PROAIM P-GHF-01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Folding Camera Gimbal Tripod Head for
Telephoto Lenses (P-GHF-01)
Assembly Manua l
L-Bracket
Storage Bag
Folding Gimbal Head
Padded Bag Strap
Quick Release Plate

Folding Camera Gimbal Setup
2
• Properly open the Folding camera Gimbal
Head as shown in the image.
NOTE: The gimbal head folds up into a compact
and manageable size, making storage and transit
super easy.
• Now, properly ghten the Folding Gimbal
Head with the help of the knob.
NOTE: There is also a spirit level at the base of
the gimbal head for extra precision, as well as
numbered scales to facilitate repeat seng on
the gimbal head.
• Loosen the knob of the Folding Gimbal Head
and mount it onto the Tripod Stand (Not
Included).
• The Folding Gimbal Head has been properly
mounted on the tripod stand.
NOTE: The gimbal head is easily mounted on a
tripod via a 3/8”-16 threaded hole at the boom
of the base.
• Open the L-Bracket by pressing its push pin.
Assembling of L-Bracket

3
• Aer sliding the camera plate, ghten the
adjustment knob properly.
• Loosen the adjustment knob of the L-Bracket
and slide the Quick Release Camera Plate
onto the L-Bracket.
• Then properly ghten it with the help of the
knob, as shown in the image.
• Rotate the Gimbal head by loosening its knob.
Assembling of Quick Release Plate
360° Rotaon of Folding Gimbal Head
NOTE: The Gimbal Head has a camera plate
with 1/4′′-20 and 3/8′′-16 mounng screws
fastened by the plaorm adjustment knob.
• Loosen the top knob of the Folding Gimbal
Head and aach the L-bracket to it.

4
• Loosen the top knob of the folding Gimbal
Head and lt the L-Bracket by 360°.
NOTE: The swing arm lt horizontally and gives
you extreme lt angles to achieve a mul
-dimensional shot as shown in the image.
• Again, properly ghten with the help of the
knob.
NOTE: Then lng axis is locked independently
using the lt fricon knob.
360° Rotaon of L-Bracket
• Aer rotang the Gimbal Head, ghten the
knob again.
NOTE: The head pans 360° while keeping the horizon straight using the bubble level at the base of the
head. Head has a 360° panoramic scale that allows easy pan adjustments.

5
• Mount the Ball Head (Not Included) onto the
Stand.
NOTE: The ball head oers smooth & accurate
swivel rotaon to your cameras, allowing you
to achieve dierent angles .
• Loosen the side knob of the Folding Gimbal
Head and increase the height of the
L-Bracket. Then securely ghten with the
knob again.
• Loosen the locking knob of the Ball Head and
slide the L-Bracket onto the Ball Head.
Camera Setup
NOTE: You can increase the height of L-Bracket
according to your requirement by sliding the
L-bracket along the Arca-Swiss clamp.
NOTE: The head pans and lts a full 360°, facilitang extreme angles and smooth, balanced shots. The
lng axis are locked independently using the pan and lt fricon knobs.

6
NOTE: The adjustment knob allows you to set
the posion of the camera (Not Included) as
needed.
• Loosen the knob of the Ball Head and slide
the camera onto it.
• Open the L-Bracket by pressing its push pin, as
shown in the image.
NOTE: There are mulple 1/4”-20 and 3/8”-16
threaded accessory sockets over the gimbal
head for mounng LED panels, monitors and
microphones, etc.
L-Bracket Setup
• Now aach the camera (Not Included) to the
camera plate by properly matching the
threads and ghten with the help of a
screwdriver.
• Aer sliding the L-Bracket, properly ghten
the locking knob.

7
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our ut-
most support and care unl you use our product.
YOUR PROAIM FOLDING CAMERA GIMBAL HEAD TRIPOD
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
• Set the camera posion according to your
requirement and ghten the knob again.
NOTE: The complete kit comes in a foam
based carrying bag with a padded strap for
added protecon and comfort.
