Pr lighting Xr380 beam User manual

XR380（BEAM）

PR-2345

This product manual contains important information about the safe installation and use of this projector.

Please read and follow these instructions carefullyand keep thismanual in a safe place for future reference.

PR LIGHTING LTD.

http://www.pr-lighting.com

INDEX

SAFETYANDWARNINGS ………………………………………………………………………………………

INSTRUCTIONS……………………………………………………………………………………………………

APPEARANCE………………………………………………………………………………………………………

INSTALLATION……………………………………………………………………………………………………

SETUPANDCONFIGURATION……………………………………………………………………………………

OPERATIONMENU ………………………………………………………………………………………………

DMXPROTOCOL…………………………………………………………………………………………………

SIGNSONTHETOUCH SCREEN…………………………………………………………………………………

ERRORMESSAGE…………………………………………………………………………………………………

10.

TECHNICALDATA…………………………………………………………………………………………………

11.

CIRCUITDIAGRAM ………………………………………………………………………………………………

12.

COMPONENTORDERCODES……………………………………………………………………………………

ACCESSORIES

The following itemsare supplied with the projectorandpleasecheck:

Name

Quantity

Unit

Remark

Gclamps

Pcs

XLR connector

Pcs

Mate and female

Safetycord

Pcs

User manual

Pcs

Ω clamps

Pcs

Optional

Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.

Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the course of product

improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence arising from

them.

Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good

condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the unit.

Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.

Note: Forthe products made by Guangzhou PR lighting Ltd, the warranty forthe whole product is one yearstarting from

the delivery date butthelight sourceis notwithinthewarranty.

1. SAFETYANDWARNINGS

NOTE

Before a projector’s installation, power-on, operation and maintenance, please carefully read

thesafetyinformationhereinafter!

Thefollowingsafetysignsareused intheusermanual.

Warning

User

Manual

Electrical

shock

Goggles

Protective

Gloves

Flames

High

Temperature

●Whenunpacking , checkif there istransportationdamage before using the projector.Should there beany

damagecausedbytransportation,consultyourdealeranddonotuseit.

●The manufacture isnot responsible for losscaused by the user not following the manual or changing the projector

ashe/shelikes

●Pleasebe notedthatthe damage causedbychangingthe projectorat will is not warranted.

●Do nothesitate to contact the dealeror the manufacturer ifanyquestionsor advice.

●Theprojectoris for indoor useonly,IP20.

●Use only in drylocations. Keep this unit away fromrainand moisture, excessive heat, humidity and dust. Do not

allowcontact with water oranyother liquids.

●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while

beingoperated

●The projector is only intended for installation, operation and maintenance by qualified personnel. And the

operationmust strictlyfollowtheproceduresinthemanual

●No repairableparts intheprojector and do not opencovers for maintenance byyourself.

●Don’t look straightly into the light sources especially for epileptics,otherwiseeyes willbeburned.

●Do notconnect thisdevice to any typeofdimmer pack

●Afterlamp switched on, the minimum distance betweentheprojector and illuminated surface is 10m

●lens and other optical parts shall be replaced immediately if they have deformed or been damaged, otherwise

thelightoutput willbecompromised.

●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a

projector whilecovers(housing)areoff

●Keep thelampcleananddo nottouchitwithbare hands.

●Whileoperatingit, wear protective items.

●Anyelectricalconnectionmustbe carried outbyaqualifiedperson.

●Beforeinstallation,pleaseconfirm the voltage supplied matcheswhat isrequiredfor the projector

●Eachprojector must be properlyearthed and installed asper related electrical standards.

●Do notuse powercord with its insulator damaged andconnect thepower cord withothercables.

●Ifthe projector isnotused orundercleaning,, please hold theplug and unplugit. Do notunplug it forcefully

orbypullingthepowercable.

●Allpower cords mustconformtorelated safety and regulations

●Whilebeingoperated, theprojectorshouldnotbe underrainsor inhumidity.

●Do not switchon and off the projector constantly in very short intervals, otherwise the light source’s and other

electrical parts’ life will be shortened .

●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety

cord suppliedthroughthesafetycord holes forsafetysupport.

●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from

powermains.

●After running for 30minutes, the temperature of the housing of the projector is 45℃.After stable

operation, itstemperatureis60℃.

●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does

not meantheprojector has somedefects.

●Do notmounttheprojectordirectlyoninflammable surface.

●Do not project the beam straightly on combustible items and the minimum distance betweenthe projector

and illuminateditemsis10m.

●Aprojector should be installed with good ventilationand the minimumdistance betweenthe projectorand

wallsis50cm.Atthesame time,pleaseensurethefansandairinletsandoutletsare workable.

2. INSTRUCTIONS

●CLEANINGANDMAINTENANCE

If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the

projector has over-temperature protective device. Ifthe temperature is too high, the protective device will be triggered to shut the

projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,

restart theprojector.

The accumulationofoil, smoke and dust onthe lens willcompromise the light output. Cleaning a projector is verynecessaryto

ensure areliable use of it. Coolingfans need to be cleaned every15days.Internal lens, reflector and hot mirrorneed to be cleaned

periodically tooptimize light output.

Cleaningfrequency is to be decided by operationsand its environment. Use soft cloth and normaldetergent for glassfor cleaning

work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean

and do not touchoptical parts withbare hands.

●Before anymaintenanceandcleaning,pleaseensuretheprojectisoffthepower

●Onlyqualifiedpersonisallowed todo maintenance

●Duringmaintenanceandbefore maintenance, theprojector mustbeoff power.

●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens

whether itrunsor not

●Do notuse alcohol or otherorganicsolvent tocleanthe housingto avoid damage.

●Do notuseany solventwith chemicalelementstoclean color filtersor hot mirror.

●LUBRICATION

To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and

focuslensbe lubricated every2 months. High quality and high temperature lubricant/grease is advised..

1 2 3 4 5

●TROUBLESHOOTING

PROBLEM

ACTION

The projector doesn’t switch on

Checkthe fuseonthepower socket.

Checkthelamp.

Thelampison but the projector doesn’t respond

tothecontroller

Makesurethatthe fixture’s start address is right

Replaceor repair theXLRsignalcable.

Theprojector functionsintermittently

Makesurethefanisworkingwellorfansandtheirshieldsarenotblocked

Beamappears dim, Lowinbrightness

Make sure the lamp is within itslifespan

Removedustor grease from thelenses.

Theprojectimageappearsto havea halo

Carefullycleanthelamp,opticallensesandothercomponents.

HeavilyDefectiveBeam

Checkif lensareingood condition(not cracked)

Cleandustorgreaseonthe lens.

3. APPEARANCE

1. FrontLens

2. LensCover

3. HeadCover

4. TiltLock

5. Handle

6. ArmCover

7. Pan Lock

Whiletransportation, the head should be locked-Tilt Lock(4) and Pan Lock(7) should be at locking positions.

Beforetheuse of theprojector,unlock both.

RearPanelof theBase

1. PowerSwitch

2. PowerSocket

3. XLR Socket(Male)

4. XLR Socket(Female)

5. EthernetSocket

FrontPaneloftheBase

1. Display

2. KeyEscape

3. KeyUP

4. KeyDown

5. KeyEnter

4. INSTALLATION

●RIGGING

Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a

projectorwithpowerwhile it is locked

Warning:Pleaserun thesafetycordthrough thesafetycordholesforsafety.

Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to

each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of

the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.

Always ensurethat the structure that you are going to mount the projector is secure and is strong enough to supportthe weight of the

fixture.

WARNING:

●TheprojectorMUSTbeliftedor carriedbythe HANDLESinsteadofclamps.

●.For safety the safety cord should afford 10 times the Projector’s weight.

●POWERCONNECTION

Connect thepowercordasfollows:

L(live)=brown

E(earth) =yellow/green

N(neutral)=blue

Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each

projector be connected withpower separatelyso that theymaybeindividuallyswitched onandoff.

Note: If projectors are connected in series, please connect POWERIN port of the 1st projector with the Power Mains, then

connectitsPOWEROUTwithPOWERINof the2nd projector,andso ontillallfixturesare connected.Ifthe voltagesupplied

is 200V-240V, the maximum projectors connected is 8pcs, if it is 100V-120V, the maximum is 4pcs. The diameter of the cores

ofthewiresfor thePowerin/outcablesmustbeequalorbiggerthan2.5mm2.

●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in

accordancewiththe standardsconcerned.

Clamp

Safetycord

●Ifany questionsabout the electricalinstallation,donot continue butconsult aqualifiedelectrician.

●DMXCONTROLCONNECTION

Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with

each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the

projector)or5pinXLRplugsand sockets.TheXLR'sare connectedasshown inthe figureabove.

Note: care should be taken to ensure that none of the pins touch the metallic bodyof the plug or each other. XLR plugs and sockets

mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol

DMX512(1990).

Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second

fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX

terminatoras showninthe figurebelow.

●DMXTERMINATOR

In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents

electricalnoisefromdisturbingand corruptingtheDMX control signals.

The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is thenplugged

into theoutput socketon the last projector inthe chain.The connectionsare illustrated below.

TO CONTROLLER

DMX512 DMX IN DMX OUT

TO TERMINATER

DMX IN DMX OUT DMX IN DMX OUT

120

DMX TERMINATOR

CONNECTION

Connect a 120 (OHM) resistor

across pins 2 and 3 in an XLR plug

and insert into the DMX out socket

on the last unit in the chain. PIN 3

PIN 2

●ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP

LockTiltbefore lampadjustment/installation/replacement.As figure1 below,loosen4 screwsoflamp chamber cover.

figure1:loosen8 pcsoffast-fitscrews

Removal/installationofa lampasthefigure2below:

Figure2:lampadjustment

1. Useacrossscrewdriver to remove screws for fansonboth sidesofthe ampandopenthe fans.

2. usea crossscrewdriverto loosen atighteningscrewonitsone side.

3.useacrossscrewdriver toadjust 2 screws on its both sides to adjust a lamp’sposition.

Figure3:lampremoval

1.Loosenthetightening screwononesideofthelamp.

2. Unplugbothlamp wiresand pushthe lampupward toremove it obliquely.

示例1：松开8颗快速安装螺丝

1 2 3

Beforethe lamp’sremoval, unplugitsboth wires.Afteranewlamp installed,plugitsboth wires.

●Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to

impairthebeamoutput.While lamp’s installation, do not damagethe metalwirearound theburner.

●Pleaseread"Instructions "enclosed withthelamp

●Do operatetheprojector whileadjustingthelamp

●REPLACEMENTOFGOBOS

Replacementofarotatinggobo wheel: openthecove and select arotatortobereplaced.Pushtherotatortowardsthefrontlenstillit

slides fromthewheeland pullit out gently; After areplacementofagobo,place the rotatorinitsoriginal placeandensure it isinright

place and not loose.

DANGER!

Before replacement ofgobos,the projectormust beoffthe power.

5. SETUPANDCONFIGURATION

●FRONTPANELOPERATION

Rotating gob wheel

Rotator

Rotatoraccessory

Gobo

Gobo spring

Theprojectorconfigurationcanbe setconvenientlyviapushbuttonsandcolortouchscreen.

To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than

3s(Only powered by the battery, pressing the OK button) to unlock the screen , then press ►key to enter the projector ’s function

menus. Each main menu hasits sub-menus. And each menu stands for special function. For the details, please seethe following 6th

point ”Operation Menu”.:

1. At the page to set the fixture’s functions, press ◄,►,▲,▼keysor theirrespective icons to select the functions desired.

2. While at 2nd,3rd and 4th level of menus, the◄key is for ESCAPE, but ►key won’t work, and OK key is used for ENTER.

Press OK key to save the changes or enter into the sub menus. Press ▲or ▼keys to change the numbers(minus or plus).

Ortouch theoptionneeded forchange.

Shortcut keys: After the Function Menu is entered into, there are all options for the functions on the top of the screen. On the

rightthereare3 shortcutkeyslike ←,Lamp Control andEnglish/Chinese.

●DMX STARTADDRESS

Eachprojector mustbe givena DMXstart address so that the correctprojector respondsto the correct controlsignals. This DMXstart

address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the

controller. The projector has 3 DMX modes. There are standard mode, short mode and extended mode. For example standard mode

has 19channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 020, No. 3 projector’s address 039,No. 4

projector’s address 058,andsoon.

Switch on the Projector . Press OK key more than 3 seconds to unlock panel, then press ►key to enter into the fixture’s operation

menus.

Select DMX Address icon and press OK key or touch the icon directly on the display and select DMX address at the 2nd level menu

fortheaddresssetting.

Press▲or ▼keysortouch<、>displayedfor theDMX addressdesired.

PressOKkeytoconfirm.

Pressthe◄key togobackto the upper levelmenu.

●DMXWIRELESSCONTROL

The wirelesscontrol is optional. If fitted with wirelessDMX moduleand the antenna, the fixture can achieve remote control and do

ascommanded.

Thesetupofitisbelow:

1. Press OK for more than 3s to unlock the control panel, then press ►key to enter into the operation menu and select

“Config Settings”.

2. Select “Wireless First” or “Wireless Only” from the menu of “Signal Select”.

Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it,

Press “Enter” for the menu of Un-link Wirelessunder the upper level menu of ConfigSettigns,then the fixture is unlinked

with the wirelesstransmitter.

●STAND-ALONEMODE

Operate the projector without connecting with a controller, enable the master mode through the operation panel, the

projector will run in Stand-Alone mode automatically.

DMX address can be set at any number within 512.

●MASTER/SLAVEMODE

Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,

connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second

fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the

last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.

Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation modecan

besetaccordingly.

After Powered on, the group willrun in Master/SlaveMode

6. OPERATIONMENU

1stLEVEL

2ndLEVEL

3rdLEVEL

4thLEVEL

5thLEVEL

Address

DMXAddress

1-XXX

IP Address

DefaultIPAddress

2.X.X.X/10.X.X.X

CustomIP Address

X.X.X.X

Subnet Mask

X.X.X.X

ArtnetUniverse

0-255

sACN Universe

1-XXXX

Reset

TotalReset

ReallyReset?

Pan&TiltReset

ReallyReset?

ColourSystemReset

ReallyReset?

GoboReset

ReallyReset?

Dimmer/StrobeReset

ReallyReset?

Fo.Fr.Pr.Reset

ReallyReset?

ConfigSettings

DMXChannelMode

Short17CH

Standard19CH

Extended21CH

ViewSelected Mode

CH01

CH02

…

CHXXX

LampControl

OFF/ON

On ByPower On

OFF/ ON

Control By DMX

OFF/ ON

ECOPower

OFF/ ON

SignalSelect

XLROnly

XLRFirst

WirelessOnly

WirelessFirst

WirelessIn/XLROut

TO CONTROLLER

DMX512 DMX IN DMX OUT

TO TERMINATER

DMX IN DMX OUT DMX IN DMX OUT

Master

Slave

ArtNetOnly

ArtNetIn/XLROut

sACN Only

sACNIn/XLROut

LossofDMX

Normaltimeout

Hold LastValue

DisplayConfig

DisplayMode

OffAfterDelay

OnAlways

DisplayInvert

Invert OFF

Invert ON

InvertAuto

LanguageSetting

English

Chinese

TemperatureUnit

CelsiusDegree

Fahrenheit Degree

Un-LinkWireless

ReallyUn-Link?

ConfirmorCancel

FactoryDefaults

RestoreDefaults?

ConfirmorCancel

Option Settings

Pan/TiltSettings

PanDMX Invert

OFF/ ON

TiltDMXInvert

OFF/ ON

PanTiltSwap

OFF/ ON

XYFeedback

OFF/ ON

Pan/Tiltmode

Speed/Time

Note: "Speed Mode" means

PanandTilt will movefrom

PointAtoPointBat their

respective maximum

speeds."Time Mode" means

bothPanandTiltwillarrive

atdesignatedpointatthe

same time.It'sadvisedTime

Mode be usedifthe

projector runscircles or in

obliquelines.

Invert Settings

DimmerInvert

OFF/ ON

CYMInvert

OFF/ ON

ColorPositions

Step/Linear

Information

ViewDMX Values

Channel Value

Strobe ×××

……

LampHours

LampHours=××××H

Reset Lamp Hours

TotalHours

TotalHours=××××H

Temperature

DisplayBoard = ×××C

Pan&TiltBoard = ×××C

DriverBoard1 = ×××C

HeadSensor =×××C

SoftwareVersion

PCBBoard Sys Boot

DisplayBoard ××× ×××

Pan&TiltBoard××× ××

DriverBoard1 ××× ×××

ElectronicSN

××××××××××××

RDMDevice Label

XR380 Beam

ANSIE1.20RDM

FanStatus

Fan Speed RSpeed

LampFan ××× ×××

BasicFan ××× ×××

HeadFan1 ××× ××

HeadFan2 ××× ××

FanError

Fan ErrorCount

LampFan ×××

BasicFan ×××

HeadFan1 ×××

HeadFan2 ×××

AccelerationSensor

XAxis：×××

YAxis：×××

ZAxis：×××

Position：×××

Service

ManualEffectControl

Strobe ×××

Dimmer ×××

……

FactoryTest

×××

Operation

Mode

DMXMode

ChangeOperation Mode?

ConfirmorCancel

MasterMode

Preset Memory

ChangeOperation

Mode?

ConfirmorCancel

User Memory1

ChangeOperation

Mode?

ConfirmorCancel

User Memory2

ChangeOperation

Mode?

ConfirmorCancel

Stand-AloneMode

Preset Memory

ChangeOperation

Mode?

ConfirmorCancel

User Memory1

ChangeOperation

Mode?

ConfirmorCancel

User Memory2

ChangeOperation

Mode?

ConfirmorCancel

Static Scene

ChangeOperation Mode?

ConfirmorCancel

User

Memories

EditUserMemory

EditUserMemory1

/Edit UserMemory2

SceneXX

（1~200Scenes）

Strobe ×××

Dimmer ×××

……

FadeTime ×××

HoldTime ×××

DelayUnit ms/s/min

LinktoStep ×××

EditStaticScene

Strobe ×××

Dimmer ×××

……

Init User Memory

Reset User Memory1

Reset User Memory?

ConfirmorCancel

Reset User Memory2

Reset User Memory?

ConfirmorCancel

Reset StaticScene

Reset StaticScene?

ConfirmorCancel

7. DMXPROTOCOL

Short

mode

Standard

mode

Extended

Mode

FUNCTION

DMX

DESCRIPTION

Strobe

000-010

011-025

Open

026-225

Strobefromslowtofast

226-246

StrobeMacro(Strobe atrandom)

247-255

Open

Dimmer

000-035

036-255

LinearDimmer（0-100%）

DimmerFine

000-255

Dimmerin16bit

ColorWheel

000-006

White

007-010

White/Red

011-015

Red

016-019

Red/Blue

020-024

Blue

025-028

Blue/Yellow

029-033

Yellow

034-037

Yellow/ Green

038-042

Green

043-047

Green/ Magenta

047-051

Magenta

052-055

Magenta/ SkyBlue

056-060

SkyBlue

061-064

SkyBlue/ DeepRed

065-069

DeepRed

070-073

DeepRed/ DeepGreen

074-078

DeepGreen

079-082

DeepGreen / DeepYellow

083-087

DeepYellow

088-091

DeepYellow/ LightBlue

092-096

LightBlue

097-100

LightBlue/ Orange

101-105

Orange

106-109

Orange/ CTO

110-114

CTO

115-118

CTO/ UV

119-123

124-127

UV/White

128-191

ForwardRotation （Fromslow

toFast）

192-255

ReverseRotation（Fromslow

toFast）

Color wheel Fine

000-255

Colorwheelin 16bit

(Validwhile thewheel

positioningislinear)

Fixed Gobo

Wheel

000-008

White

009-015

Gobo1

016-022

Gobo2

023-029

Gobo3

030-036

Gobo4

037-043

Gobo5

044-050

Gobo6

051-057

Gobo7

058-064

Gobo8

065-071

Gobo9

072-078

Gobo10

079-085

Gobo11

086-092

Gobo12

093-099

Gobo13

100-106

Gobo14

107-113

Gobo15

114-120

Gobo16

121-127

White

128-159

ForwardRotation （Fromslow

toFast）

160-191

ReverseRotation （Fromslow

toFast）

192-195

Shake1（FromslowtoFast）

196-199

Shake2 （FromslowtoFast）

200-203

Shake3（FromslowtoFast）

204-207

Shake4（FromslowtoFast）

208-211

Shake5（FromslowtoFast）

212-215

Shake6（FromslowtoFast）

216-219

Shake7（FromslowtoFast）

220-223

Shake8（FromslowtoFast）

224-227

Shake9（FromslowtoFast）

228-231

Shake10（FromslowtoFast）

232-235

Shake11（Fromslowto Fast）

236-239

Shake12（FromslowtoFast）

240-243

Shake13（FromslowtoFast）

244-247

Shake14（FromslowtoFast）

248-251

Shake15（FromslowtoFast）

252-255

Shake16（FromslowtoFast）

000-007

White

008-017

Gobo1

018-027

Gobo2

028-037

Gobo3

038-047

Gobo4

048-057

Gobo5

Rotating Gobo

Wheel

058-067

Gobo6

068-077

Gobo7

078-087

Gobo8

088-097

Gobo9

098-107

Gobo10

108-117

Gobo11

118-127

Gobo12

128-143

ReverseRotation （Fromslow

toFast）

144-159

ForwardRotation （Fromslow

toFast）

160-167

Shake1（FromFasttoslow）

168-175

Shake2 （FromFasttoslow）

176-183

Shake3（FromFasttoslow）

184-191

Shake4（FromFasttoslow）

192-199

Shake5（FromFasttoslow）

200-207

Shake6（FromFasttoslow）

208-215

Shake7（FromFasttoslow）

216-223

Shake8（FromFasttoslow）

224-231

Shake9（FromFasttoslow）

232-239

Shake10（FromFasttoslow）

240-247

Shake11（FromFast toslow）

248-255

Shake12（FromFasttoslow）

Gobo Rotation

000-127

Gobo Indexing(0-540°)

128

Stop

129-188

ForwardRotation （Fromslow

toFast）

189-195

Stop

196-255

ReverseRotation （Fromslow

toFast）

Gobo Rotation

Fine

000-255

GoboRotation in16bit

EffectWheel

000-063

White

064-127

Prism

128-191

FrostFilter

192-255

LinearPrism

EffectWheel

Rotation

000-127

Indexing

128

Stop

129-188

Anti-Clockwise rotationfrom

slowtofast

189-195

Stop

196-255

Clockwiserotationfromslowto

fast

Prism

000-016

White

017-255

Prism

000-063

Stop

064-127

Anti-ClockwiseRotation

（Fromslowto Fast）

Prism Rotation

128-191

Stop

192-255

clockwise Rotation （From

slowto Fast）

Focus

000-255

LinearFocus

FocusFine

000-255

Focus in16bit precision

Pan

000-255

Pan(0°~540°)

PanFine

000-255

Panin16bitprecision

Tilt

000-255

Tilt(0°~270°)

TiltFine

000-255

Tilt in16 bitprecision

Pan&Tilt Speeds

000-255

Pan&TiltSpeed fromFastto

Slow

Control

000-019

Reserved

The following functionscanbeactivated unless

stayingonthe DMXfor5sand the setup won’t be

saved after poweroff.

020-024

GraphicdisplayOn

025-029

GraphicdisplayOff

030-034

Reserved

035-039

Lamp HalfPower

040-044

Lamp FullPower

045-089

Reserved

090-094

Pan/Tiltspeed mode

095-099

Pan/Tilttimemode

100-129

Reserved

130-139

Lamp On

140-149

Pan/Tiltreset

150-159

Coloursystemreset

160-169

Gobo wheelsreset

170-179

Dimmer/Shutterreset

180-189

Focus/prismreset

190-199

Reserved

200-209

Totalreset

210-229

Reserved

230-239

Lamp Off

240-255

Reserved

Note:

1. Thelampcan’tbe re-struck1minuteafter lamp-off;

2. Fanerrorcancauselamp-off.

3. "SpeedMode" meansPanand Tilt will movefromPointAto PointB at theirrespectivemaximum speeds."Time Mode" means

bothPanandTiltwillarrive atdesignatedpoint at the same time.It'sadvisedTimeModebeusediftheprojectorruns circlesorin

obliquelines.

8. SIGNSONTHETOUCHSCREEN

LampControl

OptionSettings

Chinese/English

Information

Error Messages

Service

Address

OperationMode

Reset

UserMemories

ConfigSettings

9. ERRORMESSAGE

Thesystemcandetectsomeerrorsduringthereset,if displayed,touch toviewtheerror.

Theerror messagesareasfollows:

Name

Type

Correction

Pan

Timeout/magnetSensor/Encoder

Checkif wiring,positioningpartsandmotorsarenormal

Tilt

Timeout/magnetSensor/Encoder
