Prominence Home Bolivar 80099 User manual

PACKAGE CONTENTS
2
HARDWARE CONTENTS
22
26 27
23 24 25
1. Canopy
2. Canopy Cover
3. Mounting Bracket Screw
(x4)
4. Mounting Bracket
5. Yoke Cover
6. Thumbscrew (x3)
7. Set Screw (x2)
8. Motor Assembly
9. Motor Screw (x10)
10. Fitter Plate Screw (x3)
11. Fitter Plate
12. Light Kit
13. Glass Bowl
14. Owner’s Manual
15. Hardware Kit
16. Blade Arm (x5)
17. Blade (x5)
18. E26-Base LED Bulb (x2)
19. Downrod
20. Downrod Pin
21. Downrod Clip
22. Blade Screw (x15)
23. Blade Washer (x15)
24. Wire Connector (x3)
25. Pull Chain Extension (x2)
26. Metal Washer (x 15)
27. Hex Nut (x 15)
Unpack your fan and check the contents. You should
have the following items:
PACKAGE CONTENTS
HARDWARE CONTENTS
Note: Some extra hardware has been included. The quantity
listed above is the number required for installation.
Hardware Kit
Owner’s
Manual
1
2
3
4
5
8
7
9
15
11
18
17
16
12
13
19
20
21
6
14
10

MOUNTING OPTIONS
3
Two Mounting Options
Downrod Mount Angled Ceiling Mount (Up to 16 degrees)
A. 13.88 in. B. 9.63 in. C. 2.4 in. D. 11.33 in. E. 5.13 in.
DIMENSION REFERENCE
E
C
B
A
D
Choose one of the following mounting options:
Downrod Mount is best suited for ceilings 8 ft. or higher. For taller ceilings you may want to use a longer
downrod (not included).
Angled Ceiling Mount is best suited for angled or vaulted ceilings. A longer downrod is sometimes necessary to
ensure proper blade clearance from the ceiling. If using the angle mount, check to ensure the ceiling angle is not
steeper than 16°.

4
WARNING:
READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN INSTALLING THE
FAN AND SAVE INSTRUCTIONS.
All set screws of the fan must be checked and retightened where necessary before installation.
To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets, balancing
the blades or cleaning fan. Do not insert foreign objects in between rotating fan blades.
Before changing the fan direction, turn o the fan and wait for the fan blades to stop completely.
The safeguards provided by these safety instructions and by the separate installation instructions are not
meant to cover all possible conditions and situations that may occur. It must be understood that common
sense, caution and care are factors which can not be built into this product. These factors must be supplied
by the person(s) installing, caring for and operating the fan.
The fan weight is Net Weight: 16.3 lbs. (7,41 kg). Be sure the outlet box (not included) is securely attached
to the building structure and is marked “Acceptable For Fan Support”. Failure to do so can result in serious
injury.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver
--Connect the equipment into and outlet on a circuit dierent from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Please note changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
To avoid risk of electric shock, be sure to shut o power at the main fuse or circuit breaker box before
installing or servicing this xture. Turning o the electrical power by using the light switch is not
sucient to prevent electrical shock.
To reduce the risk of injury, install the fan so that the blades are at least 7 feet (2.1 Meters) above the
oor and at least 18 inches (0.5 Meters) from the tip of the blades to the wall.
To reduce the risk of re, electric shock, or personal injury, mount to outlet box marked “acceptable for
fan support” and use mounting screws provided with the outlet box.
The installation has to be in accordance with the national electrical code, ansi/nfpa 70-1999 and local
codes. If you are unfamiliar with the methods of installing electrical wiring, seek the services of a
qualied licensed electrician.
Using a full-range dimmer switch to control fan speed will cause a loud humming noise from the fan. To
reduce the risk of re or electric shock, do NOT use a full-range dimmer switch to control the fan speed.
SAFETY INSTRUCTIONS
CAUTION:

D
5
ASSEMBLY INSTRUCTIONS
1
1. Turn OFF the electrical power at the main fuse or circuit
breaker.
4
Motor Screws
Notch
3
D
2
Mounting Bracket
Screw
2. Remove the canopy from the mounting bracket by
removing the two mounting bracket screws from the
round holes in the canopy. Then loosen the other two
mounting bracket screws from the J-shaped slots. Save
the mounting bracket screws for later.
2. Install the mounting bracket to the outlet box (not
included) using the screws and washers provided with
the outlet box.
Warning: To reduce the risk of re, electrical shock,
or personal injury, mount to an outlet box marked
“acceptable for fan support” and use the mounting
screws and washers provided with the outlet box.
4. Remove all 10 motor screws from the underside of
the motor assembly using a Phillips-head magnetic
screwdriver.
Note: The slot in the underside of the tter plate allows
screwdriver access to motor screws. Save the motor screws
for later.

6
ASSEMBLY INSTRUCTIONS
Downrod Downrod Clip
Set Screw
Yoke
Downrod Pin 5
6
Downrod
Canopy
Yoke Cover
Downrod Pin
Set Screw
Yoke
Downrod
Downrod Clip
Yoke Cover
6. Feed the wires coming from the yoke through the yoke
cover, canopy and downrod.
7. Insert the downrod into the yoke of the motor assembly
and reinstall the downrod pin and downrod clip. Then
retighten the two set screws.
8. Depending on the length of downrod you use, you
may want to cut the lead wires to simplify the wiring
process. If you decide to cut the lead wires, pull the
lead wires all the way through the top of the downrod.
Measure 8 inches of lead wire, then cut o the excess
wire with wire cutters (not included). Then strip 1/2 inch
of insulation from the end of each wire and twist the
stripped ends of each strand of wire.
7
8
5. Loosen but do not remove the two set screws in the
yoke of the motor assembly. Then remove the downrod
pin and downrod clip from the bottom of the downrod.
8 in.

7
ASSEMBLY INSTRUCTIONS
Black (Hot)
Wire Connector
White (Neutral)
Bare/Green (Ground)
Black Blue White Green
10
Tab
Slot
Downrod
Pin
Downrod
Clip
Mounting
Bracket
9
WARNING: Do NOT
wire the fan motor to a
variable-speed (dimmer)
wall control.
10. Use wire connectors to connect the fan wires to the
power supply wires according to the wiring diagram and
the following instructions:
• Connect the white wire from the fan to the white (neutral)
supply wire.
• Connect the black and blue wires from the fan to the
black (hot) supply wire.
• Connect the green wire from the fan and the mounting
bracket to the bare/green (ground) supply wire.
Note: If a second hot power supply wire is available,
connect it to the blue (light power) wire from the fan for
separate light and fan wall switch control.
Important: After the connections have been made, the
wires should be turned upward and pushed carefully
up into the outlet box. Place the black and white wire
connections on opposite sides of the outlet box.
12
11. Raise the canopy, ensuring the two mounting bracket
screws are aligned with the J-shaped slots in the canopy.
Then turn the canopy clockwise until the mounting
bracket screws are completely engaged in the J-shaped
slots. Install the two previously removed mounting
bracket screws in the round holes. Securely tighten all
mounting bracket screws.
12. Partially insert the blade screws along with the blade
washers through the blade and blade arm. Place the metal
washer over the end of the blade screw and secure with
a hex nut. Repeat this step for the remaining blades and
blade arms.
11
Canopy J-shaped
Slot
Round Hole
Blade
Arm
Blade Screw
Blade Washer
Metal Washer
Hex Nut
Blade
Mounting
Bracket Screw
9. Install the ball end of the downrod into the opening
of the mounting bracket. Rotate the fan in the mounting
bracket until the slot in the ball end of the downrod
engages the tab in the mounting bracket.
DANGER: The fan and/or downrod should not rotate
in the mounting bracket if installed correctly. Failure
to align the slot in the downrod with the tab on the
mounting bracket may result in fan falling causing
serious injury or death.

8
ASSEMBLY INSTRUCTIONS
Light Kit
Reverse Switch
9-Pin Connector
Notch Fitter Plate Screw
Blade Arm
Motor Screw
Motor
Slot
14
13. Install the blade arm to the underside of the motor
assembly with motor screws previously removed (Step 4,
page ). Tighten with Phillips screwdriver. Repeat for each
blade arm.
Note: The slot in the underside of the tter plate allows
screwdriver access to motor screws.
14. To install the light kit, rst remove the three tter
plate screws from the tter plate. Then connect the 9-pin
connector from the tter plate to the 9-pin connector
from the light kit.
Note: Align the notch in the tter plate with the reverse
switch on the light kit.
13
16
15. Secure the light kit to the tter plate using the
previously removed tter plate screws.
16. Install 60-watt max. E26-base LED bulbs.
IMPORTANT: Make sure you allow the bulbs and light kit
to cool before you replace the bulbs.
15
Light Kit
Light Kit
Fitter Plate
Screw
Bulb

9
ASSEMBLY INSTRUCTIONS
17
16. Loosen two and completely remove the third
thumbscrew by turning them counterclockwise. Lift
the glass shade onto the light kit and reinstall the
thumbscrew. Tighten all three thumbscrews.
16
Light Kit
Reverse Switch
Pull Chain Extension
Thumbscrew Glass Bowl
17. Attach the appropriate pull chain extensions to each
of the pull chains. Note: When facing the reverse switch,
the pull chain on the left controls the fan and the pull
chain on the right controls the light.
18. Restore the power at the main fuse or circuit breaker.
18

10
1
2
OPERATING INSTRUCTIONS
1. The fan pull chain has four positions to control the fan
speed. One pull is HIGH, two is MEDIUM, three is
LOW, and four turns the fan OFF. The light pull chain turns
the light ON and OFF.
Note: When facing the reverse switch, the pull chain on
the left controls the fan and the pull chain on the right
controls the light.
2. Using a ceiling fan will allow you to raise your
thermostat setting in summer and lower your thermostat
setting in winter without feeling a dierence in your
comfort.
Note: Wait for the fan to stop before moving the reverse
switch.
In warmer weather, push the reverse switch left which
will result in downward airow creating a wind chill eect.
In cooler weather, push the reverse switch right which
will result in upward airow that can help move stagnant,
hot air o the ceiling area.
Reverse Switch
Reverse Switch
Fan Pull Chain Light Pull Chain

11
If you have diculty operating your new ceiling fan, it may be the result of incorrect assembly, installation or
wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please
check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing diculty in
installation, please contact the Service Department: 1-877-706-3267, 9 a.m.- 5 p.m. Central time.
PROBLEM SUGGESTED REMEDY
1. Fan does not start 1. Check main and branch circuit fuses or circuit breakers.
2. Check power supply wire connections to fan and switch wire connections in
switch housing.
CAUTION: Make sure main power is turned o.
3. Make sure forward/reverse switch pushed completely left or right. Fan will not
operate when switch is in the middle.
4. Make sure that the wall control is turned ON.
1. Make sure all screws in motor housing are snug, but not overtightened.
2. Make sure the screws which attach the blade arm to the motor are tight.
3. Make sure wire connectors in switch housing are not rattling against each other
or against the interior wall of the switch housing.
CAUTION: Make sure main power is turned o before entering switch housing.
4. Some fan motors are sensitive to signals from Solid State variable speed controls.
DO NOT USE a Solid State variable speed control.
1. Ensure all blades are screwed rmly into blade arms.
2. Ensure all blade arms are tightened securely to motor.
3. Ensure canopy and mounting bracket are tightened securely to outlet box and
outlet box is mounted rmly to ceiling joist.
4. Switch one blade with a blade from the opposite side. Or balance the fan using a
balancing kit.
5. If blade wobble is still noticeable, interchanging two adjacent (side by side)
blades can redistribute the weight and possibly result in smoother operation.
1. Check blue wire from fan to make sure it is connected to hot (black) power
supply wire.
2. Check for loose or disconnected wires in fan switch housing.
3. Check for loose or disconnected wires in light kit.
4. Check for faulty light bulbs.
CAUTION: Make sure main power is turned o before entering switch housing.
2. Fan is noisy
3. Fan wobbles
4. Light does not work:
TROUBLESHOOTING

LIMITED LIFETIME WARRANTY
To obtain Service, please contact the Service Department:
1-877-706-3267, 9 a.m.- 5 p.m. Central time.
Model Name: 52” Ceiling Fan
Model No: 80099, 80100, 80101
12
The manufacturer warrants this fan to be free from defects in workmanship and materials present at time
of shipment from the factory for a lifetime from the date of purchase by the original purchaser. The retailer
also warrants that all other fan parts, excluding any glass or acrylic blades, to be free from defects in
workmanship and material at the time of shipment from the factory for a period of one year after the date
of purchase by the original purchaser. The manufacturer agrees to correct such defects without charge or
at its option replace the ceiling fan with a comparable or superior model.
To obtain warranty service, present a copy of the receipt as proof of purchase. All costs of removing and
reinstalling the product are your responsibility. Any damage to any part such as by accident or misuse
or improper installation or by axing any accessories, is not covered by this warranty. The manufacturer
assumes no responsibility whatsoever for fan installation during the limited lifetime warranty. Any service
performed by an unauthorized person will render the warranty invalid.
Due to varying climate conditions, this warranty does not cover any changes in brass nish, including
rusting, pitting, corroding, tarnishing or peeling. Brass nishes of this type give their longest useful life
when protected from varying weather conditions. Any glass provided with this fan is not covered by the
warranty.
Any replacement of defective parts from the ceiling fan must be reported within the rst year from
the date of purchase. For the balance of the warranty, call our customer service department for return
authorization and shipping instructions so that we may repair or replace the ceiling fan. Any fan or parts
returned improperly is the sole responsibility of the purchaser. There is no other expressed warranty. The
manufacturer disclaims any and all warranties. The duration of any implied warranty which cannot be
disclaimed is limited to the time period as specied in the expressed warranty. The manufacturer shall not
be liable for incidental, consequential, or special damages arising out of or in connection with product
use or performance except as may otherwise be accorded by law. This warranty gives specic legal rights,
and you may also have other rights which vary from state to state.
This warranty supersedes all prior warranties.
Note: A small amount of“wobble”is normal and should not be considered a defect.
