RDMOTO S35SDM Install guide

RDMOTO CZECH REPUBLIC
[email protected]
www.rdmoto.cz
1
Instructions for the right side:
1. Remove fairing of motorcycle.
2. Remove original bolts from the frame of motorcycle.
3. Mount dural. adapter ID1 into the frame of motorcycle using bolts ID4.
4. Put dural. connection rod ID6 through the frame and use bolt ID5.
Instructions for the left side:
1. Remove fairing of motorcycle.
2. Fit dural adapter ID1 on the frame of motorcycle. Tighten it usin stirrup ID2 and bolt
ID6.
3. Stick 3M tape on the frame of motorcycle.
4. Tighten rod using bolt ID5
Now put fairing back on motorcycle.
Instructions for crash protectors:
1. Insert bolt ID4 through ID9, ID7 and ID3.
2. Fit this kit into the adapter ID1.
3. Fit protectors using bolts and washers (ID10 and ID11).
We recommend to use safety glue on all threads (medium strong).

RDMOTO CZECH REPUBLIC
[email protected]
www.rdmoto.cz
2

RDMOTO CZECH REPUBLIC
[email protected]
www.rdmoto.cz
3
S35SDM
Suzuki GSX 1250 FA-2010
Kit for the left side Kit for the right side
ID
Description
Cat.no.
Pcs
1
Dural. adapter
664
1
2
Threaded stirrup
665
1
3
Dural. cylinder 90mm
143
1
4
Bolt M12x135x1,25
991
1
5
Bolt M6x30
863
1
6
Bolt M6x50
867
2
7
Dural. cylinder 15mm
149
1
8
3M Tape
3M
1
9
Dural. adapter for
SLDM
537/B
1
10
Bolt M6x20
1024
2
11
Washer M6
1023
2
ID
Description
Cat.no.
Pcs
1
Dural. adapter
666
1
2
Dural. cylinder 90mm
143
1
3
Bolt M12x135x1,25
991
1
4
Bolt M10x50x1,25
921
2
5
Bolt M6x30
863
1
6
Dural. rod
667
1
7
Dural. cylinder 15mm
149
1
8
3M tape
3M
2
9
Dural. adapter for
SLDM
537/B
1
10
Bolt M6x20
1024
2
11
Washer M6
1023
2
3
4
9
8
7
6
4
