PR Lighting AQUA MARINE 580 BWS User manual

1
AQUA MARINE 580 BWS
PR-2596
The user manual contains important information about the safe installation and use of a projector. Please read
and followtheseinstructions carefullyandkeepthemanual inasafeplaceforfuture reference.

2
INDEX
1.
SAFETYANDWARNINGS…………………………………………………………………………………
3
2.
APPEARANCE………………………………………………………………………………………………
4
3.
INSTRUCTIONS……………………………………………………………………………………………
5
4.
INSTALLATION ……………………………………………………………………………………………
6
5.
SETUPANDCONFIGURATION……………………………………………………………………………
9
6.
OPERATIONMENU…………………………………………………………………………………………
11
7.
DMXPROTOCOL……………………………………………………………………………………………
16
8.
SIGNSONTHETOUCHSCREEN…………………………………………………………………………
20
9.
ERRORMESSAGES………………………………………………………………………………………
21
10.
TECHNICALDATA…………………………………………………………………………………………
22
11.
CIRCUITDIAGRAMANDPCBCONNECTIONS…………………………………………………………
26
12.
COMPONENTORDERCODES……………………………………………………………………………
29
ACCESSORIES
The followingitems are supplied withthe projector and pleasecheck:
Name
Quantity
Unit
Remark
Gclamps
2
Pcs
XLRconnector
1
Set
Male andfemale
Safetycord
1
Pc
User manual
1
Pc
Ω clamps
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.
Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the course of product
improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence arising from
them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the unit.
Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
Note:Fortheproductsmadeus thewarrantyforthewholeproductisoneyearstartingfromthedeliverydatebutthelightsourceisnotwithinthewarranty.

3
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
thesafety informationhereinafter!
Thefollowingsafetysignsareused intheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there istransportation damage before using the projector. Should there be any
damagecausedbytransportation,consultyourdealeranddonotuse it.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the projector
ashe/shelikes.
●Pleasebe noted that thedamagecausedbychangingtheprojectoratwillis not warranted.
●Do nothesitate to contact the dealer or the manufacturer if anyquestionsoradvice.
● The projector isforindoorandoutdooruse,IP66.
● Itcanbeused inhumidanddustyareas.And itcancontact water and othernon-corrosiveliquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictly followtheproceduresinthe manual
●No repairablepartsintheprojectorand do notopencovers for maintenance by yourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned..
●Do notconnectthisdevice toanytypeofdimmer pack.
●After lamp switchedon,theminimumdistancebetweentheprojectorandilluminated surfaceis18m.
●lensandotheropticalpartsshallbereplacedimmediatelyifthey havedeformedorbeendamaged,otherwise the
lightoutputwillbecompromised.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector whilecovers(housing)areoff.
●Keepthelamp cleanand do not touch itwithbare hands.
●Whileoperatingit, wearprotective items.
●Anyelectrical connectionmustbecarriedoutbyaqualified person.
●Beforeinstallation, please confirmthe voltage suppliedmatcheswhatisrequired fortheprojector.
●Eachprojector mustbeproperlyearthed and installed asper related electricalstandards.
●Do not use power cord withitsinsulatordamaged andconnectthe power cordwithothercables.
●If the projector is not used or under cleaning,, please hold the plug and unplugit. Do not unplug it forcefully
or bypullingthepower cable.
●Allpower cords mustconformtorelatedsafetyandregulations.
●Whilebeingoperated,theprojectorshouldnotbeunderrainsorinhumidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electricalparts’ life willbe shortened .

4
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety
cordsuppliedthroughthesafetycordholesforsafetysupport.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
powermains.
●After runningfor30minutes,thetemperatureofthehousingoftheprojectoris45℃.Afterstable operation,
itstemperatureis75℃.
●Whilethelampisstrickenforthefirsttime,therewillbesmoke andstrangesmell.It’s normal and does not
meantheprojectorhas some defects.
●Do notmount the projectordirectlyoninflammablesurface.
●Do notprojectthebeamstraightly oncombustibleitems andtheminimumdistancebetweentheprojector
and illuminateditemsis18m.
●Aprojector should be installed withgood ventilation and the minimum distance between the projector and
wallsis50cm.Atthesame time,pleaseensurethefansandairinletsandoutletsareworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restart theprojector.
The accumulationof oil, smoke and dust onthe lens will compromise the light output. Cleaning a projector is verynecessary to
ensurea reliable use of it. Cooling fans need to be cleaned every15days. Internallens, reflectorand hot mirror need to be cleaned
periodicallyto optimizelightoutput.
Cleaning frequencyis to be decided byoperations and its environment. Use soft cloth and normaldetergent forglass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean
and do not touch optical parts withbare hands.
Special note:
It’s normal phenomena that there will be mild water mist on the lens while the waterproof product is in use.
●Beforeanymaintenanceandcleaning,please ensuretheprojectisoffthepower.
●Onlyqualifiedpersonisallowedtodo maintenance.
●During maintenanceandbeforemaintenance, theprojector mustbeoff power.
●Do notusealcoholor otherorganicsolvent to cleanthe housingto avoid damage.
●Do not use any solventwithchemicalelementsto cleancolor filtersor hot mirror.
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and
focuslensbelubricated every2 months. Highquality and hightemperaturelubricant/greaseisadvised..
To avoid the sunlight or other light beam penetrates through the front lens into the head, which results in high
temperature internally and damaging the projector accordingly. Before power-ff, please use the Tilt channel to
lettheheadfacedown.

5
●TROUBLESHOOTING
PROBLEM
ACTION
Theprojectordoesn’t switch on
Checkthefuseonthepower socket.
Checkthelamp.
The lamp ison but the projector doesn’t respond
to thecontroller
Makesurethatthe fixture’s start address is right
Replace orrepair theXLRsignalcable.
The projector functions intermittently
Makesurethefanisworkingwellorfansandtheirshieldsarenotblocked
Beamappears dim, Low in brightness
Make sure the lampis withinitslifespan
Removedustor greasefromthelenses.
The projectimageappearstohaveahalo
Carefullycleanthelamp,opticallensesandothercomponents.
HeavilyDefectiveBeam
Checkif lensareingood condition(not cracked)
Cleandustorgreaseonthelens.
3. APPEARANCE
RearPanelof theBase
FrontPanelof theBase
1
2
3
4
5
6
7
8
9
10
11
1 2 3 4 5 6 7
1 2 3 4
1.FrontLens
2.Tilt Lock
3.ChamberCover
4.FanCover
5.Pan Lock
6.Base
7.Pan Latch
8.LowerHeadCover
9.TiltHandle
10.UpperHeadCover
11.FrontLensCover
1.Waterproof powersocket
2.Waterprooffuseholder
3.Waterproof5-pinXLRSocket(Male)
4.Waterproof 5-pinXLRSocket(Female)
5.Waterproof Ethernet Port
6.Waterproof DMXWirelessReceiver
7.Gore-Texmembrane
1.Return Key
2.UPKey
3.DownKey
4.EnterKey

6
4. INSTALLATION
●RIGGING
Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a
projectorwithpower while itis locked.
Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with2 retainersattached
to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the
underside of the base as shown above) To pass the SAFETYCORD throughthe HOLES for safety! Always ensure that the
projector is firmlyanchoredto avoidvibrationand slippingwhilstfunctioning. Always ensurethat the structurethat you are going
to mounttheprojector toissecureand strongenough tosupportthe weightofaXR1000 Framing.
WARNING:
●TheprojectorMUSTbeliftedorcarried by the HANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●POWERCONNECTION
Connectthepower cordas follows:
L(live) =brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector beconnected withpowerseparatelyso that theymaybeindividuallyswitchedonand off.
Clamp
SafetyCord
Handle
Warming
Pleaserunthesafetycordthrough
thetwo safetycordholes.

7
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordancewiththestandardsconcerned.
●If any questionsaboutthe electricalinstallation,donotcontinuebutconsult aqualifiedelectrician.
●DMXCONTROLCONNECTION:
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector)or5pinXLRplugsandsockets.TheXLR'sareconnected asshowninthefigureabove.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected inanywayother than mentioned in the above figure.TheXR330BWSacceptsdigitalcontrolsignalsinprotocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshowninthefigurebelow.
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electricalnoisefromdisturbingandcorruptingtheDMXcontrolsignals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is thenplugged
into theoutputsocketonthe last projector inthe chain.Theconnectionsare illustratedbelow.
DMX OUT
DMX512
Controller
DMX OUTDMX IN DMX
TERMINATOR
DMX IN

8
● ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
Please hold the projector well before adjustment/installation/replacement of a lamp. As shown in figure1, remove fan cover of the
headandheatsink.
Removal/Installationoflampasshowninfigure2
Adjustthelampasshown infigure3
Beforetheremovalofthelamp, unplugthe lamp wires.And plugthe lamp wiresafteranewoneisin.
●Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to impair
the beamoutput. There is a protruding metal wire in the lamp, while installation do not damage it. Hold the lamp
body well before its removal. It’s forbidden to use force on the ceramic stand, otherwise it will loosen or fall off.
●Pleaseread "Instructions"enclosed withthe lamp
●While adjustingthe lamp, it is forbidden to carryout the functions not associated withits adjustment.
Figure1:loosen4screwsofthefancoveroftheheadbeforeremovingit.Thenloosenthescrewsofheatsinkandremoveit
andthe fan.
Figure2:Unplugthelampwires,pushtheupperclipping platetowardthespringwithforce,butpushthelamp inthe
oppositedirectiontillitisofftheplate, thentakethelampoutobliquely.The same appliestoitsinstallation.
Figure 3:Afterthereplacementofthelamp, pleaseensurefirst thelampisclippedwell beforeplugginglampwires.Turnthe
lamp on and adjust the lamp’s position to the middle. After that, install the heat sink, fan and fancover.
The proceduresforthereplacementandadjustmentofthelamp:
1. After theprojectorispoweredon,disablethefollowingfunctioninthemenu: services-factory mode-lampfansensor, thenshut
itfrompower
2. Loosenthe4screws ofthefancover and removeit.
3. Loosen4 screwsofthefanplate, remove the fan and the clump weight,loosen10screwsof the heatsinkand remove it.
4. Pushthe upperclippingplateofthe lamp towardsthespring,andatthesametime pusthelamptowardstheoppositetillitisoff
theplateand remove itobliquely,
5. The installationofthelampisthe sameas itsremoval
6. Checkifthe lamp wiresareplugged well,thenturnonthelampforadjustment
7. After theadjustmentofthelamp, activatethefollowing functioninthe menu:services-factory mode-lampfansensor.Thenshut
itfromthepower
8. Checkifthe seals are good or not. If not,replace them with goodones. If no, installthe heat sink, fanandfancover in the
oppositesequencesastheremoval.
9. After installation,powerit on.Theprojectorwillexecute thetotalreset.Afterthat, the projectorcanbe used normally.
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2
示例2：拔下灯泡线,然后
将上压片向拉簧方向用力
推，灯泡往相反的方向推，
待灯泡脱离上压片时倾斜
取出，装灯泡同理.
示例1：松开后盖4颗螺丝，
取下后盖，再松开散热器
螺丝，取下散热器和尾部
风机
示例3：换泡完毕，先确定灯
泡是否卡稳，再插上灯泡线，
亮泡，调整灯泡居中，完毕
锁上散热器，风机以及后盖.
灯泡上压片
灯泡压片

9
●GOBOREPLACEMENT
5. SETUPANDCONFIGURATION
●FRONTPANELOPERATION
To browse through or change the projector ’s settings, press ENTER key for more than 3s(press ENTER key after power on) to
unlock the screen , then press UP/DOWN key to enter the projector ’s function menus. Each main menu has its sub-menus. And
eachmenustandsforspecialfunction.Forthedetails,pleaseseethefollowing6th point ”Operation Menu”.:
1. At the page to set the fixture’s functions, press UP or DOWN keytoselectthe functionsdesired.
2. While menu operations, the FUNC key to escape, and ENTER key is used to confirm. Press ENTER key to save the changes
or enterinto the sub menus. Press UP or DOWN keytochangethenumbers(minusorplus).
Press FUNC keyto go to the uppler menu. If no keyis pushed,the system will go backto initial statusautomatically.
●DMXSTARTADDRESS
Each projector must be given aDMXstart address so that the correctprojectorresponds to the correct controlsignals. This DMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3DMX modes. There are standard mode ,short mode and extended mode. For example standard mode
has 31 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 032, No. 3 projector’s address 063,No. 4
projector’s address 094, and soon.
Switch on the Projector . Press ENTER key more than 3 seconds to unlock panel, then press UP or DOWN key to enter into the
fixture’s operation menus.
SelectDMXAddressiconandpressENTER keyonthe displayandselect DMXaddressatthe2nd level menufortheaddresssetting.
Rotating gobo wheel
Rotator
Gobo
Gobo spring
Rotator
Replacement of the Gobos:
Open the chamber cover after loosening 4 screws.
Select the rotator for replacement of gobo. Push
the rotator at the opposite side of its gear till it is
off the holder of the rotating gobo wheel. Remove
the rotator gently . After replacement of the gobo,
place the rotator into the wheel and ensure it is in
the right position and not loose.
DANGER!
Beforereplacementofgobos,the projectormustbeoffthepower.

10
Press UP or DOWN keyfortheDMX addressdesired.
Press ENTER keyto confirm.
Pressthe FUNC keytogoback tothe upper levelmenu.
.
●DMXWIRELESSCONTROL
Theprojector has wirelesscontrolfunctionwith wirelessreceiver moduleandantenna forremotecontrol.
Thesetup ofitisbelow:
1. Press ENTER for more than 3s to unlock the control panel, then press UP or DOWN keyto enter into the operation
menu and select “Config Settings”.
2. Select “Wireless Only” from the menu of “Signal Select”.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it,
Press “Enter” for the menu of Un-link Wireless under the upper level menu of Config Settigns , thenthe fixture is unlinked
with thewirelesstransmitter.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR controlcable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation mode can
be setaccordingly.
After Poweredon, the groupwillruninMaster/Slave Mode
DMX OUT
MASTER SLAVE SLAVE
DMX512
Controller
DMX OUTDMX IN DMX
TERMINATOR
DMX IN

11
6. OPERATIONMENU
1st
LEVEL
2ndLEVEL
3rdLEVEL
4thLEVEL
5thLEVEL
Address
DMX Address
1-512
IP Address
DefaultIPAddress
2.X.X.X /10.X.X.X
CustomIPAddress
X.X.X.X
SubNetMask
X.X.X.X
ArtNet Universe
0-255
Reset
Total Reset
ReallyReset?
ConfirmorCancel
Pan&TiltReset
ReallyReset?
ConfirmorCancel
ColourSystemReset
ReallyReset?
ConfirmorCancel
GoboReset
ReallyReset?
ConfirmorCancel
Dimmer/Shutterreset
ReallyReset?
ConfirmorCancel
Zo.Fo.Fr. Pr.Reset
ReallyReset?
ConfirmorCancel
Config
Settings
DMX ChannelMode
Short Mode
StandardMode
ExtendedMode
ViewSelectedMode
Ch.01 Strobe
Ch.02 Dimmer
......
Ch.23 ControlFunction
LampControl
LampControl
OFF/ ON
On ByPower On
OFF/ ON
ControlByDMX
OFF/ ON
EcoPower
OFF/ ON
SignalSelect
XLR Only
XLR First
WirelessOnly
WirelessFirst

12
WirelessIn/XLR Out
ARTNETOnly
ARTNETIn/XLR Out
LossofDMX
Normaltimeout
Hold LastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
InvertOFF
Invert ON
InvertAuto
LanguageSetting
English\Chinese
TemperatureUnit
CelsiusDegree
Fahrenheit Degree
Un-LinkWireless
ReallyUn-Link?
ConfirmorCancel
Defaults
RestoreDefaults?
ConfirmorCancel
Option
Settings
Pan/TiltSettings
Pan DMX Invert
OFF/ ON
TiltDMXInvert
OFF/ ON
Pan TiltSwap
OFF/ ON
XYFeedback
OFF/ ON
Pan/Tiltmode
Speed/Time
Note:"Speed Mode" means
PanandTiltwillmovefrom
PointAtoPointBattheir
respective maximum
speeds."TimeMode" means
bothPan and Tilt willarrive
atdesignatedpointat the
sametime. It's advised Time
Modebeused iftheprojector
runscirclesorinoblique
lines.
Invert Settings
DimmerInvert
OFF/ ON

13
ZoomInvert
OFF/ ON
CYM Invert
OFF/ ON
Defaults
RestoreDefaults?
ConfirmorCancel
Information
ViewDMXValues
Channel Value
Strobe XXX
Dimmer XXX
DimmerFine XXX
CYM Macro XXX
Cyan XXX
Yellow XXX
Magenta XXX
CTO XXX
Color Wheel XXX
Color WheelFine XXX
Fixed Gobo WheelXXX
Rot.Gobo Wheel XXX
Rot.GoboRotationXXX
Rot.GoboRotationF.XXX
Effect XXX
EffectRotation XXX
Prism1 XXX
Prism1Rotation XXX
Prism2 XXX
Prism2Rotation XXX
Frost XXX
Focus XXX
FocusFine XXX
Zoom XXX
ZoomFine XXX
Pan XXX
Pan Fine XXX
Tilt XXX
Tilt Fine XXX
Pan/TiltSpeed &Time XXX
Power/SpecialFun.XXX
LampHours
XXX H
ResetLampHours
Total Hours
××××H
Temperature
DisplayBoard=×××C
Panboard=×××C
Tiltboard=×××C
DriverBoard1=×××C
DriverBoard2=×××C
DriverBoard3=×××C
HeadSensor=×××C
SoftwareVersion
PCB Sys Boot
DisplayBoard xxx xxx
Panboard xxx xxx
Tiltboard xxx xxx
DriverBoard1 xxx xxx
DriverBoard2 xxx xxx
DriverBoard3 xxx xxx
ElectronicSN
XXXXXX
RDM DeviceLabel
AQUA580BWS
ANSIE1.20RDM
Fan Status
Fan Speed Status
LampFan1 xxx on/off

14
LampFan2 xxx on/off
StrobeFanxxx on/off
Gobo Fan xxx on/off
LampTFan xxx on/off
LampRFan2 xxxon/off
Head Fan xxx on/off
FanError
Fan Value
LampFan1 xxx
LampFan2 xxx
LampTFan xxx
LampRFan xxx
HeadFan1 xxx
HeadFan2 xxx
CYM Fan xxx
GoboFam xxx
BaseFan xxx
AccelerationSensor
X Axis: XXX
YAxis:XXX
ZAxis:XXX
Position:XXX
Service
ManualEffectControl
StrobeXXX
DimmerXXX
DimmerFineXXX
CYM Macro XXX
CyanXXX
CyanFineXXX
YellowXXX
YellowFine XXX
MagentaXXX
MagentaFineXXX
CTO XXX
CTOFineXXX
Color Wheel XXX
Color Wheel Fine XXX
Fixed GoboWheel XXX
Rot.GoboWheel1 XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1Rotation F.XXX
EffectWheel RotationXXX
EffectWheel RotationFine
XXX
Prism1 XXX
Prism1 RotationXXX
Prism2XXX
Prism2 RotationXXX
FocusXXX
FocusFineXXX
ZoomXXX
ZoomFineXXX
Pan XXX
Pan FineXXX
TileXXX
TiltFineXXX
Pan &TiltSpeed &Time
XXX
ControlFunction XXX
FactoryMode
XXX

15
…
Operation
Mode
DMX Mode
Change OperationMode?
ConfirmorCancel
MasterMode
PresetMemory
Change OperationMode?
ConfirmorCancel
UserMemory1
Change OperationMode?
ConfirmorCancel
UserMemory2
Change OperationMode?
ConfirmorCancel
Stand-AloneMode
PresetMemory
Change OperationMode?
ConfirmorCancel
UserMemory1
Change OperationMode?
ConfirmorCancel
UserMemory2
Change OperationMode?
ConfirmorCancel
StaticScene
Change OperationMode?
ConfirmorCancel
User
Memories
EditUserMemory
EditUserMemory1
/
EditUserMemory2
（1~200Scenes）
SceneXX
（1~200Scenes）
StrobeXXX
DimmerXXX
DimmerFineXXX
CYM MacroXXX
CyanXXX
CyanFineXXX
YellowXXX
YellowFine XXX
MagentaXXX
MagentaFineXXX
CTO XXX
CTOFineXXX
ColorWheelXXX
Color Wheel FineXXX
Fixed GoboWheel XXX
Rot.GoboWheel1 XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1Rotation F.XXX
EffectWheel RotationXXX
EffectWheel RotationFine
XXX
Prism1 XXX
Prism1RotationXXX
Prism2XXX
Prism2RotationXXX
FocusXXX
FocusFineXXX
ZoomXXX
ZoomFineXXX
Pan XXX
Pan FineXXX
TileXXX
TiltFineXXX
Pan &TiltSpeed &Time
XXX
ControlFun.
XXX
DelayTimeXXX
Delaytimeunit msec/s/m

16
LinktoStep XXX
EditStaticScene
StrobeXXX
DimmerXXX
DimmerFineXXX
CYM Macro XXX
CyanXXX
CyanFineXXX
YellowXXX
YellowFine XXX
MagentaXXX
MagentaFineXXX
CTO XXX
CTOFineXXX
Color Wheel XXX
Color Wheel Fine XXX
Fixed GoboWheel XXX
Rot.GoboWheel1 XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1Rotation F.XXX
EffectWheel RotationXXX
EffectWheel RotationFine
XXX
Prism1 XXX
Prism1 RotationXXX
Prism2XXX
Prism2 RotationXXX
FocusXXX
FocusFineXXX
ZoomXXX
ZoomFineXXX
Pan XXX
Pan FineXXX
TileXXX
TiltFineXXX
Pan &TiltSpeed &TimeXXX
ControlFunction
XXX
InitUser Memory
ResetUserMemory1
ResetUserMemory?
ConfirmorCancel
ResetUserMemory2
ResetUserMemory?
ConfirmorCancel
ResetStaticScene
ResetStaticScene?
ConfirmorCancel
Notes: Lampfansensorisonlyused duringlamp adjustment
Open: the lamp is affected by the lamp fan. If the lamp fan fails, the lamp won’t be on.
Close: the lamp is not affected bythe lamp fan. Even if the lamp fan is not installed, the lamp will be on, but
PanandTiltarewithout force.
“Close” status is used only in emergency. If the lamp fan won’t run for long, it will cause harm to the
lamp.
After lamp adjustment, set the “lamp fan sensor as “Open” and activatetotalreset.
7. DMXPROTOCOL
Short
mode
Standard
mode
Extended
Mode
FUNCTION
DMX
DESCRIPTION
1
1
1
Strobe
000-010
Close
011-025
Open
026-225
Strobe speedfromslowto fast
226-246
Randomstrobefromslowto fast
247-255
Open

17
2
2
2
Dimmer
000-035
Close
036-255
Linear dimming（0-100%）
3
3
Dimmer Fine
000-255
Dimmer in16bit
3
4
4
CYMMacro
000-016
White
017-035
Yellow+Magenta=Red
036-054
Yellow
055-073
Yellow+Cyan=Green
074-092
Cyan
093-111
Cyan+ Magenta=purple
112-128
Magenta
129-255
CYMcolormixingfrom slowto fast
4
5
5
Cyan
000-255
Cyan(linear0~100%)
6
CyanFine
000-255
Cyan in16Bit
5
6
7
Yellow
000-255
Yellow(linear 0~100%)
8
YellowFine
000-255
Yellowin16Bit
6
7
9
Magenta
000-255
Magenta (linear0~100%)
10
Magenta Fine
000-255
Magenta in16Bit
7
8
11
CTO
000-005
No
006-024
Diffuser
025-255
Linear CTO
12
CTO Fine
000-255
CTOin 16bit
8
9
13
ColorWheel
000-063
Indexing(0-360degrees)
064-068
Color1(Red)
069-073
Color2( LightGreen)
074-078
Color3(Blue)
079-083
Color4(Cyan)
084-088
Color5(Yellow)
089-093
Color6(Magenta)
094-098
Color7(Orange)
099-103
Color8(Green)
104-108
Color9(DarkBlue)
109-113
Color10(UV)
114-118
Color11(LightYellow)
119-123
Color12(DarkYellow)
124-127
White
128-191
Rotation,Clockwisefromslowtofast
192-255
Rotation,Anti-clockwisefromfasttoslow
10
14
ColorWheelFine
0000-255
ColorWheelin16Bit
9
11
15
000-008
White
009-015
Gobo1
016-022
Gobo2
023-029
Gobo3
030-036
Gobo4
037-043
Gobo5

18
Fixed Gobo
Wheel
044-050
Gobo6
051-059
Gobo7
060-064
Gobo8
065-071
Gobo9
072-078
Gobo10
079-085
Gobo11
086-092
Gobo12
093-099
Gobo13
100-106
Gobo14
107-113
Gobo15
114-120
Gobo16
121-127
Gobo17
128-157
Clockwiserotationfromslowtofast
158-187
AntiClockwiserotation fromslowtofast
188-191
Shakeeffect1fromslowtofast
192-195
Shake effect 2fromslow tofast
196-199
Shakeeffect3fromslowtofast
200-203
Shake effect 4fromslow tofast
204-207
Shakeeffect5fromslowtofast
208-211
Shake effect 6fromslow tofast
212-215
Shakeeffect7fromslowtofast
216-219
Shake effect 8fromslow tofast
220-223
Shake effect 9fromslow tofast
224-227
Shakeeffect10fromslowtofast
228-231
Shakeeffect11fromslowtofast
232-235
Shakeeffect12fromslowtofast
236-239
Shake effect 3fromslow tofast
240-243
Shakeeffect14 fromslowtofast
244-247
Shakeeffect15fromslowtofast
248-251
Shakeeffect16fromslowtofast
252-255
Shakeeffect17fromslowtofast
10
12
16
RotatingGobo
Wheell
000-015
White
016-031
Gobo1
032-047
Gobo2
048-063
Gobo3
064-079
Gobo4
080-095
Gobo5
096-111
Gobo6
112-127
Gobo7
128-156
Rotation （clockwiseFromslowtoFast）
157-185
Reverse Rotation（anti-clockwise From slow to
Fast）
186-195
Shake ofGobo1 fromslowto fast
196-205
Shake ofGobo2 fromslowto fast

19
206-215
Shake ofGobo3 fromslowto fast
216-225
Shake ofGobo4 fromslowto fast
226-235
Shake ofGobo5 fromslowto fast
236-245
Shake ofGobo6 fromslowto fast
246-255
Shake ofGobo7 fromslowto fast
11
13
17
Gobo Rotation
000-128
GoboIndexing(0~540degrees)
129-188
Rotation （ClockwiseFromslowtoFast）
189-195
Stop
196-255
Rotation （Anti-ClockwiseFromslowtoFast）
14
18
GoboRotation
Fine
000-255
GoboRotation in16 Bit
12
15
19
EffectWheel
000-020
No
021-255
EffectWheelIn
13
16
20
EffectWheel
Rotation
000
No
001-127
Rotation （ClockwiseFromslowtoFast）
128-255
Rotation （Anti-ClockwiseFromslowtoFast）
14
17
21
Prism1
000-016
Open
017-127
Prism1
128-255
Prism2
15
18
22
Prism1 Rotation
000-127
PrismIndexing
128
Stop
129-191
Rotation(Clockwisefromslowtofast)
192
Stop
193-255
Rotation(Anti-Clockwisefromslowtofast)
16
19
23
Prism2
000-016
White
017-127
Prism3
128-255
Prism4
17
20
24
Prism2 Rotation
000-127
Prism2 Indexing
128
Stop
129-191
Rotation(Clockwisefromslowtofast)
192
Stop
193-255
Rotation(Anti-Clockwisefromslowtofast)
18
21
25
Frost
000-09
No
010-255
FrostIn
19
22
26
Focus
000-255
Linear Focus
23
27
Focus Fine
000-255
Focus in 16bitprecision
20
24
28
Zoom
000-255
Linear Zoom
25
29
ZoomFine
000-255
Zoom in16bit precision
21
26
30
Pan
000-255
Pan(0°~540°)
22
27
31
PanFine
000-255
Panin16 bit
23
28
32
Tilt
000-255
Tilt(0°~270°)
24
29
33
TiltFine
000-255
Tiltin16 bit
30
34
Pan &Tilt Speeds
000-255
Pan&TiltSpeedfromFastto Slow

20
25
31
35
Control
000-019
Reserved
Keep in the DMX range for more than 5S to activate the following
functions.Ifpower-off,thefollowingareinvalid.
020-024
Graphic DisplayOn
025-029
GraphicDisplayOff
030-034
Reserved
035-039
LampECOPower
040-044
LampFullPower
045-089
Reserved
090-094
Pan&TiltSpeedMode
095-099
Pan&TiltTimeMode
100-129
Reserved
130-139
Lamp On
140-149
Pan&TiltReset
150-159
ColorSystemReset
160-169
GoboWheel Reset
170-179
Dimmer/Shutter Reset
180-189
Zoom/Frost/Focus/Prism Reset
190-199
Reserved
200-209
TotalReset
210-229
Reserved
230-239
LampOff
240-255
Reserved
1. The projector can’t be turned on within 1 minute after the lamp-off.
2. Fanerrorcancauselamp-off.
3. "SpeedMode" meansPanandTilt willmovefromPoint AtoPointB attheirrespective maximumspeeds."Time Mode"
meansbothPanandTiltwillarriveatdesignatedpointatthesame time.It'sadvisedTimeModebeusediftheprojectorruns
circlesorinobliquelines.
8. SIGNSONTHETOUCHSCREEN
Lamp comtrol
OptionSettings
Chinese-English
Information
Errormessages
Service
Address
OperationMode
Reset
UserMemories
ConfigSettings
