Ranger design 16-U0010 User manual

INSTALLATION GUIDE
16-U0010 16-U0015
Cargo Strap and/or Mounting Kit
Cargo+ Install
Cargo Rack
Install
Cargo
+ Install
16
-
U0010
16
-
U0015
Scan the QR code for latest
Install
-
G
uide.

PAGE | 2
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1

PAGE | 3
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1
SAFETY INSTRUCTIONS
 Only a qualified person/s should install this product.
 This product requires 1 person to install.
 Always use safety gloves, glasses, and shoes.
PREPARATION
Tools Needed
Wrench ½” Socket ½” Impact

PAGE | 4
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1
BILL OF MATERIALS
16-U0010
16-U0015 – Cargo +
Bill Of Materials
Item No. Description Qty.
16-045 Cargo+ Bracket Base 2
16-046 Cargo+ Bracket Top 2
96-0015 Hardware Kit 1
Hardware Kit 96-0015
Item No. Description Qty.
90-491 Carriage Bolt 5/16”-18x1” SS 4
98-117 Flat Washer 5/16” SS 4
94-105 Hex Nut 5/16 SS 4
98-123 Lock Washer 5/16” SS 4
Bill Of Materials
Item No. Description Qty.
16-047 Cargo Strap 2
96-0014 Hardware Kit 1
Hardware Kit 96-0014
Item No. Description Qty.
90-487 Carriage Bolt 5/16-18x3/4” SS 2
98-117 Flat Washer 5/16” SS 2
94-105 Hex Nut 5/16 SS 2
98-123 Lock Washer 5/16” SS 2
16-046
16-045
16-047

PAGE | 5
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1
ASSEMBLY
STEP 1 Cargo Rack
STEP 2 Cargo Rack
STEP 3 Strap Operation
Tools:
 Impact

Socket ½”
2x
Torque to
11 lb ft
5/16-18X3/4”
Carriage Bolt
5/16 Flat
Washer
5/16 Lock
Washer
5/16 Hex Nut
90-487
98-117
98-123
94-105
½” Socket
16-047

PAGE | 6
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1
ASSEMBLY
STEP 1 Cargo+
STEP 2 Cargo+
Tools:
 Impact

Socket ½”
2x
Torque to
11 lb ft
5/16-18X3/4”
Carriage Bolt
5/16 Flat
Washer
5/16 Lock
Washer
5/16 Hex Nut
90-487
98-117
98-123
94-105
½” Socket
16-046
16-047

PAGE | 7
For
technical support, contact us at
1
-
800
-
565
-
5321
16
-
U0010
Installation Guide |
REV.A1
STEP 3 Cargo+
STEP 4 Strap Operation
“You have successfully installed your Cargo Strap, thank you for doing
business with us.”
For any feedback or suggestions, you may have, please contact: [e-mail]
Tools:
 ½” Wrench
4x
Torque to
11 lb ft
5/16-18X1”
Carriage Bolt
5/16 Flat
Washer
5/16 Lock
Washer
5/16 Hex Nut
16-045
98-117
98-123
94-105
94-491
½” Wrench
