QDI ADVANCE 10F User manual

Declaration of conformity
QUANTUMDESIGNS(HK)LTD.
5/F Somerset House, TaiKoo Place 979 Kings Road,
Quarry Bay, Hong Kong
declares that the product
Mainboard
Advance 10B/Advance 10F
is in conformity with
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
þ EN 55022 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
þ EN 50081-1 Generic emission standard Part 1:
Residential, commercial and light industry
þ EN 50082-1 Generic immunity standard Part 1:
Residential, commercial and light industry
European Representative:
QDICOMPUTER(UK)LTD QDI COMPUTER ( SCANDINAVIA ) A/S
QDISYSTEMHANDELGMBH QDICOMPUTER( NETHERLANDS)B.V.
QDICOMPUTER(FRANCE)SARL QDICOMPUTERHANDELSGMBH
QDICOMPUTER(ESPANA)S.A. QDICOMPUTER(SWEDEN)AB
Signature : Place / Date : HONG KONG/2000
Printed Name : Lv Yan Position/ Title : Assistant President

Declaration of conformity
Trade Name: QDI Computer ( U. S . A. ) Inc.
Model Name: Advance 10B/Advance 10F
Responsible Party: QDI Computer ( U. S. A.) Inc.
Address: 41456 Christy Street
Fremont, CA 94538
Telephone: [phone]
Facsimile: [phone]
Equipment Classification: FCC Class B Subassembly
Type of Product: Mainboard
Manufacturer:Quantum Designs (HK) Inc.
Address: 5/F, Somerset House, TaiKoo Place
979 Kings Road, Quarry Bay, HONG
KONG
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions : (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Signature : Date : 2000

SpeedEasyQuickSetup(English)......................................................... 1
SpeedEasy ¿ìËÙ°²×°Ö¸ÄÏ (ÖÐÎļòÌå ) ............................................... 3
Facilitéde vitesseInitialisation(Francais) ............................................. 5
1. Introduction................................................................. 9
Overview............................................................................................ 9
New Features ..................................................................................... 9
2. Installation Instructions .............................................15
External Connectors ............................................................... 15
PS/2Keyboard&PS/2MouseConnector........................................... 15
USB1&USB2 .................................................................................... 15
USB3&USB4 .................................................................................... 15
ParallelPortConnectorand SerialPortConnector .............................. 16
Line-injack, Microphone-injack, Speaker-outjack and
MIDI/Joystickconnector(Option)......................................................... 16
ATXPower Supply Connector& Power Switch(POWER)................... 16
HardDiskLEDConnector(HD_LED) .................................................. 17
ResetSwitch(RESET)....................................................................... 17
SpeakerConnector(SPEAKER) ......................................................... 17
PowerLEDConnector(PWR_LED) ..................................................... 17
ACPILEDConnector(ACPI_LED) ....................................................... 17
GREENLEDConnector(GREEN_LED) ................................................. 17
HardwareGreenConnector(SLEEP)................................................. 17
Fan Connector(CPUFAN&CHSFAN) ................................................ 18
Wake-UpOnLAN(WOL) ................................................................... 18
Wake-UpOnInternalModem(WOM) ..................................................18i
InternalAudioConnectors(AUX,CDLIN,MODEM)(Option) ................... 19
Audio/ModemRiserInterfaceConnector(AMR)
&AMRSoundOption(J4).................................................................. 19
ChassisSecurity Switch(CHSSEC) .................................................. 20
InfraredHeader (IrDA)....................................................................... 20
ExpansionSlots &I/O Portsdescription ............................................. 20
Jumper Settings ........................................................................... 21
CONTENTS
I

CONTENTS
II
FSBFrequencySelection(JFSB1,JFSB2) .............................................. 21
OverclockingJumperSetting(JCLK1,JCLK2) .........................................21
BIOS-ProtectEasyJumper(JAV).............................................................22
ClearCMOS(JCC) .................................................................................. 23
EnableUSBKeyDeviceWake-upFunction(JUSB1,JUSB2) ....................23
AC97&MC97Selection(JMC1,JMC2,JAC1) ........................................... 23
Memory Configuration................................................................. 24
3.BIOS Description ..................................................................25
UtilitySupport .............................................................................. 25
AWDFLASH.EXE ................................................................................... 25
AWARD BIOS Description ........................................................... 26
EnteringSetup .......................................................................................26
LoadSetup Defaults ............................................................................ 26
StandardCMOSSetup ......................................................................... 26
SpeedEasyCPUSetup ........................................................................ 30
AdvanceBIOS FeaturesSetup ............................................................ 31
AdvanceChipsetFeatures Setup ........................................................ 33
PowerManagementSetup................................................................... 35
PNP/PCIConfigurationSetup ................................................................ 37
IntegratedPeripherals.......................................................................... 38
PCHealthStatus.................................................................................. 40
Supervisor/User Password ...................................................................41
Boot with BIOS defaults ...................................................................... 41
Appendix A QDI Driver CD 2000 ............................................ 43
Appendix B Boot Logo .................................................... 45
RecoveryEasy....................................................................47
Introduction ...........................................................................................47
OperationProcess ................................................................................ 47
FAQ ...................................................................................................... 52

Manual for Advance 10B/Advance 10F
SpeedEasy Quick Setup
Procedures :
1. Correctly insert the processor you choose.
2. Plug in other configurations and restore the system.
3. Switch on power to the system and press the <Del> key to enter BIOS Setup.
4. Enter“SpeedEasyCPUSETUP”menu tosetuptheCPUspeed.
5. Save and exit BIOS Setup, your system will now boot successfully.
Advance 10B/Advance 10F
1

Manual for Advance 10B/Advance 10F
SpeedEasy Introduction
SpeedEasy CPU Setup Menu
Select<SpeedEasyCPUSETUP>itemfromthemainmenuandenterthesub-menu:
Figure-1SpeedEasyCPUSetupMenu
BIOS provides you with a set of basic values for yourprocessor selection instead of the
jumper settings. The processor speed can be manually selected from the “SpeedEasy
CPUSETUP”menu screen.
Warning:
Do not set CPU frequency higher than its working frequency. If you do, we will not be
responsiblefor anydamages caused. Whetheror notthe system canbe overclocked
depends on the processor’s capability. We do not guarantee the overclock system to
be stable.
Usersare provided withCPUoverclockfeaturethrough “JumperEmulation”. Thehostbus
speedcanbe set as66/75/83/100/103/105/112/115/124/133/140/150MHz.The multiplier
can be chosen from 3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 7.5, 8 or 7, 7.5, 8, 8.5, 9, 9.5, 10, 10.5,
11, 11.5, 12. However the multiplier setting will not function for bus ratio locked processor,
only bus ratio unlocked processor.
2

Manual for Advance 10B/Advance 10F
SpeedEasy ¿ìËÙ°²×°Ö¸ÄÏ¿ìËÙ°²×°Ö¸ÄÏ
¿ìËÙ°²×°Ö¸ÄÏ¿ìËÙ°²×°Ö¸ÄÏ
¿ìËÙ°²×°Ö¸ÄÏ
³ÌÐò³ÌÐò
³ÌÐò³ÌÐò
³ÌÐò £º£º
£º£º
£º
1. ÕýÈ·µØ²åÈëÄúËùÑ¡ÔñµÄ΢´¦ÀíÆ÷¡£
2. ²åÈëÆäËûÅäÖ㬠×é×°³ÉÍêÕûµÄ΢»úϵͳ¡£
3. ¿ªÆôϵͳµçÔ´£¬²¢ÇÒ°´×¡ <Del>¼ü,½øÈë BIOSÉèÖóÌÐò¡£
4. ½øÈë¡°SpeedEasy CPU SETUP¡±²Ëµ¥£¬ÒÔµ÷½ÚÖÐÑë´¦ÀíÆ÷µÄËٶȡ£
5. ´æ´¢É趨ֵ£¬Í˳ö BIOS£¬ÏµÍ³¾Í¿ÉÒÔ°´ÄãÉ趨µÄËÙ¶ÈÔËÐÐÁË¡£
3
Advance 10B/Advance 10F

Manual for Advance 10B/Advance 10F
SpeedEasy·½Ê½½éÉÜ
SpeedEasy ÖÐÑë´¦ÀíÆ÷É趨²Ëµ¥ÖÐÑë´¦ÀíÆ÷É趨²Ëµ¥
ÖÐÑë´¦ÀíÆ÷É趨²Ëµ¥ÖÐÑë´¦ÀíÆ÷É趨²Ëµ¥
ÖÐÑë´¦ÀíÆ÷É趨²Ëµ¥
´ÓÖ÷ÉèÖò˵¥ÖÐÑ¡Ôñ <SpeedEasy CPU SETUP>Ï È»áá½øÈë´Î²Ëµ¥£º
ͼ£-1SpeedEasy ÖÐÑë´¦ÀíÆ÷É趨ÏîÄ¿µ¥
BIOSΪÄãµÄÖÐÑë´¦ÀíÆ÷Ìṩһ×é»ù±¾Ñ¡ÏÒÔ´úÌ洫ͳµÄÌøÏß (jumper)·½Ê½£¬Ê¹
Äã¿ÉÒÔÔÚ¡±SpeedEasy CPU SETUP” ²Ëµ¥ÉÏ£¬ÎªÖÐÑë´¦ÀíÆ÷Ñ¡ÔñÕýÈ·µÄ¹¤×÷ƵÂÊ¡£
¾¯¸æ¾¯¸æ
¾¯¸æ¾¯¸æ
¾¯¸æ £º£º
£º£º
£º
ÇëÎð½«ÖÐÑë´¦ÀíÆ÷µÄƵÂʵ÷½ÚÖÁ¸ßì¶ÆäÕý³£¹¤×÷ƵÂÊ£¬ ·ñÔò±¾¹«Ë¾½«²»»á¸ºÔð
Óɴ˶ø²úÉúµÄÈκÎËð»Ù .ϵͳÄÜ·ñ³¬Æµ¹¤×÷ÒàÈ¡¾öÓÚ CPU µÄ¹¤×÷ÄÜÁ¦ ,ÎÒÃDz»±£
Ö¤³¬Æµ¹¤×÷µÄϵͳÎȶ¨ .
ͨ¹ý “Jumper Emulation”, ÎÒÃÇ»¹¸øÓû§Ìṩ CPU ³¬Æµ¹¦ÄÜ .ϵͳ×ÜÏßËٶȿÉÒÔ
ÉèÖÃΪ 66/75/83/100/103/105/112/115/124/133/140/150MHz.±¶ÆµÊý¿ÉÉèÖÃΪ 3/3.5/4/
4.5/5/5.5/6/6.5/7/7.5/8 »ò7/ 7.5/ 8/8.5/ 9/9.5/10/10.5/11/11.5/12¡£È»¶ø¶ÔÓÚ±¶ÆµÊý
ËøËÀµÄCPU, ´ËÏîÉèÖÃÎÞЧ ,±¶ÆµÊýÉèÖýö¶ÔδËøËÀ±¶ÆµÊýµÄCPU ÓÐЧ .
4

Manual for Advance 10B/Advance 10F 5
Installation de la carte mère Advance 10B/Advance 10F
1. Assurez-vous que votre ensemble est complet: carte mère, câbles IDE et FLOPPY,
noticed’utilisationetCD-ROMd’installation.
2. Vérifiez que l’alimentation est débranchée et reliez-vous à la terre par une courroie
à votre poignet. A défaut, maintenez le contact de vos deux mains avec un objet lui-
même relié à la terre, ou une partie en métal de votre système.
3. Fixez la carte mère dans le boîtier grâce aux vis fournies avec celui-ci.
4. Si votre carte mère est munie de cavaliers, placez les en fonction des options que
vous souhaitez utiliser: réglage de la fréquence du processeur si votre carte n’est
pas SpeedEasy, fonction allumage par saisie du mot de passe…(voir le manuel,
rubrique «configuration des cavaliers»)
5. Insérez le processeur dans son logement avec son ventilateur que vous
brancherezauconnecteur«CPUFAN».
6. Insérezla/les barrette(s)mémoiredans lesslots DIMM.
7. Installez vos éventuelles cartes PCI et AMR dans les slots prévus à cet effet (voir
pagecentrale dumanuel).
8. Branchez vos périphériques IDE et FLOPPY sur les connecteurs prévus à cet effet
grâce aux nappes fournies avec la carte. Vérifiez que le sens de branchement est
correct (liseré rouge du câble sur la broche 1 du connecteur).
9. Reliez les câbles du boîtier aux connecteurs prévus à cet effet (Connecteur
d’alimentation,LEDde marche/arrêt,disquedur,haut-parleur…).Refermezleboîtier.
10. Branchez les périphériques externes sur les sorties du fond de panier: clavier,
sourisPS/2,périphériquesUSB,moniteur,imprimante…
11. Lorsque tous les éléments du système sont installés physiquement, rebranchez
l’unitécentrale.
Installation du système.
1. Démarrezvotre systèmeen pressantle bouton«POWER».
2. Pressez la touche «Suppr» pour entrer dans le setup du BIOS.
3. Dans le menu «SpeedEasy CPU Setup», réglez la vitesse de votre processeur (AT-
TENTION:il estrecommandé dene passélectionnerune fréquencesupérieure à
celle de votre processeur, nous déclinons toute responsabilité pour les dommages
quienrésulteraient)
4. Effectuez les autres réglages du BIOS selon votre configuration (nous vous
conseillons fortement de maintenir les réglages par défaut afin d’éviter toute manipu-
lation hasardeuse pouvant résulter en un dysfonctionnement). Pour plus
d’informations sur les fonctions du BIOS, vous pouvez consulter la version
françaisedu manuelsurle CD-ROM.
5. Pressez la touche F10 ou choisissez «Save and exit» pour enregistrer vos
paramètreset relancer lamachine.
Advance 10B/Advance 10F

Manual for Advance 10B/Advance 10F
6
Installation du Advance 10B/Advance 10F système
6. Installezvotre systèmed’exploitation
7. Après installation, assurez-vous qu’il ne subsiste aucun conflit ou périphérique
inconnu dans votre système.
8. Installationdespilotes:
1. Chipset:
Les pilotes des chipsets VIA du répertoire \ChipDrv\Via peuvent être utilisés sur cette
cartemère.
Insérezle CD-ROMdans votrelecteur etcliquezsur « ChipsetDriver » pourinstaller
lespilotes
2. Logiciel PC-cillin 98:
Pour Windows 95/98, version anglaise, dans le répertoire \Pccillin\Win9X. Lancez
setup.exepourl’installation.
Pour Windows NT version anglaise, il se trouve dans le répertoire \Pccillin\Winnt40,
lancez setup.exe.
Numérodesérie:PNEF-9991-6558-5857-5535.
3. QDIManageEasy:
Lancezle setup.exe durépertoire \QMEpourinstaller leManageEasy.Pour des
informationsdétaillées surleManageEasy, référez-vousau manuelManageEasy du
répertoire\Doc.
N’oubliez pas de redémarrer votre système pour que les changements soient pris
encompte.
4. RecoveryEasy
RecoveryEasy™,la dernièreinnovation deQDI,permet deprotéger lesystème des
destructionsen créantune «partitionmiroir»de lapartition courantedu disqueduret en
sauvegardant toutes les données dans ce «miroir».
Cetteutilitaire fournitpartition dudisque, récupération/sauvegardedes données,
récupération/sauvegardedes réglagesdu CMOSetfonctions multi-boot.
RecoveryEasy permet également la protection du système contre les divers types de
virus de boot tels que CIH. Dans le cas où le système est perdu soit par erreur, soit à
caused’unvirus, ilpeutêtrerécupéré depuislapartitionmiroir.Cetteinnovation utilisela
technologiedu Biosintégré quin’occupe nil’espace disque,ni lamémoire dusystème.
C’estlasolutionidéalepour l’utilisateur.
Il faut presser les touches Ctrl + Bksp et F12 pour entrer dans les interfaces «Recovery»
et«Partition»durantledémarragedu Bios.
ATTENTION :lisezattentivementlemanuelduRecoveryEasytraduitsurleCD-ROMQDI
avant d’installer cette fonction.
Très important : n’oubliez pas votre mot de passe, faute de quoi vous
n’auriez plus accès au RecoveryEasy, même après avoir effectué un Clear
CMOS.

Manual for Advance 10B/Advance 10F 7
Le menu SpeedEasy
I. Insérez le processeur correctement.
II. Connectez les autres éléments du système (voir Installation).
III. Au démarrage du système, pressez la touche <Suppr> pour entrer dans
leBios
IV. Entrezdanslemenu«CPUSpeedEasysetup»
Note: si vous ne déterminez pas la vitesse de votre unité centrale, votre
système fonctionnera par défaut ( 200MHz pour les CPU avec une
fréquence de Bus de 100MHz et 133MHz pour les CPU à 66MHz).
V. Sauvegardez et quittez le Bios.
CMOS Setup Utility – Copyright© 1984-1999 Award Software
SpeedEasy CPU Setup
CPUModel : Intel® Celeron™ ItemHelp
CPUSpeed : 433 Mhz (66x6.5)
X Multiplier X2 Menu Level >
X Bus Clock 66MHz
Spread Spectrum Disabled
Prévenir:
Le menu SpeedEasy vous fournit un ensemble de valeurs. Vous pouvez
sélectionnermanuellement lavitessedeCPUdans cemenu soitenmode
«SpeedEasy»soitenmode«JumperEmulation»(voirmanuel).
ATTENTION: Nepassélectionnerune fréquencedefonctionnementduCPUsupérieure à
celleindiquée par leconstructeur.Nous déclinonstoute responsabilité pourtout dégâtqui
enrésulterait.
Advance 10B/Advance 10F

Manual for Advance 10B/Advance 10F
8
-- This page is intentionally left blank --

Manual for Advance 10B/Advance 10F
Chapter 1
Introduction
Chapter 1
Introduction
Overview
The Advance 10B/Advance 10F green mainboard utilizes the Apollo Pro 133A chipset and
provides high performance and cost-effective PC/ATX platform to support Intel CeleronTM
PPGA370, Pentium®III FC-PGA processors, Cyrix-III processor .The VIA® VT82C686B
chipset provides new features with Ultra ATA/100. Equipped with three memory module
socketstosupportPC100/PC133MHzSDRAMandVCMSDRAM.Italsoprovidesadvanced
featuressuchas Suspend toRAM, wake-up onLAN, wake-up oninternal/externalmodem
. The green function is in compliance with the ACPI specification.
IMPORTANT:take note of difference between two . The Advance 10B mainboard is that of
themodel withAC’97codec, theAdvance10F mainboardisthatofthe modelwithoutAC’97
codec.
Key Features
Form factor
l ATX form factor of 305mm x210mm.
Microprocessor
l SupportsallIntel®PentiumIII(Coppermine)FC-PGAprocessorsat533/600EB/667/733/
800EB/866/933MHz/1000MHzand future processorswith 133MHzbus speed.
l Supports all Intel®Pentium III(Coppermine) FC-PGA processors at 500/550/600/650/
700/750/800/850MHz and future processors with 100MHz bus speed.
l SupportsallIntel®Celeron™ FC-PGAprocessorsat533/566/600/633/667/700/733MHz
and future processors with 66MHz bus speed.
l Supports all Intel® Celeron™ PPGA processors at 300/300A/333/366/400/433/466/
500/533MHzwith 66MHzbusspeed.
l Supports later processors Cyrix-IIIat 500/533/550/600/667MHzand future processors
l Supports 66/100/133MHz Front Side Bus.
l CPU core frequency = Bus speed x3, x3.5, x4, x4.5, x5, x5.5, x6, x6.5, x7, x7.5,
x8 or x7, X7.5, X8, X8.5, X9, X9.5, X10, X10.5, X11, X11.5, X12.(BIOS will detect the
CPU ratio)
l On-board 1.5V, 2.5V regulators .
Chipset
l Apollo Pro 133A chipset: VT82C694X, VT82C686B.
9
Chapter 1

Manual for Advance 10B/Advance 10F
System memory
l Provides three 168 pin 3.3V unbuffered 100/133MHz DIMM sockets.
l Supports both100/133MHzSDRAM, VCM(Virtual Channel Memory)SDRAM.
l Minimum memorysizeis 8MB,maximummemory sizeis1.5G MB.
On-board IDE
l Supports two PCI PIO and Bus Master IDE ports.
l Two fast IDE interfaces supporting four IDE devices including IDE hard disks and
CD - ROM drives.
l Supports up to mode 4 timing.
l Supports “Ultra DMA/33”Synchronous DMAmode transferringupto 33Mbytes/sec.
l Supports “Ultra DMA/66”Synchronous DMAmode transferringupto 66Mbytes/sec.
l Supports “Ultra DMA/100”Synchronous DMA modetransferringupto100Mbytes/sec.
l Integrated 16x32bit buffer for IDE PCI Burst Transfers.
On-chipI/O
l One floppy port supporting up to two 3.5” or 5.25” floppy drives with
360K/720K/1.2M/1.44M/2.88Mformat.
l Twohighspeed16550fastcompatible UARTs(COM1/COM2/COM3/COM4
selective) with 16-byte send/receive FIFOs.
l One enabled parallel port at the I/O address 378H/278H/3BCH with additional
bi-directionI/Ocapabilityandmulti-modeasSPP/EPP/ECP(IEEE1284compliant).
l Circuit protection provided, preventing damage to the parallel port when a
connected printer is powered up or operates at a higher voltage.
l Supports LS-120 floppy disk drive and Zip drive.
l All I/O ports can be enabled/disabled in the BIOS setup.
On-chip Audio (Available for Advance 10B mainboard only)
l Build in VIA® 82C686B
l Direct Sound AC’97 Audio and AC’97 2.1 codec compliant.
AGPSLOT
l Supports 4X mode & AGP 2.0 compliant.
Advanced features
l PCI 2.2 Specification compliant.
l Provides Trend ChipAwayVirus® On Guard and PC-Cillin software with killing virus
function.
l Provides four USB ports, onboard PS/2 mouse and PS/2 keyboard ports.
l Provides infrared interface.
l Support PC99 color- coding connector Specification
Introduction
10

Manual for Advance 10B/Advance 10F
l Supports software power-down (e.g. Windows 98/Windwos 2000) .
l Supports wake-up on LAN and wake-up on internal/external modem.
l Supports auto fan off when the system enters suspend mode.
lsupportssystemmonitoring(monitors systemtemperature,CPU temperature,
voltages and fan speed).
l Provides management application such as ManageEasy.
lProtects the system BIOS from being attacked by severe virus such as CIH, by
enabling“FlashWriteProtect” in CMOSsetup or closingthe Jumper “JAV”.
BIOS
lLicensed advanced AWARD BIOS, supports flash ROM with 2M bit memory size,
plug and play ready.
lSupportsIDECD-ROMorSCSIbootup.
Green function
l Supports ACPI (Advanced Configuration and Power Interface) and ODPM (OS
Directed PowerManagement).
l Supports three green modes: Doze, Standby and Suspend.
l Supports ACPI power status: S0, S1, S3(STR), S4(STD), S5(Soft-off).
Expansion slots
l 1 ISA slots and 5 PCI slots.
l 1 AGP Slot.
l 1 AMR Slot.
11
Chapter 1

Manual for Advance 10B/Advance 10F
12
New Features
BIOS-ProtectEasy
TheBIOSofthemainboardis contained insidetheFlash ROM.Severeviruses suchasCIH
virus are so dangerous that it may overwrite the BIOS of the mainboard. If the BIOS has
been damaged, the system will be unable to boot. We provide the following solution which
protects the system BIOS from being attacked by such viruses.
There are two choices which implements this function.
1. Set the jumper (JAV) as closed, the BIOS can not be overwritten.
2. Set the jumper (JAV) as opened, meanwhile set “Flash Write Protect” as Enabled in
AWARD BIOS CMOS Setup. In this way, the BIOS can not be overwritten, but the DMI
informationcan beupdated.
Ultra ATA/100
According to the previous ATA/IDE hard drive data transfer protocol, the signaling way to
send data was in synchronous strobe mode by using the rising edge of the strobe signal.
The Ultra ATA/33 protocol doubles the burst transfer rate from 16.6MB/s to 33.3MB/s, by
using both the rising and falling edges of the strobe signal, and Ultra ATA/66 doubles the
Ultra ATA burst transfer rate once again (from 33.3MB/s to 66.6MB/s) by reducing setup
times and increasing the strobe rate. In the same way, the burst transfer rate of Ultra
ATA/100 is higher than ATA/66 (from 66.6MB/s to 100MB/s)by reducing the pulse width
from 30ns to 20ns and increasing the strobe rate.
Itcan be addedinto existing systemswithout theneedfor terminationdevices, new cable,
or other hardware changes, industry implementation of ATA/100 will provide an inexpen-
sive, simple, non-proprietary, high-speed method of host to storage access.
The 80-conductor, 40-pin cable standard in ATA/66 has enhanced reliability and bee
carried forward to ATA/100. of course, backwards compatible with ATA/33.
PC-133 Memory
PC133 SDRAM Unbuffered DIMM defines the electrical and mechanical requirements for
168-pin, 3.3 Volt, 133MHz, 64/72-bit wide, Unbuffered Synchronous DRAM Dual In-Line
MemoryModules (SDRAMDIMMs). Relatively , thepeak bandwidthof PC-133memoryis
the 33% higher than PC-100 memory. These latest SDRAMs are necessary to meet the
enhanced133MHzbusspeedrequirement.
Introduction

Manual for Advance 10B/Advance 10F
Suspend to RAM
Suspend to RAM is a cost-effective, optimal implementation of the Advanced Configura-
tion and Power Interface (ACPI) 1.0 specification, which makes a PC’s power consump-
tion drop to the lowest possible level and enables quick wakeup. When the system is in
Suspend-to-RAMstatus,the systemcontext is maintainedin system memory,the system
consumes only a small fraction of the power used for full operation. Instead of shutting
down the system to save power when not in use and then having to reboot later, Sus-
pend-to-RAM solution enables the system to quickly wake up, restoring all applications
and features, enabling operation in a few seconds.
Toimplement thisfunction, thefollowing requirmentsareessential:
1. Power supply requirements: The current of 5VSB line of the power supply should be
morethan0.75A.
2. TheBIOS option“ACPIfunction”shouldbe enabled,and“ACPI SuspendType”should
be set as S3 in AWARD BIOS CMOS setup. Refer to page 35 for detail
3. An ACPI-enabled operating system such as Windows 98 or Windows 2000 family is
needed.
a.Inorder toinstallACPI-enabledWindows98operatingsystem,thesetupcommand
should be typed as shown below:
D:\SETUP /P J
(This manual assumes that your CD-ROM device driver letter is D:).
4. Three ways to enter Suspend-to-RAM status under ACPI-enabled Windows 98:
lClick Start -> Shut down -> Standby to enable the system to enter Suspend-to-
RAMstatus.
lClick Start -> Setup -> Control Panel -> Power Management -> Advanced and
choose Standby item, the system will enter Suspend-to-RAM status when you
press power button.
lFrom Power Management Properties in Control Panel, set the latency time in
System Standby, the system will enter Suspend-to-RAM status when time out.
The same ways used to power up the system can be used to wake up the system from
Suspend-to-RAM status. For example, pushing the power button, through the Wake-on-
LAN,Wake-on-Modemfunction orRTCAlarm.
Chapter 1
13

Manual for Advance 10B/Advance 10F
-- This page is intentionally left blank --
14

Manual for Advance 10B/Advance 10F
Chapter 2
Installation Instructions
Chapter 2
Installation Instructions
Thissection coversExternalConnectors, JumperSettings andMemory Configuration.Re-
fertothe mainboard layoutchart for locationsof all jumpers,externalconnectors, slots and
I/O ports. Furthermore, this section lists all necessary connector pin assignments for your
reference. The particular state of the jumpers, connectors and ports are illustrated in the
following figures. Before setting the jumpers or inserting these connectors, please pay
attention to the directions.
Be sure to unplug the AC power supply before adding or removing expansion
cards or other system peripherals, otherwise your mainboard and expansion
cards might be seriously damaged.
External Connectors
PS/2 Keyboard Connector, PS/2 Mouse Connector
PS/2 keyboard connector is for the usage of PS/2 keyboard. If using a standard AT size
keyboard, an adapter should be used to fit this connector. PS/2 mouse connector is for the
usageof PS/2mouse.
USB1,USB2
Two USB ports are available for connecting USB devices.
USB3,USB4
Two USB ports are not available on the back panel. Therefore, we provide a 10-pin ribbon
cable with bracket to connect Built-in on-board USB header. ( manufacturing option)
chapter 2
15
PS/2 Mouse Connector
PS/2 Keyboard Connector
USB1
USB2
1
+5v
T1-
T1+
GND
GND
GND
GND
T0+
T0-
+5v
ForAdvance10B
mainboardonly
ForAdvance10B
mainboardonly

Manual for Advance 10B/Advance 10F
Parallel Port Connector and Serial Port Connector (UART1, UART2)
The parallel port connector can be connected to a parallel device such as a printer, while
the serial port connector can be connected to a serial port device such as a serial port
mouse. You can enable/disable them and choose the IRQ or I/O address in “Integrated
Peripherals”fromAWARD BIOS SETUP.
Line-in jack, Microphone-in jack, Speaker-out jack and
MIDI/Joystick connector (option)
The Line-in jack can be connected to devices such as a cassette or minidisc player for
playbackor recording.TheMicrophone-in jackcan beconnected toa microphone forvoice
input. The Speaker-out jack allows you to connect speakers or headphones for audio
outputfrom theinternal amplifier.
The MIDI/Joystick connector allows you to connect a game joystick or a MIDI device.
Note: The jacks and the MIDI/Joystick connector shown above are available for
Advance 10B mainboard with AC’97 codec only.
ATX Power Supply Connector & Power Switch (POWER)
Be sure to connect the power supply plug to this connector in its proper orientation. The
power switch (POWER) should be connected to a momentary switch (power button).
When powering up your system, first turn on the mechanical switch of the power supply (if
one is provided), then push once the power button. When powering off the system, you
needn’t turn off the mechanical switch, justPush once*the power button.
Note: * If you change “soft-off by PWR-BTTN” from default “Instant-off” to “Delay
4 Secs” in the “POWER MANAGEMENT SETUP” section of the BIOS, the power
button should be pressed for more than 4 seconds before the system powers
down.
Installation Instruction
16
POWER
ATX Power Supply Connector
20
MIDI/Joystick
Speaker out Line in Microphonein
Parallel Port
UART1 UART2
1
ForAdvance10B
mainboardonly
