Ranger design C24-DL User manual

INSTALLATION GUIDE
C24-DL STRAIGHT PARTITION
Sprinter Partition ( Walk-Through, Steel )
For full install guide visit:
https://rangerdesign.com/products/van-
partition-walk-through-mercedes-sprint-
er/

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 2
QUICK START GUIDE
REQUIRED ITEMS
2
PERSONS
qCordless Impact
qCordless Drill
qCutter
qMallet
qPlusnut Tool
qTape Measure
qT40 Torque Bit
q3/8" Drill Bit
q7/16" Socket
q1/2" Socket
q9/16" Wrench
q3/16" Driver Bit
qDrill Stop
q1.1 Setup...................................................................................................................................................
q1.2 Partition assembly...............................................................................................................................
3 - 4
5
Phase 1 - Assembly
q2.1 Tips on how to attach a plusnut..........................................................................................................
q2.2 Vehicle preparation..............................................................................................................................
q2.3 Straight partition installation................................................................................................................
6
7
7 - 13
Phase 2 - Installation

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 3
PHASE 1 – ASSEMBLY
1.1 SETUP
1.1.2 Verify all parts are present.
Item No. Description Qty.
30-051 Top Bracket 1
30-052 Floor Bracket 1
30-072 Passenger Side Panel 1
30-073 Driver Side Panel 1
30-500 Edge Trim ( QTY in Inches ) 45
70-350 Grab Handle 1
79-932 Warning Label ( Bilingual ) 1
94-3001 Assembly Fastener Bag 1
94-6093 Assembly Fastener Bag 1
96-3001 Installation Fastener Bag 1
1.1.1 Unpack components; compare with the bill of materials.
30-500
30-051
30-052
30-073
30-072
70-350

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 4
1.1.3 Identify the Assembly and Installation fastener bags.
4×4× 4×4×
#90-200 Hex Bolt 5/16" × 1/2"
#98-116 Flat Washer
#94-116 Serrated Nut
#90-204 Hex Bolt 5/16" × 3/4"
#98-116 Flat Washer
#94-116 Serrated Nut
94-3001 Fastener Bag Hardware Assembly
96-3001 Fastener Bag Hardware Assembly
94-6093 Fastener Bag Hardware Assembly
2×2×
#90-893 Cap Screw 1/4" × 3/4"
#94-112 Serrated Nut
#98-118 Lock Washer
#98-112 Flat Washer
#94-130 Plusnut
#90-983 Double Ended Bolt
#94-100 Hex Nut
#98-180 Short Partition Spacer
6×
#98-118 Lock Washer
#98-112 Flat Washer
#94-130 Plusnut
#90-984 Long Double
Ended Bolt
#94-100 Hex Nut
#98-181 Long Partition Spacer
6×
5×5×
#90-118 Hex Bolt 1/4" × 1-1/4"
#98-118 Lock Washer
#98-112 Flat Washer
#94-130 Plusnut .250

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 5
PHASE 1 – ASSEMBLY
1.2 PARTITION ASSEMBLY
1.2.1 Remove all the PVC from all the parts, then attach the grab handle on the passenger side panel.
1.2.2 Attach the edge trims on these locations.
TOOLS
qCordless Impact
q3/16" Driver Bit
HARDWARE USED
2×
#90-893 Cap Screw 1/4" × 3/4"
#94-112 Serrated Nut
TOOLS
qMallet
qCutter

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 6
PHASE 2 – INSTALLATION
2.1 TIPS ON HOW TO ATTACH A PLUSNUT
FORWARD REVERSE
TIPS: Put the plusnut on the plusnut gun, then attach the plusnut in the hole by turning the gun forward until the
plusnut locks, then remove the gun by turning in reverse.
2.1.1 Attach the plusnut using the plusnut gun.
2.1.2 Attach the plusnut using the 6490 plusnut tool.
6490 HARDWARE USED
Flat washer 1/4"
Flat washer 1/4" BS × 3/4" OD
TOOLS
qCordless Impact
q7/16" Socket
q9/16" Wrench
TIPS STEP 1:
Assemble the 6490 plusnut tool with the hardware needed,
plusnut and the 9/16" wrench as shown.
FORWARD REVERSE
TIPS STEP 2:
Attach the plusnut in the hole by turning
the bolt forward using an impact with a
7/16" socket until the plusnut locks, then
remove the bolt by turning the impact in
reverse.
NOTE: The hardware used for the 6490 plusnut tool is not included in the fastener bag.
The 6490 plusnut tool can be ordered separately upon demand at no charge.

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 7
PHASE 2 – INSTALLATION
2.2 VEHICLE PREPARATION
2.2.1 Floor preparation.
Remove the two D-rings in the pillars, for
re-use.
TOOLS
qCordless Impact
qT40 Torque Bit
PHASE 2 – INSTALLATION
2.3 STRAIGHT PARTITION INSTALLATION
2.3.1 Floor bracket installation.
Attach the oor bracket to the oor
re-using the 2 D-ring bolts.
HARDWARE USED
2×
Use the D-ring bolt
TOOLS
qCordless Impact
qT40 Torque Bit

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 8
2.3.2 Attaching plusnuts.
NOTE: Check if the holes of the partition align with the holes of the van.
TOOLS
qPlusnut Tool
# 94-130
Plusnut .250
HARDWARE USED
17×
Attach plusnuts in the holes.
Put the assembled partition in place, then mark all the holes through the van.
TOOLS
qCordless Drill q3/8” Drill Bit or Step Drill q1" Hole Saw
qDrill Stop
NOTE: • For the B-pilar plastic cover and wood floor use 1" hole saw to
drill a hole in the B-pilar plastic cover or wood floor, then drill 3/8"
hole in the van.
• Enlarge all the holes in the van that align with the holes of the
partiton using 3/8” drill bit or step drill.

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 9
2.3.3 Attach the top bracket to the van.
TOOLS
qCordless Impact
q7/16" Socket
HARDWARE USED
5×
#90-118 Hex Bolt 1/4" × 1-1/4"
#98-118 Lock Washer
#98-112 Flat Washer

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 10
TOOLS
qCordless Impact
q7/16" Socket
HARDWARE USED
6×
2.3.4 Install double ended bolts and spacers into van before placing partition panels
TOOLS
qCordless Impact
q7/16" Socket
#94-130 Plusnut
#90-984 Double Ended Bolt
#98-181 Short Partition Spacer
HARDWARE USED
6×
√
×
#94-130 Plusnut
#90-983 Double Ended Bolt
#98-180 Short Partition Spacer

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 11
2.3.5 Put the side panels in place, then bolt the driver and passenger side panels to the van.
TOOLS
qCordless Impact
q7/16" Socket
#98-118 Lock Washer
#98-112 Flat Washer
#94-100 Hex Nut
HARDWARE USED
12×

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 12
2.3.6 Attach the driver and passenger side panels to the top bracket.
TOOLS
qCordless Impact
q1/2" Socket
HARDWARE USED
4×
#90-200 Hex Bolt 5/16" × 1/2"
#98-116 Flat Washer
#94-116 Serrated Nut

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 13
2.3.7 Attach the driver and passenger side panels to the oor bracket.
HARDWARE USED
4×
TOOLS
qCordless Impact
q1/2" Socket
#90-204 Hex Bolt 5/16" × 3/4"
#98-116 Flat Washer
#94-116 Serrated Nut

For technical support, contact us at 1-800-565-5321 C24-DL Installation Guide |REV. G1 | Page 14
2.3.7 Apply the warning label on the passenger side panel.
NOTE: English warning label is already
attached on the passenger
panel.
“You have successfully installed your partition,
Thank you for doing business with us.”
For any feedback or suggestions, you may have, please contact: [email protected]
