Power Electronics SD700 Series Instructions for use

Variable Speed Drive
Application Manual
PUMPS

Variable Speed Drive
Application Manual
PUMPS
Edition: March 2011
SD70MTAP01BI Rev. B

SD700
POWER ELECTRONICS
2

POWER ELECTRONICS
SD700
3
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards from occurring.
Edition of March 2011
This publication could present technical imprecision or misprints. The information here included will be
periodically modified and updated, and all those modifications will be incorporated in later editions.
To consult the most updated information of this product you might access through our website
www.power-electronics.com where the latest version of this manual can be downloaded.
WARNING
This symbol means improper operation may results in serious personal
injury or death.
CAUTION
Identifies shock hazards under certain conditions.Particular attention should
be given because dangerous voltage may be present. Maintenance
operation should be done by qualified personnel
Identifies potential hazards under certain conditions. Read the message and
follow the instructions carefully.
Identifies shock hazards under certain conditions.Particular attention should
be given because dangerous voltage may be present.

SD700
POWER ELECTRONICS
4
Revisions
Date Revision Description
08 / 01 / 2010 A First edition. SW version 2.0 (2.3)
31 / 03 / 2011 B Software version updating and misprinting errors.
SW Version 2.0 (26)

POWER ELECTRONICS
SD700
INDEX
5
INDEX
SAFETY INSTRUCTIONS........................................................................................................... 7
1. INTRODUCTION .................................................................................................................. 11
2. VISUALIZATION AND STATUS PARAMETER. GROUP 0................................................. 12
2.1. Parameters SV.5 –Programmable Parameters......................................................... 12
2.2. Parameters SV.8 –Pump Control.............................................................................. 13
3. DESCRIPTION OF PROGRAMMING PARAMETERS ........................................................ 15
3.1. Group 1 –G1: Options Menu..................................................................................... 15
3.2. Group 4 –G4: Inputs.................................................................................................. 16
3.3. Group 8 –G8: Outputs............................................................................................... 19
3.4. Group 12 –G12: Auto Reset...................................................................................... 20
3.5. Group 13 –G13: Fault History ................................................................................... 21
3.6. Group 25 –G25: Pump Control ................................................................................. 22
4. MODBUS COMMUNICATION.............................................................................................. 40
4.1. Remote Control Functions ......................................................................................... 40
4.2. Summary of Modbus Addresses................................................................................ 41
5. FAULT MESSAGES. DESCRIPTION AND ACTIONS ........................................................ 46
5.1. Descripción of Fault List............................................................................................. 46
5.2. Procedure for Fault Solutions..................................................................................... 46
6. COMMONLY USED CONFIGURATIONS............................................................................ 47
6.1. Pressure Group Control with 3 Auxiliarey Pumps, Start and Stop on Demand.......... 47
6.2. Pressure Group Control with Eight Pressure References.......................................... 49
7. CONFIGURATION REGISTER ............................................................................................ 52
8. CE CERTIFICATE................................................................................................................ 58

SD700
POWER ELECTRONICS
6
INDEX

POWER ELECTRONICS
SD700
SAFETY INSTRUCTIONS
7
SAFETY INSTRUCTIONS
IMPORTANT!
Read this manual carefully to maximise the performance of this product and to ensure its safe
use.
In this manual, safety messages are classified as follows:
WARNING
Do not remove the cover while the power is applied or the unit is in operation.
Otherwise electric shock could occur.
Do not run the drive with the front cover removed.
Otherwise you may get an electric shock due to the high voltage terminals or exposure of charged
capacitors.
Do not remove the cover except for periodic inspections or wiring, even if the input power is not
applied. Otherwise you may access the charged circuits and get an electric shock.
Wiring and periodic inspections should be performed at least 10 minutes after disconnecting the
input power and after checking the DC Link voltage is discharged with a meter (below 30VDC).
Otherwise you may get an electric shock.
Operate the switches with dry hands.
Otherwise you may get an electric shock.
Do not use cables with damaged insulation.
Otherwise you may get an electric shock.
Do not subject the cables to abrasions, excessive stress, heavy loads or pinching.
Otherwise, you may get an electric shock.

SD700
POWER ELECTRONICS
8
SAFETY INSTRUCTIONS
CAUTION
Install the drive on a non-flammable surface. Do not place flammable material nearby.
Otherwise fire could occur.
Disconnect the input power if the drive gets damaged.
Otherwise it could result in a secondary accident or fire.
After the input power is applied or removed, the drive will remain hot for a couple of minutes.
Touching hot parts may result in skin burns.
Do not apply power to a damaged drive or to a drive with parts missing even if the installation is
complete.
Otherwise you may get an electric shock.
Do not allow lint, paper, wood chips, dust, metallic chips or other foreign matter into the drive.
Otherwise fire or accident could occur.
WARNINGS
RECEPTION
The SD700 is carefully tested and perfectly packed before leaving the factory.
In the even of transport damage, please ensure that you notify the transport agency and POWER
ELECTRONICS: 902 40 20 70 (International [phone]) or your nearest agent, within
24hrs from receipt of the goods.
UNPACKING
Make sure model and serial number of the variable speed drive are the same on the box, delivery
note and unit.
Each variable speed drive is supplied with a SD700 technical manual.
RECYCLING
Packing of the equipments should be recycled. For this, it is necessary to separate different
materials included (plastic, paper, cardboard, wood, ...) and deposit them on proper banks.
Waste products of electric and electronic devices should be selectively collected for their correct
environmental management.
EMC
This type of PDS (Power Device System) is not intended to be used on a low-voltage public network
which supplies domestic premises.
Radio frequency interference is expected if used on such a network.

POWER ELECTRONICS
SD700
SAFETY INSTRUCTIONS
9
SAFETY
Before operating the drive, read this manual thoroughly to gain and understanding of the unit. If
any doubt exists then please contact POWER ELECTRONICS, (902 40 20 70 / [phone]
57) or your nearest agent.
Wear safety glasses when operating the drive with power applied and the front cover is
removed.
Handle the drive with care according to its weight.
Install the drive according to the instructions within this manual.
Do not place heavy objects on the drive.
Ensure that the mounting orientation is correct.
Do not drop the drive or subject it to impact.
The SD700 drives contain static sensitive printed circuits boards. Use static safety procedures
when handling these boards.
Avoid installing the drive in conditions that differ from those described in the Technical
Characteristics section.
CONNECTION PRECAUTIONS
To ensure correct operation of the drive it is recommended to use a SCREENED CABLE for the
control wiring.
For EMERGENCY STOP, make sure supply circuitry is open.
Do not disconnect motor cables if input power supply remains connected. The internal circuits of
the SD700 Series will be damaged if the incoming power is connected and applied to output
terminals (U, V, W).
It is not recommended to use a 3-wire cable for long distances. Due to increased leakage
capacitance between conductors, over-current protective feature may not operate correctly.
Do not use power factor correction capacitors, surge suppressors, or RFI filters on the output
side of the drive. Doing so may damage these components.
Always check whether the DC Link LED is OFF before wiring terminals. The capacitors may
hold high-voltage even after the input power is disconnected. Use caution to prevent the
possibility of personal injury.
TRIAL RUN
Verify all parameters before operating the drive. Alteration of parameters may be required
depending on application and load.
Always apply voltage and current signals to each terminal that are within levels indicated within
this manual. Otherwise, damage to the drive may result.

SD700
POWER ELECTRONICS
10
SAFETY INSTRUCTIONS
OPERATION PRECAUTIONS
When the Auto Restart function is enabled, keep clear of driven equipment, as the motor will
restart suddenly after a fault is reset.
The “STOP / RESET” key on the keypad is active only if the appropriate function setting has been
made. For this reason, install a separate EMERGENCY STOP push button that can be operated
at the equipment.
If a fault reset is made with the reference signal still present then a restart will occur. Verify that it
is permissible for this to happen, otherwise an accident may occur.
Do not modify or alter anything within the drive.
Before programming or operating the SD700 Series, initialise all parameters back to factory
default values.
EARTH CONNECTION
The drive is a high frequency switching device and leakage current may flow. Ground the drive to
avoid electrical shock. Use caution to prevent the possibility of personal injury.
Connect only to the dedicated ground terminal of the drive. Do not use the case or the chassis
screw for grounding.
When installing, grounding wire should be connected first and removed last.
The earth cable must have a minimal cross sectional area that meets local country electrical
regulations.
Motor ground must be connected to the drive ground terminal and not to the installation‟s ground.
We recommend that the section of the ground connection cable should be equal or higher than
the active conductor.
Installation ground must be connected to the drive ground terminal.

POWER ELECTRONICS
SD700
INTRODUCTION
11
1. INTRODUCTION
The information included in this manual is only linked with the parameters related to Pump Macro software.
For additional information about the parameters and the programming of SD700, refer to „Software and
Programming Manual‟.
For additional information about the hardware of the equipment and its installation, refer to „Hardware and
Installation Manual‟.

SD700
POWER ELECTRONICS
12
VISUALIZATION AND STATUS PARAMETERS. GROUP G0
2. VISUALIZATION AND STATUS
PARAMETERS. GROUP G0
2.1. Parameters SV.5 –Programmable Parameters
This group is not only a display group. Some parameters can be adjusted in this group. The
parameters of this group described in the following table affect to the pump macro.
Screen
Units
Description
PMP manSP=+0.0%
% motor speed
To set the value of the LOCAL manual speed reference. For additional details, check G25.1.3.
PMP MRe1=0.0%
% motor speed
To set the local reference 1 of PID. Multi-reference 1. For additional details, check G25.1.5.
PMP MRe2=0.0%
% motor speed
To set the local reference 2 of PID. Multi-reference 2. For additional details, check G25.1.6.
PMP MRe3=0.0%
% motor speed
To set the local reference 3 of PID. Multi-reference 3. For additional details, check G25.1.7.
PMP MRe4=0.0%
% motor speed
To set the local reference 4 of PID. Multi-reference 4. For additional details, check G25.1.8.
PMP MRe5=0.0%
% motor speed
To set the local reference 5 of PID. Multi-reference 5. For additional details, check G25.1.9.
PMP MRe6=0.0%
% motor speed
To set the local reference 6 of PID. Multi-reference 6. For additional details, check G25.1.10.
PMP MRe7=0.0%
% motor speed
To set the local reference 7 of PID. Multi-reference 7. For additional details, check G25.1.11.
PMP MRe8=0.0%
% motor speed
To set the local reference 8 of PID. Multi-reference 8. For additional details, check G25.1.12.
T AutOFF=OFF
hours
Time for Automatic Stop. For additional details, check G25.1.13.
TIME OFF=OFF
min
It shows the resting time in minutes, for the automatic stopping of the system.
MAX flow=1000l/s
Eng. Units
It allows setting a level for the maximum flow as in G25.10.2.
RESET LEVL=+100%
% Max range
of sensor
It allows setting a reset level for the flow control algorithm as in G25.10.4.
SLEP FLO=0.0l/s
Eng. Units
It allows setting a flow level to sleep the drive as in G25.4.11.

POWER ELECTRONICS
SD700
VISUALIZATION AND STATUS PARAMETERS. GROUP G0
13
2.2. Parameters SV.8 –Pump Control
Screen
Units
Description
R=0.0Bar 0.0Bar
Engineering
units
It shows the PID reference value (left hand) and the sensor value which is sent by the
feedback signal (right hand).
REGL +0.0%+0.0%
% sensor
range
It shows the drive status during the pump control operation according to the following table:
Status
Description
REGL
Drive is regulating in PID mode.
PMAN
The drive is at protected manual mode.
OMAN
Drive is in manual mode, not protective mode.
HIPP
Drive is stopped (pause) due to high pressure, according to
the read data in the analogue input.
HIPR
A fault due to high pressure has occurred according to the
read data in the analogue input or in the digital input.
FLOD
The drive has stopped (Pause status) due to No Flow
detection.
NFLO
The drive has tripped (Fault status) due to No Flow detection.
CAVS
The drive has stopped (Pause status) due to Cavitation.
CAVI
The drive has tripped (Fault status) due to Cavitation.
LOPR
The drive has tripped due to low pressure fault.
LOWA
The drive has tripped due to a fault detected in one of the
digital inputs configured as „No Water‟
CYCL
The drive has tripped due to excessive starting cycles.
IRFA
The drive has tripped due to a fault in the irrigation equipment
which has been detected in the digital input configured in that
option.
FLOW
The drive is limiting the speed to limit the flow.
OFF
The drive has received the stop command.
SLEP
The drive is in sleep mode because there is no flow demand.
BYPA
The drive is forcing the speed after starting or stopping some
of the fixed pumps.
RAMP
Setpoint ramp activated.
FILL
The drive is running at reduced speed because Pipe Fill
function is active.
COMP
The time of automatic stop has expired and the drive is
stopped.
JOCK
The Jockey pump is running.
PRIM
Priming pump is connected.
FINP
Fault occurred because the pressure switch is open.
Additionally, the reference in PID mode (as %) followed by feedback (as %) is shown.
1OFF 2OFF 3OFF
-
The status of the fixed pumps 1-3 is shown according to the next information:
Status
Description
OFF
Pump disabled by keypad.
RDY
Pump ready to start.
ON
Pump started.
FLT
Pump in a fault status (input which controls the signal is
active).
Note: See digital input configuration in Pump Control mode.
G1.7 and G4.1.4 parameters are linked to this.
4OFF 5OFF
-
It shows the status for the fixed pumps 4-5 according to the above mentioned information.
Flow = 0.0l/s
Engineering
units
It shows the present value read by the analogue input or by pulse input where sensor is
connected.

SD700
POWER ELECTRONICS
14
VISUALIZATION AND STATUS PARAMETERS. GROUP G0
Screen
Units
Description
STATUS PUMP
PROGRAM
-
In the visualization lines of the display, it is possible to select this option. In this way the
following messages are going to be shown according to the current program status:
Status
Description
PID REGULATION
Drive is regulating in PID mode.
PROTECTED MANUAL
The drive is at protected manual mode.
OVERRIDE MANUAL
Drive is in manual mode, not protective mode.
HI PRESSURE PAUS
Drive is stopped (pause) due to high pressure,
according to the read data in the analogue input.
HI PRESSURE FAUL
A fault due to high pressure has occurred according to
the read data in the analogue input or in the digital input.
NO FLOW PAUSE
The drive has stopped (Pause status) due to No Flow
detection.
NO FLOW FAULT
The drive has tripped (Fault status) due to No Flow
detection.
CAVITATION PAUSE
The drive has stopped (Pause status) due to Cavitation.
CAVITATION FAULT
The drive has tripped (Fault status) due to Cavitation.
LO PRESSURE FAUL
The drive has tripped due to low pressure fault.
LO WATER FAULT
The drive has tripped due to a fault detected in one of
the digital inputs configured as „No Water‟
CYCLING FAULT
The drive has tripped due to excessive starting cycles.
IRRIGATOR FAULT
The drive has tripped due to a fault in the irrigation
equipment which has been detected in the digital input
configured in that option.
LIMITING FLOW
The drive is limiting the speed to limit the flow.
PUMP STOP
The drive has received the stop command.
SLEPT NO DEMAND
The drive is in sleep mode because there is no flow
demand.
BYPASSING SPEED
The drive is forcing the speed after starting or stopping
some of the fixed pumps.
SETPOINT RAMP
Setpoint ramp activated.
PIPE FILLING
The drive is running at reduced speed because Pipe Fill
function is active.
COMPLETED
The time of automatic stop has expired and the drive is
stopped.
JOCKEY PUMP ON
The Jockey pump is running.
PRIMING PUMP ON
The Priming pump (suction filling) is connected.
PRESSU SWITCH ON
The pressure switch is open.

POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
15
3. DESCRIPTION OF PROGRAMMING
PARAMETERS
The different parameters of the SD700 are displayed in the alphanumeric LCD. These parameters are
organized in groups (G1, G2, G3, …).
The most of parameters related to the pump control are included in Group 25, except for the settings of the
in puts and outputs, that are included in groups G4 and G8. Also, there are some visualizing parameters
included in visualization groups SV.5 and SV.8 described before.
Therefore, all the parameters that affect to the pump macro are listed below.
3.1. Group 1 –G1: Options Menu
Parameter
Name /
Description
Range
Function
Set on
RUN
7 PROG= STANDARD
G1.7 / Program
activation
STANDARD
PUMP
It allows selection additional functionalities. If PUMP is selected, then
extended functionality for pumping control G25 will appear as available.
The group G25 will be hidden if the pump program is not active.
Once selected the pump program, a character will appear in the upper
line of the display, beside the drive status, indicating constantly that the
pump program is active. The letter “b” in Spanish and the letter “p” for
English / German.
The most of parameters relative to the pump control are located in Group
25, excepting those setting relatives to inputs and outputs that can be
found in groups G4 and G7.
Additionally there are some visualization screens included in visualization
groups SV.5 and SV.8.
For additional information, see the „Pump Application Manual‟ for the
SD700.
YES
3.1.1. Subgroup 1.10 –S1.10: Eloader (EEPROM Charger)
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
UPLOAD=N
G1.10.1 / Saves
the parameters
of the drive to the
display.
N
Y
When adjusting this value to Yes, the copy of parameters to the display starts,
saving the configuration of the drive.
A screen will appear showing the uploading progress:
UPLOADING…100%
When this process is over, the progress screen will automatically return to the
main screen, set by default to No.
Note: In order to carry out the parameter load correctly, the user should firstly
configure the digital inputs corncerning „STOP‟ functions before any other
function.
NO
DOWNLOAD=N
G1.10.2 / Saves
the parameters
of the display to
the drive.
N
Y
When adjusting this value to Yes, the copy of parameters stored in the display to
the drive will start modifying and programming the parameters of this new drive.
A screen will appear showing the downloading progress:
DOWNLOADING …100%
When this process is over, the progress screen will automatically change to the
main screen, set by default to No.
Note: Before downloading, read carefully the note refered to the digital inputs
configuration in Subgroup [4.1].
NO

SD700
POWER ELECTRONICS
16
DESCRIPTION OF PROGRAMMING PARAMETERS
3.2. Group 4 –G4: Inputs
3.2.1. Subgroup 4.1 –S4.1: Digital Inputs
Pumps program activation, in G1.7 PROG = PUMP, requires the following considerations:
Some configuration options are available when the pump program is active, which can be set in the same
way that the options available in the standard program.
Nevertheless, when the pump program is active, the drive will assume that only the configurable options
from 50 to 75 (for G4.1.5 to G4.1.10) can be set, without taking into consideration the setting on parameter
„G4.1.4 DIGIT I MODE‟, which means a block setting.
This means that the user will configure the pump program freely, according to his requirements, selecting
the correct functionality and protections. For a correct programming of the digital inputs when the pump
program is active, there is additional information in G25 Pump Control.
Note: Digitial outputs should be configured in order to provide an optimum performance.
The following instructions should be followed:
oStep 1: Set the digital input 1 to the „50PMP.START/STP] option.
oStep 2: Whenever the user requires the use of PID multireferences, the user must carry
out the following configuration in the order described: set the digital output 2 as ‟63
SETPONT PIN1‟, the digital output 3 as ‟64 SETPONT PIN2‟ and the digital output 4 as
‟65 SETPONT PIN3‟.
oStep 3: Once steps 1 and 2 have been succesfully completed, the user may proceed
with the required functions programming.
Note: Selection of the pump program will set all the Digital Inputs to mode „00 – un used‟. If re-
programming is needed, it will be necessary to configure their functionality in a separate way again. So it
guarantees a safety installation operation, avoiding that hardware external to the equipment can cause any
kind of damage.
Note: The digital outputs will also be affected due to pump control activation.
To select one auxiliary pump it is necessary to act in the following way (If you do not want to
connect the input of auxiliary pump Fault Skip to step 2 directly) :
oStep 1: Set any free digital input to options „52 FIX PUMP1 FLT‟, „53 FIX PUMP2 FLT‟,
„54 FIX PUMP3 FLT‟, „55 FIX PUMP4 FLT‟ or „56 FIX PUMP5 FLT‟
oStep 2: To enable the control of the pump in the corresponding screen G25.9.1,
G25.9.2, G25.9.3, G25.9.4 and G25.9.5 respectively.
To remove this pump configuration and release the relay for another use, the user should:
oDisable the control of the pump in the corresponding screen G25.9.1, G25.9.2, G25.9.3,
G25.9.4 or G25.9.5 respectively.

POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
17
Parameter
Name /
Description
Range
Function
Set on
RUN
5 DIGITL IN 1=06
G4.1.5 / Multi-
function Digital
Input 1
configuration
00 –75
Apart from the existing options described in „SW and Programming
Manual‟ of the SD700), when selecting the pump program from
parameter G1.7, the following options are also available:
OPT
DESCRIPTION
FUNCTION
50
PMP
START/STP
Automatic starting of the system. (NO)
51
FLOW PULSE
Pulses input for the flowmeter. (NO)
52
FIX PUMP1
FLT
Auxiliary pump 1 fault. (NO).
53
FIX PUMP2
FLT
Auxiliary pump 2 fault. (NO).
54
FIX PUMP3
FLT
Auxiliary pump 3 fault. (NO).
55
FIX PUMP4
FLT
Auxiliary pump 4 fault. (NO).
56
FIX PUMP5
FLT
Auxiliary pump 5 fault. (NO).
57
MAN
PROTstart
Manual starting including those
protections enabled by the user. (NO).
58
HI PRESS FLT
High Pressure trip. (NC).
59
LO WATER
FLT
No Water trip. (NC).
60
LO PRESS
FLT
To detect a Low Pressure situation.
(NO).
61
FLOW
SWITCH
To connect an external flow switch
(open / closed). (NC).
62
IRRIGAT TRIP
To detect an external fault from the
irrigation equipment. (NO).
63
SETPONT
PIN1
Configuration of the low, medium and
high bit respectively, for multiple PID
setpoints selection, according to the
following table:
They are NO contact.
DIGITAL INPUTS
PID
SETPOINT
DI(z)
=65
DI(y)
=64
DI(x)
=63
0
0
0
G25.1.5
„SETPT1‟
0
0
X
G25.1.6
„SETPT2‟
0
X
0
G25.1.7
„SETPT3‟
0
X
X
G25.1.8
„SETPT4‟
X
0
0
G25.1.9
„SETPT5‟
X
0
X
G25.1.10
„SETPT6‟
X
X
0
G25.1.11
„SETPT7‟
X
X
X
G25.1.12
„SETPT8‟
64
SETPONT
PIN2
65
SETPONT
PIN3
Note: See following page.
YES
6 DIGITL IN 2=00
G4.1.6 / Multi-
function Digital
Input 2
configuration
00 –75
7 DIGITL IN 3=00
G4.1.7 / Multi-
function Digital
Input 3
configuration
00 –75
8 DIGITL IN 4=00
G4.1.8 / Multi-
function Digital
Input 4
configuration
00 –75

SD700
POWER ELECTRONICS
18
DESCRIPTION OF PROGRAMMING PARAMETERS
Parameter
Name /
Description
Range
Function
Set on
RUN
9 DIGITL IN 5=00
G4.1.9 / Multi-
function Digital
Input 5
configuration
00 –75
Note: Coming from the previous page.
OPT
DESCRIPTION
FUNCTION
66
MAN REF 2
To select the second source or the
alternative source for the speed
reference. (NO).
67
MAN OVR STAR
Manual starting without protections,
for testing starting. (NO).
69
PRESSUR
SWITC
Detection of the pressure existing in
the system to be used with the
Priming pump. (NO)
70
ALTER PID
STP
When it is activated the input
configured with this option, the
pump program will consider the
alternative PID setpoint according to
the setting of the parameter
G25.2.2. (NO).
75
A.MACRO
CTRL
It alternates the control mode in
pump macro (see remote control
functions).
YES
10 DIGITL IN 6=17
G4.1.10 / Multi-
function Digital
Input 6
configuration
00 –75
YES
3.2.2. Subgroup 4.4 –S4.4: Pulse Input
Parameter
Name /
Description
Range
Function
Set on
RUN
1 Sensr U=l/s
G4.4.1 / Sensor
units of Pulse
Input
%
l/s
m³/s
l/m
m³/m
l/h
m³/h
m/s
m/m
m/h
Allows selection of the units to measure the flow.
Note: To use this input you should have a flowmeter with a digital pulse
output of pulsewidth greater than 50ms.
Used for flow limitation algorithm. See S25.10.
YES
2 Pls/s = 100l/s
LIQU AMOUNT/PULS
G4.4.2 /
Flowmeter
configuration
0 to 32760
Flow units
It allows setting the amount of the fluid per pulse received.
For example, if setting is „2Pls/s=100l/s‟, and the present flow is 500l/s, 5
pulses/sec will be received.
YES
3 M Rng=1000l/s
FLOW MAX RANGE
G4.4.3 / Maximum
range of flow
meter
0 to 32760
Flow units
It allows user to set the maximum range of the flow meter. It is used to
calculate the reset level of the flow control algorithm.
Parameter G25.10.4 is linked with the value set in this parameter.
Example: If you set a maximum range of 100 units „G4.4.3=100‟, and the
reset level of the flow algorithm is desired below 30 units, you have to set
„G25.10.4=30%‟.
YES
