Provision ISR I1-380AHDB36 User manual

720P Basic-AHD Series
USER MANUAL

1
Contents
1) CAUTIONS
2 ) Product Introduction
2.1 Camera Introduction
2.2 Product Features
3)
Product Installation
4) Technical Specification
3.1General Notes
3.2Installation Tools and Information
3.3Installation Method
3.4Connections

2 3
1 CAUTIONS
1. To reduce the risk of electric shock, do not open the
machine and maintain by yourself, please consult a
professional service person.
2. To prevent fire or shock hazard, use the power after
safety certification, the input voltage, current, voltage
polarity and operating temperature must meet the
requirements of this camera.
3. Please note the operating temperature and environ-
mental requirements of the camera, avoid too low or too
high temperature. General operating temperature range
of -10°C ~ +50°C (Fahrenheit temperature is 14°F ~
122°F). Avoid flooding and rain, minimize dust and
moisture erosion, otherwise camera would be damaged.
4. Cameras in use should avoid direct sunlight, glare,
otherwise the sensor will be damaged.
5. Do not touch the sensor surface, if any foreign objects
exits, a cotton swab or lens paper can be used to wipe,
if it is difficult to remove, a neutral detergent diluted with
water would be useful. Do not use corrosive solution.
6. In order to make the camera work smoothly and
obtain asatisfactory image, the power cord and video
connection can not be too long, otherwise the increase
of line loss will lead to the inadequate magnitude of the
operating voltage of the camera or video signal
Inadequate.
7. In order to prevent the camera from falling, please
do not place the camera on an unstable bracket, base
or other unstable objects. Otherwise it will lead to
injury, at the same time, the camera will be damaged.
8. The camera cannot be placed near the radiator or
heating resistor.

4 5
2 Product Introduction
2.1 Camera Introduction
PROVISION-ISR’s new series of cameras are adopted
CMOS image sensor with high performance, which
provides mega pixel resolution and supports HD video.
Moreover, it supports monitoring signals coaxial
transmission. Transmission distance can reach more
than 300M based on 75-3 coaxial cable. The series
can support both AHD/CVBS 960H output as well as
realize high speed, long distance and real time video
transmission.
2.2 Product Features
● 1/3” 1.3M CMOS Sensor
● AHD 720P 25fps/30fps
● AHD, CVBS format output
● Low Illumination, 0.01LUX@(F1.2, AGC ON)
● Auto White balance
● Auto Eletronic Shutter
● Auto Gain Control
● 2DNR
3 Product Installation
3.1 General Notes
1. Make sure the unit is powered off before installation.
2. Check power supply voltage consistent with the
electric voltage to prevent voltage unworthy, resulting in
damage to the device.
3. Do not use in the environment beyond the boundaries
of the temperature, and maintain good ventilation to
prevent the rain in order to reduce the risk of fire or
electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way to
remove or modify the equipment; can only use the
required accessories of manufacturers. Problems
caused by unauthorized repair are at your own risk.

6 7
3.2 Installation Tools and Information
Prepare the required engineering data and instructions.
Before installation please prepare the following tools
and instrumentation: A straight or a Phillips-head
screwdriver, multi-meter, scissors, needle nose pliers,
tape measure, pencil and so on.
3.3 Installation Method
1. Check the equipment whether it is damaged.
2. Mounting bracket or base.
① If the cement wall, install the expansion screws
(expansion screw holes need stand or base hole), and
then mount bracket or base.
② If the wooden wall, use self-tapping screws to mount.
3. Mounting the camera
a. Dome Camera
Adjust the lens position and make it aim at the monitoring
points and present a clear picture, manually fix lens
location and adjust the hemisphere cover. Re-examine
the screen whether the character meets the requirement.
Tighten the hemisphere cover.
b. Bullet Camera
Adjust the body so that the lens aims at the monitoring
points and presents a clear picture. Tighten the screws,
to ensure that it does not move.
Installation method above is for reference only, the
specific installation, please be kind.
Note:
The wall needs to bear at least 3X
weight of bracket (base) and
camera.

8 9
3.4 Connection
Connection as shown in the figure below
4 Specifications:
Basic-AHD camera (720P)
DI-380AHDB36 / I1-380AHDB36
Model
Image Sensor
Effective Pixels
Scanning System
Resolution
Min. Illumination
Day & Night
IR LED
OSD Menu
Backlight Compensation
S/N Ratio
White Balance
Noise Reduce
Video Output
Defog
Privacy Mask
Motion Detection
D-Effect
Lens
Power
Operation temp.
Dimension
Net Weight
DI-380AHDB36
24 LED (15m)
3.6mm
98.8*98.8*90mm
160g
I1-380AHDB36
24 LED (15m)
3.6mm
162.5*67.5*67.5mm
180g
1/3” 1.3M Prime Sensor CMOS
1296(H) ×964 (V)
Internal synchronization
Digital:1280×720, Analog:960H
COLOR: 0.1Lux@(F1.2, AGC ON), B&W: 0.01Lux@(F1.2, AGC ON)
EXTERNAL
Not Available
Not Available
≥48dB (AGC Off)
Auto
2D-NR
AHD: (720P@25fps, 720P@30fps), CVBS: (1280x576 , 1280x480)
Not Available
Not Available
Not Available
Not Available
DC12V±10%
-20°C~+45°C, Humidity 90% or less (non-condensing)
