Power Electronics SD750SP User manual

SD750SP
HARDWARE AND INSTALLATION
MANUAL
LOW VOLTAGE VARIABLE SPEED DRIVE

SD750SP
LOW VOLTAGE VARIABLE SPEED DRIVE FOR SOLAR
PUMPING
Hardware and Installation
Manual
Edition: March 2022
SD75SPHW01AI Rev. A

SD750SP
POWER ELECTRONICS
2
ABOUT THIS MANUAL
EN
ABOUT THIS MANUAL
PURPOSE
This manual contains important instructions for the installation, configuration and use of Power Electronics
SD750SP variable speed drives.
Power Electronics reserves the right to modify product features.
TARGET AUDIENCE
This manual is intended for qualified customers who will install, configure and operate Power Electronics
SD750SP variable speed drives.
Only qualified technical personnel validated by Power Electronics may install and start up the SD750SP
variable speed drives
REFERENCE MANUALS
The following reference documents are available for this equipment:
•SD750SP Hardware and Installation Manual.
•Application Manual Pumps.
POWER ELECTRONICS CONTACT INFORMATION
Power Electronics USA Inc.
1510 N. Hobson Street, Gilbert,
Phoenix
AZ 85233
UNITED STATES OF AMERICA
US Sales: 602-354-4890 / [phone]
Power Electronics España, S.L.
Polígono Industrial Carrases
Ronda del Camp d’Aviació nº 4
46160, Llíria (Valencia)
SPAIN
Telephone: [phone]
Website: www.power-electronics.com

POWER ELECTRONICS
SD750SP
REVISIONS CONTROL
3
REVISIONS CONTROL
DATE (DD/MM/YYYY)
REVISION
DESCRIPTION
28 / 03 / 2021
A
First edition.
The equipment and technical documentation are periodically updated. Power Electronics reserves the right to modify all or part of the
contents of this manual without previous notice. To consult the most updated information of this product, you may access our website
www.power-electronics.com, where the latest version of this manual can be downloaded. The reproduction or distribution of the present
manual is strictly forbidden, unless express authorization from Power Electronics.

SD750SP
POWER ELECTRONICS
4
TABLE OF CONTENTS
EN
TABLE OF CONTENTS
ABOUT THIS MANUAL ...............................................................................................................................2
SAFETY SYMBOLS.....................................................................................................................................8
SAFETY INSTRUCTIONS............................................................................................................................9
TORQUE AND SCREW SIZING.................................................................................................................14
INTRODUCTION...................................................................................................................................15
CONFIGURATION TABLE & STANDARD RATINGS .........................................................................16
Configuration table .............................................................................................................................16
Standard ratings.................................................................................................................................16
400Vac –565Vcc.............................................................................................................................17
TECHNICAL CHARACTERISTICS ......................................................................................................18
DIMENSIONS........................................................................................................................................21
Dimensions of frame 1........................................................................................................................21
Dimensions of frame 2........................................................................................................................22
Dimensions of frame 3........................................................................................................................23
Dimensions of frame 4........................................................................................................................24
Dimensions of frame 5........................................................................................................................25
Dimensions of frame 6........................................................................................................................26
Dimensions of frame 7........................................................................................................................27
Dimensions of frame 8........................................................................................................................28
RECEPTION, HANDLING AND TRANSPORTATION .........................................................................29
Reception...........................................................................................................................................29
Standard storage................................................................................................................................29
Extended storage ...............................................................................................................................30
Handling and Transportation..............................................................................................................30
MECHANICAL INSTALLATION...........................................................................................................32
Environmental ratings.........................................................................................................................32
Drive mounting ...................................................................................................................................33
Wall mounting drives .......................................................................................................................33
Stand alone drives...........................................................................................................................34
Clearances.........................................................................................................................................35
Cooling...............................................................................................................................................37
POWER CONNECTION........................................................................................................................39
AC Configuration................................................................................................................................39
DC configuration.................................................................................................................................40
Topology.............................................................................................................................................41
Power connection...............................................................................................................................43
Power connection for 6 pulses.........................................................................................................44
Wiring.................................................................................................................................................45

POWER ELECTRONICS
SD750SP
TABLE OF CONTENTS
5
Wiring grouping................................................................................................................................45
Minimum distances between cables................................................................................................46
Reference cable section ..................................................................................................................47
Ground connection.............................................................................................................................48
EMC installation requirements............................................................................................................49
Introduction......................................................................................................................................49
SD750SP compliance......................................................................................................................50
Connection ......................................................................................................................................50
Protections .........................................................................................................................................51
Short circuit......................................................................................................................................51
Ground fault protection....................................................................................................................53
Other protections.............................................................................................................................53
Safety Stop Function .......................................................................................................................53
Safety Stop Function –STO (Safe Torque Off)...............................................................................53
IT Grids - Floating earth drives...........................................................................................................53
Power terminals..................................................................................................................................54
Connections for frame 1 ..................................................................................................................54
Connections for frame 2 ..................................................................................................................55
Connections for frame 3 ..................................................................................................................56
Connections for frame 4 ..................................................................................................................57
Connections for frame 5 ..................................................................................................................58
Connections for frame 6 ..................................................................................................................59
Connections for frame 7 ..................................................................................................................60
Connections for frame 8 ..................................................................................................................61
CONTROL CONNECTION ...................................................................................................................62
Wiring recommendations....................................................................................................................62
Control board terminals description....................................................................................................63
STO - Safe Torque Off .......................................................................................................................69
Safety integrity level SIL3- PLe........................................................................................................70
Connection with ATEX motors............................................................................................................72
MODBUS COMMUNICATION..............................................................................................................74
Introduction.........................................................................................................................................74
Hardware technical specifications ......................................................................................................75
Ethernet connection............................................................................................................................76
RS485 connection..............................................................................................................................76
COMMISSIONING ................................................................................................................................78
USE OF THE DISPLAY ........................................................................................................................80
Graphic display...................................................................................................................................80
MAINTENANCE....................................................................................................................................81
Warnings............................................................................................................................................81
Routine Inspection..............................................................................................................................81
ACCESSORIES....................................................................................................................................84
Codes and description........................................................................................................................84
Communication boards.......................................................................................................................84
Expansion boards...............................................................................................................................84
Mechanical accessories .....................................................................................................................85
IP20 connection boxes ....................................................................................................................85
Plinths85
DECLARATION OF CONFORMITY CE.....................................................................................................86

SD750SP
POWER ELECTRONICS
6
ABOUT THIS MANUAL
EN
ACRONYMS
The terms commonly used in the documentation of Power Electronics’ products are listed in the table
below.
Please notice this is a general series of terms and it encompasses all our product divisions (industrial,
solar, storage, and electric mobility), thus, some of the following expressions may not apply to this
particular manual.
ACRONYM
MEANING
AASS
Auxiliary Services
AC
Alternating Current
AI
Analogue Input
AO
Analogue Output
BESS
Battery Energy Storage System
BMS
Battery Manager Solution
CCID
Charge circuit interrupting device
CCL
Charge Current Limit.
CCS
Combined charging system –charging and communications protocol following the standard IEC
61851-23 Annex CC
CHAdeMO
Charging and communications protocol following the standard IEC 61851-23 Annex AA
CPU
Central Processing Unit
DC
Direct Current
DCL
Discharge Current Limit
DI
Digital Input
DSP
Digital Signal Processor
DO
Digital Output
EMS
Energy Management System
EV
Electric Vehicle
FPGA
Programmable device (Field-Programmable Gate Array)
FRU
Field Replaceable Unit
GFDI
Ground Fault Detector Interrupter
GPRS
General Packet Radio Services, a data transmission system
HVAC
Heating, Ventilation, and Air Conditioning
IGBT
Insulated Gate Bipolar Transistor
IMI
Insulation monitoring device
IT
Grid system where the power supply is kept isolated and the electrical equipment system is
grounded.
LOTO
Lock Out –Tag Out
MCB
Miniature Circuit Breaker
MPCS
Multi Power Conversion System
MID
Measuring Instrument Directive
MV
Medium Voltage. This term is used to refer to high voltage in general
PE
Ground connection
PI
Proportional and Integral
POI
Point Of Interconnection
PPE
Personal Protection Equipment
PV
Photovoltaic energy

POWER ELECTRONICS
SD750SP
ABOUT THIS MANUAL
7
ACRONYM
MEANING
RCD
Residual Current Device
RCM
Residual Current Monitor
RFID
Radio Frequency Identification
SOC
State Of Charge –referred to battery
SOH
State Of Health –referred to battery. It compares the actual state of the battery to its initial
conditions. It is measured in percentage
STO
Safe Torque Off
TN
Grid system where the power supply is grounded, and the electrical equipment system is brought
to the same ground through the neutral connector.
TT
Grid system where both the power supply and the electrical devices are connected to the ground
via separate connections
UPS
Uninterruptible Power Supply
VSD / VFD
Variable Speed Drive, Variable Frequency Drive. Both terms are used

SD750SP
POWER ELECTRONICS
8
SAFETY SYMBOLS
EN
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards from occurring.
In this manual, safety messages are classified as follows:
Other symbols used in this manual for safety messages are the following:
WARNING
Identifies potentially hazardous situations where dangerous voltage may be
present, which if not avoided, could result in minor personal injury, serious
injury or death.
Be extremely careful and follow the instructions to avoid the risk of electrical
shocks.
CAUTION
Identifies potentially hazardous situations, which if not avoided, could result
in product damage, or minor or moderate personal injury.
Read the message and follow the instructions carefully.
NOTICE
Identifies important measures to take in order to prevent damage equipment
and warranty lost, as well as encouraging good use and environmental
practices.
Hot surface. Be careful and follow the instructions to avoid burns and personal injuries.
Risk of fire. Be careful and follow the instructions to prevent causing an unintentional fire.
Caution, risk of electric shock. Energy storage timed discharge. Wait for the indicated
time to avoid electrical hazards.
Caution, risk of hearing damage. Wear hearing protection.

POWER ELECTRONICS
SD750SP
SAFETY INSTRUCTIONSINTRODUCTIONINTRODUCTION
9
SAFETY INSTRUCTIONS
Read carefully all documentation before manipulating the equipment and pay special attention to safety
recommendations to maximize the performance of this product and to ensure its safe use and installation.
It is the installer’s responsibility to follow the instructions provided on this manual, to follow good electrical
practices and to identify all mentioned warnings and recommendations before starting up and operating
the SD750SP.
WARNING
Do not remove the cover while the drive is powered or running.
Otherwise, you may get an electric shock.
Do not run the drive with the front cover removed.
Otherwise, you may get an electric shock.
The drive does not remove the voltage from the input terminals of the drive. Before working on
the drive, isolate the whole drive from the supply.
If you do not remove the power supply, you may get an electric shock.
Do not remove the cover except for periodic inspections or wiring, even if the input power is not
applied.
Otherwise, you get an electric shock.
Operate the drive with dry hands.
Otherwise, you may get an electric shock.
Do not use cables with damaged insulation.
Otherwise, you may get an electric shock.
Do not subject the cables to abrasions, excessive stress, heavy loads, or pinching.
Otherwise, you may get an electric shock.
Do not make any insulation or voltage withstand tests on the motor while the drive is connected.

SD750SP
POWER ELECTRONICS
10
SAFETY INSTRUCTIONS
EN
WARNING
10 min
Both wiring and periodic inspections must be carried out at least 10 minutes
after disconnecting the input power. To remove the front cover, make sure
that the red "DC Link" LED is off. Then remove the metal cover from the
terminals and check the following with a multimeter:
•Voltage between the output busbars U, V, W, and the cabinet is
around 0V.
•Voltage between the terminals + HVDC, -HVDC and the cabinet is
below 30VDC.
If you omit this recommendation, you may get an electric shock.
Even though multimeters have their own revisions Schedule, it is convenient
to verify it works properly, specially to check voltage absence. It could be
damaged and show incorrect values. Use a 1.5V battery to verify proper
functioning.
CAUTION
Install the drive on a non-flammable surface. Do not place flammable material
nearby.
Otherwise, a fire could occur.
Disconnect the input power if the drive is damaged.
Otherwise, it could result in a secondary accident or fire.
Do not allow lint, paper, wood chips, dust, metallic chips, or other foreign matter
into the drive.
Otherwise, a fire or accident could occur.
After stopping the drive, some of its parts will stay warm for a while. Wait for the
drive to cool down for handling.
Touching hot parts may result in skin burns.
Do not apply power to a damaged drive or to a drive with parts missing, even if
the installation is complete.
Otherwise, you may get an electric shock.
It is not allowed to weld the cabinet or structure; this could damage the sensitive
electronic components inside the cabinet or structure.

POWER ELECTRONICS
SD750SP
SAFETY INSTRUCTIONSINTRODUCTIONINTRODUCTION
11
NOTICE
RECEPTION
SD750SP drives are delivered tested and perfectly packed.
In the event of damage during transport, please ensure to notify the transport agency and POWER
ELECTRONICS: 902 40 20 70 (International [phone]) or your nearest agent, within 24h from
receiving the goods.
UNPACKING
Make sure model and serial number of the variable speed drive are the same on the box, delivery note
and unit.
Each variable speed drive is delivered with Hardware and Software technical manuals.
RECYCLING
Packaging equipment must be recycled. Separate all different materials (plastic, paper, cardboard,
wood…) and place them in the corresponding containers. Ensure waste collection is properly managed
with a Non-Hazardous Waste Agent.
To guarantee health and natural environmental sources protection, the European Union has
adopted the WEEE directive concerning discarded electric and electronic equipment
(SEEA).
Waste of electrical and electronic equipment (WEEE) must be collected selectively for
proper environmental management.
Our products contain electronic cards, capacitors and other electronic devices that should
be separated when they are no longer functional. These WEEEs should be managed
accordingly with a Hazardous Waste Agent.
Power Electronics promotes good environmental practices and recommends that all its
products sold outside of the European Union, once they reach the end of their life, are
separated and the WEEE managed according to the particular country applicable legislation
(especially: electronic cards, capacitors, and other electronic devices).
If you have any questions about the electric and electronic equipment waste, please contact Power
Electronics.
ELECTROMAGNETIC COMPATIBILITY (EMC)
The drive is intended to be used in industrial environment (Second Environment). It achieves compliance
with category C3 defined in IEC/EN 61800-3 standard when the installation recommendations within this
manual are followed. The driver can optionally operate in domestic environments (First Environment),
complying with category C2 defined in IEC / EN 61800-3 standard. For category C1 consult Power
Electronics. Optional IT filter.
Select communication and control system according to the drive EMC environment. Otherwise, systems
could suffer from interferences due to a low EMS level.
CAPACITORS DEPLETION
If the drive has not been operated for a long time, capacitors lose their charging characteristics and are
depleted. To prevent depletion, once a year run the device under no-load conditions during 30-60 minutes.

SD750SP
POWER ELECTRONICS
12
SAFETY INSTRUCTIONS
EN
SAFETY
•Before operating the drive, read this manual thoroughly to gain an understanding of the unit. If any
doubt exists, please contact POWER ELECTRONICS, (902 40 20 70 / [phone]) or your
nearest agent.
•Wear safety glasses when operating the drive with power applied or for when the front cover is
removed.
•Handle and transport the drive following the recommendations within this manual.
•Install the drive according to the instructions within this manual and the local regulations.
•Do not place heavy objects on the drive.
•Ensure that the drive is mounted vertically and keeping the minimum clearance distances.
•Do not drop the drive or subject it to impact.
•The SD750SP drives contain static sensitive printed circuits boards. Use anti-static safety
procedures when handling these boards.
•Avoid installing the drive in conditions that differ from those described in the Environmental Ratings
section.
CONNECTION PRECAUTIONS
•To ensure a correct operation of the drive, it is recommended to use a SCREENED CABLE for
the control wiring.
•The motor cable should comply with the requirements within this manual. Due to increased
leakage capacitance between conductors, the external ground fault protection threshold value
should be adjusted ad hoc.
•Do not disconnect motor cables if the input power supply remains connected.
•The internal circuits of the SD750SP Series will be damaged if the incoming power is connected
and applied to output terminals (U, V, W).
•Do not use power factor correction capacitors banks, surge suppressors, or RFI filters on the
output side of the drive. Doing so may damage these components.
•Always check whether the “DC Link”red LED is OFF before wiring terminals. The capacitors may
hold high-voltage even after the input power is disconnected.
•Do not connect the drive in grids whose THDv is higher than 8%.
COMMISSIONING
•Verify all parameters before operating the drive. Alteration of parameters may be required
depending on application and load.
•Always apply voltage and current signals to each terminal that are within the levels indicated in
this manual. Otherwise, damage to the drive may occur.
•For correct starting, refer to the start-up section.
HANDLING PRECAUTIONS
•When the "Automatic Restart" function is selected, observe the appropriate safety measures to
avoid any damage in case of sudden restart of the motor after an emergency and subsequent
reset.
•The "STOP / RESET" key on the driver's own keypad will be operative as long as this option has
been selected. By pressing this button, the drive will not perform an emergency stop. The driver
has a STO function which, installed with an external EMERGENCY pushbutton, will disconnect
the motor power supply and prevent the ability to generate torque in the motor.
•If an alarm is reset without having lost the reference signal (setpoint), an automatic start may
occur. Check that the system has not been configured as such. Failure to do so could result in
personal injury.
•Do not modify anything inside the driver without the supervision of Power Electronics.
•Before starting the parameter setting, reset all parameters.

POWER ELECTRONICS
SD750SP
SAFETY INSTRUCTIONSINTRODUCTIONINTRODUCTION
13
EARTH CONNECTION
•Ground the drive and adjoining cabinets to ensure a safe operation and to reduce electromagnetic
emission.
•Connect the input PE terminal only to the dedicated PE terminal of the drive. Do not use the case,
nor chassis screw for grounding.
•Ground the drive chassis through the labelled terminals. Use appropriate conductors to comply
with local regulations. The ground conductor should be connected first and removed last.
•Motor ground cable must be connected to the PE output terminal of the drive and not to the
installation’s ground. We recommend that the section of the ground conductor (PE) is equal or
greater than the active conductor (U, V, W).
•If the user decides to use screened motor cable, ensure a good 360° connection of the cable
screen in both the drive cabinet and the motor terminal box.
CYBER SECURITY DISCLAIMER
This product is designed to be connected to and to communicate information and data via a network
interface. The customer is thesole responsible for providing and continuously ensuring asecure connection
between the product and customer network or any other network (as the case may be). Customer shall
establish and maintain any appropriate measures (such as but not limited to the installation of firewalls,
application of authentication measures, encryption of data, installation of antivirus programs, etc.) to protect
the product, the network, its system and the interface against any kind of security breaches, unauthorized
access, interference, intrusion, leakage and/or theft of data or information.
Power Electronics and its affiliates are not liable for damages and/or losses related to such security
breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information.

SD750SP
POWER ELECTRONICS
14
TORQUE AND SCREW SIZING
EN
TORQUE AND SCREW SIZING
The following table shows, broadly speaking, the recommended tightening torque for both mechanical and
electrical connections, applicable to all cabinets [
1
,
2
]:
SCREW SIZE
RECOMMENDED TORQUE
METRIC (mm)
ENGLISH
(inches)
DIN (Nm)
ASTM (ft*lb)
6,9 QUALITY[a]
8,8 QUALITY[a]
A449 TYPE 1[a]
A325 TYPE 1[a]
M3
1/8
1
1,3
-
-
M4
5/32
2,5
3
M5
3/16
4
6
M6
1/4
5
10
4
M8
5/16
20
25
9
M10
7/16
40
50
25
M12
1/2
60
70
38
50 –58
M14
9/16
100
120
54
-
M16
5/8
150
210
75
99 –120
[a] For other qualities, follow the screw’s manufacturer guidelines.
CAUTION
For all screwing that hold a particular component such as a bus, contactor, etc. it will be necessary to
apply the tightening torque indicated by the manufacturer of the same component.
Screwing should be tightened correctly only whennecessary,i.e. whenthe factory marks are not in place.
For small screws that do not have marks, the good electrical praxis will determine if it is loose.
1
Power Electronics recommends the use of Zinc Steel quality 8.8 bolts for internal connections in general, DC and
earth connections included.
2
Power Electronics recommends the use of A2-70 stainless bolts for external connections in general, AC connections
included.

POWER ELECTRONICS
SD750SP
INTRODUCTION
15
INTRODUCTION
Power Electronics has a strong commitment to reduce the levelized cost of water (LCoW) by offering
upgraded energy saving solutions. Synergies of the industrial and solar division have been exploited to
launch the high power solar pumping system SD750SP. This equipment is a customised VSD with an
increased DC range, adapted to work with AC or DC power or with a hybrid system. The SD750SP has an
updated firmware that is also capable of finding the MPP (Maximum Power Point) to maximise installation
performance.
This product allows simultaneous connection to the grid (AC) and PV field (DC). The AC input voltage
determines the DC bus voltage of the SD750SP and therefore the required DC voltage of the strings. The
maximum power produced at the set DC voltage depends on the number of PV panels connected inseries.
The SD750SP also allows self-sufficient operation by connecting itself to the PV field and generating the
energy needed to start and accelerate the pumping system. The minimum power required depends on the
hydraulic response of the complete pump load system.
The SD750SP is a compact solution that allows a quick and easy installation and commissioning. Optional
solar kits with diodes, DC protections, disconnection and filtering are available. A complete integration in
a cabinet is also available, which facilitates installation and commissioning.
1

SD750SP
POWER ELECTRONICS
16
CONFIGURATION TABLE & STANDARD RATINGS
EN
CONFIGURATION TABLE &
STANDARD RATINGS
Configuration table
To consult the configuration table of SD750SP drives manufactured by Power Electronics, please refer
to the latest brochure (visit http://www.power-electronics.com).
Standard ratings
Voltages in the standard ratings shown in the following tables are the three-phase input voltages for the
drive.
The number of pulses depend on the number of transformer secondaries at drive input.
•6 pulses: Transformer with a single secondary.
•12 pulses: Transformer with two secondaries.
•18 pulses: Transformer with three secondaries.
•24 pulses: Transformer with four secondaries.
2

POWER ELECTRONICS
SD750SP
CONFIGURATION TABLE AND STANDARD RATINGS
17
400Vac –565Vcc
FRAME
CODE
OPERATION TEMPERATURE 50°C
AC SUPPLY
OPERATION TEMPERATURE 50 ºC
MPPT DC POWER SUPPLY
I(A) Rated
Motor Power
(kW) at
400VAC
150%
Overload
(A) 60s
I(A) DC input
I(A) DC input
120% Overload
30s
1
SD75P0006 5
6
2,2
9
6
8
SD75P0009 5
9
4
14
9
11
SD75P0012 5
12
5,5
18
12
15
SD75P0018 5
18
7,5
27
18
23
SD75P0024 5
24
11
36
24
30
2
SD75P0032 5
32
15
48
32
40
SD75P0038 5
38
18,5
57
38
48
SD75P0048 5
48
22
72
48
60
3
SD75P0060 5
60
30
90
60
75
SD75P0075 5
75
37
113
75
94
SD75P0090 5
90
45
135
90
113
SD75P0115 5
115
55
173
115
144
4
SD75P0150 5
150
75
225
150
188
SD75P0170 5
170
90
255
170
213
5
SD75P0210 5
210
110
315
210
263
SD75P0250 5
250
132
375
250
313
SD75P0275 5
275
150
413
275
344
6
SD75P0330 5
330
160
495
330
413
SD75P0370 5
370
200
555
370
463
SD75P0460 5
460
250
690
460
575
7
SD75P0580 5
580
315
870
580
725
SD75P0650 5
650
355
975
650
813
SD75P0720 5
720
400
1080
720
900
8
SD75P0840 5
840
450
1260
840
1050
SD75P0925 5
925
500
1388
925
1156
SD75P0990 5
990
560
1485
990
1238
>81
SD75P1150 5
1150
630
1725
1150
1438
SD75P1260 5
1260
710
1890
1260
1575
SD75P1440 5
1440
800
2160
1440
1800
SD75P1580 5
1580
900
2370
1580
1975
SD75P1800 5
1800
1000
2700
1800
2250
1
For higher power ratings, consult Power Electronics.

SD750SP
POWER ELECTRONICS
18
TECHNICAL CHARACTERISTICS
EN
TECHNICAL CHARACTERISTICS
INPUT
Power range [1]
1,5 kW –1000 kW
Voltage range
380 –480 Vac (±10%)
Voltage range dc
540 –1000Vdc (Frames 1 and 2 up to 830Vdc)
Input frequency
50 Hz / 60 Hz (±6%)
Input rectifier technology
Diode-Diode Frames 1 and 2 / Thyristor-Diode Frames 3 to 8
Displacement power factor
(DPF = cos φ)
≥ 0,98
Power factor
(PF= I1/Irms· cos φ)
≥ 0,91
Momentary power loss
> 2 s (depending on the load inertia)
EMC input filter
Second environment (Industrial): (C3 Standard)
First environment (Domestic): C2 (Optional). C1 consult Power Electronics
Optional IT filter
Harmonics filter
Choke coils 3% impedance
Current THD (%)
< 40%
Regenerative
No
OUTPUT
Output frequency [1]
0...599 Hz
Overload capacity
Constant torque: 125% during 30 s at 50ºC
Efficiency (at full load)
≥ 98%
Control method
V / Hz
VECTOR CONTROL
Open Loop. PWM speed control / torque, AVC: speed control / torque
Close Loop (Encoder): PWM speed control / torque, AVC: speed control / torque
PMSM I/f, sensorless and HEPOL (High Efficiency Performance Open Loop)
Carrier frequency
4 to 8 kHz –PEWave
Output dV/dt filter
500 to 800 V/µs [2]
Output cable length [3]
USC 300m, SC 150m
Dynamic brake
External B150 Dynamic Brake (Integrated in Frames 1 and 2)
ENVIRONMENTAL
CONDITIONS
Operation ambient temperature
Minimum: -20°C Maximum: +50°C
Storage temperature
Minimum: -40°C Maximum: +70°C
Altitude
1000 m
Power altitude derating [1]
>1000 m, 1% PN (kW) per 100 m; 4000 m maximum
Ambient humidity
<95%, non-condensing
Degree of protection
IP20[4], IP54[5], IP42[6]
Vibration
Amplitude: ± 1 mm (2 Hz - 13.2 Hz), ± 0.075 mm (13.2 Hz –57 Hz)
Acceleration: 6.86 m/s² (13.2 Hz - 57 Hz), 9.8 m/s² (57 Hz - 150 Hz)
Heating resistors
Optional
PROTECTIONS
Motor protections
Rotor Locked. Motor overload (thermal model). Output current limit. Phase current
imbalance. Phase voltage imbalance. Motor overtemperature (PT100 signal). Speed
Limit. Torque Limit.
Drive protections
IGBT’s Overload. Input Loss. Low Input Voltage. High Input Voltage. DC Bus. Voltage
Limit. DC Bus Low Voltage. High Supply Frequency. Low Supply Frequency. IGBT
Temperature. Heat-sink overtemperature. Power supply fault. Drive thermal model.
Ground Fault. Software and Hardware fault. Analog Input signal loss (speed
reference loss). Safe stop / Emergency stop.
[1] For operation frequencies higher than 100 Hz consult Power Electronics.
[2] Valid for frames 3 to 8, depending on the SD750 rated power. Optional filter available for frames 1 and 2.
[3] Follow Power Electronics installation recommendations. For greater cable lengths, consult Power Electronics. Consult for greater lengths.
[4] Available for 380–480Vac up to frame 4.
[5] Applicable to the electronics.
[6] Applicable to the electronics.
[7] Certification in process.
3
