Qlight QML User manual

PB 1
Water, Vibration, and Oil Resistant LED Work Lights
QML/ QMHL
QML - 150 - D - 24
[Model number] [Product length] [Mount bracket] [Voltage]
| | | |
• QML-Anti-glare
• QMHL- High illumination • 150 - 150mm • 250 - 250mm • D : No bracket • K : Tilt bracket
• MF : Tilt and swivel bracket
• 24 - DC24V
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
3OHDVHWXUQRWKHSRZHURIWKHSURGXFWLPPHGLDWHO\LILWIDLOVWRRSHUDWHSURSHUO\
&DUHIXOO\ZLUHWKHSURGXFWDFFRUGLQJWRHDFKSURGXFW¶VVSHFL¿FDWLRQ
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
)DLOXUHWRIROORZDQ\RIWKHLQVWUXFWLRQVDERYHPD\FDXVHPDOIXQFWLRQRUGDPDJHWRWKHSURGXFW¿UHDQGHOHFWULFVKRFN
:LUHWKHSURGXFWLQDQHQYLURQPHQWZLWKRXWFRRODQWLQRUGHUWRSUHYHQWFRRODQWRZLQJLQWRWKHFRUHZLUHRISRZHUOLQH
8. Keep the lens in a clean condition (Contamination may cause luminance decrease)
9. Clean the product using a soft cloth dampened with water (Do not use thinner, benzene, gasoline and oil)
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, and or malfunction of the
product that would void the warranty.
’XULQJZLULQJRUPDLQWHQDQFHSOHDVHFRPSOHWHO\WXUQRWKHSRZHURIWKHSURGXFW)DLOXUHWRIROORZWKLVPD\OHDGWRDQHOHFWULFVKRFN
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
UDWLQJVLQGLFDWHGIRUHDFKSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\FDXVHD¿UHWRWKHSURGXFWHOHFWULFVKRFNSK\VLFDOLQMXU\
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
IROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
3OHDVHDSSO\WKHFRUUHFWYROWDJHWRWKHSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
IROORZWKLVPD\FDXVHGDPDJHWRSURSHUW\¿UHHOHFWULFVKRFNDQGORVVRIOLIH
Ordering Specications
www.qlight.com
Please scan the QR code for more
detailed product information.
67
69K
6030

2 3
QML/ QMHL-150-D QML/ QMHL-150-K
QML/ QMHL-150-MF
36
155
140
90
105
27
CABLE ENTRY M12 CABLE ENTRY M12
4- Ø4.5
FITTING HOLES
36 155
105
156
27
15
50.5
10
30
60
36 155
105
191
52
45
87.1 67.9
65.8
45
65.8
SIDE VIEW
90˚
90˚
3- Ø6.3
FITTING HOLES
SIDE VIEW
90˚
90˚
TOP VIEW
80˚
80˚
4- Ø6.3
FITTING HOLES
Model number QML-150-D
QML-150-K
QML-150-MF
QML-250-D
QML-250-K
QML-250-MF
QMHL-150-D
QMHL-150-K
QMHL-150-MF
QMHL-250-D
QMHL-250-K
QMHL-250-MF
Lens color Translucent Translucent Transparent Transparent
Light color (Standard) Cool daylight
Color temperature
(Standard) 6,000-7,000K
/XPLQRXVX[ 875lm 2,014lm 884lm 1,892lm
Illumination (at 1m)
620Lux 890Lux 1,000Lux 1,900Lux
Model number QML-150-D
QML-150-K
QML-150-MF
QML-250-D
QML-250-K
QML-250-MF
QMHL-150-D
QMHL-150-K
QMHL-150-MF
QMHL-250-D
QMHL-250-K
QMHL-250-MF
Rated voltage DC24V DC24V DC24V DC24V
Range for operation
voltage DC21.5V-26.5V
Power consumption 14W 30W 12W 25W
Insulation resistance Min. 100M9’&PHJDRKPPHWHU
Withstanding voltage DC : 500V AC, 60Hz, 1 minute
Protection rating IP67/ IP69K
Operating
temperature
-30°C to +60°C
Materials Housing :AI, Lens : Tempered glass, Bracket : K type-STS430/MF type-AI
&HUWL¿FDWH
/ DC only (QMLseries only)
Weight(approx.)
QML-150-D : 0.75kg
QML-150-K : 0.93kg
QML-150-MF : 0.98kg
QML-250-D : 1.30kg
QML-250-K : 1.46kg
QML-250-MF : 1.52kg
QMHL-150-D : 0.95kg
QMHL-150-K : 1.05kg
QMHL-150-MF : 1.45kg
QMHL-250-D : 1.20kg
QMHL-250-K : 1.30kg
QMHL-250-MF : 1.70kg
■Optics Specications
■General Product Specifications
Product Specications
Dimensions
(Units : mm)

2 3
1
2
3
4
1
2
3
4
QML/ QMHL-250-DQML/ QMHL-250-K
36
255
240
100
115
33
CABLE ENTRY M12
4- Ø4.5
FITTING HOLES
36 255
115
166
33
CABLE ENTRY M12
30
60
255
52
115
201
SIDE VIEW
90˚
90˚
3- Ø6.3
FITTING HOLES
15
50.5
10
QML/ QMHL-250-MF
SIDE VIEW
90˚
90˚
4- Ø6.3
FITTING HOLES
45
65.8
137.1 117.9
45
65.8
80˚
80˚
TOP VIEW
36
• External power line - Dura & Flex-F VU(0.5sq) x 2C 450mm
• When wiring the product, please ensure that the terminals
are not exposed to coolant in order to prevent the bare wire
from being contaminated.
• Please connect the 4 pins located in M12 connector cable to the
M12 socket of the product.
DC
M12 Connector Attached Type
White
Black Fuse Power
Fuse Power
Dimensions
(Units : mm)
Wiring Instructions
+
-
+
-

4 5
①
K type bracket
MF type Bracket
Lens
(Tempered glass)
Lens
(Tempered glass)
Housing(AI)
Lens
(Tempered glass)
Housing(AI)
Housing(AI)
Parts Denition/ Bracket Adjustment
■Parts Definition
■Bracket Adjustment
• K type bracket
- Loosen the bolt ①and adjust the tilt angle to the desired location before securing the bolt.
• MF type bracket
- When tilt adjustment is needed, loosen the bolt ②and adjust the tilt angle.
When swivel angle adjustment is needed, loosen the bolt ③and swivel angle to the desired location.
When angle adjustment is done, please secure the bolt.
VIEW “A”
VIEW “A”
QML-150/ 250-D QML-150/ 250-MF
QML-150/ 250-K
②
③

4 5
Condensing Lens
Condensing Lens
Condensing Lens
M12 Connector
Lens
(Tempered glass)
Lens
(Tempered glass)
Lens
(Tempered glass)
Housing(AI)
Housing(AI)
Housing(AI)
Parts Denition/ Bracket Adjustment
■Parts Definition
※ Please refer to page 4 in regards to bracket adjustment.
■M12 Connector Type Model(Customization)
• M12 connector type product with a cable entry is available upon request.
• Applied models : QML-150-D, QML-150-K, QML-250-D, QML-250-K,
QMHL-150-D, QMHL-150-K, QMHL-250-D, QMHL-250-K
VIEW “A”
VIEW “A”
QMHL-150/ 250-D QMHL-150/ 250-MF
QMHL-150/ 250-K
K type bracket
MF type Bracket

6 7
Installation/ Mounting Hole Specications
• First, machine taps or holes on the mounting surface (①).
• The mounting holes of this product are 4.5mm(D type) and 6.3mm(K type, MF type) in diameter.
• When machining taps, fasten the bolt through the mounting hole of the product.
• When machining holes, insert the bolt through the hole of the product, and tighten the nut from the opposite side of the mounting
surface.
■Installation
• Machine holes on the mounting surface referring to the diagram below.
■Mounting Hole Specifications
140
240
90
100
45
45
30
15
4-Ø4.5 HOLES 4-Ø4.5 HOLES
4-Ø6.3 HOLES
3-Ø6.3HOLES
QML/ QMHL-150-D
QML/ QMHL-150/ 250-K
QML/ QMHL-250-D
QML/ QMHL-150/ 250-MF
①
①
①
①
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP67/ IP69K.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP67/ IP69K), it may cause malfunction or damage to the product.
• For further information, please visit our website (www.qlight.com).

6 7
Product installation direction
■ Install the product in accordance with the manual. Otherwise rainwater or moisture may penetrate into the product.
ㆍELECTRONIC SOUNDER/SIGNAL HORN
Sounder part shall not be facing the sky.
Sounder part shall not be facing the sky.
ㆍBEACON/SIGNALING LIGHT
Power cord inlet part shall not be facing the sky.
Power cord inlet part shall not be facing the sky.
ㆍSIGNAL TOWER LIGHTS
ㆍHEAVY-DUTY & EXPLOSION PROOF SIGNALINGS
※For products with a protection rating of less than IPX4, please install it vertically.
※For products with a protection rating of less than IPX4, please install it vertically.
