Quick GP Series User manual

GP Series
GP2 500
GP2 1200
GP2 1200 D
GP2 1200 FF
GP2 1500
GP2 1500 D
GP2 1500 FF
GP2 2000
GP2 2000 D
GP2 2000 FF
*Other languages available by scanning the QR code on the
back of this manual or on the label on the product.
REV 000A
March, 2023
HORIZONTAL WINDLASSES
ROPE AND CHAIN ON A SINGLE GYPSY
*EN - INSTALLATION AND USER'S MANUAL
EN
*Altre lingue disponibili scansionando il codice QR presente
sul retro del seguente manuale o sull’etichetta alloggiata sul
prodotto.
ES *Otros idiomas disponibles escaneando el código QR en la
parte posterior de este manual o en la etiqueta del producto.
FR *Autres langues disponibles en scannant le code QR au dos
de ce manuel ou sur l'étiquette du produit.
DE
*Andere Sprachen sind durch Scannen des QR-Codes auf der
Rückseite dieser Betriebsanleitung oder auf dem Aufkleber
am Produkt verfügbar.
PT *Outros idiomas disponíveis, digitalizando o código QR no
verso deste manual ou no rótulo do produto.

GP Series EN
INDEX
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
1 - Information about the product 5
1.0 - Model code 5
1.1 - GP2 Technical Data 5
2 - Supply and equipment 6
2.0 - Standard supply and material included in the package 6
2.1 - Tools required for installation 6
2.2 - Recommended Quick®accessories not included 6
3 - Introduction 6
3.0 - Important notes 6
3.1 - Precautions 7
3.2- Precautions for the installer 7
4 - Installation 7
4.0 - Installation requirements 7
4.1 - Installation procedures 8
5 - Wiring diagram 9
5.0 - Example of connection of GPSeries 9
6 - Cautions & Use 10
6.0 - Important cautions 10
6.1 - Clutch use 10
6.2 - Use of the drum 1200/1500/2000 11
6.3 - Troubleshooting 11
6.4 - Automatic free fall system 12
7 - Maintenance 13
8 - Product disposal 13
9 - List of components GP2 500 14
10 - List of components GP2 1200 15
11 - List of components GP2 1500/2000 16
12 - Spare parts 17
13 - Dimensions 18

GP Series EN
GP2 1200 250 12 D
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
5
1.0 - Model code
1.1 - GP2 Technical Data
MODELS GP2 500 GP2 1200 (D / FF) (6) GP2 1500 (D / FF) (6) GP2 2000 (D / FF) (6)
MODEL POWER 150 W 250 W 500w800 W
Motor voltage 12 V 12 V 12 V 12 V 24 V
Maximum instantaneous pull 220 Kg (485.0 lb) 550 Kg (1212.5 lb) 680 Kg (1499.0 lb) 900 Kg (1984 lb) 900 Kg (1984 lb)
Maximum work load 70 Kg (154.3 lb) 170 Kg (374.8 lb) 250 Kg (551.0 lb) 350 Kg (772.0 lb) 350 Kg (772.0 lb)
Work load 35 Kg (77.2 lb) 50 Kg (110.2 lb) 85 Kg (187.0 lb) 120 kg (265.0 lb) 120 kg (265.0 lb)
Current consumption at work
load (1) 29 A 35 A 76 A 96 A 50 A
Maximum recovery speed (2) 38.9 m/min
(83.7 ft/min)
31.2 m/min
(102.4 ft/min)
25.5 m/min
(83.7 ft/min)
29.6 m/min
(97.1 ft/min)
29.6 m/min
(97.1 ft/min)
Recovery speed at work load (2) 28.5 m/min
(33.8 ft/min)
25.1 m/min
(82.3 ft/min)
10.3 m/min
(33.8 ft/min)
20.0 m/min
(65.6 ft/min)
20.1 m/min
(65.9 ft/min)
Minimum motor cable cross
section (3) 4 mm² (AWG 12) 10 mm² (AWG 7) 10 mm² (AWG7) 16 mm² (AWG5) 10 mm² (AWG7)
Circuit breaker (4) 40 A 50 A 80 A 40 A
Deck thickness (5) 20 ÷ 40 mm (3/4” ÷ 1” 9/16)
Weight - model without drum 6 kg (13.2 lb) 8 kg (17.6 lb) 10.2 kg (22.4 lb)
Weight-model with drum - 9 kg (19.8 lb) 11.5 kg (25.3 lb)
Weight-model Free Fall - 10.9 kg (24.0 lb) 10.9 kg (24.0 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 6 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4)Withspeciccircuitbreakerfordirectcurrent(DC)anddelayedcircuitbreaker(thermal-magneticorhydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
GYPSY (*) 6 mm 7 mm - 1/4” 8 mm 5/16”
Chain size 6 mm 6 mm 7 mm 7 mm 1/4” 1/4” 8 mm 8 mm 5/16”
DIN 766 ISO DIN 766 ISO*** G4 BBB DIN 766 ISO*** G4
Rope size** 1/2” (12.7 mm) 1/2” (12.7 mm) 1/2” (12.7 mm)
(*) For gypsy codes, see the exploded drawing from page 14 to 17
(**) The values in the table refer to a polyester rope featuring 3 strands with rope/chain junction according to the Quick®system
(***) ISO EN 818-3.
READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USING THE PRODUCT. IF IN DOUBT, CONTACT YOUR QUICK®
DEALER.
QUICK®RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT
PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED VERSION AND THE ORIGINAL TEXT IN THE ITALIAN
LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.
VOLTAGE (V)MODEL
SERIES NAME
POWER (W)
DRUM (D)
COVER (-)
FREE FALL (F)
1 - Information about the product

GP Series
EN
GP Series
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
6
2.0 - Standard supply and material included in the package
• Windlass
• Reversing contactor box
• Base gasket
• Lever
• Screws for assembly
• Installation and user’s manual, Warranty
• Drilling template
2.1 - Tools required for installation
GP2
• Drill with bit: Ø 9 mm (23/64”) and Ø 11 mm (7/16”)
• Hollow mill Ø 40 mm (1” 9/16)
• Hex wrench: 13 mm
2.2 - Recommended Quick®accessories not included
• Controls for control board UP/DOWN
• Push-button panel
• Foot-operated switch
• Hydraulic-magnetic circuit breaker
• Anchor chain counter
• Control system via RRC radio
2 - Supply and equipment
BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK® DEALER.
3.0 - Important notes
This manual features Warning and/or Caution symbols that are important for safety.
Please follow the instructions provided.
Warning symbol for dangerous
situations.
Caution symbol to prevent direct or
indirect damage to the product.
Thismanualprovidesboatmanufacturersandnauticalequipmentinstallerswithinstructionsonhowtoassemblethespecied
Quick®product and operate it correctly.
3 - Introduction

EN
GP Series
DP Series
Max 5°
2 A1 A 3 A
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
7
3 - Introduction
3.1 - Precautions
Quick®windlasses are designed and manufactured to weigh the anchor.
• Do not use these products for any other type of operation.
• Quick®shall not be held liable for direct or indirect damage caused by improper use of the product.
• The windlass is not designed to support loads generated in particular weather conditions (storm).
• Weighing the anchor: switch on the boat's engine.
• Operate the product from a position where it is possible to supervise the work area.
• Always deactivate the windlass when not being used.
• Make sure that there are no bathers nearby before dropping the anchor.
• The splice between the rope and the chain must be tightly woven for the rope to slide easily into the gypsy shape.
For any problem or request, feel free to contact Quick® Technical Service.
• For improved safety, we recommend installing at least two controls to operate the windlass in case one is damaged.
• We recommend the use of Quick®switch as motor safety device.
• Secure the chain with a retainer before sailing off.
• The reversing contactor box must be installed in a position protected from any water entry.
• Aftercompletingtheanchorage,securethechaintoxedpointssuchaschainstopperorbollard.
• To prevent accidental releases, the anchor must be secured. The windlass must not be used as sole securing device.
• Isolatethewindlassfromtheelectricalsystemduringnavigationandsecuretheropetoaxedpointoftheboat.
• This equipment is not intended for use by people (including children) with reduced physical, sensory or mental capabilities.
3.2- Precautions for the installer
CARRY OUT THE INSTALLATION IN GOOD LIGHTING CONDITIONS.
It is advisable to wear suitable clothing and personal protective equipment (PPE).
The product is not suitable for installation in potentially explosive environments and/or atmospheres.
Installationandsubsequentinspectionorrepairworkmustonlybecarriedoutbyqualiedpersonnel.
CARRY OUT INSTALLATION/MAINTENANCE WORK MAKING SURE THAT THE PRODUCT IS DISCONNECTED
FROM THE ELECTRICAL SYSTEM.
Quick®accepts no responsibility for inadequate connection of users to the electrical system and inadequate safety
of the electrical system.
4.0 - Installation requirements
A ROLLER ALIGNMENT
Precise alignment of the windlass is essential for the correct operation of the product.
Thewindlassmustbepositionedbyaligningthegypsywiththebowroller(g.1A / 2A).
An excessive negative tilt of the chain could interfere with the windlass base 2A.
Apositivechaintiltofupto5°isallowed(g.3A).
4 - Installation

GP Series
EN
B
A
B
C
Nm
8÷10
45°
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
8
4.1 - Installation procedures
AIdentify the ideal position and drill the holes using the
drilling template supplied.
BRemove the excess material from the rope/chain passage
hole,nishitandsmoothitwithaspecicproduct(marine
paint, epoxy resin or gel) ensuring the free passage of the
chain.
CPosition the upper section inserting the gasket between
the deck and the base. Fix the windlass by screwing the
nutsontothexingstuds.
Connect the supply cables from the windlass to the
reversing contactor unit.
STUD
B DECK LEVEL
Ensure that the upper and lower surfaces of the deck are as
parallel as possible. If this is not the case, compensate the
differenceappropriately(g.B).
A lack of parallelism could result in a loss of motor power.
Thedeckthicknessmustbeincludedamongthegureslisted
in the table.
In case of different thickness, please contact your Quick®
dealer.
C PEAK DEPTH AND BOW ROLLER HEIGHT
Theremustbenoobstaclestothepassageofcables,ropeandchainunderdeck(g.1C).
Insufcientdepthofthepeakcouldcausechainjamming(g.2C).
Max
5 mm (3/6”)
GASKET
NUT
GROWER
1C 2C
40 cm (16”)
4 - Installation

GP Series EN
-
+
M1 M2
MULTI-PURPOSE
PUSH-BUTTON
PANEL
WINDLASS
BATTERY
HYDRAULIC-
MAGNETIC
CIRCUIT
BREAKER
(SEE TABLE ON
PAGE 5)
REVERSING
CONTACTOR BOX
MOD. T6411-12 (12V)
MOD. T6415-12 (12V)
MOD. T6415-24 (24V)
FOOT-OPERATED SWITCHES
BROWN
BROWN
BLACK
BLACK
BLUE
BLUE
A1
A2
C
4A FUSE
(12V)
2A (24V)
L = L1 + L2 + L3 + L4 + L5
L3
L2
L1
L4
L5
CHAIN-COUNTER
PUSH-BUTTON PANEL
RRC REMOTE RADIO CONTROLS
POCKET
SIZE
RECEIVER PUSH-BUTTON
PANEL
TRANSMITTERS
CHAIN COUNTER
FROM PANEL
CONTROLS FROM
CONTROL BOARD
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
9
5.0 - Example of connection of GPSeries
with recommended Quick®accessories for the operation of the windlass
5 - Wiring diagram

GP Series
EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
10
6.0 - Important cautions
• Stay clear of chains, ropes and gypsy.
• Operate the windlass from a position where it is possible to supervise the work area
• Make sure the electric motor is not powered when the windlass is used manually (even when using the handle to
disengage the clutch), because people with windlass remote controls (remote push-button panel or radio control)
might accidentally operate it.
• Secure the chain with a retainer before sailing off.
• DO NOT operate the windlass by using the electrical power when the handle is inserted in the drum or into the gypsy cover.
• Quick® recommends using a suitable power fuse/thermal-magnetic/hydraulic-magnetic protection for the motor
used, to protect the motor from overheating or short circuits.
• The circuit breaker can be used to isolate the windlass control circuit, thus avoiding accidental activation.
6.1 - Clutch use
The clutch (B) provides a link between the gypsy and the main shaft (A). The clutch can be released (disengagement) by using
handle (C) which, when inserted into bush (D) of the drum (E) or into the gypsy cover (F), must be turned counter-clockwise.
The clutch will be re-engaged by turning it clockwise.
A
WEIGHING THE ANCHOR
ATurn on the boat engine.
BMake sure the clutch is engaged and remove the handle.
CPress the UP button on the control provided. (*)
Check the upward movement of the chain for the last few meters in order to avoid damage to the bow.
CASTING THE ANCHOR
The anchor can be cast by using the electrical controls or manually.
Manually
The clutch must be disengaged allowing the gypsy to revolve and letting the chain or rope fall into the water.
To slow down the chain, the handle must be turned counter-clockwise.
Electrically
To cast the anchor by using the electrical power, press the DOWN button on the control provided.
In this manner, anchor casting is under control and the chain unwinds evenly.
In order to avoid any stress on the windlass once the boat is anchored, fasten the chain or secure it to a safe point by
means of a rope.
B
RE-ENGAGED
DISENGAGEMENT
D
C
F
E
6 - Cautions & Use

GP Series EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
11
6 - Cautions & Use
6.2 - Use of the drum 1200/1500/2000
WARNING: before any warping operation, ensure that the anchor and its rope or chain are securely fastened to a
bollard or other strong point on the boat.
WARNING: during recovery, keep a suitable safety distance between your hands and the windlass drum.
1. Open the clutch with the lever (C), (at least 2 turns of the
bush (D) counter-clockwise).
2. Remove the lever from the bush (D), wind the rope over
the drum (at least 3 turns).
3. Activate the windlass control by keeping the rope under tension during the recovery. By varying this tension during
recovery, it is possible to change the winding speed of the rope.
X2 Min. 3 turns
CC
DD
6.3 - Troubleshooting
If the windlass stops and the hydraulic magnetic (or thermal magnetic) switch has not tripped, wait a few seconds and try again
(avoid keeping the button pressed). *ref. page 10
If the hydraulic magnetic switch, has tripped, reset it and wait a few minutes before weighing anchor once again.
If, after a number of attempts, the windlass is still blocked, we suggest to move the boat to release the anchor.

GP Series
EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
12
6 - Cautions & Use
6.4 - Automatic free fall system
WARNING: the automatic system must be activated or
deactivated with the clutch closed (engaged) in order to avoid
possible malfunctions of the electromechanical parts.
TURNING THE AUTOMATIC FREE FALL SYSTEM ON
This procedure activates the automatic free fall system.
• Turn cover Auntil hole for pin B isfacingup(asing.1).
• Cut windlass power supply.
• Lock chain using a stopper.
• Pull knob Cuntil pin Bcomesfullyout(asing.2).
• Ensure clutch is closed (engaged).
• Release the chain.
• Restore windlass power supply.
By holding down the DOWN button of the control at your disposal, the
clutch is opened (disengaged) and the gypsy rotates freely in relation to its
axis.
By holding down the UP button of the control at your disposal, the clutch is
closed(engaged)andthegypsystaysxedtoitsaxis.
Casting the anchor with automatic free fall system
With the automatic system activated, press and hold the DOWN button of
the control at your disposal until the point where the anchor can free fall
without any constraints, then release the button.
To slow or stop the anchor's fall, press and hold the UP button on the
control at your disposal until the desired effect is obtained.
Weighing the anchor with automatic free fall system
Carry out the procedure as described in the paragraph 6.1 - WEIGHING THE
ANCHOR.
TURNING THE AUTOMATIC FREE FALL SYSTEM OFF
This procedure deactivates the automatic free fall system.
•TurncoverAuntilholeforpinBisfacingup(asing.1).
• Cut windlass power supply.
• Lock chain using a stopper.
•Usingasuitabletool,presspinBtowardsgypsycentre(asing.3).
• Ensure clutch is closed (engaged).
• Release the chain.
• Restore windlass power supply.
With the automatic free fall system deactivated, the chain can only be
lowered with electrical drive or manually (see section 6.1 - CLUTCH USE).
FIG.1
FIG.2
FIG.3
A
A
A
C
B
C
C
B
B

GP Series EN
GP Series
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
13
WARNING: make sure the electrical power to the motor is switched off when working manually on the windlass.
Carefully remove the chain from the gypsy or the rope from the drum.
Quick® windlasses are made of materials resistant to the marine environment: it is essential, in any case, to periodically
remove salt deposits that form on the external surfaces to avoid corrosion and consequently damage to the device.
Thoroughly wash the surfaces and parts where salt can deposit with fresh water.
Once a year, disassemble the gypsy and the drum according to the following sequence:
WARNING: make sure that the anchor and its rope or chain are securely fastened to a bollard or other strong point
on the boat.
Drum version
• Use the handle (A) to loosen the bush (B); pull off the drum (C1)
• Remove the top clutch cone (D)
• Undo the retaining screws (E) to remove the chain stripper (F)
• Remove the gypsy (G)
• Remove the bottom clutch cone (H)
No-drum version
• Use the handle (A) to remove the gypsy cover (C1)
• Remove the top clutch cone (D)
• Undo the retaining screws (E) to remove the chain stripper (F)
• Remove the gypsy (G)
• Remove the bottom clutch cone (H)
Clean all the parts removed to avoid corrosion, and grease (with marine grease) the shaft thread and the gypsy where the
clutch cones rest.
Remove any oxide deposits from the terminals of the electric motor and the reversing contactor unit; grease them.
Ifrequired,windlassmustbedisassembledbyqualiedpersonnel.
Make sure that the motor gearbox is cold before disassembling it.
The disposal must be carried out according to the regulations of the place where the work is carried out.
7 - Maintenance
Aswithinstallation,attheendofthisproductlife,dismantlingmustbecarriedoutbyqualiedpersonnel.
This product is made up of various materials, some can be recycled and others must be suitably disposed of; enquire about the
recycling or disposal systems provided for by local regulations for this product category.
Some parts of the product may contain pollutants or hazardous substances that, if dispersed, may be harmful to the
environment and human health.
As indicated by the symbol on the side, it is forbidden to dispose of this product as domestic waste.
Separate the products for disposal in accordance with the regulations in force in your area or return the product
to the seller when purchasing a new equivalent product. Local regulations may impose severe penalties for the
improper disposal of this product.
8 - Product disposal
A
B
E
G
H
F
C2
C1

GP Series
EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
14
No. NAME
1 WINDLASS LEVER - NYLON
2 GYPSY COVER
3 CLUTCH CONE
4 A GYPSY 6 MM
4B GYPSY 7 MM - 1/4”
4C GYPSY 8 MM
4D GYPSY 5/16”
5 SCREW
6 GROWER
7 CHAIN STRIPPER
8 OIL SEAL
9 SCREW
10 SCREW
11 WINDLASS COVER
12 PRESSURE LEVER SCREW
13 PRESSURE LEVER SPRING
14 PRESSURE LEVER
15 REED SENSOR
16 CASING GASKET 150W
17 BEARING
18 OUTPUT SHAFT GEAR
19 SHAFT
20 PIN
21 EXTERNAL SNAP RING
22 BEARING
23 GEAR
24 GEAR
25 PIN
26 WINDLASS BASE
27 SCREW
28 SCREW
29 MOTOR
30 SCREW
31 PRESSURE LEVER PIN
32 PIN
33 WASHER
34 ROLLER SHELL
35 GEAR
36 CRANKSHAFT WHEEL
37 GASKET
38 STUDS
39 WASHER
40 SERRATED WASHER
41 NUT
42 HEXAGON HOLLOW CYLINDRICAL
SCREW
43 SPACER
44 O-RING
9 - List of components GP2 500
29
30
31
30
21
22
22
23
22
18
17
27
38
39
40
36
22
41
14
13
12
11
16
10
942
32
33
34
35
33
37
28
15
25
26
17
7
3
8
4
3
2
1
5
6
44
43
20
20
19
22
24

GP Series EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
15
10 - List of components GP2 1200
No. NAME
1 WINDLASS LEVER - NYLON
2 GYPSY COVER
3 WINDLASS CLUTCH CONE
4 A GYPSY 6 MM
4B GYPSY 7 MM - 1/4”
4C GYPSY 8 MM
4D GYPSY 5/16”
5 SCREW
6 GROWER
7 CHAIN STRIPPER
8 BUSH
9 DRUM
10 OIL SEAL
11 SCREW
12 GRUB SCREW
13 WINDLASS COVER
14 PRESSURE LEVER SCREW
15 PRESSURE LEVER SPRING
16 PRESSURE LEVER
17 REED SENSOR
18 CASING GASKET
19 BEARING
20 OUTPUT SHAFT Z88 GEAR
21 SERIES SHAFT
22 SPINA 8X16
23 SERIES LONG SHAFT
24 KEY
25 EXTERNAL SNAP RING
26 BEARING
27 GEAR
28 GEAR
29 WINDLASS BASE
30 SCREW
31 MOTOR
32 SCREW
33 PIN
34 PIN
35 WASHER
36 ROLLER SHELL
37 GEAR
38 CRANKSHAFT GEAR
39 GASKET
40 STUDS
41 WASHER
42 SERRATED WASHER
43 NUT
44 SPACER
45 O-RING
46 GYPSY COVER FF
47 SPRING
48 BRAKE PIN
49 BRAKE PIN COVER
50 KNOB
51 SCREW
52 DOWEL
53 PIN
54 SPRING
26
27
26
20
19
30
40
41
42
31
38
32
33
26
43
22
16
15
14
13
18
12 11
32
33
34
35
36
37
35
39
17
22
29
19
7
3
10
4
46
50
51
53
54
52
48
47
49
3
2
9
8
1
5
6
22
24
22
22
25
22
25
23
21
26
26
28
45
44

GP Series
EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
16
11 - List of components GP2 1500/2000
3
22
17
50
45
23
17
53
24
25
24
30
15
46
47
3
26
28
21 18 20 19 27 18
27
27
10
9
7
8
7
1
43
12
11 3
5
6
5
4
3
252
13
51
38
39
40
41
42
14
48
44
32
31
35
34
34
49
36
51
33
29
16
37
59
60
58
54
61
62
56
55
57
No. NAME
1 A MOTOR 800W 12V
1B MOTOR 800W 24V
1C MOTOR 500W 12V
2 SOLAR GEAR
3 PIN
4 FIXED CROWN
5 SCREW
6 RING Ø 80
7FIFTH WHEEL
8 PLANETARY GROUP
9 MOBILE CROWN
10 BEARING
11 SNAP RING
12 KEY
13 SCREW
14 PRESSURE LEVER
15 PRESSURE LEVER SPRING
16 PRESSURE LEVER SCREW
17 PIN
18 WASHER
19 IDLE GEAR
20 BEARING
21 PIN
22 SCREW
23 WINDLASS BASE
24 BEARING
25 SNAP RING
26 OUTPUT GEAR
27 PIN
28 SHORT SHAFT
29 OIL SEAL
30 WINDLASS COVER
31 ASSEMBLED REED SENSOR
32 CHAIN STRIPPER
33 SCREW
34 WINDLASS CLUTCH CONE
35 A GYPSY “GP2” 6 MM
35B GYPSY “GP2” 7 MM - 1/4”
35C GYPSY “GP2” 8 MM
35D GYPSY “GP2” 5/16”
36 GYPSY COVER
37 NYLON WINDLASS LEVER
38 GASKET/TEMPLATE
39 STUD
40 WASHER
41 SERRATED WASHER
42 NUT
43 CABLE
44 SCREW
45 CASING GASKET
46 LONG SHAFT
47 KEY
48 DRUM
49 BUSH
50 PIN
51 GROWER
52 PIN
53 CABLE GLAND
54 GYPSY COVER FF
55 SPRING
56 BRAKE PIN
57 BRAKE PIN COVER
58 DOWEL
59 PIN
60 SPRING
61 KNOB
62 SCREW

GP Series EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
17
12 - Spare parts
1 2 3
4
5
12
7
9
8
10
6
11 13
14 16
15
POS. NAME
1 A OSP GYPSY GP2 500/1200 5/16” FVSSB070516MA00
1B OSP GYPSY GP2 500/1200 6MM FVSSB0706G0MA00
1C OSP GYPSY GP2 500/1200 7MM-1/4” FVSSB070714MA00
1D OSP GYPSY GP2 500/1200 8MM FVSSB0708G0MA00
1E OSP GYPSY GP2 500/1200 ROPE FVSSB07CMG00A00
1F OSP GYPSY GP2 1500/2000 6MM FVSSBGP20006A00
1G OSP GYPSY GP2 1500/2000 8MM FVSSBGP20008A00
1H OSP GYPSY GP2 1500/2000 7MM-1/4” FVSSBGP20714A00
1I OSP GYPSY GP2 1500/2000 5/16” FVSSBGP20516A00
1M OSP GYPSY ROPE 1500/2000 GP2 FVSSBGP20CM0A00
2 OSP CLUTCH CONE KIT GP2 FVSSCFG00000A00
3 A OSP PRESSURE LEVER KIT GP2 500/1200 FVSSTCMG0000A00
3B OSP PRESSURE LEVER KIT GP2 1500/2000 FVSSTCGP2200A00
4 OSP STRAIGHT NYLON WINDLASS LEVER FVSSLVSDN000A00
5 OSP GYPSY COVER “SERIES 2” FVSSCPBBASG0A00
6 A OSP PIN GUIDE KIT GP2 500/1200 FF FVSSGPGFFS00A00
6B OSP PIN GUIDE KIT GP2 FF 1500/2000 FVSSGPGFF000A00
7 OSP GYPSY COVER “GP2” FF COMPLETE FVSSCPBBGFF0A00
8OSP WINDLASS DRUM “SERIES 2” STAINLESS
STEEL FVSSMSE0800XA00
9 OSP DRUM BUSH “SERIES 1-2” FVSSGMSDCP05000
10 A OSP TRANS. KIT 1200 GP2 FF FVSSGP1200FFA00
10B OSP TRANS. KIT 1500/2000 GP2 FF FVSSGP1520FFA00
11 A OSP TRANS. KIT WITHOUT DRUM 500/1200 GP2 FVSSGP051200A00
11B OSP TRANS. KIT WITHOUT DRUM 1500/2000 GP2 FVSSGP152000A00
12 OSP TRANS. KIT WITH DRUM 1500/2000 GP2 FVSSGP1520D0A00
13 OSP FIXING KIT GP2 500/1200 FVSSFSGP2120A00
14 OSP FIXING KIT GP2 15/2000 FVSSFSGP2200A00
15 OSP CASING GASKET KIT GP2 500/1200 FVSSGP212GC0A00
16 OSP CASING GASKET KIT GP2 15/2000 FVSSGP220GC0A00

GP Series
EN
QUICK GPSeries INSTALLATION AND USER’S MANUAL - REV000A
18
13 - Dimensions
213 (8 23/64)
129 (5
3
/
32
) 184 (7
17
/
64
)
197 (7
49
/
64
)
249 (9
25
/ 32 )
135 (5
5
/
16
) 217 (7
31
/
32
)
GPSeries 500 - 1200 - 1200 D - 1200 FF
GPSeries 1500 - 1500 D - 1500 FF - 2000 - 2000 D - 2000 FF
GENERIC IMAGES

QUICK®S.p.A. - Via Piangipane, 120/A - 48124 Piangipane (RAVENNA) - ITALY
Tel. [phone] - Fax [phone] - www.quickitaly.com - [e-mail]
GP Series REV 000A
GP2 500
GP2 1200
GP2 1200 D
GP2 1200 FF
GP2 1500
GP2 1500 D
GP2 1500 FF
GP2 2000
GP2 2000 D
GP2 2000 FF
Product serial number
