Pro-Form PFEL04907.0 User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
Serial Number Decal
(on underside of
frame)
Model No. PFEL04907.0
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact Customer
Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
USER’S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE ELLIPTICAL EXERCISER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
2
WARNING DECAL PLACEMENT
The warning decal shown at the right
has been applied in the location
shown. If the decal is missing or
illegible, call the telephone num-
ber on the front cover of this man-
ual and request a free replace-
ment decal. Apply the decal in the
location shown. Note: The decal
may not be shown at actual size.
PROFORM is a registered trademark of ICON IP, Inc.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or per-
sons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. Keep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around your elliptical exerciser to mount,
dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 275 lbs.
(124 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the handle-
bars when mounting, dismounting, or using
your elliptical exerciser.
10. Keep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the user’s move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your elliptical exerciser only as
described in this manual.

4
BEFORE YOU BEGIN
Thank you for selecting the new PROFORM®FX 5
elliptical exerciser. The FX 5 elliptical exerciser pro-
vides a wide array of features designed to make your
workouts at home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
To avoid a registration fee for any service needed
under warranty, you must register the elliptical
exerciser at www.proformservice.com/registration.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handgrip Pulse Sensor
Handlebar
Wheel
Pedal
Roller
Console
Water Bottle Holder
(No water bottle is
included)
Leveling Foot
Track
Fan

5
ASSEMBLY
To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included hex keys, assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number
following the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-
assembled. If a part is not in the hardware kit, check to see if it has been preassembled.
M8 x 50mm Button
Screw (65)–2
M8 x 35mm Button
Bolt (67)–4
M10 x 20mm Button
Screw (58)–4
M10 x 25mm
Washer (52)–4
M8 x 16mm Button
Screw (53)–5
M8 Nylon
Locknut (68)–4
19mm Wave
Washer (71)–4
M8 x 25mm Button
Screw (77)–6
16mm Wave
Washer (66)–4
M8 x 25mm
Washer (54)–8
M4 x 19mm
Screw (75)–4
M4 x 35mm
Screw (74)–2
M4 x 50mm
Screw (76)–4
M10 x 35mm Shoulder
Screw (57)–2

6
1.
Attach a Wheel (8) to one side of the Frame (1)
with an M10 x 35mm Shoulder Screw (57).
Attach the other Wheel in the same way.
2. Apply a generous amount of the included
grease to the Pivot Axle (41). Then, insert the
Pivot Axle through the Frame (1).
Apply a small amount of grease to a 16mm
Wave Washer (66). Slide the Wave Washer
onto the right side of the Pivot Axle (41).
Identify the Right Upper Body Arm (37), which is
marked with an “R” sticker. Slide the Right
Upper Body Arm onto the Pivot Axle (41). Attach
the Right Upper Body Arm with an M8 x 25mm
Button Screw (77), a Pivot Axle Cover (44), and
an M8 x 25mm Washer (54).
Attach the Left Upper Body Arm (23) in the
same way.
1
2
66
57
1
8
37
23
41
Grease
1
44
77
54
3. Orient the Water Bottle Holder (6) as shown.
Hold the Water Bottle Holder near the Frame
(1) and insert the Wire Harness (73) upward
through the Water Bottle Holder.
Next, slide the Water Bottle Holder (6) onto the
Frame (1). Attach the Water Bottle Holder with
two M4 x 35mm Screws (74).
3
1
73
6
74
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.

7
4. Orient the Upright Cover (5) and the Upright (3)
as shown. While another person holds the
Upright Cover and the Upright near the Frame
(1), insert the Wire Harness (73) upward
through the Upright Cover and the Upright. Tip:
Use an elastic band or a piece of tape to pre-
vent the Wire Harness from falling into the
Upright.
Tip: Avoid pinching the Wire Harness (73)
during this step. Insert the Upright (3) through
the Upright Cover (5) into the Frame (1). Then,
slide the Upright Cover upward and attach the
Upright to the Frame with three M8 x 16mm
Button Screws (53). Tip: Start all the Button
Screws before tightening them.
4
3
1
5
73
53
53
53
5
5. The Console (4) requires four 1.5V “D” batteries
(not included); alkaline batteries are recom-
mended. IMPORTANT: If the elliptical exercis-
er has been exposed to cold temperatures,
allow it to warm to room temperature before
inserting batteries into the Console. If you
do not do this, the console displays or other
electronic components may become dam-
aged. Remove the two screws from the back of
the console, and remove the battery cover.
Insert four batteries into the Console. Orient the
batteries as shown by the markings inside the
battery compartment. Then, reattach the battery
cover.
Note: The Console (4) can be operated with an
optional power supply instead of batteries. To
purchase a power supply, call the telephone
number on the front cover of this manual.
Plug one end of the power supply into the jack
on the Console. Plug the other end of the
power supply into an appropriate outlet that is
properly installed in accordance with all local
codes and ordinances.
4
Batteries
Batteries
Battery
Cover
Screws
Avoid pinching the
Wire Harness (73)
during this step

8
7
36
22
67
68
37
6
6. While another person holds the Console (4)
near the Upright (3), connect the console wire to
the Wire Harness (73). Insert the excess wire
downward into the Upright.
Tip: Avoid pinching the wires during this
step. Slide the Upright Cover (5) upward to the
top of the Upright (3). Attach the Console (4)
and the Upright Cover to the Upright with four
M4 x 19mm Screws (75).
Console
Wire
73
75
3
5
4
Avoid pinching the
Wire Harness (73)
during this step
Hexagonal
Holes
7. Identify the Right Handlebar (36), which is
marked with an “R” sticker. Orient the Right
Handlebar as shown; make sure that the
hexagonal holes are in the indicated loca-
tion.
Insert the Right Handlebar (36) into the Right
Upper Body Arm (37). Attach the Right
Handlebar with two M8 x 35mm Button Bolts
(67) and two M8 Nylon Locknuts (68). Make
sure that the Nylon Locknuts are inside the
hexagonal holes.
Repeat this step for the Left Handlebar (22).

9
9
65 53
54
2
1
9. Insert the Track (2) into the Frame (1). Attach
the Track with two M8 x 50mm Button Screws
(65), two M8 x 16mm Button Screws (53), and
two M8 x 25mm Washers (54).
7
76
2
8
8. Tighten the three Feet (9) into the underside of
the Track (2).
Orient the Track (2) and the Track Cover (7) as
shown. Attach the Track Cover to the Track with
four M4 x 50mm Screws (76).
9
9
9

10
37
Grease
38
58
46
46
52
52
39
71
31
11. Apply a generous amount of grease to the axle
on the Right Upper Body Arm (37) and to the
right Crank Arm (31).
Apply a small amount of grease to two 19mm
Wave Washers (71). Slide one Wave Washer
onto the Right Upper Body Arm (37); slide the
other Wave Washer onto the right Crank Arm
(31).
Identify the Right Pedal Leg (38) and Right Link
Arm (39) assembly, which is marked with an “R”
sticker. Orient the assembly as shown.
At the same time and with the help of another
person, slide the Right Pedal Leg (38) onto the
Right Upper Body Arm (37) and slide the Right
Link Arm (39) onto the right Crank Arm (31).
Attach the Right Pedal Leg (38) and the Right
Link Arm (39) with two M10 x 20mm Button
Screws (58), two Axle Covers (46), and two M10
x 25mm Washers (52).
Repeat this step for the other side of the
elliptical exerciser.
12. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the
elliptical exerciser.
11
39
47
Grease
38 49
54
77
77
49
54
66
10. Identify the Right Link Arm (39) and the Right
Pedal Leg (38), which are marked with “R” stick-
ers, and orient them as shown.
Apply a generous amount of grease to a Link
Axle (47). Also, apply a small amount of grease
to a 16mm Wave Washer (66). Slide the Link
Axle through the Right Link Arm (39) and then
slide the Wave Washer onto the right side of the
Link Axle.
With the help of another person, slide the Right
Pedal Leg (38) onto the right side of the Link
Axle (47). Attach the Right Link Arm (39) and the
Right Pedal Leg with two M8 x 25mm Button
Screws (77), two Link Axle Covers (49), and two
M8 x 25mm Washers (54).
Repeat this step for the Left Link Arm and
the Left Pedal Leg (not shown).
10

11
HOW TO USE THE ELLIPTICAL EXERCISER
HOW TO MOVE THE ELLIPTICAL EXERCISER
Due to the size and weight of the elliptical
exerciser, moving it requires two persons. Stand in
front of the elliptical exerciser, hold the upright, and
place one foot against one of the front wheels. Pull on
the upright and have a second person lift the track
until the elliptical exerciser will roll on the front wheels.
Carefully move the elliptical exerciser to the desired
location, and then lower it to the floor.
HOW TO LEVEL THE ELLIPTICAL EXERCISER
If the elliptical
exerciser
rocks slightly
on your floor
during use,
turn one or
both of the lev-
eling feet
beneath the
base or
beneath the front stabilizer until the rocking motion is
eliminated.
HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
To mount the elliptical exerciser, hold the handlebars
and step onto the pedal that is in the lower position.
Then, step onto the other pedal. Push the pedals until
they begin to move with a continuous motion. Note:
The crank arm covers can turn in either direction.
It is recommended that you turn the crank arm
covers in the direction shown by the arrow below;
however, for variety, you can turn the crank arm
covers in the opposite direction.
To dismount the elliptical exerciser, wait until the ped-
als come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals
will continue to move until the flywheel stops.
When the pedals are stationary, step off the higher
pedal first. Then, step off the lower pedal.
Place
your foot
here
Pull on
upright
Leveling
Foot
Leveling
Foot
Lift here
Pedals
Crank Arm
Cover
Handlebars

12
FEATURES OF THE CONSOLE
The advanced console offers an array of features
designed to make your workouts more effective and
enjoyable.
When you use the manual mode of the console, you
can change the resistance of the pedals with the touch
of a button. As you exercise, the console will display
continuous exercise feedback. You can even measure
your heart rate using the handgrip pulse sensor.
The console has five calorie goal workouts designed
to help you burn 300, 400, or 500 calories in 25-, 30-
or 45-minute workouts. The calorie goal workouts auto-
matically control the resistance of the pedals and
prompt you to vary your pace while counting the calo-
ries you burn.
The console also has five preset workouts that auto-
matically change the resistance of the pedals and
prompt you to vary your pace while guiding you through
an effective workout.
To use the manual mode of the console, follow the
steps beginning on page 13. To use a calorie goal
workout, see page 15. To use a preset workout, see
page 16.
CONSOLE DIAGRAM

13
HOW TO USE THE MANUAL MODE
Note: If there is a sheet of clear plastic on the face of
the console, remove the plastic.
1. Press the Resistance decrease button or begin
pedaling to turn on the console.
A moment after you turn on the console, the dis-
plays will light.
2. Select the manual mode.
Each time you turn on the console, the manual
mode will be selected automatically. If you have
selected a workout, reselect the manual mode by
pressing the Workout button repeatedly until the
words MANUAL MODE appear in the upper
display.
3. Begin pedaling and change the resistance of
the pedals as desired.
As you pedal, change the resistance of the pedals
by pressing the Resistance increase and decrease
buttons repeatedly. There are ten resistance lev-
els. Note: After you press the buttons, it will take a
moment for the pedals to reach the selected resis-
tance level.
4. Follow your progress with the displays.
The left display—This
display will show the
elapsed time. Note:
When you select a
workout, the display will
show the time remain-
ing in the workout instead of the elapsed time.
The left display will also show your heart rate when
you use the handgrip pulse sensor (see step 5 on
page 14).
When you select a workout, the left display will also
show the approximate number of calories you have
burned.
The center display—
When you select the
manual mode, the cen-
ter display will show a
track that represents
640 revolutions. As you
exercise, indicators will appear in succession
around the track until the entire track appears. The
track will then disappear and the indicators will
again begin to appear in succession.
The center display will
also show the resis-
tance level of the ped-
als for a few seconds
each time the resis-
tance level changes.
The right display—
This display will show
the distance (total revo-
lutions) you have ped-
aled and your pedaling
pace, in revolutions per
minute (rpm).
The upper display—When you select the manual
mode, the upper display will show the approximate
number of calories you have burned.

14
5. Measure your heart rate if desired.
If there are sheets of
clear plastic on the
metal contacts on the
handgrip pulse sen-
sor, remove the plas-
tic. To measure your
heart rate, hold the
handgrip pulse sensor
with your palms resting
against the metal con-
tacts. Avoid moving
your hands or gripping the contacts tightly.
When your pulse is
detected, a heart-
shaped symbol will
flash in the left display.
Each time your heart
beats, one or two
dashes will appear, and then your heart rate will
be shown. For the most accurate heart rate read-
ing, hold the contacts for at least 15 seconds. Note:
If you continue to hold the handgrip pulse sensor,
the display will show your heart rate for up to 30
seconds.
If your heart rate is not shown, make sure that your
hands are positioned as described. Be careful not
to move your hands excessively or to squeeze the
metal contacts tightly. For optimal performance,
clean the metal contacts using a soft cloth; never
use alcohol, abrasives, or chemicals to clean
the contacts.
6. Turn on the fan if desired.
The fan has high and low speed settings. Press
the Fan button repeatedly to select a fan speed or
to turn off the fan. Note: If the pedals do not move
for about thirty seconds, the fan will turn off auto-
matically.
7. When you are finished exercising, the console
will turn off automatically.
If the pedals do not move for several seconds, a
series of tones will sound, the console will pause,
and the time will flash in the display.
If the pedals do not move for about five minutes,
the console will turn off and the display will be
reset.
Metal Contacts

15
HOW TO USE A CALORIE GOAL WORKOUT
1. Turn on the console.
See step 1 on page 13.
2. Select a calorie goal workout.
Press the Workout button repeatedly until the name
of the desired calorie goal workout appears in the
upper display. When you select a calorie goal
workout, the name of the workout and the workout
time will appear in the displays and a profile of the
resistance levels of the workout will scroll across
the center display.
3. Begin pedaling to start the workout.
Each workout is divided into 25, 30, or 45 one-
minute segments. One resistance level and one
target rpm (revolutions per minute) setting are pro-
grammed for each segment. Note: The same resis-
tance level and/or target rpm setting may be pro-
grammed for consecutive segments.
During the workout, the workout profile will show
your progress (see the drawing above). The flash-
ing segment of the profile represents the current
segment of the workout. The height of the flashing
segment indicates the resistance level for the cur-
rent segment. At the end of each segment of the
workout, a series of tones will sound and the next
segment of the profile will begin to flash. If a differ-
ent resistance level is programmed for the next
segment, the resistance level will flash in the dis-
play for a few seconds to alert you. The resistance
of the pedals will then change.
As you exercise, you will be prompted to keep
your pedaling pace near the target rpm setting for
the current segment. When the words PEDAL
FASTER appear in the upper display or the GO
FASTER indicator on the pace guide is lit,
increase your pace. When the words PEDAL
SLOWER appear or the GO SLOWER indicator is
lit, decrease your pace. When the words PEDAL-
ING IN RANGE appear or when the center indica-
tor is lit, maintain your current pace.
IMPORTANT: The target rpm settings are
intended only to provide motivation. Your actu-
al pace may be slower than the target rpm set-
tings. Make sure to pedal at a pace that is com-
fortable for you. Note: If you manually override
the resistance settings of a calorie goal workout,
you may not reach your calorie goal.
If you stop pedaling for several seconds, a series
of tones will sound and the workout will pause. To
restart the workout, simply resume pedaling. The
workout will continue until the last segment of the
profile flashes and the last segment of the workout
ends.
When the last segment of the workout ends, the
words PROGRAM DONE will appear in the upper
display.
4. Follow your progress with the displays.
See step 4 on page 13.
5. Measure your heart rate if desired.
See step 5 on page 14.
6. Turn on the fan if desired.
See step 6 on page 14.
7. When you are finished exercising, the console
will turn off automatically.
See step 7 on page 14.
Profile

16
HOW TO USE A PRESET WORKOUT
1. Turn on the console.
See step 1 on page 13.
2. Select a preset workout.
To select a preset workout, press the Workout but-
ton repeatedly until the words UPPER BODY,
WHOLE BODY, or LOWER BODY appear in the
upper display.
When you select a preset workout, the name of
the workout and the workout time will appear in
the displays and a profile of the resistance levels
of the workout will scroll across the center display.
3. Begin pedaling to start the workout.
Each workout is divided into 20, 30, or 45 one-
minute segments. One resistance level and one
target rpm (revolutions per minute) setting are pro-
grammed for most segments. (Note: The same
resistance level and/or target rpm setting may be
programmed for consecutive segments.) The dis-
plays for a preset workout will work in the same way
as the displays for a calorie goal workout (see step
3 on page 15).
As you exercise, you will be prompted to keep
your pedaling pace near the target rpm setting for
the current segment. When the words PEDAL
FASTER appear in the upper display or the GO
FASTER indicator on the pace guide is lit,
increase your pace. When the words PEDAL
SLOWER appear or the GO SLOWER indicator is
lit, decrease your pace. When the words PEDAL-
ING IN RANGE appear or when the center indica-
tor is lit, maintain your current pace.
IMPORTANT: The target rpm settings are
intended only to provide motivation. Your actu-
al pace may be slower than the target rpm set-
tings. Make sure to pedal at a pace that is com-
fortable for you.
If you stop pedaling for several seconds, a series
of tones will sound and the workout will pause. To
restart the workout, simply resume pedaling. The
workout will continue until the last segment of the
profile flashes and the last segment of the workout
ends.
When the last segment of the workout ends, the
words PROGRAM DONE will appear in the upper
display.
4. Follow your progress with the displays.
See step 4 on page 13.
5. Measure your heart rate if desired.
See step 5 on page 14.
6. Turn on the fan if desired.
See step 6 on page 14.
7. When you are finished exercising, the console
will turn off automatically.
See step 7 on page 14.
Profile

Inspect and tighten all parts of the elliptical exerciser
regularly. Replace any worn parts immediately.
To clean the elliptical exerciser, use a damp cloth and
a small amount of mild soap. IMPORTANT: To avoid
damage to the console, keep liquids away from
the console and keep the console out of direct
sunlight.
HOW TO ADJUST THE DRIVE BELT
If the pedals slip while you are pedaling, even while
the resistance is adjusted to the highest setting, the
drive belt may need to be adjusted. To adjust the drive
belt, see assembly step 11 on page 10 and remove
the Left Pedal Leg (24) and the Left Link Arm (25).
Then, see EXPLODED DRAWING A near the end of
this manual and remove the M6 x 25mm Button Screw
(61) from the center of the left Crank Arm Cover (32),
and then carefully remove the left Crank Arm Cover.
Next, remove all the screws from the left side shield,
and then carefully remove the left side shield.
Loosen, but do not
remove, the three
screws (A). Insert
the shaft of a
screwdriver down-
ward between the
Idler (12) and the
pulley located on
the Eddy
Mechanism (10).
Pull the top of the
screwdriver toward
the rear of the
elliptical exerciser until the Belt (80) is tight, and then
tighten the three screws.
Reattach the left side shield and the left crank arm
cover. Then, see step 11 on page 10 and reattach the
left pedal leg and the left link arm.
HOW TO ADJUST THE REED SWITCH
If the console does not display correct feedback, the
reed switch should be adjusted. To adjust the reed
switch, first see EXPLODED DRAWING A near the
end of this manual and loosen the M6 x 25mm Button
Screw (61) in the center of the right Crank Arm Cover
(32), and then carefully rotate the right Crank Arm
Cover out of the way.
Next, see the drawing below and locate the Reed
Switch (21). Loosen, but do not remove, the indicated
M4 x 16mm Screw (72). Slide the Reed Switch slightly
closer to or away from the Magnet (18) on the Pulley
(13).
Then, retighten the M4 x 16mm Screw (72). Turn one
of the Crank Arms (31) for a moment. Repeat until the
console displays correct feedback. When the Reed
Switch is correctly adjusted, replace the crank arm
cover.
CONSOLE TROUBLESHOOTING
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries. See assembly step 5 on page 7
for replacement instructions.
HANDGRIP PULSE SENSOR TROUBLESHOOTING
If the console does not display your heart rate when
you hold the handgrip pulse sensor, or if the displayed
heart rate appears to be too high or too low, see step
5 on page 14.
HOW TO LEVEL THE ELLIPTICAL EXERCISER
If the elliptical exerciser rocks slightly on your floor
during use, see HOW TO LEVEL THE ELLIPTICAL
EXERCISER on page 11.
HOW TO GREASE THE ROLLERS
See the EXPLODED DRAWING near the end of this
manual. If the Rollers (27) squeak when moving on
the Track (2), apply the contents of the included pack-
et of white marine grease equally to each Roller.
Spread the grease evenly around the Rollers. Pedal
the elliptical exerciser until a thin film of grease is dis-
tributed along the Track; wipe off any excess grease.
17
MAINTENANCE AND TROUBLESHOOTING
21
18
13
72
31
10
A
12
80

18
These guidelines will help you to plan your exercise
program. For detailed exercise information, obtain a
reputable book or consult your physician. Remember,
proper nutrition and adequate rest are essential for
successful results.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, exercising at the proper inten-
sity is the key to achieving results. You can use your
heart rate as a guide to find the proper intensity level.
The chart below shows recommended heart rates for
fat burning and aerobic exercise.
To find the proper intensity level, find your age at the
bottom of the chart (ages are rounded off to the near-
est ten years). The three numbers listed above your
age define your “training zone.” The lowest number is
the heart rate for fat burning, the middle number is the
heart rate for maximum fat burning, and the highest
number is the heart rate for aerobic exercise.
Burning Fat—To burn fat effectively, you must exer-
cise at a low intensity level for a sustained period of
time. During the first few minutes of exercise, your
body uses
carbohydrate calories for energy. Only after
the first few minutes of exercise does your body begin
to use stored
fat calories for energy. If your goal is to
burn fat, adjust the intensity of your exercise until your
heart rate is near the lowest number in your training
zone. For maximum fat burning, exercise with your
heart rate near the middle number in your training
zone.
Aerobic Exercise—If your goal is to strengthen your
cardiovascular system, you must perform aerobic
exercise, which is activity that requires large amounts
of oxygen for prolonged periods of time. For aerobic
exercise, adjust the intensity of your exercise until
your heart rate is near the highest number in your
training zone.
WORKOUT GUIDELINES
Warming up—Start with 5 to 10 minutes of stretching
and light exercise. A warm-up increases your body
temperature, heart rate, and circulation in preparation
for exercise.
Training Zone Exercise—Exercise for 20 to 30 min-
utes with your heart rate in your training zone. (During
the first few weeks of your exercise program, do not
keep your heart rate in your training zone for longer
than 20 minutes.) Breathe regularly and deeply as you
exercise–never hold your breath.
Cooling down—Finish with 5 to 10 minutes of
stretching. Stretching increases the flexibility of your
muscles and helps to prevent post-exercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three
workouts each week, with at least one day of rest
between workouts. After a few months of regular exer-
cise, you may complete up to five workouts each
week, if desired. Remember, the key to success is to
make exercise a regular and enjoyable part of your
everyday life.
EXERCISE GUIDELINES
WARNING: Before beginning
this or any exercise program, consult your
physician. This is especially important for
persons over the age of 35 or persons with
pre-existing health problems.
The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determin-
ing heart rate trends in general.

19
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right.
Move slowly as you stretch—never bounce.
1. Toe Touch Stretch
Stand with your knees bent slightly and slowly bend forward from
your hips. Allow your back and shoulders to relax as you reach
down toward your toes as far as possible. Hold for 15 counts,
then relax. Repeat 3 times. Stretches: Hamstrings, backs of
knees, and back.
2. Hamstring Stretch
Sit with one leg extended. Bring the sole of the opposite foot
toward you and rest it against the inner thigh of your extended
leg. Reach toward your toes as far as possible. Hold for 15
counts, then relax. Repeat 3 times for each leg. Stretches:
Hamstrings, lower back, and groin.
3. Calf/Achilles Stretch
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your back
foot flat on the floor. Bend your front leg, lean forward, and move
your hips toward the wall. Hold for 15 counts, then relax. Repeat
3 times for each leg. To cause further stretching of the achilles
tendons, bend your back leg as well. Stretches: Calves, achilles
tendons, and ankles.
4. Quadriceps Stretch
With one hand against a wall for balance, reach back and grasp
one foot with your other hand. Bring your heel as close to your
buttocks as possible. Hold for 15 counts, then relax. Repeat 3
times for each leg. Stretches: Quadriceps and hip muscles.
5. Inner Thigh Stretch
Sit with the soles of your feet together and your knees outward.
Pull your feet toward your groin as far as possible. Hold for 15
counts, then relax. Repeat 3 times. Stretches: Quadriceps and hip
muscles.
1
2
3
4
5

20
1 1 Frame
2 1 Track
3 1 Upright
4 1 Console
5 1 Upright Cover
6 1 Water Bottle Holder
7 1 Track Cover
8 2 Wheel
9 3 Foot
10 1 Eddy Mechanism
11 1 Axle
12 1 Idler
13 1 Pulley
14 1 Crank
15 2 Crank Bearing
16 1 Resistance Motor
17 1 Resistance Cable
18 2 Magnet
19 2 Upper Body Bushing
20 1 Clamp
21 1 Reed Switch/Wire
22 1 Left Handlebar
23 1 Left Upper Body Arm
24 1 Left Pedal Leg
25 1 Left Link Arm
26 2 Pedal
27 2 Roller
28 4 Roller Bushing
29 2 Roller Axle
30 2 Roller Cover
31 2 Crank Arm
32 2 Crank Arm Cover
33 1 Left Side Shield
34 2 Upper Body Endcap
35 2 Pedal Leg Endcap
36 1 Right Handlebar
37 1 Right Upper Body Arm
38 1 Right Pedal Leg
39 1 Right Link Arm
40 1 Right Side Shield
41 1 Pivot Axle
42 2 Inner Pivot Bushing
43 2 Outer Pivot Bushing
44 2 Pivot Axle Cover
45 8 Crank Arm Bushing
46 4 Axle Cover
47 2 Link Axle
48 8 Link Axle Bushing
49 4 Link Axle Cover
50 2 Key
51 14 M6 x 12mm Button Screw
52 4 M10 x 25mm Washer
53 13 M8 x 16mm Button Screw
54 12 M8 x 25mm Washer
55 4 M8 Split Washer
56 2 Snap Ring
57 2 M10 x 35mm Shoulder Screw
58 4 M10 x 20mm Button Screw
59 4 M4 x 12mm Flange Screw
60 2 M4 x 12mm Screw
61 5 M6 x 25mm Button Screw
62 3 M6 Flange Nut
63 3 M6 Fender Washer
64 2 M10 Flange Nut
65 2 M8 x 50mm Button Screw
66 4 16mm Wave Washer
67 4 M8 x 35mm Button Bolt
68 4 M8 Nylon Locknut
69 2 M8 x 50mm Hex Bolt
70 2 M8 Nylon Locknut
71 4 19mm Wave Washer
72 11 M4 x 16mm Screw
73 1 Wire Harness
74 2 M4 x 35mm Screw
75 4 M4 x 19mm Screw
76 4 M4 x 50mm Screw
77 6 M8 x 25mm Button Screw
78 2 Handlebar Endcap
79 2 Foam Grip
80 1 Belt
* – Hex Key
* – Grease Packet
* – User’s Manual
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. PFEL04907.0 R0807B
Note: Specifications are subject to change without notice. See the back cover of this manual for information
about ordering replacement parts. *These parts are not illustrated.
