Ranger design 1520-TC User manual

INSTALLATION GUIDE
1520-TC Single Clamp Ladder Rack
Transit Connect ( Aluminum )

QUICK START GUIDE
REQUIRED ITEMS
2
PERSONS
NOTE: Use Sawhorses if possible, or use the box as a at protective surface on the ground or table.
qCordless Impact
qRatchet
qTape Measure
qMallet
qMarker
qLadder
qCutter
q1/2" Socket
qSawhorse ( Optional )
qBox
qKnife
q1/2" Wrench
q7/16" Socket
qSilicone
q1.1 Setup...............................................................................................................................................
q1.2 Ladder Rack Assembly....................................................................................................................
3 - 5
5 - 13
q2.1 Mounting Tracks Installation............................................................................................................
q2.2 Ladder Rack Installation..................................................................................................................
q2.3 Note.................................................................................................................................................
14
15 - 18
19
Phase 1 - Assembly
Phase 2 - Installation

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 3
PHASE 1 – ASSEMBLY
1.1 SETUP
1.1.1 Unpack components; compare with the bill of materials.
1.1.2 Verify all parts are present.
Item No. Description Qty.
10-149 Clamp Handle Support 1
10-545 Ski Plastic Plug 2
10-548 Hook Protector ( 4 - 3/8" L ) 1
10-722 Mounting Track 2
10-4440 “C” Foot 4
15-2041 Front Crossbow 1
15-2046 Rear Crossbow 1
15-3003 Ladder Clamp Hasp 1
15-3004 Ladder Clamp Rear Hook 1
15-3006 Ladder Clamp Bar ( Passenger Side ) 1
15-3013 Ski ( Right ) 1
15-4290 Front Hook 1
94-1006 Assembly Fastener Kit 1
96-1015 Install Fastener Kit 1
BILL OF MATERIALS
15-3006
15-2046
10-722
15-2041
15-3013
15-3004
15-4290
15-3003
10-4440
10-545
10-149
10-548

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 4
94-1006 Fastener Kit Fastener Assembly
1.1.3 Fastener kits.
2×
#90-487 Carriage Bolt 5/16" × 3/4"
#98-123 Lock Washer
#94-105 Hex Nut
#98-117 Flat Washer
10×
#90-491 Carriage Bolt 5/16" × 1"
#98-123 Lock Washer
#94-105 Hex Nut
#98-117 Flat Washer
2×
#98-123 Lock Washer
#94-105 Hex Nut
#98-117 Flat Washer
1×
#90-491 Carriage Bolt 5/16" × 1"
#98-123 Lock Washer
#94-105 Hex Nut
#98-117 Flat Washer
#98-160 Spacer
# 90-487
2×
Carriage Bolt
5/16"-18 × 3/4"
SS304
# 90-491
11×
Carriage Bolt
5/16"-18 × 1"
SS304
# 98-117
Flat Washer
5/16", O.D 3/4"
SS18-8
15×
# 98-123
Lock Washer
Regular 5/16"
SS304
15×
# 94-105
Hex Nut
5/16"-18
SS316wax
15×
# 98-160 Spacer
SS18-8
1×

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 5
Fastener Assembly96-1015 Fastener Kit
# 98-117
16×
Flat Washer
5/16", O.D. 3/4"
SS18-8
8× # 98-123
Lock Washer
5/16"
SS304
8× # 94-150 Channel Nut
5/16"
# 90-209
Hex Bolt
5/16"-18 × 1"
SS304
16×
8× # 94-116
Serrated Nut
5/16"-18
ZINC
8×
#90-209 Hex Bolt 5/16" × 1"
#98-123 Lock Washer
#98-117 Flat Washer
#94-150 Channel Nut
8×
#90-209 Hex Bolt 5/16" × 1"
#98-117 Flat Washer
#94-116 Serrated Nut
#98-149 Neoprene Spacer
PHASE 1 – ASSEMBLY
1.2 LADDER RACK ASSEMBLY
1.2.1 Peel the backer off of the adhesive on the hook protector, then attach the hook protector
to the upper rear hook.
TOOLS
qKnife
REMOVE
# 98-149
Spacer
0.290" ID × 1.375" OD × 0.125" L
NEOPRENE
8×

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 6
1.2.2 Attach the rear hook to the ladder clamp, with the pre-assembled hardware on the pivot bar.
TOOLS
qCordless Impact
q1/2" Socket
q1/2" Wrench
#90-225 Hex Bolt
5/16" - 18 × 2" SS304
#98-117 Flat Washer
#98-117 Flat Washer
#94-111 Lock Nut
HARDWARE USED
2× hardware is pre-assembled.

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 7
1.2.3 Slide carriage bolts on the bottom face of the crossbows.
Rear crossbow
• Slide 2 pcs. of 1" carriage bolts.
Front crossbow
• Slide 2 pcs. of 1" carriage bolts.
DRIVER SIDE
HARDWARE USED
4×
#90-491 Carriage Bolt
5/16" × 1" SS304
PASSENGER SIDE
4×
#90-491 Hex Bolt
5/16" × 1" SS304
Rear crossbow
• Slide 2 pcs. of 3/4" carriage bolts.
• Slide 2 pcs. of 1" carriage bolts.
Front crossbow
• Slide 2 pcs. of 1" carriage bolts.
HARDWARE USED
2×
#90-487 Carriage Bolt
5/16" × 3/4" SS304
TIPS: Use tape to keep the bolts from sliding off.
NOTE: The track plug must be removed from the underneath of the front crossbow, and reinstalled
after the feet have been installed in the nal position.

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 8
1.2.4 Install the feet on the Front, and Rear Crossbows.
HARDWARE USED
8× hand-tighten the nuts.
Carriage bolts are already on
the crossbows.
#98-123 Lock Washer
#98-117 Flat Washer
#94-105 Hex Nut
1.2.5 Fasten the Ladder Clamp assemblies to the Rear Crossbow.
HARDWARE USED
2×
Carriage bolts are already on
the crossbows.
#98-123 Lock Washer
#98-117 Flat Washer
#94-105 Hex Nut
TOOLS
qCordless Impact q1/2" Socket
qTape Measure qMarker
12 - 3/4"

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 9
1.2.6 • Pull out the 14.5" track plug on the passenger side of the front crossbow.
• Loosen the pre-assembled hardware on the front hook and slide the hook onto the passenger
side of the front crossbow to the position shown below.
• Cut the track plug, then attach it back to the crossbow.
8.5"
Tighten the nuts just to hold the front
hook for adjustment.
HARDWARE USED
2× hardware is pre-assembled.
#98-123 Lock Washer
#98-117 Flat Washer
#90-491 Carriage Bolt 5/16" × 1"
#94-105 Hex Nut
TOOLS
qMarker

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 10
1.2.7 Install the front crossbow to the ski.
HARDWARE USED
2×
Carriage bolts are already on
the ski.
#98-123 Lock Washer
#98-117 Flat Washer
#94-105 Hex Nut
TOOLS
qCordless Impact
q1/2" Socket

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 11
1.2.8 Loosen the pre-assembled hardware on the ladder clamp hasp, slide the hasp on the ski to the
position shown below, and tighten the nuts.
15 - 1/2"
HARDWARE USED
2× hardware is pre-assembled.
#98-123 Lock Washer
#98-117 Flat Washer
#90-487 Carriage Bolt 5/16" × 3/4"
#94-105 Hex Nut
TOOLS
qCordless Impact
q1/2" Socket
qTape Measure
qMarker

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 12
1.2.9 Slide 3pcs. of carriage bolts on the rear end of the ski, then attach end plugs on both ends of the ski.
end plug
end plug
HARDWARE USED
3×
#90-491 Carriage Bolt
5/16" × 1" SS304
TOOLS
qMallet
end plug

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 13
1.2.10 Install the Rear Crossbow to the ski with the clamp handle support, aligning the rear surface of the
crossbow bracket to the rear surface of the ski.
TOOLS
qCordless Impact
q1/2" Socket
HARDWARE USED
2×
#98-123 Lock Washer
#98-117 Flat Washer
#94-105 Hex Nut
1×
#98-123 Lock Washer
#98-160 Spacer
#98-117 Flat Washer
#94-105 Hex Nut
Carriage bolts are already on
the ski.
Carriage bolts are already on
the ski.

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 14
PHASE 2 – INSTALLATION
2.1 MOUNTING TRACKS INSTALLATION
2.1.1 • Pull the plugs off, then apply a bead of silicone around the each hole.
• Install the mounting tracks on the roof.
FRONT
NOTE: The ends of the mounting tracks with the half-circles go to the front of the vehicle.
#90-209 Hex Bolt 5/16" × 1"
#98-117 Flat Washer
#94-116 Serrated Nut
#98-149 Neoprene Spacer
TOOLS
qCordless Impact
q1/2" Socket
HARDWARE USED
8×
use use use use

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 15
PHASE 2 – INSTALLATION
2.2 LADDER RACK INSTALLATION
2.2.1 Position the Ladder Rack ( minimum two persons ) on the vehicle so that the feet are on the tracks.
NOTE: If you do not have a hoist, lift the ladder rack onto the roof manually.
Ladder Rack

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 16
2.2.2 • While making sure the crossbows are parallel to each other, slide the rack to the appropriate position,
then attach all the “C” feet to the mounting tracks.
• Tighten the bolts that attach the foot plate to the ladder rack leg.
distance < A >
distance < A >
distance < B >
distance < B >
distance < foot to end of track >
TOOLS
qRatchet
q1/2" Socket
qTape Measure
FASTENERS USED
8×
#90-209 Hex Bolt 5/16" × 1"
#98-123 Lock Washer
#98-117 Flat Washer
#94-150 Channel Nut

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 17
2.2.3 Center the crossbows on the vehicle, then tighten all the “C” feet to the crossbows.
TOOLS
qRatchet
q1/2" Socket

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 18
2.2.4 Ladder Rack adjustment.
1"
TOOLS
qCordless Impact
q1/2" Socket
front hook
rear hook
NOTE: The ladder cannot extend beyond the rear bumper of the vehicle.
Now adjust the front hook to be snug against
the ladder rung and tighten the bolts on the
front crossbow.
When the rear hook touches the ladder,
the handle should be 1" below the ladder
clamp hasp.
IMPORTANT: • After installation is complete, cut the track plug underneath the front crossbow to ll all the
unused space.
• Place the ladder rack warning label on a visible area, recommended on a partition.

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 19
PHASE 2 – INSTALLATION
2.3 NOTE
2.3.1 If the handle is interfering with the door or roof of the vehicle, the handle can
be installed in an alternate position.
If the handle is interfering with the door
or roof of the vehicle, disassemble the
handle, then assemble it in an alternate
position as shown.
Handle

For technical support, contact us at 1-800-565-5321 1520-TC Installation Guide |REV. D2 | Page 20
“You have successfully installed your
1520-TC Ladder Rack
Thank you for doing business with us.”
For any feedback or suggestions you may have, please contact: [e-mail]
