Power Electronics SD750 Series User manual

SD750
ACCESSORIES MANUAL
PROFIBUS BOARD
LOW VOLTAGE VARIABLE SPEED DRIVE

Accessories Manual
Profibus board
Edition: July 2021
SD75MA06BI Rev. B

SD750
POWER ELECTRONICS
2
ABOUT THIS MANUAL
ABOUT THIS MANUAL
PURPOSE
This manual contains important instructions for the installation, configuration and use of the Profibus
optional board for Power Electronics’ SD750 variable speed drives.
TARGET AUDIENCE
This manual is intended for qualified customers who will install, operate and maintain Power Electronics
SD750 variable speed drives.
Only trained electricians may install and commission the drives.
REFERENCE MANUALS
The following reference documents are available for SD750 variable speed drives:
•Hardware and Installation Manual.
•Programming and Software Manual.
•Maintenance Manual.
•Pumps Application Manual.
POWER ELECTRONICS CONTACT INFORMATION
Power Electronics USA Inc.
1510 N. Hobson Street, Gilbert,
Phoenix
AZ 85233
UNITED STATES OF AMERICA
US Sales: 602-354-4890 / [phone]
Power Electronics España, S.L.
Polígono Industrial Carrases
Ronda del Camp d’Aviació nº 4
46160, Llíria (Valencia)
SPAIN
Fax: [phone]
Website: www.power-electronics.com

POWER ELECTRONICS
SD750
REVISIONS
3
REVISIONS CONTROL
DATE (DD/MM/YYYY)
REVISION
DESCRIPTION
06/03/2020
A
First Edition.
01/07/2021
B
Commissioning. Faults and warnings mapping. Misprints corrections.
The equipment and technical documentation are periodically updated. Power Electronics reserves the right to modify all or part of the
contents of this manual without previous notice. To consult the most updated information of this product, you may access our website
www.power-electronics.com, where the latest version of this manual can be downloaded. The reproduction or distribution of the present
manual is strictly forbidden, unless express authorization from Power Electronics.

SD750
POWER ELECTRONICS
4
TABLE OF CONTENTS
TABLE OF CONTENTS
ABOUT THIS MANUAL ...............................................................................................................................2
SAFETY SYMBOLS.....................................................................................................................................5
SAFETY INSTRUCTIONS............................................................................................................................6
INTRODUCTION.....................................................................................................................................7
Profibus board specifications................................................................................................................8
LED Indicator........................................................................................................................................9
CONNECTION TO THE DRIVE............................................................................................................10
Connectors Description......................................................................................................................11
Connection Scheme...........................................................................................................................11
COMMISSIONING ................................................................................................................................12
Parameters setting .............................................................................................................................15
Modbus Addresses.............................................................................................................................18
FAULTS AND WARNINGS MAPPING.................................................................................................20
Description of Fault List......................................................................................................................20
Troubleshooting..................................................................................................................................20
List of Warning Messages..................................................................................................................20

POWER ELECTRONICS
SD750
SAFETY SYMBOLS
5
EN
SAFETY SYMBOLS
Always follow safety instructions to prevent accidents and potential hazards from occurring.
In this manual, safety messages are classified as follows:
Other symbols used in this manual for safety messages are the following:
WARNING
Identifies potentially hazardous situations where dangerous voltage may be
present, which if not avoided, could result in minor personal injury, serious
injury or death.
Be extremely careful and follow the instructions to avoid the risk of electrical
shocks.
CAUTION
Identifies potentially hazardous situations, which if not avoided, could result
in product damage, or minor or moderate personal injury.
Read the message and follow the instructions carefully.
NOTICE
Identifies important measures to take in order to prevent damage equipment
and warranty lost, as well as encouraging good use and environmental
practices.
Hot surface. Be careful and follow the instructions to avoid burns and personal injuries.
Risk of fire. Be careful and follow the instructions to prevent causing an unintentional fire.
Caution, risk of electric shock. Energy storage timed discharge. Wait for the indicated
time to avoid electrical hazards.
Caution, risk of hearing damage. Wear hearing protection.

SD750
POWER ELECTRONICS
6
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
IMPORTANT!
Read carefully this manual to maximize the performance of the product and to ensure its safe installation
and use.
In order to appropriately use the drive, please, follow all instructions described in the Hardware and
Installation Manual which refer to transportation, installation, electrical connection and commissioning of
the equipment.
For maintenance operations, follow the instructions from the Maintenance Manual.
Power Electronics accepts no responsibility for any damages resulting from incorrect use of equipment.
CAUTION
Read carefully the Hardware and Installation Manual, the Maintenance Manual and all documentation
related to the drive to guarantee its safe use and avoid the risk of personal injuries and damages to the
equipment.
Ensure compliance with local and national regulations of the installation site.

POWER ELECTRONICS
SD750
INTRODUCTION
7
EN
INTRODUCTION
SD750 drives are compatible with several optional boards:
•Communication boards (Ethernet/IP, Profinet, CANopen, Profibus…).
•Encoder board.
•Digital and analog I/O expansion boards.
•Optical fiber board
…among others. Up to three optional boards can be connected, maximum two of the same type.
This manual focuses on the optional Profibus expansion board. This board allows the equipment to
be integrated into Profibus communication network in a comfortable and simple way.
It has been designed to provide information about its operational status at any time.
Below is the front of the Profibus expansion board:
1

SD750
POWER ELECTRONICS
8
INTRODUCTION
Profibus board specifications
The Profibus expansion board specifications are detailed below:
Interface
•Profibus connector - DP D-SUB 9 pins.
Interface Profibus-DP
• Profibus - DP interface.
• Transmission speed auto-detected up to 12Mb.
• Diagnostic data length of 13 Bytes (maximum).
• Data length for 176 Byte Configuration (maximum).
• Configuration data length of 8 Bytes (maximum).
• Polling length of 120 Bytes (maximum).
• GSD file PE_SD750.GSD.
GSD File
The GSD file contains information about the Profibus communication module installed in the
equipment. When the Profibus network is configured, its software configuration requires a GSD file.
** To download the file, please contact Power Electronics.

POWER ELECTRONICS
SD750
INTRODUCTION
9
EN
LED Indicator
The profibus expansion board has one led indicator on the top of the board, which provides information
about the status. Note that the led is bi-color and will change its color and frequency according to the
situation.
Refer to the following table for the description of all the possible colors and frequencies of the led
indicator, as well as what they represent.
LED
COLOR /
FREQUENCY
DESCRIPTION
STATUS
Red, steady
Hardware failure or inability to install the protocol.
The board probably has to be repaired.
Red, slow flashing
The board cannot stablish communication with the
network controller or initialize the protocol.
Red, fast flashing
The board cannot stablish communication with the
SD750 central board.
Green, slow flashing
The system is operating correctly.1.
Green, fast flashing
Test mode. User has set the board to test mode.
1
When it is indicated that the system works correctly, it means that the communication of the Profibus board with the
integrated communication chip and with the central micro of the SD750 is correct. This does not mean, however, that
communication with the PLC is correct.

SD750
POWER ELECTRONICS
10
CONNECTION TO THE DRIVE
CONNECTION TO THE DRIVE
The Profibus expansion board connects directly, via the sixteen-pin ID connector on the back, to any of
the three expansion connectors on the central control board of the SD750 drive. The Profibus expansion
board allows to configure the SD750 as a slave to a PLC master using the Profibus industrial
communication protocol. This communication allows to exchange information between both devices by
configuring read and write variables.
CAUTION
Power Electronics’ SD750 drives operate with a high electric energy.
Make sure the power has been turned off and wait at least 10 minutes to ensure that the DC bus has
been discharged, make sure with a multimeter that there is no input, output or DC bus voltage before
installing the expansion board. Otherwise, there is a risk of personal injury or accident.
2

POWER ELECTRONICS
SD750
CONNECTION TO THE DRIVE
11
EN
Connectors Description
The Profibus connection is made using a standard 9-pin SUB-D connector according to the definition of
the EN 50170 standard. The wiring for the nine-pin connector is shown in the figure below:
Connection Scheme
The following image shows a detailed distribution of the components of the optional Profibus board:
On the Profibus board there are two connectors used to connect the board to the SD750 drive. In addition,
there is a connector (SUB-D / F 9-pin) that is used for connection to the Profibus network.

SD750
POWER ELECTRONICS
12
COMMISSIONING
COMMISSIONING
Follow the next steps to carry out the commissioning of the Profibus board:
1. Load the GSD file into the PLC master.
Once the GSD file is loaded, which allows us to introduce the SD750 device into a Profibus network,
the configuration from the PLC master will indicate to the system how many variables are going to
be shared, both writing variables (from the PLC to the SD750) and reading variables (from SD750
to PLC). Depending on the GSD loaded, the number of inputs and outputs and the possibility to
select the content of these variables will vary. There are five different types of configuration of inputs
and outputs:
Type 1
Inputs and Outputs
Type
5 inputs
Selectable
Read and write
5 outputs
Selectable
Read and write
Type 2
Inputs and Outputs
Type
10 inputs
Selectable
Read and write
10 outputs
Selectable
Read and write
Type 3
Inputs and Outputs
Type
20 inputs
Selectable
Read and write
20 outputs
Selectable
Read and write
3

POWER ELECTRONICS
SD750
COMMISSIONING
13
EN
Type 4
Inputs and
Outputs
Screen
Value
Input 1
Status Comms
3584
Input 2
Motor Speed (%)
2002
Input 3
Motor Current
2006
Input 4
Motor Power
2009
Input 5
Motor Torque
2007
Input 6
Motor Frequency
2004
Output 1
Host Start Control
3585
Output 2
Host Comms Control (Ref)
3569
Type 5
Inputs and
Outputs
Screen
Value
Input 1
Status Comms
3584
Input 2
Motor Speed (%)
2002
Input 3
Motor Current
2006
Input 4
Motor Power
2009
Input 5
Motor Torque
2007
Input 6
Motor Frequency
2004
Input 7
Motor Voltage
2005
Input 8
Motor phi cosine
2008
Input 9
DC bus Voltage
2034
Input 10
Speed Reference
2000
Input 11
Drive temperature
2038
Input 12
IGBT Temperature
2039
Input 13
Digital Input status
2080
Input 14
Output Relays status
2081
Input 15
AI 1 percentage (%)
2061
Input 16
AI 2 percentage (%)
2064
Output 1
Host Start Control
3585
Output 2
Host Comms Control (Ref)
3569
Output 3
Host Reset Control
3587
Output 4
Host Trip Control
3588

SD750
POWER ELECTRONICS
14
COMMISSIONING
2. Configure network parameters (G21, see section “Parameters setting”) so they match with the data
expected by the master.
3. Configure the Profibus slave on the PLC master (network configuration and number of shared
variables).
4. Configure the Profibus slave on the SD750 (network and Custom Modbus configuration associated
with the shared variables).
5. Connect the Profibus board and check its status and communication.
6. Verify communication is stablished. Configure action in case of communication faults with the
master.
7. Connect communication wiring and ensure communication with the SD750 is correct (G23.3).
Configure action in case of communication fault.
Once the slave has been configured correctly, both in the PLC and in the SD750 itself, the connection may
be made, and the configured variables will be shared.
The rest of the commissioning depends on the PLC, the program used, etc.

POWER ELECTRONICS
SD750
COMMISSIONING
15
EN
Parameters setting
The parameters that are activated once the board is connected are summarized below:
NOTICE
For more details about the Modbus address and value range, see the SD750 Drive
Programming and Software Manual.
Subgroup 20.2: Profibus
The G20.2 group corresponds to the Profibus configuration parameters:
NOTICE
These parameters must match the configuration of the PLC.
Subgroup 20.2.1: Master inputs
Shows the number of master inputs, which matches the configuration of the PLC.
Screen
Range
Function
Set on
RUN
G20.2.1.1-Protocol N
Master Inputs
0 to 20
Defines the number of inputs (N) for the Profibus protocol. The registers of the drive are mapped
onto these generic registers.
Note: This parameter is read only type.
YES
G20.2.1.2-Protocol N
Master Input 1 Add = 0
0 to 65535
These parameters store the information of the variables corresponding to the inputs of the PLC
master. These inputs are mapped into the consecutive registers of the Modbus configurable
mirrors.
The number of G20.2.1.x parameters shown depends on the number of inputs (N) defined in
G20.2.1.1.
YES
G20.2.1.3 Protocol N
Master Input 2 Add = 0
…
G20.2.1.21 Protocol N
Master Input 20 Add = 0
Subgroup 20.2.2: Master Outputs
Shows the number of master outputs, which matches the configuration of the PLC.
Screen
Range
Function
Set on
RUN
G20.2.2.1-Protocol N
Master Outputs
0 to 20
Defines the number of outputs (N) for the Profibus protocol. The registers of the drive are
mapped onto these generic registers.
Note: This parameter is read only type.
YES
G20.2.2.2-Protocol N
Master Output 1 Add = 0
0 to 65535
These parameters store the information of the variables corresponding to the outputs of the PLC
master. These outputs are mapped into the consecutive registers of the Modbus configurable
mirrors.
The number of G20.2.2.x parameters shown depends on the number of outputs (N) defined in
G20.2.2.1.
YES
G20.2.2.3-Protocol N
Master Output 2 Add = 0
…
G20.2.2.21-Protocol N
Master Output 20 Add = 0

SD750
POWER ELECTRONICS
16
COMMISSIONING
Other subgroups
Screen
Range
Function
Set on
RUN
G20.2.3 –Profibus node
address = 1
0 to 126
This parameter allows setting the slave ID address.
YES
G20.2.4 –Connector Fault
Mode = Fault
0 to 1
This parameter allows configuring the fault mode of the connector when communication with the
master is not allowed.
OPT.
FUNCTION
Fault
The drive will trigger fault F113: Lost PBUS c1 comms when communication is
not enabled.
Ignore
The fault is ignored, and it is not triggered.
Note: The status of the connector shows if the communication with another device is correct. In
case of incorrect communication, the user can select whether a fault appears or is ignored.
YES
G20.2.5 –Connector State
= Off
0 to 1
This parameter shows the state of the connector.
YES
NOTICE
From version 6.0.0 of the SD750 and 2.0.0 of the Coin Profibus, these variables will have a
default value belonging to the most probable configuration in the field.
It is only necessary to define those input and output variables that have been configured in
the master PLC.
Subgroup 20.6: Custom Modbus configuration
Screen
Range
Function
Set on
RUN
G20.6.1 Custom
modbus addr 1 = 0
0 to 65535
These parameters allow configuring 120 consecutive registers (4500 to 4619) variables from the
Modbus map as required. This is particularly useful when designing a SCADA, so that the client
can consult several registers in a single reading operation.
They are grouped as follows:
•Subgroup 20.6.1: Values 1 to 30
•Subgroup 20.6.2: Values 31 to 60
•Subgroup 20.6.3: Values 61 to 90
•Subgroup 20.6.4: Values 91 to 120
In parameters G20.6.x, user must enter the Modbus registers (Modbus address –40001) that will
be pointed to. Once configured, parameters G20.7.x can be used to read or write the value of
each register.
Example: Let us suppose we want to store the local speed reference (G3.3, Modbus 40053). We
must configure register 52 (40053 –1) in G20.6.1, at Custom modbus addr1.
Then, in G20.7.1, Custom modbus val 1 we will read the current value of the local speed reference.
To modify it, we must enter the new value and save changes.
Note: When reading or writing a variable, keep in mind the type of variable and its Modbus range
to ensure values are interpreted correctly.
YES
G20.6.2 Custom
modbus addr 2 = 0
…
G20.6.120 Custom
modbus addr 120 = 0

POWER ELECTRONICS
SD750
COMMISSIONING
17
EN
Subgroup 20.7: Custom Modbus values
Screen
Range
Function
Set on
RUN
G20.7.1 Custom
modbus val1 = 0
0 to 65535
These parameters can be used to read and write the values of the registers that were previously
configured in G20.6. They are grouped as follows:
•Subgroup 20.7.1: Values 1 to 30
•Subgroup 20.7.2: Values 31 to 60
•Subgroup 20.7.3: Values 61 to 90
•Subgroup 20.7.4: Values 91 to 120
Note: When reading or writing a variable, keep in mind the type of variable and its Modbus range
to ensure values are interpreted correctly.
YES
G20.7.2 Custom
modbus val2 = 0
…
G20.7.120 Custom
modbus val30 = 0
Subgroup 23.3: Communications
The G23.3 group allows to view the status of communication expansion boards.
Screen
Range
Function
Set on
RUN
G23.3.7 Profibus
board status = Off
Off
On
Shows the status of the Profibus board.
OPT.
FUNCTION
Off
The board is not connected.
On
The board is connected
NO
G23.3.8 Profibus
board test = No
No
Yes
Enables the LED fast blinking. This is useful to locate the board in case several boards of the
same type are connected.
Note: This parameter will only appear if a Profibus board has been connected.
NO
G23.3.9 Profibus
Com Error = Fault
Off
Warning
Fault
Allows defining the behavior of the drive in case communication with the Profibus board is lost.
OPT.
FUNCTION
Off
Drive will remain operating normally.
Warning
Warning “W37: Profibus expansion” expansion will be triggered.
Fault
Fault “F72: Expansion Profibus comm” will be triggered and the drive will
stop.
NO
NOTICE
The possible states of the parameters of the G23.3 group are detailed below:
•If G23.3.7 changes from Enabled to Disabled and G23.3.9 is Disabled nothing happens.
•If G23.3.7 changes from Enabled to Disabled and G23.3.9 indicates warning, W37 will appear:
Expansion Profibus. If the communication is restored again, this warning disappears.
•If G23.3.7 changes from Enabled to Disabled and G23.3.9 indicates fault, F72 will appear: Com
Ex Profibus.

SD750
POWER ELECTRONICS
18
COMMISSIONING
Modbus Addresses
Configuration parameters
The configuration parameters for the Profibus board are summarized below:
Parameter
Screen
Address
Range
Modbus Range
Access [1]
G20.2.1.2
to
G20.2.1.21
Protocol N Master Input 1 to 20
41031
to
41050
0 to 65535
0 to 65535
RO
G20.2.2.2
to
G20.2.2.21
Protocol N Master Output 1 to 20
43261
to
43280
0 to 65535
0 to 65535
RO
G20.2.3
Profibus node address
40661
0 to 126
0 to 126
RW
G20.2.4
Connector Fault Mode
40665
Fault
Ignore
0 to 1
RW
G20.2.5
Connector State
40666
Off
On
0 to 1
RO
G20.6.1
to
G20.6.120
Custom Modbus addresses 1 to 120
44601
to
44720
0 to 65535
0 to 65535
RW
G20.7.1
to
G20.7.120
Values of custom Modbus registers 1
to 120
44801
to
44920
0 to 65535
0 to 65535
RW
G23.3.7
Profibus board status = Off
41027
Off
On
0 to 1
RO
G23.3.8
Profibus board test = No
41028
No
Yes
0 to 1
RW
G23.3.9
Profibus Com Error = Fault
41029
Off
Warning
Fault
0 to 2
RW
[1] Access: RW: Read and write. RO: Read only.
Custom Modbus
Custom Modbus come by default as detailed in the tables below. For more information on Modbus
addresses, see the Software and Programming Manual for the SD750 drive.
Master inputs
Position
Parameter
Modbus
Address
Modbus Range
1
Status Comms
43585
Real Value = Modbus Value
2
Motor speed (%)
42003
Real Value = (Modbus Value / 100)
3
Motor current
42007
Real Value = (Modbus Value / 10)
4
Motor power
42010
Real Value = Modbus Value
5
Motor torque
42008
Real Value = (Modbus Value / 100)
6
Motor frequency
42005
Real Value = (Modbus Value / 10)
7
Motor voltage
42006
Real Value = Modbus Value
8
Motor phi cosine
42009
Real Value = (Modbus Value / 100)
9
DC bus voltage
42035
Real Value = Modbus Value
10
Speed reference
42001
Real Value = (Modbus Value / 100)
11
Drive temperature
42039
Real Value = Modbus Value
12
IGBT temperature
42040
Real Value = Modbus Value
13
L1-L2 supply voltage
42031
Real Value = Modbus Value
14
L2-L3 supply voltage
42032
Real Value = Modbus Value
15
AI1 percentage (%)
42062
Real Value = (Modbus Value / 100)
16
AI2 percentage (%)
42065
Real Value = (Modbus Value / 100)
