PR Lighting XLED 590 User manual

2/18
INDEX
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
POWER SUPPLY – MAINS 4
CONTROL CONNECTIONS 4
DMX TERMINATOR 5
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
OPERATION MENU 7
DMX PROTOCOL 12
LED INDICATION 13
MAINTENANCE 13
KEEPING THE PROJECTOR CLEAN 13
TROUBLESHOOTING 13
TECHNICAL DATA 14
ELECTRICAL DIAGRAM 16
COMPONENT ORDER CODES 17
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without
notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of
product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence
arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
G clamps 2 Pcs
Ωclamps 2 Pcs Options
XLR cable 1 Pc 5-pin plug
Safety cord 1 Pc
This manual 1 Pc

7/18
OPERATION MENU
1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 6th LEVEL
PR LIGHTING
DMX Address
PR LIGHTING
DMX Address
XXX
PR LIGHTING
Reset
PR LIGHTING
Reset
Are You Sure
PR LIGHTING
DMX Mode
Standard 16
PR LIGHTING
DMX Mode
Extended 16
PR LIGHTING
DMX Mode
PR LIGHTING
DMX Mode
Short 8
PR LIGHTING
When DMX is Lost
Normal Time Out
PR LIGHTING
Config Settings
PR LIGHTING
Loss of DMX PR LIGHTING
When DMX is Lost
Hold Last Value
PR LIGHTING
Pan DMX Invert
OFF
PR LIGHTING
Pan DMX Invert PR LIGHTING
Pan DMX Invert
ON
PR LIGHTING
Tilt DMX Invert
OFF
PR LIGHTING
Tilt DMX Invert PR LIGHTING
Tilt DMX I vert
ON
PR LIGHTING
Pan Tilt Swap
OFF
PR LIGHTING
Pan Tilt wap PR LIGHTING
Pan Tilt Swap
ON
PR LIGHTING
Dimmer Invert
OFF
PR L GHTING
Dimmer Invert PR LIGHTING
Dimmer Invert
ON
PR LIGHTING
Defaults
Off
PR LIGHTING
Option Settings
PR LIGHTING
Defaults PR LIGHTING
Defaults
Restore Defaults
PR LIGHTING
Display
On Always
PR LIGHTING
Display Mode PR LIGHTING
Display
Off After Delay
www.carlosmendoza.com.mx

8/18
PR LIGHTING
Display Invert
Off
PR LIGHTING
Display Invert PR LIGHTING
Display Invert
On
PR LIGHTING
Display Dimming
PR LIGHTING
Disp Dim Level
X
PR LIGHTING
Display Options
PR LIGHTING
Display Contrast
PR LIGHTING
Display Contrast
XX
PR LIGHTING
LED Hours
PR LIGHTING
LED Hours =
******
PR LIGHTING
Power On Hours
PR LIGHTING
Power On Hours =
******
PR LIGHTING
Driver Board
PR LIGHTING
Driver Board =
XX℃
PR LIGHTING
Temperature PR LIGHTING
Head Sensor
PR LIGHTING
Head Sensor =
XX℃
PR LIGHTING
Software Version
PR LIGHTING
Display Board
PR LIGHTING
Display Board =
*.*.*
PR LIGHTING
View DMX Values
PR LIGHTING
DMX Channel
XXX= XXX
PR LIGHTING
Information
PR LIGHTING
Electronic SN
PR LIGHTING
Electronic SN =
************
PR LIGHTIN
Factory Se
OFF
PR LIGHTING
Calibration Menu
Red
PR LIGHTING
Cal bration Menu
Red
XX
PR LIGHTING
Calibration Menu
Green
PR LIGHTING
Cal bration Menu
Green
XX
PR LIGHTI G
Factory Setup
R LIGHTING
F ctory Setup
ON
(Or press buttons
UP 、DOWN and
ENTER to enter
Calibration Menu) Calibration Menu
Blue
PR LIGHTING
Cal bration Menu
Blue
XX
PR LIGHTING
Self Test
OFF
PR LIGHTING
Test Modes
PR LIGHTING
Self Test PR LIGHTING
Self Test
ON
www.carlosmendoza.com.mx

9/18
PR LIGHTING
Operation Mode =
DMX Operation
PR LIGHTING
Select Memory
User Memory 1
PR LIGHTING
Select Memory
User Memory 2
PR LIGHTING
Select Memory
Preset Memory 1
PR LIGHTING
Select Memory
Preset Memory 2
PR LIGHTING
Operation Mode =
Master Mode
PR LIGHTING
Select Memory
Preset Memory 3
PR LIGHTING
Select Memory
User Memory 1
PR LIGHTING
Select Memory
User Memory 2
PR LIGHTING
Select Memory
Preset Memory 1
PR LIGHTING
Select Memory
Preset Memory 2
PR LIGHTING
Operation Mode =
Slave Mode
PR LIGHTING
Select Memory
Preset Memory 3
PR LIGHTING
Operation Mode
PR LIGHTING
Operation Mode =
Static Scene
PR LIGHTING
Dimmer
PR LIGHTING
Dimmer
XXX
PR LIGHTING
Color Temp.
PR LIGHTING
Color Temp.
XXX
PR LIGHTING
RGB Macros
PR LIGHTING
RGB Macros
XXX
PR LIGHTING
Red
PR LIGHTING
Red
XXX
PR LIGHTING
Green
PR LIGHTING
Green
XXX
PR LIGHTING
Blue
PR LIGHTING
Blue
XXX
PR LIGHTING
Strobe
PR LIGHTING
Strobe
XXX
www.carlosmendoza.com.mx

10/18
PR LIGHTING
Pan Coarse
PR LIGHTING
Pan Coarse
XXX
PR LIGHTING
Pan Fine
PR LIGHTING
Pan Fine
XXX
PR LIGHTING
Tilt Coarse
PR LIGHTING
Tilt Coarse
XXX
PR LIGHTING
Tilt Fine
PR LIGHTING
Tilt Fine
XXX
PR LIGHTING
M-Speed
PR LIG TING
M Spee
X X
PR LIGHTING
Delay
R LIGHTING
Delay
X.XX Seconds
PR LIGHTING
User Memory
1
PR LIGHTING
Scene
XX
PR L GHTI G
L k To tep
PR LIGHTING
Link To Step
XX
PR LIGHTING
Dimmer
PR LIGHTING
Dimmer
XXX
PR LIGHTING
Color Temp.
PR LIGHTING
Color Temp.
XXX
PR LIGHTING
RGB Macros
PR LIGHTING
RGB Macros
XXX
PR LIGHTING
Red
PR LIGHTING
Red
XXX
PR LIGHTING
Green
PR LIGHTING
Green
XXX
PR LIGHTING
Blue
PR LIGHTING
Blue
XXX
PR LIGHTING
Strobe
PR LIGHTING
Strobe
XXX
PR LIGHTING
Pan Coarse
PR LIGHTING
Pan Coarse
XXX
PR LIGHTING
Pan Fine
PR LIGHTING
Pan Fine
XXX
PR LIGHTING
Tilt Coarse
PR LIGHTING
Tilt Coarse
XXX
PR LIGHTING
Tilt Fine
PR LIGHTING
Tilt Fine
XXX
PR LIGHTING
User Memories
PR LIGHTING
Edit U er Memory
PR LIGHTING
User Memory
2
PR LIGHTING
Scene
XX
PR LIGHTING
M-Speed
PR LIGHTING
M-Speed
XXX
www.carlosmendoza.com.mx

11/18
PR LIGHTING
Delay
PR LIGHTING
Delay
X.XX Seconds
PR LIGHTING
Link To Step
PR LIGHTING
Link To Step
XX
PR LIGHTING
Dimmer
PR LIGHTING
Dimmer
XXX
PR LIGHTING
Color Temp.
PR LIGHTING
Color Temp.
XXX
PR LIGHTING
RGB Macros
PR LIGHTING
RGB Macros
XXX
PR LIGHTING
Red
PR LIGHTING
Red
XXX
PR LIGHTING
Green
PR LIGHTING
Green
XXX
PR LIGHTING
Blue
PR LIGHTING
e
XXX
PR LIGHTING
Strobe
PR GHTING
Strobe
XXX
PR LIGHTIN
Pan Coa e
PR LIGHTING
Pan Coarse
XXX
R LIGHTING
Pa Fine
PR LIGHTING
Pan Fine
XXX
PR LIGHTING
Tilt Coarse
PR LIGHTING
Tilt Coarse
XXX
PR LIGHTING
Tilt Fine
PR LIGHTING
Tilt Fine
XXX
PR LIGHTING
Static Scene
PR LIGHTING
M-Speed
PR LIGHTING
M-Speed
XXX
PR LIGHTING
Reset User
Memory 1
PR LIGHTING
Reset User 1
Unlock 2 3 4
（Press buttons
UP、DOWN and
ENTER）
PR LIGHTING
Reset User
Memory 2
PR LIGHTING
Reset User 2
Unlock 2 3 4
PR LIGHTING
Init User Memory
PR LIGHTING
Reset
Static Scene
PR LIGHTING
Reset Static Scn
Unlock 2 3 4
www.carlosmendoza.com.mx

12/18
DMX PROTOCOL
Short
mode Standard mode Extended mode FUNCTION DMX DESCRIPTION
1 1 1 Dimmer 000-255 Dimming from dark to light
2 Dimmer 16 Bit 000-255 Dimmer in 16 Bit precision
2 3 Colour Temperature 000-255 Colour temperature adjustment
000-016 The projector functions and contr d
by RGB channels
017-024 White (Colour Temperature 100 0K)
025-032 White (Colour Temperat re 7200K)
033-040 White (Colour Temperature 5600K)
041-048 White (Colour Temperature 3200K)
049-056 Cyan
057-064 Yellow
065-072 Magenta
073-080 R d
081-088 G een
089 096 Blue
97-104 Aqua
105-112 Amber
113-120 Orange
121-128 Pink
3 4 Macro Channel
129-255 RGB Color Cycle
2 4 5 RED 000-255 Red, dimming from dark to light
6 RED 16Bit 000-255 Red in 16 Bit precision
3 5 7 GREEN 000-255 Green, dimming from dark to light
8 GREEN 16Bit 000-255 Green in 16 Bit precision
4 6 9 BLUE 000-255 Blue, dimming from dark to light
1 BLUE 16Bit 000-255 Blue in 16 Bit precision
000-009 No strobe
5 7 11 Strobe 010-255 Strobe speed from slow to fast
6 8 12 Pan 000-255 Pan rotation from 0° to 540°
9 13 Pan Fine (16Bit) 000-255 Pan rotation in 16 precision
7 10 14 Tilt 000-255 Tilt rotation from 0° to 270°
11 15 Tilt Fine (16Bit) 000-255 Tilt rotation in 16 precision
12 16 Pan & Tilt Speed 000-255 Pan &Tilt speed from fast to slow
000-047 Reserved
048-080 Reset
8 13 17 Control
081-255 Reserved
www.carlosmendoza.com.mx

13/18
LED INDICATION
On DMX signal OK
Off No DMX signal
Green
Flash DMX signal error
Yellow On
Setting the panel
Blue On Power
Red Slave mode or Running self test mode
Red/Green Green Master mode
MAINTENANCE
To prolong the life of the projector, some maintenance work has to be done to ensure the LED opt al system in good
condition. If the projector does not function, check the fuses on the power socket of the proje tor, they should only be
replaced by fuses of the same specification. Should these be damaged, call a qualified techn cian efore replacement.
The projector has thermal protection device that will switch off the projector in case of overheating.Should either of these
operate, check that the fans are not blocked, and if they are dirty, clean them before s itching on the projector again.
Check that the fans are operational, if not, call a qualified technician.
Any maintenance work should only be carried out by qualified technician .
KEEPING THE PROJECTOR CLEAN
To ensure the reliability of the projector, it should be kept cle n It ecommended that the fans should be cleaned
every 15 days. LED lens should also be regularly cleaned o ma ntain an optimum light output.
Cleaning frequency depends on the environment in wh ch the fixture operates: damp, smoke or particularly dirty
surroundings can cause greater accumulation of dirt o he nit’s optics. A soft cloth and typical glass cleaning products
should be used for cleaning. It is recommended to cl an the external optics at least once every 20 days.
Do not use any organic solvent, e.g. alcoh to clean housing of the apparatus.
TROUBLESHOOTING
PROBLEM ACTION
The projector doesn’t switch on ¾Check the fuse on the power socket.
The lamp comes on but the projector
doesn’t r spond to the controller
¾Make sure that the projector is correctly configurated.
¾Replace or repair the DMX cable.
The beam appears dim ¾Check that the optics is clean.
www.carlosmendoza.com.mx

14/18
TECHNICAL DATA
VOLTAGES:
100V/120V/200V/220V /230V/240V AC, 50/60Hz
POWER CONSUMPTION:
480W@220V
LED:
Type OSRAM Diamond Dragon
Power consumption 5W
Amount 90（30R＋30G＋30B）
Manufacturers Rated LED Life 50000 Hours
COLOURS:
RGB colour mixing
COLOUR TEMPERATURE CORRECTION:
Linearly colour temperature correction
DIMMER:
0-100% linearly adjustable
STROBE:
1~25 F.P.S
HEAD MOVEMENT:
Pan 540º, Tilt 270º with auto position correction
BEAMANGLE:
Projector beam angle 2 °
Options 10°, 35°
Note: Projector specifi ations are subject to change according to different projector beam angles.
CONTROL:
DMX512, 5 pin interfaces
RDM c ntrol protocol
8 channels in short mode, 13 channels in standard mode, and 17 channels in extended mode
Ma ter/Slave mode
Static scene mode
Stand-alone mode
Self-test mode
OTHER FUNCTIONS:
Adjustable Pan & Tilt speed
www.carlosmendoza.com.mx

+ -
PAN ENCODE
+ -
TILT ENCODE
AC INPUT
NL E
View side of no axletree
TILT
A
B
C
D
A
B
C
D
View side of no axletree
PAN
A
B
C
D
A
B
C
D
V
S
G
Fuse
VCC
GND
PWM
V
G
TXD
RXD
V
G
A-IN2
A-IN1
DMX
1 23
4 51
2
3
4 5
DMX-IN DMX-OUT
M1 M2 M3
J1 J2 J3
V S2 S1
VCC
GND
PWM
V
G
S
V
B
G
R R B
V+
POWER
GND
R
G
B
ANODE
POWER-SW
V
G
S2 S1
POWER PCB
LED DRIVE PCB
LED PCB
MAIN PCB
Box Fan Head Fan
GND
+24V
P 810 -006
T-Input
Head
www.carlosmendoza.com.mx

17/18
COMPONENT ORDER CODES
NAME PART NO. QUANTITY REMARK
PAN ROTATION MOTOR 1
TILT ROTATION MOTOR 030040052 1 23HS0015L
FAN IN BASE 030060060 1 DC24V, 0.14A
FAN IN LAMP HEAD 030060061 1 DC24V, 0.22A
LENS 070070006 90
LED 150020201 30 Red
LED 150020202 30 Green
LED 150020204 30 Dark blue
POWER STWITCH 190010104 1 AC250V,10A
POWER SUPPLY 192010130 1 DC24V/2A
LED CONTROL PCB 230020400 1
LED DRIVE PCB 230020402 1
FUSE 270041006 1 5X20,10A
PAN DRIVE BELT 290151256 1 HTD330-3M
TILT DRIVE BELT 290151223 1 HTD426-3M-8
www.carlosmendoza.com.mx

18/18
PR LIGHTING LTD.
PR New Hi-tech Science Park, 1582 Xingye Avenue
Nancun Panyu, Guangzhou, 511442 China
TEL: [phone]
FAX: [phone]
P/N: 320050005
Last Revision: 20090324
