Owner’s Manual

2Celebrity XL
SAFETY GUIDELINES
Please read and follow all instructions in this owners manual before attempting to operate your Scooter
for the first time. If there is anything in this manual you do not understand, or if you require additional
assistance for set-up, contact your authorised Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions, and
instructions in this owners manual. Using your Pride product safely also depends upon your own good
udgement and/or common sense, as well as that of your provider, caregiver, and/or healthcare
professional. Pride is not responsible for in uries and/or damage resulting from any persons failure to
follow the warnings, cautions, and instructions in this owners manual. Pride is not responsible for in uries
and/or damage resulting from any persons failure to exercise good udgement and/or common sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It is very
important for you to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAU ION! Failure to heed the cautions in this owners manual may result in damage to your
Scooter.
Copyright © 2001
Pride Mobility Products, Ltd.
INFMANU1216/REV D/MAY 2001

3
Celebrity XL
CONTENTS
I. INTRODUCTION ......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 6
III. SPECIFICATIONS ..................................................................................................................... 9
IV. DESCRIPTION .......................................................................................................................... 11
V. BATTERIES AND CHARGING ............................................................................................ 16
VI. OPERATION ............................................................................................................................... 20
VII. COMFORT ADJUSTMENTS................................................................................................ 22
VIII. DISASSEMBLY AND ASSEMBLY ..................................................................................... 2
IX. TROUBLESHOOTING ............................................................................................................ 28
X. CARE AND MAINTENANCE ................................................................................................ 29
XI. WARRANTY................................................................................................................................30

4Celebrity XL
I. INTRODUCTION
Welcome to Pride Mobility Products, Ltd. (Pride). Congratulations on the purchase of your new Pride Scooter.
Your Scooter design combines the most advanced state-of-the-art components with modern, attractive styling.
We are certain that the design features and trouble-free operation will add convenience to your daily living and
ensure complete satisfaction.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before
you attempt to operate your Scooter for the first time. These instructions were produced for your benefit.
Your understanding of these instructions is essential for the safe operation of your new Pride Scooter.
Pride is not liable for damage to property or personal injury arising out of the unsafe use of a Pride Scooter. Pride
is also not liable for any property damage or personal injury arising out of the failure of any person and or/user to
following the instructions and recommendations set forth in this manual or any other instructions or recommendations
contained in other Scooter related literature issued by Pride or contained on the Pride Scooter itself.
This owners manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual and the product you have purchased.
If you experience any problems with your Scooter that you are unable to solve, or if you do not feel capable of safely
following any of the instructions and/or recommendations contained in this manual, please contact your authorised
Pride provider for assistance.
Once you understand how to operate and take care of your Scooter, we are certain that it will give you years of trouble-
free service and enjoyment.
Information Exchange
We want to hear your questions, comments, and suggestions regarding this manual. We would also like to hear about the
safety and reliability of your new Pride Scooter and the service you received from your authorised Pride provider.
Please notify us of any change of address so we can keep you apprised of important information regarding safety, new
products, and new options that can increase your ability to use and enjoy your Pride Scooter. Please feel free to write us
at the address below:
Pride Mobility Products, Ltd.
Unit 106
Heyford Park Camp Road
Upper Heyford, Oxfordshire, OX2 HA

Celebrity XL
I. INTRODUCTION
Pride Owners Club
As a Pride product owner, you are invited to register your products warranty and enroll in the Pride Owners Club.
You may do so by filling out and returning your enclosed registration card or by visiting Prides web site at
www.pridemobility.com. As a registered member, each time you visit our site you will have access to the most
interactive and honest educational venue available today for people with mobility needs, their families, and friends.
From our home page, click on the button that reads Owners Club to enter a page dedicated to current and
potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,
product and funding information, and interactive message boards. Message boards invite you to speak with other
Pride customers as well as Pride representatives who are available to assist you with any questions or concerns
you may have. You will receive a free gift simply for registering with the Pride Owners Club.
My Authorised Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Quick Reference Information:
Scooter Model:________________________________________________________________________
Serial Number:__________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your warranty card or owners manual, write to us and we will be glad
to send you a new one immediately.

6Celebrity XL
SAFETY PRECAUTIONS
nDo not leave the key in the switch when your Celebrity XL is unattended.
nMake certain that the seat is locked into place and that the key is removed from the key switch before
getting on or off of your Celebrity XL, and make certain that the seat is in a locked position when you
are operating your Scooter.
nReduce your Celebrity XLs speed when you are operating it on uneven terrain, soft surfaces, and
around corners.
nProceed with extreme caution as you approach the downgrade of a ramp or incline and when driving
near a raised surface or unprotected ledges and drop offs (kerbs, porches, stairs, etc.).
nUse extreme caution when operating your Celebrity XL on busy streets and in parking lots or shopping
malls.
nKeep your hands on the tiller and your feet on the floorboard when you are operating your Celebrity
XL.
nMake certain that the tyres are properly inflated (30 psi).
nMake certain that your Celebrity XLs batteries are properly secured when you are transporting your
Scooter in another vehicle.
nDisconnect your Celebrity XLs batteries if you will not be using your Scooter for more than 48 hours.
nBattery posts, terminals and related accessories contain lead and lead compounds. Wash hands after
handling.
II. SAFETY
WARNING! Do not expose the electronics to any type of moisture (rain, snow, mist, or wash) at any
time. Such exposure can damage the electronics. Never attempt to ride a Scooter that has been
exposed to moisture until it has dried thoroughly.
Do not operate or store your Scooter where it may be exposed to inclement weather conditions
such as rain, snow, mist, and below-freezing temperatures (such as storage on an outside car/van
lift). Attempting to operate your Scooter in such conditions can damage the electronics and
potentially result in loss of control.
Do not operate your Scooter in icy or slippery conditions or on salted surfaces (i.e., walks or roads).
Such use may result in an accident, personal injury, or adversely affect the performance and/or
safety of your Scooter.
Always protect batteries from freezing temperatures and never charge a frozen battery. his will
damage the battery and may cause personal injury. Charging a battery in freezing conditions does
not prevent the battery from freezing.
As you begin to use your Celebrity XL during your daily activities, you will encounter situations that may require
some practice. Simply take your time as you operate your Scooter and you will soon be in full and confident
control as you maneuver through doorways, on and off of elevators, up and down ramps, and over moderate
terrain.
DOORS
nDetermine if the door opens toward or away from you.
nUse your hand to turn the knob or push the handle or push-bar.
nDrive your Celebrity XL slowly forward to push the door open; or drive your Scooter slowly backwards as
you pull the door open.

7
Celebrity XL
10.5%
(100-200 lbs.)
68 kg/
11-14 stone
8.7%
(250 lbs.)
113-136 kg/
18-21 stone
ELEVATORS
Modern elevators have a door-edge safety mechanism that, when pushed, reopens the elevator door(s).
nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the Scooter to reopen the door.
nUse care that pocketbooks, packages, or Celebrity XL accessories do not become caught in the elevator
doors.
RAMPS AND OTHER INCLINES
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
scooter access. Some ramps may have turning switchbacks that require you to have good cornering skills
on your Celebrity XL.
nTake wide swings with your Scooters front wheel(s) around any tight corners. If you do that, the rear
wheels will follow a wide arc and will not cut the corner short, bump into, or get hung up on any railing
corners.
nWhen driving down a ramp, keep your Celebrity XLs speed adjustment dial (see IV. Description) set
to the tortoise (slowest speed setting) to ensure a safely controlled descent.
nAvoid sudden stops and starts.
Other inclines may be natural or, if man-made, not designed specifically for Scooters. Figure 1 illustrates
your Celebrity XLs stability and its ability to climb grades under various weight loads and under controlled
testing conditions.
Pride conducted controlled incline testing with the Celebrity XLs seat in the highest position, adjusted backward
on the seat base to the farthest rearward position. These tests show that your Celebrity XLs ability to travel up
inclines is affected by your weight, your Scooters speed, your angle of approach to the incline, and your Scooter
setup.
Figure 1. Maximum Recommended Incline Angle
II. SAFETY
68 kg/
11-14 stone
(100 - 200 lbs)
10.5%
113 - 136 kg/
18 - 21 stone
(250 lbs)
8.7%

8Celebrity XL
Figure 2. Normal Driving Position
When you approach an incline, it is best to lean forward. See figures 2 and 3. This shifts the center of gravity of
you and your Celebrity XL toward the front of the Scooter for improved stability.
Figure 3. Increased Stability Driving Position
DRIVING SURFACES
Your Celebrity XL was designed to provide optimum stability under normal driving conditions  dry, level
surfaces composed of concrete or asphalt. However, Pride recognizes that there will be times when you will
operate your Scooter on surfaces other than concrete or asphalt. For that reason, we also designed your
Celebrity XL to perform admirably on packed soil, grass, and gravel.
nFeel free to use your Celebrity XL safely on lawns and in park areas.
nAvoid tall grass that can entangle the running gear.
nPacked soil, gravel, driveways, or roads will not present a problem for your Celebrity XL.
nAvoid loosely packed gravel and sand.
nIf you feel unsure about a driving surface, avoid that surface.
II. SAFETY
WARNING! Do not exceed the incline guidelines or any other specifications presented in this
manual.

9
Celebrity XL
Figure 4. Celebrity XL Specifications
III. SPECIFICATIONS
(25")
(19.5")
(18.5")
(24"- 28.5")
(43")
(54")
Turning Radius
(47.75" - 55")
(17"- 21")
(8"-12")
(25" - 28")
80˚
(1.5")
(1.75")
(20 cm - 30.5 cm)
63.5 cm - 71 cm
15 cm (6") 4 cm
43 cm - 53 cm
4.5 cm
121 cm - 140 cm
137 cm
109 cm
49.5 cm
47 cm
63.5 cm
61 cm - 72 cm

10 Celebrity XL
6SHFLILFDWLRQV
Length: 137 cm (54”)
Width: 63.5 cm(25”)
Tyres: Type: Pneumatic Front: 10 cmx 29 cm(4” x 11.5”)
Rear: 10 cmx 30 cm(4” x 12”)
Weight Capacity: 136 kg/21 stone (300 lbs.) maximum
BatteryType (not included): Two 12V, 32 amp hours (AH), U-1 type sealed lead-acid (SLA) or two 12V, 40 AH, SLA
Horsepower: 1.4 HP (Peak)
Charger: Onboard 5-amp charger
Speed (Max): Variable up to 6.4 km/hr (4 mph) (60%reverse)
MaximumGrade: Please refer to figure 1.
Range: Up to 32 - 40 km(20 - 25 miles) per charge with 32 AH batteries
Up to 40 - 48 km(25 - 30 miles) per charge with40 AHbatteries
Turning Radius: 109 cm(43” )
Body Colours: Candy Apple Red, Forest Green, or Viper Blue
Seating:
Style: High back with headrest and sliders
Dimensions: 49.5 cm(19.5”) width (usable) x 63.5 cm 71 cm(25” - 28”) height (usable)
x47cm(18.5”)depth(usable)
Seat cover material: Gray or beige vinyl
Armrests: Match seat cover material
User adjustable seat height fromground: 62 cm- 72 cm(24.5” - 28.5”)
User adjustable seat height fromscooter deck: 43cm- 53 cm(17”- 21”)
Included Features: Sliding seat, energy-saving auto shutoff feature, height adjustable armrests, front and rear suspension, full light
package
Brakes: Electronic regenerative braking and electromechanicaldisc brake
Rear Wheel Drive: Sealed transaxle, 24 VDC motor
Wheels: Pride MicroMag aluminumalloy wheels in black, red, or gold
Tiller Type: Infinitely adjustable
Freewheel Mechanism: Freewheel release lever located on transaxle
Scooter Weight:
Total weight with batteries: w/two 12V, 32 AHbatteries: 99 kg (219.5 lbs.)
w/two12V, 40 AHbatteries: 106 kg (234.5 lbs.)
Total weight without batteries: 76 kg (169.5 lbs.)
Component Breakdown:
Front Section: 25 kg (61.5 lbs.)
Rear Section (w/out batteries or rear shroud): 31 kg(68.5 lbs.)
Rear Plastic Shroud: 1.5 kg (3.5 lbs.)
Seat: 16 kg (36 lbs.)
Batteries (2 required): 11 kg (25 lbs.) each (12V, 32 AH); 15 kg (32.5 lbs.) each (12V, 40 AH)
Front-to-rear Lockup: Lock pinand camlever system
Ground Clearance: 15 cm(6”)
Optional Accessories: Cane/Crutch holder, walker holder, rearview mirror, cup holder, power seat, oxygen bottle holder, front and rear
bumper, rear basket, power seat assembly, front basket
