Pro-Form 280 RAZOR PFEVEL73008.0 User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. PFEVEL73008.0
Serial No.
Write the serial number in the
space above for reference.
USERʼS MANUAL
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if there are missing parts, please
contact us at the numbers or
addresses listed below:
Call: 08457 089 009
Outside UK: 0 (44) 113 3877133
Fax: [phone]
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8 G
UK
Serial
Number
Decal

TABLE OF CONTENTS
WARNINGDECALPLACE ENT ..............................................................2
I PORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSE BLY ...............................................................................5
HOWTOUSETHEELLIPTICALEXERCISER ..................................................13
AINTENANCEANDTROUBLESHOOTING ...................................................20
EXERCISEGUIDELINES ...................................................................21
PARTLIST ..............................................................................24
EXPLODEDDRAWING ....................................................................26
ORDERINGREPLACE ENTPARTS ..................................................BackCover
2
PROFOR is a registered trademark of ICON IP, Inc.
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the
warning decal(s). If a decal is missing or
illegible, see the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal(s) may not be shown at
actual size.

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or per-
sons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. Keep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around your elliptical exerciser to mount,
dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 250 lbs.
(113 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the upper
body arms when mounting, dismounting, or
using your elliptical exerciser.
10. Keep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the userʼs move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your elliptical exerciser only as
described in this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
BEFORE YOU BEGIN
Thank you for purchasing the revolutionary
PROFOR ®280 RAZOR elliptical exerciser. The 280
RAZOR elliptical exerciser provides a wide array of
features designed to make your workouts at home
more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the back
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Pulse Sensor
Upper Body Arm
Pedal Disc
Wheel
Pedal
Console
Leveling Foot

5
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: Some small parts may have
been preassembled. If a part is not in the hardware kit, check to see if it has been preassembled. To
avoid damaging plastic parts, do not use power tools for assembly.
M4 x 16mm
Round Head
Screw (84)–10
M4 x 16mm
Screw (94)–14
M6 x 18mm Patch
Screw (102)–4
M10 x 70mm Button Screw (75)–6M10 x 41mm Shoulder
Screw (63)–2
M6 x 36mm Button
Bolt (76)–4
M6 x 16mm Patch
Screw (80)–2
Wave Washer
(88)–2
M10 Split
Washer (78)–10
M6 Locknut
(77)–6
M6 Split Washer
(101)–4
M8 Locknut
(82)–4
M6 Washer
(35)–4
M10 x 20mm Button
Screw (79)–4
M8 x 38mm Button
Bolt (98)–4
M6 x 72mm Shoulder
Bolt (21)–2

6
2. Attach a Wheel (50) to the front of the Frame
(1) with an 10 x 41mm Shoulder Screw (63).
Repeat this step to attach the other Wheel
(50).
2
1.
Identify the Left and Right Frame Covers (48,
49), which are marked with “Left” and “Right”
stickers.
Orient the Left and Right Frame Covers (48, 49)
with the rounded sides in the indicated loca-
tions.
While another person lifts the rear of the Frame
(1), attach each Frame Cover (48, 49) to the
Frame with two 4 x 16mm Screws (94).
48
Rounded
Side
1
Rounded
Side
1
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
94
63 50
1
63
50
94
49

7
4. Slide the Console Cover (96) onto the Upright
(2) and move it downward.
Then, insert the Console Bracket (3) into the top
of the Upright (2).
Tip: Avoid pinching the Wire Harness (86).
Attach the Console Bracket (3) with four 6 x
18mm Patch Screws (102) and four 6 Split
Washers (101).
4
3.Tip: Avoid pinching the Wire Harness (86).
Start all screws before tightening any of
them.
Have another person hold the Upright (2) near
the Frame (1).
Locate the wire tie in the Upright (2). Tie the
lower end of the wire tie to the Wire Harness
(86). Next, pull the upper end of the wire tie
upward out of the top of the Upright. Then, untie
and discard the wire tie.
Tip: To prevent the Wire Harness (86) from
falling inside the Upright (2), secure the Wire
Harness with a rubber band.
Attach the Upright (2) to the Frame (1) with four
10 x 20mm Button Screws (79) and four 10
Split Washers (78). Do not tighten the Button
Screws yet.
3
Avoid pinching the
Wire Harness (86)
Avoid pinching the
Wire Harness (86)
2
1
86
78
78
78
79
79
79
102
102
101
101
86
96
Wire Tie
2
3

8
7. The Console (4) can use four AA batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Remove the screw, remove the battery
cover, insert the batteries into the battery com-
partment, and then reattach the battery cover.
Make sure to orient the batteries as shown
by the diagram inside the battery compart-
ment.
7
4
Batteries
Cover
Screw
5. Identify the Left and Right Pulse Bars (5, 16),
which are marked with “Left” and “Right” stick-
ers.
Have another person hold the Right Pulse Bar
(16) near the Console Bracket (3).
Locate the wire tie in the Console Bracket (3).
Tie the lower end of the wire tie to the right
Pulse Wire (37). Next, pull the upper end of the
wire tie upward out of the top of the Console
Bracket. Then, untie and discard the wire tie.
Repeat this step for the Left Pulse Bar (5).
5
16
5
3
37
37
86
Wire Tie
Wire Tie
6
16
5
82
98
37
86
Hexagonal
Holes
6. Slide the Right Pulse Bar (16) onto the right
side of the Console Bracket (3). Make sure that
the hexagonal holes are in the indicated
location.
Tip: Avoid pinching the wires during this
step. Attach the Right Pulse Bar (16) to the
Console Bracket (3) with two 8 x 38mm
Button Bolts (98) and two 8 Locknuts (82).
Make sure that the Locknuts are in the
hexagonal holes.
Repeat this step for the Left Pulse Bar (5).
3
37
Avoid
pinching
the wires

9
9
9. Slide the Console Cover (96) upward to the
Console (4).
Attach the Console Cover (96) with four 4 x
16mm Round Head Screws (84).
96
84
4
84
8. While another person holds the Console (4)
near the Console Bracket (3), connect the con-
sole wire to the Wire Harness (86). Then, con-
nect the console pulse wires to the Pulse Wires
(37).
Insert the excess wires downward into the
Upright (2).
Tip: Avoid pinching the wires. Attach the
Console (4) with four 4 x 16mm Screws (94).
8
4
3
94
2
94
86
37
Console
Wire
Pulse Wires
Avoid pinching
the wires

10
11. Identify the Left Upper Body Arm (8), which is
marked with a “Left” sticker.
Orient the Left Upper Body Arm (8) and an
Upper Body Leg (6) as shown. Make sure that
the hexagonal holes and the wide side of the
Upper Body Leg are in the indicated loca-
tions.
Slide the Left Upper Body Arm (8) onto the
Upper Body Leg (6).
Attach the Left Upper Body Arm (8) with two 6
x 36mm Button Bolts (76) and two 6 Locknuts
(77). Make sure that the Locknuts are inside
the hexagonal holes.
Repeat this step for the Right Upper Body
Arm (not shown) and the other Upper Body
Leg (not shown).
11
8
77
76
Hexagonal
Holes
Wide Side
6
10. Identify the Left Pedal (12), which is marked
with a “Left” sticker, and orient it as shown.
Attach the Left Pedal (12) to the left Pedal Arm
(14) with three 10 x 70mm Button Screws
(75), three 10 Split Washers (78), and an 4
x16mm Screw (94).
Repeat this step for the Right Pedal (13) and
the right Pedal Arm (14).
10
14
14
75
78
78
12
13
94
