PROAIM P-SMMT-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Smart-Mount - VESA Mount 75mm/100mm for
Monitors (P-SMMT-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Vesa-Mount for Monitor
Assemb ly Manua l

2
Vesa Mount Setup
• Pull and remove the detachable locking pin
from the Vesa Mount.
NOTE: There's a detachable locking pin that,
when pulled out, lets you aen the mount to
stay on the Monitor for the next placement and
secures it in open and closed posions.
• Aer inserng the bolts, ghten them using
the Allen key to aach the Vesa Mount to the
monitor securely.
• Re-insert the detachable locking pin, as shown
in the image.
• Properly insert the detachable locking pin so
that the movement of the T-Slot plate can be
stabilized.
• Mount the mulfunconal 360° Rotatable Grip
Head (Not Included) on the light stand
(Not Included).
• Now, loosen the T-knob.
NOTE: It quickly connects to 5/8" baby-pin light
stands and c-stands.
• Aer loosening the knob, open the Grip Head
and mount the Monitor (Not Included) via the
T-slot with V-centering onto the Grip Head.
NOTE: Mount your monitor to a C-stand via
T-slot with V-centering using 2.5" Grip Heads.
• Now, match the threaded holes of the Vesa
Mount and 75mm Monitor (Not Included), and
insert bolts in them.

3
YOUR PROAIM SMART-MOUNT - VESA MOUNT 75MM/100MM
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
NOTE: Smart-mount perfectly ts most 75×75
and 100x100 mm monitors.
• Secure open and closed posions via tethering
and detachable locking pin.
• The two slots at the hinge end allow black
hook-and-loop straps for cable management
and organizaon.
NOTE: The versale design has circular cutouts
for bolng to head/wooden/set walls.
• Aer inserng the T-Slot in the clamp, ghten
it using the T-knob.

4
