R&S CMW-KM5 Series User manual

R&S®CMW-KM5xx/-KS5xx
LTE UE Firmware Applications
User Manual
User Manual
1173.9628.02 ─ 21
(;×îL2)
Test & Measurement
深圳德标仪器 135-1095-0799

This user manual describes the following R&S®CMW options:
●R&S®CMW-KM500 (LTE FDD R8, TX measurement, uplink)
●R&S®CMW-KM502 (LTE FDD R10 UL CA, TX measurement, uplink)
●R&S®CMW-KM550 (LTE TDD R8, TX measurement, uplink)
●R&S®CMW-KM552 (LTE TDD R10 UL CA, TX measurement, uplink)
●R&S®CMW-KM012 (TX measurement, multi evaluation list mode)
●R&S®CMW-KS500 (LTE FDD R8, SISO, basic signaling)
●R&S®CMW-KS502 (LTE FDD R10, CA, basic signaling)
●R&S®CMW-KS510 (LTE R8, SISO, advanced signaling)
●R&S®CMW-KS512 (LTE R10, CA, advanced signaling)
●R&S®CMW-KS520 (LTE MIMO 2x2, generic signaling)
●R&S®CMW-KS521 (LTE MIMO 4x2, generic signaling)
●R&S®CMW-KS522 (LTE MIMO 8x2, generic signaling)
●R&S®CMW-KS525 (LTE user-defined bands, generic signaling)
●R&S®CMW-KS550 (LTE TDD R8, SISO, basic signaling)
●R&S®CMW-KS552 (LTE TDD R10, CA, basic signaling)
●R&S®CMW-KE100 (Basic fading support: AWGN generator)
●R&S®CMW-KE500 (LTE fading profiles TS 36.521, excerpts)
●R&S®CMW-KE501 (LTE fading profiles MIMO 4x2 from TS 36.521 B2.3)
●R&S®CMW-KE502 (LTE fading profiles MIMO 8x2 from TS 36.521 B2)
© 2015 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
The following abbreviations are used throughout this manual: R&S®CMW is abbreviated as R&S CMW.
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
3User Manual 1173.9628.02 ─ 21
Contents
1 Preface.................................................................................................... 9
1.1 R&S CMW Models......................................................................................................... 9
1.2 How to Read Firmware Application Chapters............................................................ 9
1.2.1 General Description...................................................................................................... 10
1.2.2 Application Sheets........................................................................................................ 10
1.2.3 GUI Reference.............................................................................................................. 10
1.2.4 Programming Examples................................................................................................10
1.2.5 Command Reference.................................................................................................... 11
2 LTE Signaling....................................................................................... 12
2.1 What's New in this Revision.......................................................................................12
2.2 General Description.................................................................................................... 14
2.2.1 Scenarios...................................................................................................................... 14
2.2.2 Test Setups................................................................................................................... 17
2.2.3 Initiating Signaling Tests............................................................................................... 24
2.2.4 Carrier Aggregation.......................................................................................................25
2.2.5 External Fading............................................................................................................. 27
2.2.6 Internal Fading.............................................................................................................. 28
2.2.7 Data Tests and Voice Over LTE................................................................................... 29
2.2.8 Audio Tests and Speech Quality Tests......................................................................... 30
2.2.9 Connection States.........................................................................................................30
2.2.10 Handover.......................................................................................................................34
2.2.11 Physical DL Channels and Signals............................................................................... 36
2.2.12 MIMO and Beamforming............................................................................................... 40
2.2.13 Scheduling Type RMC.................................................................................................. 45
2.2.14 User-Defined Channels.................................................................................................61
2.2.15 CQI Channels................................................................................................................64
2.2.16 Semi-Persistent Scheduling (SPS)............................................................................... 67
2.2.17 Operating Bands........................................................................................................... 68
2.2.18 Trigger Signals.............................................................................................................. 71
2.2.19 Relative Power Control Tests........................................................................................72
2.2.20 Extended BLER Measurement......................................................................................75
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
4User Manual 1173.9628.02 ─ 21
2.2.21 RLC Throughput Measurement.....................................................................................86
2.3 Application Sheets......................................................................................................88
2.3.1 Combined Signal Path Measurements..........................................................................88
2.3.2 LTE IP-Based Data Tests............................................................................................. 92
2.3.3 VoLTE Call Setup and Audio Tests...............................................................................96
2.4 GUI Reference........................................................................................................... 108
2.4.1 Signaling View.............................................................................................................109
2.4.2 Signaling Control.........................................................................................................128
2.4.3 Using the Shortcut Softkeys........................................................................................133
2.4.4 General Settings......................................................................................................... 134
2.4.5 I/Q Settings................................................................................................................. 137
2.4.6 RF Settings................................................................................................................. 138
2.4.7 Internal Fading............................................................................................................ 145
2.4.8 Downlink Power Levels............................................................................................... 150
2.4.9 Uplink Power Control.................................................................................................. 153
2.4.10 Physical Cell Setup..................................................................................................... 159
2.4.11 Network Settings......................................................................................................... 165
2.4.12 Connection Configuration............................................................................................176
2.4.13 CQI Reporting............................................................................................................. 207
2.4.14 UE Measurement Report Settings.............................................................................. 210
2.4.15 Messaging (SMS) Parameters.................................................................................... 211
2.4.16 Shortcut Configuration................................................................................................ 215
2.4.17 Message Monitoring Settings......................................................................................215
2.4.18 BLER Measurement Configuration............................................................................. 216
2.4.19 RLC Throughput Measurement Configuration............................................................ 220
2.4.20 Annex: UE Capabilities............................................................................................... 223
2.5 Programming.............................................................................................................237
2.5.1 General Configuration................................................................................................. 238
2.5.2 BLER Tests................................................................................................................. 264
2.5.3 RLC Throughput Tests................................................................................................268
2.6 Command Reference................................................................................................ 270
2.6.1 Conventions and General Information........................................................................ 270
2.6.2 General Settings......................................................................................................... 276
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
5User Manual 1173.9628.02 ─ 21
2.6.3 Connection Control and States................................................................................... 279
2.6.4 Event Log.................................................................................................................... 292
2.6.5 UE Measurement Report Contents............................................................................. 293
2.6.6 UE Capabilities............................................................................................................300
2.6.7 UE Info........................................................................................................................ 330
2.6.8 Routing Settings..........................................................................................................332
2.6.9 Internal Fading............................................................................................................ 368
2.6.10 Downlink Power Levels............................................................................................... 377
2.6.11 Uplink Power Control.................................................................................................. 382
2.6.12 Physical Cell Setup..................................................................................................... 393
2.6.13 Network Settings......................................................................................................... 400
2.6.14 Connection Configuration............................................................................................422
2.6.15 CQI Reporting Settings............................................................................................... 488
2.6.16 UE Measurement Report Settings.............................................................................. 491
2.6.17 Messaging (SMS)........................................................................................................493
2.6.18 Message Monitoring Settings......................................................................................499
2.6.19 BLER Measurement....................................................................................................500
2.6.20 RLC Throughput Measurement...................................................................................521
2.7 List of Commands.....................................................................................................526
3 LTE Multi Evaluation Measurement..................................................542
3.1 What's New in this Revision.....................................................................................542
3.2 General Description.................................................................................................. 543
3.2.1 LTE TX Tests.............................................................................................................. 543
3.2.2 LTE RX Tests..............................................................................................................549
3.2.3 List Mode.....................................................................................................................550
3.2.4 LTE UL Signal Properties............................................................................................556
3.2.5 Limit Settings and Conformance Requirements..........................................................559
3.2.6 Measurement Results................................................................................................. 569
3.3 GUI Reference........................................................................................................... 588
3.3.1 Measurement Control..................................................................................................588
3.3.2 Accessing Parameters and Settings........................................................................... 589
3.3.3 Signal Routing and Analyzer Settings.........................................................................589
3.3.4 Carrier Aggregation Settings.......................................................................................593
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
6User Manual 1173.9628.02 ─ 21
3.3.5 Measurement Control Settings....................................................................................597
3.3.6 Trigger Settings...........................................................................................................612
3.3.7 Limit Settings...............................................................................................................615
3.3.8 Shortcut Configuration................................................................................................ 615
3.3.9 Additional Softkeys and Hotkeys.................................................................................616
3.3.10 Measurement Results................................................................................................. 617
3.4 Programming.............................................................................................................619
3.4.1 General Examples.......................................................................................................620
3.4.2 Using LTE List Mode...................................................................................................627
3.5 Command Reference................................................................................................ 633
3.5.1 Conventions and General Information........................................................................ 633
3.5.2 General Measurement Settings.................................................................................. 638
3.5.3 Multi Evaluation Measurement Commands................................................................ 649
3.5.4 Combined Signal Path Commands............................................................................. 782
3.6 List of Commands.....................................................................................................784
4 LTE PRACH Measurement................................................................ 797
4.1 What's New in this Revision.....................................................................................797
4.2 General Description.................................................................................................. 797
4.2.1 Test Setup...................................................................................................................798
4.2.2 How to Measure an Uplink PRACH Signal................................................................. 798
4.2.3 Defining the Scope of the Measurement.....................................................................799
4.2.4 Parallel Signaling and Measurement.......................................................................... 800
4.2.5 Trigger Modes............................................................................................................. 800
4.2.6 Calculation of Modulation Results...............................................................................801
4.2.7 LTE PRACH UL Signal Properties.............................................................................. 802
4.2.8 Limit Settings and Conformance Requirements..........................................................804
4.2.9 Measurement Results................................................................................................. 806
4.3 GUI Reference........................................................................................................... 815
4.3.1 Measurement Control..................................................................................................815
4.3.2 Parameters and Settings.............................................................................................816
4.3.3 Measurement Results................................................................................................. 830
4.4 Programming.............................................................................................................833
4.4.1 Key Features...............................................................................................................833
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
7User Manual 1173.9628.02 ─ 21
4.4.2 Specifying General and Common Measurement Settings.......................................... 834
4.4.3 Specifying Required PRACH Settings........................................................................ 834
4.4.4 Specifying Additional Measurement-Specific Settings................................................ 834
4.4.5 Configuring the Trigger System.................................................................................. 835
4.4.6 Specifying Limits......................................................................................................... 835
4.4.7 Performing Single-Shot Measurements...................................................................... 836
4.4.8 Single-Shot and Continuous Measurements...............................................................837
4.5 Command Reference................................................................................................ 838
4.5.1 Conventions and General Information........................................................................ 838
4.5.2 General Measurement Settings.................................................................................. 842
4.5.3 PRACH Measurement Commands............................................................................. 842
4.5.4 Combined Signal Path Commands............................................................................. 871
4.6 List of Commands.....................................................................................................872
5 LTE SRS Measurement......................................................................875
5.1 What's New in this Revision.....................................................................................875
5.2 General Description.................................................................................................. 875
5.2.1 Test Setup...................................................................................................................875
5.2.2 How to Measure an Uplink SRS Signal.......................................................................876
5.2.3 Parallel Signaling and Measurement.......................................................................... 876
5.2.4 Trigger Modes............................................................................................................. 876
5.2.5 Limit Settings and Conformance Requirements..........................................................877
5.2.6 Measurement Results................................................................................................. 878
5.3 GUI Reference........................................................................................................... 881
5.3.1 Measurement Control..................................................................................................881
5.3.2 Parameters and Settings.............................................................................................881
5.3.3 Measurement Results................................................................................................. 892
5.4 Programming.............................................................................................................893
5.4.1 Key Features...............................................................................................................894
5.4.2 Specifying General and Common Measurement Settings.......................................... 894
5.4.3 Specifying Additional Measurement-Specific Settings................................................ 895
5.4.4 Configuring the Trigger System.................................................................................. 895
5.4.5 Specifying Limits......................................................................................................... 895
5.4.6 Performing Single-Shot Measurements...................................................................... 895
深圳德标仪器 135-1095-0799

Contents
R&S®CMW-KM5xx/-KS5xx
8User Manual 1173.9628.02 ─ 21
5.4.7 Single-Shot and Continuous Measurements...............................................................896
5.5 Command Reference................................................................................................ 897
5.5.1 Conventions and General Information........................................................................ 897
5.5.2 General Measurement Settings.................................................................................. 901
5.5.3 SRS Measurement Commands.................................................................................. 901
5.5.4 Combined Signal Path Commands............................................................................. 911
5.6 List of Commands.....................................................................................................911
Index....................................................................................................913
深圳德标仪器 135-1095-0799

Preface
R&S®CMW-KM5xx/-KS5xx
9User Manual 1173.9628.02 ─ 21
1 Preface
The operation of the R&S CMW is described in several user manuals:
●The R&S CMW user manual describes the base software, common features of the
firmware applications and basic principles for manual operation and remote control.
There is a separate manual version for each R&S CMW model.
●Additional user manuals, like this document, describe the firmware applications.
There is only one version of these manuals for all R&S CMW models.
Rohde & Schwarz provides registered users a "CMW Customer Web" section on
GLORIS, the Global Rohde & Schwarz Information System: https://extranet.rohde-
schwarz.com. From this resource, you can download software updates, waveform
library updates and documentation updates, for example updates of this document.
1.1 R&S CMW Models
The R&S CMW software supports several instrument models. Depending on the
model, only a subset of the software packages and software options is allowed.
To check whether this document is relevant for your instrument model and which soft-
ware options are supported, refer to the preface of your model-specific base user man-
ual. The PDF filename of this manual starts with CMW<Model>_UserManual, for
example CMW500_UserManual.
1.2 How to Read Firmware Application Chapters
Each firmware application is described in a separate chapter. These chapters can be
read independently of each other. However, they are all organized as follows:
1. General Description
2. Application Sheets (optional)
3. GUI Reference
4. Programming Examples
5. Command Reference
The chapters "System Overview" and "Remote Control" in the R&S CMW user manual
provide additional important information independent of the individual firmware applica-
tions. The most important parts are referenced by the firmware application descrip-
tions.
R&S CMW Models
深圳德标仪器 135-1095-0799

Preface
R&S®CMW-KM5xx/-KS5xx
10User Manual 1173.9628.02 ─ 21
1.2.1 General Description
This section provides a general description of the firmware application, independent of
a specific operation mode (manual or remote control). It gives a high-level introduction
to the capabilities of the firmware application. Background information related to the
network standard is given as far as it is directly related to administrable parameters.
For measurement applications a detailed description of measurement results and a
description of configurable limits is given, including the relation to conformance require-
ments defined in network standard specifications.
1.2.2 Application Sheets
This optional section provides short application examples for select issues and related
background information.
1.2.3 GUI Reference
The GUI reference describes the manual operation of the firmware application via the
Graphical User Interface (GUI).
The description of a configuration dialog usually starts with a screenshot presenting the
preset values of the parameters (sometimes preset values are modified to enable hid-
den parts of a dialog). Below the screenshot all shown parameters are described. For
each single parameter a link to the corresponding command description in the "Com-
mand Reference" is provided. Ranges for numeric parameters and reset values are
given there.
For measurement results links to the corresponding command descriptions are provi-
ded (commands to retrieve the results). The measurement results are described in
detail in the "General Description".
1.2.4 Programming Examples
The programming examples show how to control and configure the firmware applica-
tion via a remote-control program and how to retrieve measurement results. The exam-
ples consist of comprehensive command sequences. You can check just a single com-
mand of a sequence to get an example for the syntax of this single command. But you
can also consider an entire sequence showing the commands in the context of a com-
mand script, under consideration of dependencies and required orders of the com-
mands.
The command sequences are written with the intention to list most commands of the
firmware application. They do not show the fastest way for a given configuration task.
The fastest way would use many reset values and omit the corresponding commands.
The examples are referenced by the command descriptions of the "Command Refer-
ence".
How to Read Firmware Application Chapters
深圳德标仪器 135-1095-0799

Preface
R&S®CMW-KM5xx/-KS5xx
11User Manual 1173.9628.02 ─ 21
1.2.5 Command Reference
The command reference provides information on the remote commands of the firm-
ware application. The commands are grouped according to their function.
Each command description indicates the syntax of the command header and of the
parameters. For input parameters the allowed ranges, reset values and default units
are listed, for returned values the expected ranges and default units. Most commands
have a command form and a query form. Exceptions are marked by "Setting only",
"Query only" or "Event". Furthermore a link to the "Programming Examples" is provided
and the first software version supporting the command is indicated.
How to Read Firmware Application Chapters
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
12User Manual 1173.9628.02 ─ 21
2 LTE Signaling
The "LTE signaling" firmware application emulates an E-UTRAN cell and communi-
cates with the UE under test. The UE can synchronize to the downlink signal and
attach to the PS domain. A connection can be set up (3GPP compliant RMC or user-
defined channel).
Two basic signaling options are available: R&S CMW-KS500 for R8 FDD signals and
R&S CMW-KS550 for R8 TDD signals. At least one of these basic options is required
to use the signaling application. Both basic options support only configurations with a
single antenna (SISO).
The basic functionality can be enhanced via the following options:
●R&S CMW-KS502 adds support of DL carrier aggregation for FDD signals.
R&S CMW-KS552 adds support of DL carrier aggregation for TDD signals.
●R&S CMW-KS510 provides advanced parameter settings for R8.
●R&S CMW-KS512 provides advanced parameter settings for R10, including UL
carrier aggregation.
●R&S CMW-KS520 adds support of DL beamforming, MIMO 2x2 and SIMO 1x2.
R&S CMW-KS521 is required for DL MIMO 4x2 (prerequisite R&S CMW-KS520).
R&S CMW-KS522 is required for DL MIMO 8x2 (prerequisite R&S CMW-KS521).
●R&S CMW-KS525 adds a user-defined operating band and special bands.
●R&S CMW-KE100 and R&S CMW-KE500 enable internal fading.
R&S CMW-KE501 is required for MIMO 4x2 fading (prereq. R&S CMW-KE500).
R&S CMW-KE502 is required for MIMO 8x2 fading (prereq. R&S CMW-KE501).
Tests can be performed using the LTE "Multi Evaluation" measurement, the "PRACH"
measurement or the "SRS" measurement (all included in the options R&S CMW-
KM500 and R&S CMW-KM550).
Data transfer tests can be performed using the Data Application Unit (DAU, option
R&S CMW-B450x and R&S CMW-KM050). The DAU also provides an IMS server for
voice over IMS and SMS over IMS. Audio tests can be performed using the audio
board plus a speech codec (R&S CMW-B400B and R&S CMW-B405A).
The "LTE signaling" application provides additional measurements. For details refer to:
●chapter 2.3.1, "Combined Signal Path Measurements", on page 88
●chapter 2.2.19, "Relative Power Control Tests", on page 72
●chapter 2.3.2, "LTE IP-Based Data Tests", on page 92
●chapter 2.2.20, "Extended BLER Measurement", on page 75
●chapter 2.2.21, "RLC Throughput Measurement", on page 86
2.1 What's New in this Revision
This revision describes version 3.5.20 and later of the "LTE Signaling" firmware appli-
cation. Compared to version 3.5.10, it provides the following new features and
changes:
What's New in this Revision
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
13User Manual 1173.9628.02 ─ 21
●Uplink carrier aggregation:
–Background information, see Carrier Aggregation
–Enabling SCC uplink, see Use UL
– SCC UL trigger signals, see Trigger Signals
– Joint uplink power control, see Uplink Power Control
●New carrier aggregation scenarios, see chapter 2.2.1, "Scenarios", on page 14
List of the new scenarios:
– "2CC CA - 4 RF Out - Distributed" (with/without fading)
– "3CC CA - 6 RF Out" (with/without fading)
– "4CC CA - 4 RF Out" (no fading)
– "4CC CA - 8 RF Out" (with/without fading)
●UE capability report enhancement for four carriers, see RF UE Capabilities
●TDD UL/DL configuration and special subframe configuration per component car-
rier, see Use Carrier Specific
●Multi-cluster allocation enhancements:
– Commands enabling/disabling multi-cluster allocation, see CONFigure:LTE:
SIGN<i>:CONNection[:PCC]:MCLuster:UL
– Multi-cluster allocation for UL user-defined channels, see User-Defined Chan-
nels
●The RLC mode is also configurable in test mode, see Default Bearer
●Mobile-originating/terminating circuit-switched fallback to TD-SCDMA, see CS Fall-
back (MO) and Inter/Intra-RAT (hotkey)
●New handover method "Handover" supported for handover to WCDMA, see Hand-
over
●The following scheduling types are now also supported for transmission mode 8
and 9 (see CQI Channels):
Follow CQI, follow PMI, follow PMI-RI, follow CQI-PMI-RI
●SCC DL operating bands 252 and 255 for license assisted access (LAA), see
Operating Bands
●Short message service enhancements:
– Configurable protocol identifier TP-PID, see Protocol Identifier
– Information about success of last short message transfer, see Last Message
Sent
Software Version
To check your R&S CMW software version, open the "Setup" dialog and click "HW/SW
Equipment". The initial software version for each remote control command is quoted in
the reference description.
What's New in this Revision
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
14User Manual 1173.9628.02 ─ 21
2.2 General Description
The following sections describe how to use the R&S CMW for LTE signaling tests and
provide background information.
●Scenarios................................................................................................................ 14
●Test Setups.............................................................................................................17
●Initiating Signaling Tests......................................................................................... 24
●Carrier Aggregation.................................................................................................25
●External Fading.......................................................................................................27
●Internal Fading........................................................................................................ 28
●Data Tests and Voice Over LTE............................................................................. 29
●Audio Tests and Speech Quality Tests...................................................................30
●Connection States...................................................................................................30
●Handover.................................................................................................................34
●Physical DL Channels and Signals......................................................................... 36
●MIMO and Beamforming.........................................................................................40
●Scheduling Type RMC............................................................................................ 45
●User-Defined Channels...........................................................................................61
●CQI Channels..........................................................................................................64
●Semi-Persistent Scheduling (SPS)......................................................................... 67
●Operating Bands..................................................................................................... 68
●Trigger Signals........................................................................................................71
●Relative Power Control Tests..................................................................................72
●Extended BLER Measurement................................................................................75
●RLC Throughput Measurement...............................................................................86
2.2.1 Scenarios
The scenario selection is the first setting to be done for test configuration.
The LTE signaling application provides different scenarios for tests with or without
MIMO, fading and carrier aggregation (CA). The number of component carriers (CC) is
also selected via the scenario (one PCC + n SCC). Selecting a scenario hides/shows
parts of the GUI as required by the scenario.
The following table lists all available scenarios with a short explanation. The subse-
quent tables list the prerequisites for each scenario.
Table 2-1: Scenario overview
Scenario name Explanation
"1 Cell - 1 RF Out" Basic LTE cell (no MIMO, no fading, no CA)
"1 Cell - 2 RF Out" DL MIMO / SIMO nx2 (no fading, no CA)
"1 Cell - 4 RF Out" DL MIMO 4x2 and external RF fading (no I/Q fading, no CA)
"2CC CA - 2 RF Out" DL CA with two CC (no MIMO, no fading)
"2CC CA - 4 RF Out"
"2CC CA - 4 RF Out - Distributed"
DL CA with two CC and DL MIMO nx2 (no fading)
The two scenarios provide the same functionality but have different HW prerequisites,
see subsequent tables.
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
15User Manual 1173.9628.02 ─ 21
Scenario name Explanation
"3CC CA - 3 RF Out" DL CA with three CC (no MIMO, no fading)
"3CC CA - PCC MIMO - 4 RF Out" DL CA with three CC and PCC DL MIMO nx2 (no SCC MIMO, no fading)
"3CC CA - SCC1 MIMO - 4 RF Out" DL CA with three CC and SCC1 DL MIMO nx2 (no PCC/SCC2 MIMO, no fading)
"3CC CA - 6 RF Out" DL CA with three CC and DL MIMO nx2 (no fading)
"4CC CA - 4 RF Out" DL CA with four CC (no MIMO, no fading)
"4CC CA - 8 RF Out" DL CA with four CC and DL MIMO nx2 (no fading)
"1 Cell - Fading - 1 RF Out" Fading variants of the scenarios. Supported are internal extended fading and external
fading.
"2CC CA - Fading - 2 RF Out"
"1 Cell - Fading - 2 RF Out" Fading variants of the scenarios. Up to two DL TX antennas per carrier, internal exten-
ded fading and external fading are supported. For more antennas, internal standard
fading is supported.
"2CC CA - Fading - 4 RF Out"
"2CC CA - Fading - 4 RF Out - Distrib."
"3CC CA - Fading - 6 RF Out"
"4CC CA - Fading - 8 RF Out"
"1 Cell - Fading - MIMO4x2 - 2 RF Out" DL MIMO 4x2 and internal extended fading or external fading (no CA)
"1 Cell - IQ Out, RF In" RF uplink as for "1 Cell - 1 RF Out", baseband downlink via the I/Q board.
Allows you for example to insert an R&S SMU200A into the downlink path.
For all DL CA scenarios, you can also enable UL CA with two component carriers.
External fading can for example be added via a connected R&S SMW200A.
Which scenarios are offered for selection, depends on the available software and hard-
ware options. The following tables list all available scenarios and the required options.
The tables distinguish between single-CMW scenarios and multi-CMW scenarios:
●Single-CMW scenarios
The required hardware fits into a single instrument. So these scenarios are availa-
ble on a single R&S CMW if the required options are equipped.
Single-CMW scenarios can also be used on a multi-CMW if the required options
are available. The options can be distributed over several instruments. But the
SUW, TX and I/Q board for each input or output path must be available in the
same instrument. For one path, you cannot use for example an SUW of one instru-
ment plus the I/Q board of another instrument. The SW licenses are pooled in the
R&S CMWC, so it does not matter where they are installed.
●Multi-CMW scenarios
The required hardware does not fit into a single instrument. Two instruments are
required. They are controlled by an R&S CMWC. The test software including the
LTE signaling application is installed and executed on the R&S CMWC.
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
16User Manual 1173.9628.02 ─ 21
Table 2-2: Required hardware and software options for single-CMW scenarios
SUW TX I/Q Board Software Options1)
"1 Cell - 1 RF Out" 1 1 - -
"1 Cell - 2 RF Out" 1 2 - KS520
"1 Cell - 4 RF Out" 2 4 - KS520, KS521
"2CC CA - 2 RF Out" 2 2 - KS502/KS552
"2CC CA - 4 RF Out" 2 4 - KS502/KS552, KS520
"3CC CA - 3 RF Out" 3 3 - KS502/KS552, KS512
"3CC CA - PCC MIMO - 4 RF Out" 3 4 - KS502/KS552, KS512, KS520
"3CC CA - SCC1 MIMO - 4 RF Out" 3 4 - KS502/KS552, KS512, KS520
"4CC CA - 4 RF Out" 4 4 - KS502/KS552, KS512
"1 Cell - Fading - 1 RF Out, External" 1 1 B510x or B520x KS510
"1 Cell - Fading - 1 RF Out, Internal" 1 1 B510F or B520F KS510, KE100, KE500
"1 Cell - Fading - 2 RF Out, External" 1 2 B510x or B520x KS510, KS520
"1 Cell - Fading - 2 RF Out, Internal" 1 2 B510F or B520F KS510, KS520, KE100, KE500
"1 Cell - Fading - MIMO4x2 - 2 RF Out, Ext." 2 2 B510x plus B520x KS510, KS520, KS521
"1 Cell - Fading - MIMO4x2 - 2 RF Out, Int." 2 2 B510F plus B520F KS510, KS520, KS521, KE100, KE500, KE501
"2CC CA - Fading - 2 RF Out, External" 2 2 B510x plus B520x KS502/KS552, KS512
"2CC CA - Fading - 2 RF Out, Internal" 2 2 B510F plus B520F KS502/KS552, KS512, KE100, KE500
"2CC CA - Fading - 4 RF Out, External" 2 4 B510x plus B520x KS502/KS552, KS512, KS520
"2CC CA - Fading - 4 RF Out, Internal" 2 4 B510F plus B520F KS502/KS552, KS512, KE100, KE500, KS520
"1 Cell - IQ Out, RF In" 1 - B510x or B520x -
1) All listed options are R&S CMW-... options. Example: B510F means R&S CMW-B510F. All scenarios require KS500 for FDD and
KS550 for TDD in addition to the listed options. KS502/KS552 means KS502 for FDD or KS552 for TDD.
Table 2-3: Required hardware and software options for multi-CMW scenarios
SUW TX I/Q Board Software Options1)
Instrument number 1 2 1 2 CMW 1 CMW 2 Sum of all R&S CMW and R&S CMWC
"2CC CA - 4 RF Out - Distributed" 1 1 2 2 - - KS502/KS552, KS520
"2CC CA - Fading - 4 RF Out - Distr., Ext." 1 1 2 2 B510x B510x KS502/KS552, KS512, KS520
"2CC CA - Fading - 4 RF Out - Distr., Int." 1 1 2 2 B510F B510F KS502/KS552, KS512, KE100, KE500, KS520
"3CC CA - 6 RF Out" 1 2 2 4 - - KS502/KS552, KS512, KS520
"3CC CA - Fading - 6 RF Out, External" 1 2 2 4 B510x B510x +
B520x
KS502/KS552, KS512, KS520
"3CC CA - Fading - 6 RF Out, Internal" 1 2 2 4 B510F B510F +
B520F
KS502/KS552, KS512, KE100, KE500, KS520
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
17User Manual 1173.9628.02 ─ 21
SUW TX I/Q Board Software Options1)
Instrument number 1 2 1 2 CMW 1 CMW 2 Sum of all R&S CMW and R&S CMWC
"4CC CA - 8 RF Out" 2 2 4 4 - - KS502/KS552, KS512, KS520
"4CC CA - Fading - 8 RF Out, External" 2 2 4 4 B510x +
B520x
B510x +
B520x
KS502/KS552, KS512, KS520
"4CC CA - Fading - 8 RF Out, Internal" 2 2 4 4 B510F +
B520F
B510F +
B520F
KS502/KS552, KS512, KE100, KE500, KS520
1) All listed options are R&S CMW-... options. Example: B510F means R&S CMW-B510F. All scenarios require KS500 for FDD and
KS550 for TDD in addition to the listed options. KS502/KS552 means KS502 for FDD or KS552 for TDD. It does not matter which
license is available in which instrument. All SW licenses are pooled in the R&S CMWC.
For further reference:
●chapter 2.2.2, "Test Setups", on page 17
●chapter 2.2.4, "Carrier Aggregation", on page 25
●chapter 2.2.5, "External Fading", on page 27
●chapter 2.2.6, "Internal Fading", on page 28
chapter 2.4.7.1, "Fading Simulator", on page 146 (extended vs. standard fading)
●chapter 2.2.12, "MIMO and Beamforming", on page 40
●"Scenario, Fading" on page 135 (scenario selection)
2.2.2 Test Setups
The following sections provide an overview of typical test setups for the individual sce-
narios.
2.2.2.1 Test Setup for Scenario 1 Cell - 1 RF Out
The basic test setup for a "1 Cell - 1 RF Out" scenario uses a bidirectional RF connec-
tion between the tester and the device under test (DUT). It carries both the downlink
and the uplink signal:
●The R&S CMW transmits the downlink signal to which the DUT can synchronize in
order to perform an attach. The downlink signal is used to transfer signaling mes-
sages and user data to the DUT.
●The DUT transmits an uplink signal that the R&S CMW can receive and decode in
order to set up a connection and perform various measurements.
For this setup, the DUT is connected to one of the bidirectional RF COM connectors at
the front panel of the R&S CMW. No additional cabling and no external trigger are nee-
ded. The input level ranges of all RF COM connectors are identical.
See also: "RF Connectors" in the R&S CMW user manual, chapter "Getting Started"
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
18User Manual 1173.9628.02 ─ 21
Fig. 2-1: Test setup for "1 Cell - 1 RF Out"
2.2.2.2 Test Setup for Scenario 1 Cell - 2 RF Out
The scenario "1 Cell - 2 RF Out" is used for setups with two UE RX antennas (SIMO
1x2, MIMO nx2 and beamforming). A test setup for this scenario involves one uplink
and two downlink signals at the UE side. Typically, one bidirectional connection carries
one uplink and one downlink signal. An additional connection carries the second down-
link signal. The two downlink signals must be transmitted via different TX modules and
different RF connectors, which implies that the instrument must support at least two TX
paths. You can use for example RF 1 COM for the bidirectional connection and RF 3
COM for the second downlink connection.
Fig. 2-2: Test setup for "1 Cell - 2 RF Out"
Using several signaling applications in parallel
Depending on the installed hardware and software options, you can run several signal-
ing application instances in parallel.
Example: Assume an instrument with two Signaling Unit Wideband (SUW), one Signal-
ing Unit Universal (SUU), four TX paths and four RX paths.
This instrument allows you to run for example:
●Two LTE signaling instances using the "1 Cell - 2 RF Out" scenario, or
●Two LTE signaling instances using the "1 Cell - 1 RF Out" scenario, plus one
instance of an SUU signaling application (e.g. GSM / CDMA2000)
●One LTE signaling instance using the "1 Cell - 2 RF Out" scenario, plus one
instance of an SUW signaling application (e.g. WCDMA)
●One LTE signaling instance using a carrier aggregation scenario with or without
MIMO
The LTE and WCDMA signaling applications both use the SUW. Signaling instance 1
uses SUW1, while instance 2 uses SUW2. An SUW can only be used by one instance
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
19User Manual 1173.9628.02 ─ 21
at a time. You can run for example LTE signaling instance 2 and WCDMA signaling
instance 1 in parallel, but not instance 1 of both applications.
2.2.2.3 Test Setup for Scenario 1 Cell - 4 RF Out
The scenario "1 Cell - 4 RF Out" is used for MIMO 4x2 setups, where the four TX
antenna signals must be available at the RF connectors. Typically, an external RF
fader is inserted into the downlink connection and one bidirectional connection carries
one uplink and one downlink signal. Three additional connections carry the other
downlink signals.
All downlink signals must be transmitted via different TX modules and different RF con-
nectors, which implies that the instrument must support four TX paths and must be
equipped with two signaling units SUW.
Fig. 2-3: Test setup for "1 Cell - 4 RF Out"
2.2.2.4 Test Setup for Single-CMW CA Scenarios
The Carrier Aggregation (CA) scenarios allow you to establish a Release 10 connec-
tion with several component carriers. A carrier can be a Primary Component Carrier
(PCC) or a Secondary Component Carrier (SCC).
Independent of the scenario, there is always one UL PCC and one DL PCC. For a CA
scenario, there is at least one additional DL SCC. If you enable UL carrier aggregation,
there is one additional UL SCC.
Depending on the scenario, a downlink carrier can have one output path (SISO) or two
output paths (for example MIMO nx2). In total, up to four output paths are supported.
Each output path must use a different TX module and each input path a different RX
module. The output paths of a carrier must use different RF connectors.
With an advanced frontend, you can route two paths to the same connector. This
allows you to choose the optimum test setup depending on the number of antenna
connectors of your UE. There is no need for external combiners.
The following example setup is suitable for CA with four downlinks and a UE with only
two antenna connectors. There are two PCC downlinks (MIMO), two SCC downlinks
(one MIMO SCC or two SISO SCCs), one PCC uplink and one SCC uplink.
RF 1 COM is used for the uplinks, the first PCC downlink and the first SCC downlink.
RF 3 COM is used for the second PCC downlink and the second SCC downlink.
General Description
深圳德标仪器 135-1095-0799

LTE Signaling
R&S®CMW-KM5xx/-KS5xx
20User Manual 1173.9628.02 ─ 21
Fig. 2-4: Test setup for CA, four DL, two UL, 2 DUT antenna connectors
For a UE with four antenna connectors, the following test setup could be used instead.
Each downlink signal is now routed to a different connector.
Fig. 2-5: Test setup for CA, four DL, two UL, 4 DUT antenna connectors
For CA with one uplink and two downlinks, you could for example use only RF 1 COM
(uplink, PCC downlink and SCC downlink). Or you could use RF 1 COM (uplink and
PCC downlink) and RF 3 COM (SCC downlink).
2.2.2.5 Test Setup for Multi-CMW CA Scenarios
Some carrier aggregation scenarios require a multi-CMW test setup, comprising one
R&S CMWC plus two R&S CMW.
For a list of multi-CMW scenarios and required options, see table 2-3.
The three instruments are connected to each other via their rear panels. This rear
panel cabling is identical for all multi-CMW test setups. For details, please refer to the
R&S CMWC documentation.
In the current LTE software version, the routing for multi-CMW scenarios is configured
automatically. The graphical user interface of the LTE signaling application displays the
General Description
