Qlight QWL20 User manual

PB 1
Water, Vibration Resistant LED Work Lights
QWL20/ QWL20-DT
QWL20-DT - 12/24
[Model number] [Voltage]
| |
• QWL20
• QWL20-DT • 12/24 - DC12V-24V
67
7540
Please scan the QR code for more
detailed product information.
www.qlight.com
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, and or malfunction of the
product that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
    ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
    malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
    follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
    follow this may cause damage to property, ¿re, electric shock and loss of life.)
Ordering Specications

2 3
-
+
(+)
(T)
QWL20
QWL20-DT
Power
M8 HEX. BOLT
38
26.5
84.6
41.5
31.5 119.2
84.634.6
57.3
24.5
9.5
CABLE ENTRY
M8 HEX. BOLT
38
26.5
84.6
41.5
31.5 119.2
84.634.6
57.3
24.5
9.5
DT04-2S
CONNECTOR
62.5
QWL20 QWL20-DT
Model number QWL20 QWL20-DT
Lens color Translucent
Light color (Standard) Cool daylight
Color temperature
(Standard) 5,500-6,500K
Luminous ux 1,000lm
Illumination (at 1m)
4,000Lux
• External power line - UL2464-18AWG(0.75sq) x 2C 440mm
• Black output line is negative(-).
• DT04-2S connector is attached to this product.
• Use DT06-2S connector to wire in accordance with polarity.
Red/White
Black Fuse Power
■Optics Specications
Model number QWL20 QWL20-DT
Rated voltage DC12V-24V
Range for operation
voltage DC10V-30V
Power consumption 12W
Insulation resistance Min. 100M(500V DC mega ohm meter)
Withstanding voltage 500VAC, 60Hz, 1 minute
Protection rating IP67
Operating
temperature
-40℃ to +75 ℃
Materials Housing :AI, Lens : PC,  Bracket : STS
Certi¿cate
Weight(approx.)
0.4Kg
■General Product Specications
Product Specications
Dimensions
(Units : mm)
Wiring Instructions

2 3
①
②
Bracket(STS)
Housing(Al)
Lens(PC)
Parts Denition/ Bracket Adjustment
■Parts Denition
■Bracket Adjustment
• In case angle adjustment is needed after installation, please slightly loosen the bolt (1) and adjust the angle as desired, and
fasten the bol later
QWL20 / QWL20-DT
• First, machine holes on the mounting surface(2).
• The mounting holes of this product are 9mm in diameter.
• Please insert the bolt through the hole of bracket, and tighten the nut from the opposite of the mounting surface.
Ø9 HOLE
• Machine holes on the mounting surface referring to the diagram below.
Installation/ Mounting Hole Specications
■Installation
■Mounting Hole Specications

Qlight Co., Ltd. www.qlight.com | [email protected]
Head O-ce | Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea
                       Tel. +82-2-2679-6152(Toll free. +82-80-328-2222)  Fax. +82-2-2679-6154
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. +82-55-328-1111(Toll free. +82-80-328-1111)
Qlight OverSEAs Sales Dept | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : +82-51-620-4100
Qlight Public Relations & Marketing Team O-ce | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel. +82-51-245-0017
Qlight USA, Inc. www.qlight.com www.qlightusa.com | [email protected]
3003 North First Street, Suite #341, San Jose, CA 95134 USA Tel. +1 - 408 - 519 - 5740  Fax. +1 - 408 - 519 - 5739
SHANGHAI Qlight Electronic Co., Ltd. www.qlight.com www.qlightcn.com | [email protected]
China Factory/ Shanghai Sales O-ce | #19, Nanda Road, Baoshan Area, Shanghai, China Tel. +86 - 21 - 6651 - 7100  Fax. +86 - 21 - 6315 - 3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China  
Tel +86 - 513 - 8384 - 9999 Fax +86 - 513 - 8384 - 9910
Product Operation Inquiry / Customer Support +82-51-620-4100
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
    RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea ( Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea ( Postal Code : 50805)
For your safety
Speci¿cation and dimensions listed in this catalogue subject to change without notice for product quality improvement.
The newest product information is available on our website.(www.qlight.com)
Please read the instruction manual attached to the product carefully before installation and use.
www.qlight.com
EN - QWL20 - 2202A
