Owner’s Manual

www.pridemobility.com Jazzy 1107
SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU2673/RevC/January2006
Thesymbolsbelow areusedthroughoutthis owner'smanualandon thepowerchair toidentifywarningsand important
information.Itisveryimportant foryoutoreadthem andunderstandthemcompletely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot).
PROHIBITED! These actions should be prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel and/
or damage to equipment (black symbol with red circle and red slash).

Jazzy 1107 www.pridemobility.com 3
I. INTRODUCTION.................................................................................................................................4
II. SAFETY .................................................................................................................................................6
III. YOUR POWER CHAIR....................................................................................................................15
IV. ASSEMBLY/DISASSEMBLY........................................................................................................20
V. COMFORT ADJUSTMENTS........................................................................................................24
VI. BATTERIES AND CHARGING ....................................................................................................30
VII. OPERATION.......................................................................................................................................34
VIII.CARE AND MAINTENANCE ........................................................................................................41
IX. WARRANTY........................................................................................................................................46
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetherightto makechangesasthey becomenecessary.Anychanges toourproductsmay causeslightvariations
betweentheillustrationsandexplanations inthismanualand theproductyouhavepurchased.

4 www.pridemobility.com Jazzy 1107
I. INTRODUCTION
SAFETY
WELCOMEto Pride MobilityProducts Corporation (Pride).The power chairyou have purchasedcombines state-of-
the-artcomponentswithsafety,comfort,andstyling inmind.We areconfidentthatthesedesignfeatureswillprovide you
withthe conveniencesyou expect duringyour daily activities.Once youunderstand how tosafelyoperateand care for
yourpowerchair,it shouldgive youyearsof troublefree operationand service.
Readandfollowall instructions,warnings,andnotesinthis manualbeforeattemptingtooperateyour powerchairforthe
first time. Inaddition, your safetydepends upon you, aswell as your provider, caretaker, orhealthcare professional in
usinggoodjudgement.
Ifthereisany informationinthis manualwhichyoudo notunderstand,or ifyourequireadditional assistanceforsetupor
operation,please contactyour authorizedPride Provider. Failuretofollow theinstructions inthismanualandthose
locatedonyourpowerchaircanleadtopersonalinjuryand/ordamagetothepowerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery ofthis product, you promise that you willnot change, alter, or modifythis product orremove or
renderinoperableorunsafeanyguards,shields,orothersafetyfeaturesof this product;fail,refuse,orneglecttoinstallany
retrofitskits fromtime totime providedby Prideto enhanceor preserve the safe useof thisproduct.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliabilityof yournewpower chair,andaboutthe serviceyou received fromyour authorizedPrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and newoptions thatcan increaseyour abilityto useand enjoyyour powerchair.Please feelfree tocontact us
atthe addressbelow:
PrideMobilityProducts Corporation
Attn:CustomerCareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jazzy 1107 www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asan ownerof aPride product,you areinvited toregister yourproduct's warrantyand enrollin thePride OwnersClub.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregisteredmember,eachtimeyouvisit oursite,youwillhaveaccesstothe mostinteractive
andhonesteducationalvenueavailabletodayfor peoplewithmobilityneeds,theirfamilies,andfriends.
Fromourhome page,select“Owners Club”toenter apage dedicated tocurrent andpotentialPride productowners.You
willgainaccessto interviews,stories,recreationideas, dailylivingtips,product andfundinginformation,and interactive
messageboards.These messageboardsinvite you tocommunicatewith otherPridecustomers aswellas Priderepresen-
tativeswhoare availableto assist youwith anyquestionsor concernsyou mayhave.
MyAuthorizedPrideProvider:
Name:_____________________________________________________________________________________
Address:___________________________________________________________________________________
Phone Number:______________________________________________________________________________
PurchaseDate:_______________________________________________________________________________

6 www.pridemobility.com Jazzy 1107
II. SAFETY
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to
reduce the risk of leakage or explosive conditions.
EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to TT
TT
T with ++
++
+
Connect Black wire to TT
TT
T with ––
––
–
PRODUCT SAFETY SYMBOLS
Thesymbolsbelowareused onthepowerchairto identifywarnings,mandatoryactions,and prohibited actions.Itisvery
importantforyou toreadand understandthemcompletely.

Jazzy 1107 www.pridemobility.com 7
II. SAFETY
Do not remove anti-tip wheels.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access. Failure to heed could result in personal injury and/or property
damage.
Prevent personal injury and equipment damage. Do not connect an extension
cord to the AC/DC converter or the battery charger.

8 www.pridemobility.com Jazzy 1107
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairis astate-of-the-artlife-enhancementdevicedesigned toincreasemobility. Prideprovidesanextensive
varietyof products to best fit the individual needsof the power chair user. Please be aware that thefinal selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableofmaking suchadecision, andhis/herhealthcare professional(i.e.,medical doctor, physicaltherapist,etc.).
Thecontentsof thismanualare basedonthe expectationthata mobilitydeviceexpert hasproperlyfitted the powerchair
totheuser and hasassistedthe prescribinghealthcareprofessional and/ortheauthorized PrideProviderinthe instruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities,youwillprobablyencountersituationsin whichyou willneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onand off ofelevators, upand down ramps,and over moderateterrain.
Belowaresomeprecautions, tips,andothersafetyconsiderations thatwillhelpthe userbecomeaccustomedto operating
thepowerchair safely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailable from yourauthorized PrideProvider to furthercustomize your powerchair to bettersuit your needsand/or
preferences.However,underno circumstancesshould youmodify,add, remove,ordisable anyfeature,part, orfunction
ofyourpower chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Getto knowthe feelof your powerchair andits capabilities. Pride recommends thatyou performa safety checkbefore
eachuse tomake sureyour power chair operates smoothlyand safely.
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkforpropertireinflation.Maintainbutdonotexceed 35psi(2.4bar)ineachtire(ifequippedwithpneumatictires).
!Checkall electricalconnections. Makesure theyare tightand notcorroded.
!Checkall controller connectionsto the powerbase. Makesure they aresecured properly.
!Checkthe brakes. See VIII.“Care and Maintenance.”
!Checkbattery charge.See VI.“Batteries andCharging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jazzy 1107 www.pridemobility.com 9
II. SAFETY
Weight Limitations
Yourpowerchair isratedfora maximumweightcapacity. Pleaserefertothe specificationstableforthis limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchair isequippedwithpneumatic tires,youshouldcheck orhavetheair pressurecheckedregularly.Proper
inflationpressureswillprolong thelifeofyour tiresandhelpensure thesmoothoperationof yourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhaveturning switchbacks(180-degreeturns) thatrequire youtohave goodcorneringskills onyour powerchair.
!Proceedwith extremecaution asyou approachthe downgradeof a ramp or otherincline.
!Takewideswings withyourpowerchair’s frontwheelsaroundanytightcorners. Ifyoudothat,thepowerchair’srear
wheelswillfollow awide arc,not cutthecorner short,and notbumpinto orget hungup onanyrailing corners.
!Whendriving down aramp, keep thepower chair’s speedadjustment set tothe slowest speedsetting to ensurea
safelycontrolled descent.See VII. “Operation.”
!Avoid sudden stopsand starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyand then accelerate
cautiously. When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly.If your powerchairstarts tomovedown theinclinefaster thanyouanticipated ordesired,allow ittocome
toacomplete stopby releasingthejoystick, thenpushthe joystickforward slightlytoensure asafely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backward. This may result in personal injury.

10 www.pridemobility.com Jazzy 1107
II. SAFETY
5 (8.7%)
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications pre-
sented inthis manual. Doingso couldcause instability inyourpowerchair, resulting inpersonal injury and/
or damage to your power chair.
Incompliancewith theAmericans withDisabilitiesAct of1990,all handicappublic accessramps arerequired to havea
maximumslopeof 5°(8.7%). Therefore,Pride recommendsthat themaximumslope ofan inclineyou attempttosafely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpower chairisequipped withtwopowerful brakesystems:
!Regenerative—uses electricitytorapidlyslow thevehiclewhen thejoystickreturns tothecenter/stop position.
!DiscParkBrake—activates mechanicallyafterregenerativebraking slowsthevehicletonear stop,orwhenpower is
removedfromthe systemforany reason.
Cornering Information
Whileyourpower chairis equippedwithrear casterwheels andfrontanti-tip wheels,excessively highcorneringspeeds
canstill create the possibility of tipping. Factorswhich affect the possibility of tipping include,but are not limited to:
corneringspeed,steeringangle(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfroman
area of low traction to an area of high traction (such as passing from a grassy area to a paved area – especially at high
speedwhile turning),and abruptdirectional changes.High cornering speedsare notrecommended. Ifyou feelthat you
maytipover ina corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your
power chair from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizesthattherewillbetimes whenyou willencounter othersurface
types.For thisreason, yourpower chair isdesigned toperform admirablyon packed soil,grass, andgravel. Feelfree to
useyour powerchair safelyon lawns andin parkareas.
!Reduceyourpower chair’sspeedwhen drivingonuneven terrainand/or softsurfaces.
!Avoidtallgrassthatcan entangletherunninggear.
!Avoidloosely packed graveland sand.
!Ifyoufeelunsure aboutadriving surface,avoidthatsurface.

Jazzy 1107 www.pridemobility.com 11
II. SAFETY
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Freewheel Mode
Yourpowerchairisequippedwitha manualfreewheelsystemtoallowformanualmaneuverabilitybyatrainedattendant.For
moreinformationabouthowtoplaceyourpowerchairintoandoutoffreewheel mode,seeIII.“Your PowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwith extreme cautionwhen driving nearraised surfaces, unprotectedledges and/or drop-offs(curbs, porches,
stairs,etc.).The correctmethod forapproachinga curbis illustratedin figure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2 inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware that it
may be difficult for traffic to see you when you are seated on your power chair. Obey all local pedestrian
traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution.
Stairs and Escalators
Powerchairs are notdesigned totravel up ordown stairs orescalators.Alwaysuse an elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
Doors
!Determineif thedoor openstoward oraway fromyou.
!Driveyourpowerchair gentlyandslowlyforward topushthedoor open.Ordrive yourpowerchairgently andslowly
backwardto pull the door open.
CURB
CURB

12 www.pridemobility.com Jazzy 1107
II. SAFETY
Transfers
Transferringontoandoffofyourpowerchairrequiresagoodsense
ofbalance.Alwayshave anattendantorhealthcare professional
presentwhilelearningtoproperlytransferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthatyou
oratrainedattendantperformthefollowingtasksbeforeattempt-
ingatransfer:
!Turnoffthe powerto thecontroller SeeVII.“Operation.”
!Ensureyour powerchair isnot infreewheel mode.See III.
“YourPowerChair.”
!Turn both caster wheels toward the transfer destination to
improvepowerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed from
yourpowerchair.
!Flipupthefootplatformormovethelegrestsaside; thiswill
helpto keepyourfeetfromgettingcaughtonthefootrigging
duringthetransfer.
!Reduce thedistance between yourpower chair and the ob-
jectyouare transferringonto.
WARNING! Before transferring, position yourself
as far back as possible in the power chair seat
to prevent the power chair from tipping forward
during transfer and causing injury.
Figure 4.IdealTransfer Position
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power chair
to tip and cause personal injury.
Elevators
Modernelevators havea dooredge safety mechanismthat, whenpushed, reopensthe elevatordoor(s).
!Ifyou are inthe doorway ofan elevator when thedoor(s) begin toclose, push onthe rubber door edgeor allow the
rubberdoor edge to contactthe power chair and thedoor will reopen.
!Usecare that pocketbooks, packages, orpower chair accessories do not becomecaught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwith yourpowerchair,youmay find itnecessarytousealift/elevation producttoaidintransporta-
tion.Pride recommends that you closelyreview the instructions,specifications, and safetyinformation setforth by the
manufacturerofthelift/elevationproductbeforeusingthat product.
Motor Vehicle Transport
Priderecommendsthatyou donotremain seatedinyourpower chairwhiletraveling inamotor vehicle. Thepowerchair
shouldbe stowed in thetrunk of acar or in theback of a truck or van withthe batteries removed andproperly secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.

Jazzy 1107 www.pridemobility.com 13
II. SAFETY
Positioning Belts
YourauthorizedPride Provider,therapist(s),and otherhealthcare professionalsareresponsible fordetermining yourre-
quirementfora positioningbelt in orderto operateyourpower chairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationaboutyour powerchair’sbatteries, seeVI.“Batteries andCharging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Inclement Weather Precautions
Exposureofyour power chairtoinclement weatherconditionsshould beavoidedwhenever possible.Ifsuddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyour power chairbeforestoring, charging,oroperating yourpowerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Reaching and Bending
Neverreach,lean,orbend whiledrivingyourpowerchair.If itisabsolutelynecessaryto reach, lean,orbendwhileseated
onyour power chair, it isimportant to maintain astable center of gravityand keep the powerchair from tipping. Pride
recommendsthat the powerchair user determinehis/her personal limitations andpractice bending andreaching in the
presenceofaqualifiedhealthcare professional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.

14 www.pridemobility.com Jazzy 1107
II. SAFETY
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperating apowerchair.This includesawarenessofsafetyissueswhen
takingprescribedorover-the-counter drugsorwhen theuserhasspecific physicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermust exercise careandcommonsensewhen operatinghis/herpowerchair.Thisincludes awareness
ofsafetyissueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio Frequency Interference can come from sourcessuch as cellular phones, mobile two-way
radios(such aswalkie-talkies),radio stations,TV stations,amateur radio(HAM) transmitters,wireless computerlinks,
microwavesignals, paging transmitters,and medium-range mobiletransceivers used byemergency vehicles. Insome
cases,thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested andhas passedat an immunitylevel of20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If unin-
tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-
424-8205 to report the incident.

Jazzy 1107 www.pridemobility.com 15
III. YOUR POWER CHAIR
THE JAZZY 1107
TheJazzyhastwomainassemblies:theseatassemblyandthepowerbaseassembly.Seefigure5.Typically,theseatassembly
includesthearmrests,seatback, andseatbase.The powerbaseassemblyincludes twomotor/brakeassemblies,two drive
wheels,twoanti-tipwheels,twocaster wheels,twobatteryboxes,andwiring harnesses.Seefigures5,6,and 7.
Figure 5.The Jazzy 1107
SEATBACK
ARMRESTS
CONTROLLER
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOT RIGGING (FOOT
PLATFORM SHOWN)
SEATBASE
SEATBACKRELEASELEVER
CONTROLLER
HARNESS

16 www.pridemobility.com Jazzy 1107
III. YOUR POWER CHAIR
Figure 6.The Jazzy 1107 Power Base
SIDE TRAPEZE BARS FRONT TRAPEZE BAR
MANUAL
FREEWHEELLEVER
MOTOR/BRAKEASSEMBLY
CONTROLLER
CONNECTOR
BATTERY BOX
BATTERY BOX

Jazzy 1107 www.pridemobility.com 17
III. YOUR POWER CHAIR
JAZZY1107SPECIFICATIONS
Suspension: ActiveTrac
DriveWheels: 10in.,pneumatic,(10in.,solidareoptional)
CasterWheels: 6in.,solid,rear-mounted
Anti-tipWheels: 5in.,solid,front-mounted
MaximumSpeed:¹ Up to4.5mph
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.5in.
TurningRadius:² 21.875in.(withfootplatform)
OverallSize:² Length:40.25in.(withfootplatform)
Width:23.375in.
SeatingOptions: Medium-BackSeat(standard)
LimitedReclineHigh-BackSeat(optional)
FullReclineHigh-BackSeat(optional)
SpecialtySeat(optional)
Drivetrain: Twomotor, mid-wheeldrive
Range:¹ Up to 25 miles
Batteries:³ Two12-volt,U-1batteries,32AH
BatteryCharger: 5-amp,off-board
Electronics: 60-ampPrideFLIGHTController
50-ampPGDrivesVSIController
WeightCapacity: 300lbs.
ComponentWeights: Base: 98 lbs. (right section 40.5 lbs.; left section 40.5 lbs.; center section 17 lbs.)
Medium-BackSeat:37lbs.(averageweightwitharmrestsanduniversalmountingsystemextrusions)
Batteries: 29lbs. each (batteryboxes 4.5 lbs. each)
¹Varieswith userweight,terraintype, batteryamphourrating (AH),batterycharge, battery condition,andtire condition.
²Dueto manufacturingtolerances and continuedproduct improvement, thisspecification can be subject tovariance of
(+ or – ) 3%.
³AGMor Gel-Celltype recommended.
NOTE: All specifications subject to change without notice.
Electrical Components
Theelectrical components consist of thecontroller assembly, the batteries, and themotors.Thebatteries, motors, and
controllerpower module are located on thepower base assembly. See figures 6 and 7.The controlleris located on the
seatassembly.Connectivity betweenthe controller andthe motors,the batteries,and the batterychargeris provided by
oneor more wiringharnesses.
ControllerHarness Connector: The controller harness connector is wherethe controller plugs into the powerbase.
Eachcontrolleruses adifferenttypeof harness.Ifthe controllerhasa powermodulein the powerbase,the connectorisa
smallcommunications-typeconnector.Ifthecontrollerisintegrated,thentheharnesshasalarge9-pinconnector.Regardless
ofwhichtypeofcontrollerisused, theharnessmustbesecuredtothe seat assemblyandnotallowedtodragon thefloor.

18 www.pridemobility.com Jazzy 1107
III. YOUR POWER CHAIR
BatteryHarnessConnector: This iswhere the controllerconnects to thebattery boxes.
MainCircuitBreaker(locatedonrearbatterybox): Themain circuitbreakeris asafetyfeature builtintoyour power
chair.Whenthebatteries andthemotors areheavilystrained(e.g., fromexcessiveloads), themaincircuit breakertripsto
preventdamage tothe motorsandthe electronics.If thecircuit trips,allow yourpower chairto “rest”for approximately
oneminute. Next, push inthe circuit breakerbutton, turn on thecontroller,andcontinue normal operation. Ifthe main
circuitbreakercontinues totrip repeatedly,contactyour authorizedPrideProvider.
ControllerPowerModule: Thecontroller powermodule enablesthe controllerto communicatewith thebatteries and
themotors.
MotorConnectors:This is wherethe motorsconnect tothe controllerpower module.
Figure 7. Jazzy 1107 Electrical Components (FLIGHT Controller Shown)
BATTERY HARNESS CONNECTOR CONTROLLER HARNESS CONNECTOR
MOTOR
CONNECTOR
MOTOR CONNECTOR
CONTROLLERPOWERMODULE

Jazzy 1107 www.pridemobility.com 19
Manual Freewheel Levers
Your power chair has a manual freewheel lever on each motor. See figure 6. Manual freewheel levers enable you to
disengagethedrivemotorsfrom the gearboxesandmaneuverthechair manually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage ordisengage the drive motors:
1. Locatethe lever ontop of each motor.
2. Pullthe twolevers upwardto engagethe drivemotors. Seefigure 8.
3. Pushthe twolevers downwardto disengagethe drivemotors. Seefigure 9.
Ifaleveris difficulttomovein eitherdirection,slightly rockthepowerchair back andforth.Thelever shouldthenmove
tothedesired position.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
III. YOUR POWER CHAIR
Figure 8. Drive Mode (Drive Engaged) Figure 9. Freewheel Mode (Drive Disengaged)
MANUALFREEWHEELLEVER MANUALFREEWHEELLEVER

20 www.pridemobility.com Jazzy 1107
Figure 10. Jazzy 1107 AssemblyView
INITIAL ASSEMBLY
Yourpowerchairmayrequiresome assemblyeitherbeforeinitialuseoraftertransportation.Itmayalsorequire disassem-
bly to make some comfort adjustments. Figure 10 details those parts of the power chair that are designed to be disas-
sembledand assembled by an enduser or by a qualifiedcaregiver before using theproduct or making comfort adjust-
ments.
IV. ASSEMBLY/DISASSEMBLY
ARMRESTANGLE ADJUSTMENT
ANTI-TIP WHEEL HEIGHT
ADJUSTMENT FOOT PLATFORM HEIGHT/DEPTH
ADJUSTMENT
SEATHEIGHT/ANGLE
ADJUSTMENT
CONTROLLER POSITION
SEAT INSTALLATION
ARMREST WIDTH ADJUSTMENT
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local hardware stores
or through your authorized Pride Provider.
