LED is OFF before wiring
terminals. The charge capacitors may hold high-voltage even after the
input power is disconnected. Use caution to prevent the possibility of
personal injury.
COMMISSIONING
Follow the steps described in this manual.
Always apply voltage and current signals to each terminal that are
within levels indicated within this manual. Otherwise, damage to the
optional board may result.

POWER ELECTRONICS
SD500 –ETHERNET
SAFETY INSTRUCTIONS
11
E
N
G
L
I
S
H
OPERATION PRECAUTIONS
When the Auto Restart function is enabled, keep clear of driven
equipment, as the motor will restart suddenly after a fault is reset.
The “STOP / RESET” key on the keypad is active only if the
appropriate function setting has been made. For this reason, install a
separate EMERGENCY STOP push button that can be operated at
the equipment.
If a fault reset is made with the reference signal still present, then a
restart will occur. Verify that it is permissible for this to happen,
otherwise an accident may occur.
Do not modify or alter anything within the drive.
Before programming or operating the SD500 Series, initialise all
parameters back to factory default values.
EARTH CONNECTION
The inverter is a high frequency switching device, and leakage current
may flow. Ground the inverter to avoid electrical shock. Use caution to
prevent the possibility of personal injury.
Connect only to the dedicated ground terminal of the inverter. Do not
use the case or the chassis screw for grounding.
When installing, grounding wire should be connected first and
removed last.
The earth cable must have a minimal cross sectional area that meets
local country electrical regulations.
Motor ground must be connected to the drive ground terminal and not
to the installation’s ground. We recommend that the section of the
ground connection cable should be equal or higher than the active
conductor.
Installation ground must be connected to the inverter ground terminal.

SD500 –ETHERNET
POWER ELECTRONICS
12

POWER ELECTRONICS
SD500 –ETHERNET
13
E
N
G
L
I
S
H
PART I
ETHERNET BOARD

SD500 –ETHERNET
POWER ELECTRONICS
14

POWER ELECTRONICS
SD500 –ETHERNET
PART I - INTRODUCTION
15
E
N
G
L
I
S
H
1. INTRODUCTION
1.1. Ethernet Networks
1.1.1. Introduction
Ethernet is used to designate a family of frame-based computer
networking technologies for local area networks (LANs). It was
mainly developed by Xerox Corporation, Intel Corporation and
Digital Equipment Corporation (DEC) companies in 1980, and has
continued evolving since then.
Ethernet defines a number of wiring and signalling standards for the
physical layer and the frame formats of the data link layer of the OSI
model.
Ethernet is the most commonly used LAN technology because it
achieves a good balance between speed, cost and installation
easiness. Additionally, it is very accepted in the market and supports
all popular virtual network protocols.
Some of the advantages of Ethernet that makes it the ideal network
technology for most current computer users are:
Easy installation and maintenance, together with their low cost.
Flexibility for interconnecting different topologies.
Stable standard that allows interconnecting devices from
different manufacturers.

SD500 –ETHERNET
POWER ELECTRONICS
16
PART I - INTRODUCTION
1.1.2. Types of Ethernet Networks
There are different implementations for Ethernet network, according
to the physical environment referred. The existing Ethernet
technologies differ in the following characteristics:
Transmission speed: Transmission capacity of the
environment in Mbps.
Cable type: Used technology of the physical layer.
Maximum length: Maximum allowed distance between two
adjacent nodes (without repeaters).
Typology: Defines the performance of the central linking
points.
Technology
Transmiss.
speed
Cable type
Maximum
distance
Typology
10Base2
10 Mbps
Coaxial
185m
Connector T
10BaseT
10 Mbps
Twisted Pair
100m
Hub or Switch
10BaseF
10 Mbps
Fibre Optics
2000m
Hub or Switch
100BaseTX
100 Mbps
Twisted Pair
(5UTP category)
100m
Half Duplex (Hub) and Full
Duplex (Switch)
100BaseT4
100 Mbps
Twisted Pair
(3UTP category)
100m
Half Duplex (Hub) and Full
Duplex (Switch)
100BaseFX
100 Mbps
Fibre Optics
2000m
Hubs use is not allowed

POWER ELECTRONICS
SD500 –ETHERNET
PART I - INTRODUCTION
17
E
N
G
L
I
S
H
1.2. Description of the Ethernet Board
The Ethernet board for SD500 drives allows integrating the drive in a
LAN (Local Area Network). It supports the TCP/IP standard
communication protocol and the industrial application layer protocol
Ethernet/IP for industrial automation applications.
Thanks to this board, the drive can be controlled and monitored by the
user or through a PLC sequence program or any master device (client).
Figure PI-1.1 Ethernet board description
3
2
1
1. Ethernet network connector
2. Connector for drive
3. Status leds

SD500 –ETHERNET
POWER ELECTRONICS
18
PART I –TECHNICAL CHARACTERISTICS
2. TECHNICAL CHARACTERISTICS
2.1. General Information
2.1.1. Contents of the Ethernet Board Kit
The kit of the Ethernet board contains:
o1 Ethernet board.
o1 Fixation screw.
o1 Technical manual.
2.1.2. Specifications of Ethernet Board
oDevice Type: Network adapter.
oShape Factor: Inserted board.
oWiring Type: Ethernet 10Base-T, Ethernet 100Base-TX.
oData Exchange Protocol: Modbus TCP/IP, Ethernet/IP.
oAuto-addressing Protocol DHCP supported.
oData Transmission Speed: 10Mbps, 100Mbps
oStandards: IEEE 802.3, IEEE 802.3u (only for 100Base-TX).
oCable Lengths: Maximum 100m per network segment.
