PROAIM P-MLMT-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Mul-Monitor VESA Mount System (P-MLMT-01)
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
2 x Cross Tubes
2 x Vesa Mount
2 x Clamps
2 x Cross Bars
2 x Pole
Bag
2 x T-Type Allen Key
(Sizes: 3x16”,4mm)

2
Mul-Monitor VESA Mount Setup
 Loosen and open the ratchet knob of the
clamp.
 Align and aach the clamp with the rod and
then ghten it using the ratchet knob.
 Similarly, attach the other clamp with the rod
as shown in the image.
 Now, loosen the knob of the clamp and insert
the pole by matching it with the clamp hole.
 Aer inserng the pole, ghten it with the
help of clamp knob.
 Similarly, follow the same procedure for
aaching the another pole of cart.
Assembly of clamps

3
 Five positions are provided to adjust the
height in the pole, so that height can be
adjusted according to your setup
requirement.
NOTE: It adjusts height in ve posions for
seated/standing monitor viewing angles. as you
can see in images.
 Insert the cross tube by matching it with the
hole of the pole, as shown in the image.
 Similarly, remove both the rod end caps.
 Then loosen all the knobs attached fixed to
the pole and then remove the rod end cap.
 Similarly, insert the second cross tube.

4
 Loosen both the knobs of the cross bar, as
shown in the image.
 Now align the holes of the cross bar to cross
tubes, and then insert the crass bar by simply
sliding.
 Now equally insert both the cross tubes into
the second pole equally, as shown in the
image.
 Properly tighten and secure the bolt on the
back side of the cross bar with the help of the
Allen key.
 After inserting the cross bar, securely
re-tighten the knobs, and similarly insert the
second cross bar.
 Properly tighten the knobs of the pole to
secure the assembly.

5
 Then insert the rod end cap to secure the
cross tube, as shown in the image.
 Now, secure it with the help of the provided
knob of the pole.
 Then, mount the cross bar on the Vesa
Mount.
 Loosen and remove the bolt present on the
side of Vesa Mount.
 Loosen the knob of the Vesa Mount, as
shown in the image.
 Now, insert the bolt by matching the thread
holes of Cross Bar and Vesa Mount and
secure the assembly with the Allen key.
Assembly of Vesa Mount

6
 Follow the same procedure to aach the
second Vesa Mount.
 Remove the Vesa Mount by loosening the
knob attached to it.
 Re-ghten the knob of the Vesa Mount and
properly secure it with the cross bar.
 Place and attach the Vesa Mount by matching
it with the thread hole at the back of the LCD
monitor (Not Included), as shown in the
 Tighten the assembly with the help of the
Allen key.
 Similarly, properly secure all the bolts by
tightening them.

7
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our ut-
most support and care unl you use our product.
YOUR PROAIM MULTI-MONITOR VESA MOUNT SYSTEM
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
 Finally our Mul-Monitor Vesa mount
system setup is ready to use.
 Insert the LCD monitor (Not Included) on the
Vesa Mount and properly align it. Now, insert
bolts and properly ghten them with the help
of Allen key.
