Quick Prince DP1 Series User manual

REV 001b
High Quality Nautical Equipment
Manuale d'uso SALPA ANCORA VERTICALI
User's Manual VERTICAL WINDLASSES
Manuel de l'utilisateur GUINDEAUX VERTICAUX
Benutzerhandbuch VERTIKAL ANKERWINDEN
Manual del usuario MOLINETES VERTICALES
DP1 SERIE PRINCE
300/500W
DP1 312
DP1 512
DP1 524
IT
GB
FR
DE
ES

3
DP1 300/500W - REV001B
Pag. 4 Caratteristiche tecniche
Pag. 5 Installazione
Pag. 6 Schema di collegamento
Pag. 7 Uso - Avvertenze importanti
Pag. 8/9 Manutenzione
Pag. 10/11 Set
Pag. 12 Technical data
Pag. 13 Installation
Pag. 14 Connection diagram
Pag. 15 Usage - Warning
Pag. 16/17 Maintenance
Pag. 18/19 Set
Pag. 20 Caractéristiques techniques
Pag. 21 Installation
Pag. 22 Schéma de cablage
Pag. 23 Utilisation - Avvertissements importants
Pag. 24/25 Entretien
Pag. 26/27 Groupe
Seite 28 Technische Eigenschaften
Seite 29 Montage
Seite 30 Anschlussplan
Seite 31 Gebrauch - Wichtige Hinweise
Seite 32/33 Wartung
Seite 34/35 Gruppe
Pág. 36 Características técnicas
Pág. 37 Instalación
Pág. 38 Esquema de montage
Pág. 39 Uso - Advertencias importantes
Pág. 40/41 Mantenimiento
Pág. 42/43 Grupo
INDICE
INDEX
SOMMAIRE
INHALTSANGABE
INDICE
IT
GB
FR
DE
ES

12
TECHNICAL DATA
GB
DP1 300/500W - REV001B
Quick®reserves the right to introduce changes to the equipment and the contents of this manual without prior notice.
In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text.
F
1° EXAMPLE: DP1312D DP1 312 D
a
DP1 524 -
Name of the line:
[ DP1 ]
Motor power:
[ 3 ] = 300 W
[ 5 ] = 500 W
Motor supply voltage:
[ 12 ] = 12 V
[ 24 ] = 24 V
Drum:
[ D ] = with drum
[ - ] = without drum
(1) After an initial period of use.
(2) Measurements taken with a gypsy for a 8 mm chain.
(3) Minimum allowable value for a total length L<20m (see pag. 44). Determine the cable size according to the length of the wiring.
(4) With circuit breaker designed for direct currents (DC) and delayed-action (thermal-magnetic or hydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
(6) Only on request.
HOW TO IDENTIFY THE WINDLASS THROUGH THE CODE:
A B C D
A B C D A B C D
2° EXAMPLE: DP1524
a a a a a a a
85 (3 7/32)
271 (9 5/8)
61 (2
13
/
32
)69 (2
23
/
32
)
181 (7 23/32)
122 (4
11/16)
134,4 (5 9/32)
75,4 (2 31/32)
DIMENSIONS OF MODELS mm ( inch ) • DP1 300 / 500W - / D
(*) For the gypsy codes, please consult the exploded drawing on page 16.
MODELS
DP1 – / D DP1 HI SPEED (6)
MOTOR POWER
300W 500W 500W
Motor supply voltage 12V 12V 24V 12V 24V
Maximum pull 370 kg (815,7 lb) 660 kg (1455,0 lb) 600 kg (1322,8 lb)
Maximum working load 120 kg (264,5 lb) 200 kg (440,9 lb) 220 kg (485,0 lb) 170 kg (374,8 lb) 200 kg (440,9 lb)
Working load 40 kg (88,2 lb) 65 kg (143,3 lb) 70 kg (154,3 lb) 65 kg (143,3 lb) 70 kg (154,3 lb)
Current absorption @ working load (1) 65 A 80 A 40 A 100 A 50 A
Maximum chain speed (2) m/min 26,3 (86,3 ft/min) 28,9 (94,8 ft/min) 28,2 (92,5 ft/min) 43,0 (141,1 ft/min) 42,5 (139,4 ft/min)
Max. chain speed @ working load (2) m/min 24,4 (80,1 ft/min) 24,3 (79,7 ft/min) 24,1 (79,1 ft/min) 34,5 (113,2 ft/min) 35,0 (114,8 ft/min)
Motor cable size (3) 16 mm
2
(AWG5) 10 mm
2
(AWG7) 25 mm
2
(AWG3) 10 mm
2
(AWG7)
Protection circuit breaker (4) 50 A 60 A 40 A 80 A 40 A
Deck thickness (5) 20 ÷ 30 mm (25/32” ÷ 1” 3/16)
Weight - model without drum 7,6 Kg (16,7 lb)
Weight - model with drum 8,4 Kg (18,5 lb)
GYPSY (*) 6 mm 1/4”
Chain size 6 mm 6 mm 1/4”
DIN 766 ISO BBB

13
INSTALLATION
GB
DP1 300/500W - REV001B
WARNING: before wiring up, be sure the electrical cables are not live.
BEFORE USING THE WINDLASS READ THESE INSTRUCTIONS CAREFULLY.
IF IN DOUBT, CONTACT YOUR NEAREST “QUICK
®
” DEALER.
WARNING: the Quick
®
windlasses are designed to weigh the anchor. Do not use the equipment for other purposes.
Quick
®
shall not be held responsible for damage to equipment and/or personal injury, caused by a faulty use
of the equipment. The windlass is not designed for the loads that might occur in extreme weather conditions (storms).
Always deactivate the windlass when not in use. Check that there are no swimmers nearby before dropping anchor.
The splice between the rope and the chain must be tightly woven for the rope to slide easily into the gypsy shape. For
any problem or request, feel free to contact Quick
®
Technical Service. For improved safety we recommend installing at
least two anchor windlass controls in case one is accidentally damaged. We recommend the use of the Quick
®
hydraulic-
magnetic switch as the motor safety switch. Secure the chain with a further device before starting the navigation.
The contactor unit or reversing contactor unit must be installed in a point protected from accidental water contact.
After completing the anchorage, secure the chain or rope to fixed points such as chain stopper or bollard.
To prevent accidental releases, the anchor must be secured. The windlass shall not be used as the only securing device.
Isolate the windlass from the power system during navigation (switch the circuit breaker off) and lock the chain securing it to
a fixed point of the boat.
THE PACKAGE CONTAINS: windlass (on deck unit + motorgearbox) - reversing contactor unit - base gasket - drill template - handle
- bolts and screws (for assembly) - user’s manual - conditions of warranty.
TOOLS REQUIRED FOR INSTALLATION: drill and drill bits: 9 mm (23/64") and Ø 11 mm (7/16”); Ø 46 mm (1"13/16) and Ø 62 mm
(2"7/16) hollow mill; hexagonal wrench: 13 mm.
“QUICK®”ACCESSORIES RECOMMENDED: anchoring RL control board (mod. 800) - Waterproof hand helds R/C (mod. HRC1002)
- Foot switch (mod. 900) - Hydraulic-magnetic circuit breaker - Anchor chain counter (mod. CHC1102M and CHC1202M) - Radio control
RRC (mod. R02, PO2, H02).
INSTALLATION REQUIREMENTS: the windlass must be positioned with the gypsy aligned with the bow roller. Ensure that the up-
per and lower surfaces of the deck are as parallel as possible. If this is not the case, compensate the difference appropriately (a lack of
parallelism could result in a loss of motor power). The deck thickness must be included among the figures listed in the table. In cases of
other thicknesses it is necessary to consult a Quick
®
retailer. There must be no obstacles under deck to the passage of cables, rope and
chain; lack of depth of the peak could cause jamming.
FITTING PROCEDURE: when the ideal position has been established, drill four holes using the drilling template provided.Remove
excess material from the chain passage, refine and flatten with a specialized product (marine paint, gel coat or two pack epoxy) to
assure free passage for both rope and chain. Position the upper section, inserting the gasket between the deck and the base and
connect the lower section to the assembly, inserting the shaft into the reduction unit. Fix the windlass by screwing the nuts onto the
fixing studs. Connect the supply cables from the windlass to the reversing contactor unit.
Max
5 mm
(3/16”)
40 cm (16”)
P A I N T
45°
Available motorgear-
boxes positioning

14
GB
DP1 300/500W - REV001B
-
+
BASIC SYSTEM
SEE PAGE 44
SHOWING THE MAIN
CONNECTION DIAGRAM
MULTI-PURPOSE
WATERTIGHT HAND HELD
REMOTE CONTROL
MOD. HRC 1002
WINDLASS
MOTOR
BATTERY
HYDRAULIC-
MAGNETIC
CIRCUIT
BREAKER
(see table on
page 12)
REVERSING
CONTACTOR UNIT
MOD. T6415-12 (12V)
MOD. T6415-24 (24V)
CA2
FOOT SWITCHES MOD. 900U AND 900D
BLACK
BROWN
BLUE
A1
FUSE
4A (12V)
2A (24V)
BROWN
BLACK
BLUE
L = L1 + L2 + L3 + L4 + L5
L1
L2 L3
L4
L5
CONNECTION DIAGRAM
RADIO POCKET
WATERTIGHT
PANEL
CHAIN COUNTER
WINDLASSES
CONTROL
BOARD
WATERTIGHT HAND HELD
CHAIN COUNTER
HANDHELD
RECEIVER
QUICK
®
ACCESSORIES
FOR WINDLASS OPERATION
TRANSMITTERS
REMOTE RADIO CONTROLS
RADIO POCKET

15
GB
DP1 300/500W - REV001B
WARNING
WARNING: stay clear of the chains, ropes and gypsy. Make sure the electric motor is off when windlass is used manu-
ally (even when using the handle to disengage the clutch). In fact people with windlass remote controls (hand-held re-
mote control or radio-controlled systems) might accidentally operate it.
WARNING :secure the chain with a device before starting the navigation.
WARNING :do not operate the windlass by using the electrical power when the handle is inserted in the drum or into
the gypsy cover.
WARNING :Quick
®
recommend using a circuit breaker designed for direct current (DC) with delayed-action (thermal-
magnetic or hydraulic-magnetic) to protect the motor supply line from overheating or short circuits. The circuit breaker
can be used to cut off power to the windlass control circuit and so avoid accidental activation.
CLUTCH USE
The clutch (5) provides a link between the gypsy and the main shaft (11 or 12). The clutch can be released (disengagement)
by using the handle (1) which, when inserted in the bush (2) of the drum or into the gypsy cover (4), must be turned counter-
clockwise. The clutch will be re-engaged by turning it clockwise (engagement).
WEIGHING THE ANCHOR
Turn on the engine. Make sure the clutch is engaged and remove the handle. Press the UP button on the control provided.
If the windlass stops and the hydraulic magnetic switch (or thermal cutout) has not tripped, wait a few seconds and try again
(avoid keeping the button pressed).
If the hydraulic magnetic switch, has tripped, reset it and wait a few minutes before weighing anchor once again.
If, after a number of attempts, the windlass is still blocked, we suggest to move the boat to release the anchor. Check the up-
ward movement of the chain for the last few meters in order to avoid damages to the bow.
CASTING THE ANCHOR
The anchor can be cast by using the electrical control or manually. To operate manually, the clutch must be disengaged allow-
ing the gypsy to revolve and letting the rope or chain fall into the water. To slow down the chain, the handle must be turned
clockwise.
To cast the anchor by using the electrical power, press the DOWN button on the control provided. In this manner, anchor cast-
ing is under control and the chain and rope unwind evenly.
In order to avoid any stress on the windlass -once the boat is anchored- fasten the chain or secure it in place with a rope.
USAGE

16
GB
DP1 300/500W - REV001B
MAINTENANCE
43
42
44
41
45
40
39
38
36
34
35
31
30
32
1
2
3
4
6
21
22
7
15
8
9
10
11
13
14
14
14
12
9
5
5
33
37
16
24
25
27
29
28
20
17
18
23
26
19
POS. DESCRIPTION CODE
1 Straight windlass lever - nylon PVLVSDN00000
2 Bush SGMSD0400000
3 Drum MSE050000R03
4 Gypsy cover ZSPMSGB05R03
5 Clutch cone DP1 MSFDP1000000
6 Gypsy 500W 6mm MSB040600000
7 Oil seal 20*42*7mm PGPRL2042700
8 Anello elastico interno MBAN4217Y000
9 Anello elastico esterno MBAE2012Y000

17
GB
DP1 300/500W - REV001B
MAINTENANCE
WARNING: make sure the electrical power to the motor
is switched off when working manually on the windlass.
Carefully remove the chain from the gypsy or the rope from
the drum.
Quick
®
windlasses are manufactured with materials resistant to
marine environments. In any case, any salt deposits on the outside
must be removed periodically to avoid corrosion and damage to
the equipment. The parts where salt may have built up should be
washed thoroughly with fresh water.
Once a year, the drum and the gypsy are to be taken apart as fol-
lows:
DRUM VERSION
Use the handle (1) to loosen the bush (2); pull off the drum (3) and
the top clutch cone (5); loosen the fixing screws (20) of the rope/
chain stripper (21) and remove it. Pull off the gypsy (6).
NO-DRUM VERSION
Use the handle (1) to remove the gypsy cover (4); remove the top
clutch cone (5); loosen the fixing screws (20) of the rope/chain strip-
per (21) and remove it. Pull off the gypsy (6).
Clean all the parts removed to avoid corrosion, and grease the shaft
thread (11 or 12) and the gypsy (6) where the clutch cones rest (5).
Clean all the parts removed to avoid corrosion, and grease the shaft
thread (11 or 12) and the gypsy (6) where the clutch cones rest (5).
Remove any oxide deposits from the terminals of the electric motor
and the reversing contactor unit; grease them.
POS. DESCRIPTION CODE
10 Bearing MBJ160040000
11 Shaft DP1 MSASDP100R00
12 Shaft DP1 D MSASDP1D0R00
13 Key 6*6*25 MBH060625X00
14 Key 6*6*50 MBH060650X00
15 Oil seal 20*35*7mm PGPRL2035700
16 Chain guide cover DP1 PDGCDP100000
17 Plastic chain pipe DP1 PDPSSDP10R01
18 Screw M 4*30 stainless steel MBV0430MXVEP
19 Screw M 5*30 stainless steel MBV0530MXCE0
20 Screw M 5*40 stainless steel MBV0540MXCE0
21 Chian stripper DP1 stainless steel SPMSNDP10000
22 Plug 4*22 stainless steel MBSC04022A00
23 Screw M 6*12 stainless steel MBV0612MXTSC
24 Cover base DP1 stainless steel SPMSGB0DP1X0
25 Insert plastic cover DP1 PDNC0DP10000
26 Nut M4 MBD04MXEN000
27 Nut M5 MBD05MXEN000
28 Round base DP1
anodized aluminium SGMSC0DP1A00
29 Gasket / jig PGBSDP100000
30 Sensor KNREEDCL0000
31 Stud MBP080608X00
32 Gearbox flange gasket
300/500W PGFLRDTG4000
33A Gearbox 500W Quick series SLMR05TG4000
33B Gearbox “Hi Speed” 500W
Quick series SLMR05TG40HS
34 Washer MBR08X000000
35 Spring washer MBR08XDE0000
36 Nut MBD08MXEN000
37 Screw MBV0516MXE00
38 Geared motor seal PGBMR0400000
39 Key MBH040415F00
40A Electric motor 300W 12V EMF031200000
40B Electric motor 500W 12V EMF051200000
40C Electric motor 500W 24V EMF052400000
41 Flange gasket PGGPMFN04000
42
Motor casing watertight 300/500W PCCCPM040000
43 Poles gasket
electric motor 300/500W PGGPMPM04000
44 Bottom protec cover
electric motor 300/500W PCCPPMFN0400
45 Screw MBV03916AXCC

18
GB
DP1 300/500W - REV001B
SET
TOP WITH DRUM - DP1
CODE
OSP TOP DP1 1/4” D FVSSTDP1D001A00
OSP TOP DP1 6MM D FVSSTDP1D006A00
DRUM - DP1
CODE
OSP WINDLASS DRUM 500W Ø50MM FVSSMSE04000A00
COMPLETE BASE - DP1
CODE
OSP WINDLASS BASE SERIES DP1 COMP FVSSBDP110C00A00
* OSP CHAIN GUIDE COVER KIT DP1 FVSSCPSCDP10A00
* CHAIN GUIDE
COVER KIT

19
GB
DP1 300/500W - REV001B
SET
GEARBOX
CODE
OSP GEARBOX 500W WINDLASS QUICK TG40 FVSSMR05TG40A00
OSP GEARBOX 500W WINDLASS QUICK TG40 HS FVSSMR0540HSA00
MOTORGEARBOX
CODE
OSP MOTORGEARBOX 300W 12V QUICK FVSSR0312Q00A00
OSP MOTORGEARBOX 500W 12V QUICK FVSSR0512Q00A00
OSP MOTORGEARBOX 500W 12V QUICK HS FVSSR0512QHSA00
OSP MOTORGEARBOX 500W 24V QUICK FVSSR0524Q00A00
OSP MOTORGEARBOX 500W 24V QUICK HS FVSSR0524QHSA00
ELECTRIC MOTOR
CODE
OSP ELECTRIC MOTOR WINDLASS 300W 12V FVSSM0312000A00
OSP ELECTRIC MOTOR WINDLASS 500W 12V FVSSM0512000A00
OSP ELECTRIC MOTOR WINDLASS 500W 24V FVSSM0524000A00
TOP WITHOUT DRUM - DP1
CODE
OSP TOP DP1 1/4” FVSSTDP10001A00
OSP TOP DP1 6MM FVSSTDP10006A00

44
DP1 300/500W - REV001B
44
MAIN CONNECTION DIAGRAM
QUICK
®
WINDLASS
WATERTIGHT HAND
HELD
CHAIN-COUNTER
MOD. CHC 1102 M
MULTI-PURPOSE
WATERTIGH
HAND HELD
REMOTE
CONTROL
MOD. HRC 1002
WATERTIGHT PANEL
CHAIN-COUNTER
MOD. CHC 1202 M
WINDLASSES
CONTROL BOARD
MOD. 800
L = L1 + L2 + L3 + L4 + L5
SENSOR
MOTOR
FUSE
4A (12V) 2A (24V)
BATTERY
HYDRAULIC
MAGNETIC
CIRCUIT BREAKER
(see table on page
4/12/20/28/36)
C
A2 A1
REVERSING CONTACTOR UNITS MOD. T6415-12 (12V) MOD. T6415-24 (24V)
L1
L2
L3
BLUE
BROWN
BLACK
BLUE
BROWN
BLACK
UP
SENSOR
DOWN
-
+
GREY
RED
GREEN
BROWN
WHITE
BLUE
BLACK
BLUE
BROWN
BLACK
L4
150
CAN H
CAN L
CAN H
CAN L
CAN L
CAN H
L5
MOD. 900/D
DOWN
FOOT SWITCH
MOD. 900/U
UP
UP
DOWN
-
+
RADIO RECEIVER RRC MOD. R02 (2CH)

NOTE
NOTES - NOTES - NOTIZEN - NOTAS

NOTE
NOTES - NOTES - NOTIZEN - NOTAS

QUICK®S.p.A. - Via Piangipane, 120/A - 48124 Piangipane (RAVENNA) - ITALY
Tel. [phone] - Fax [phone]
www.quickitaly.com - E-mail: [e-mail]
Codice e numero seriale del prodotto
Product code and serial number
Code et numéro de série du produit
Code- und Seriennummer des Produkts
Código y número de serie del producto
GB
FR
DE
IT
ES
DP1 SERIE PRINCE
300/500W
R001b
