RDMOTO KTM5SD User manual

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.cz
1
KTM5SD
KTM RC 125/200/390 2014-
Kit for the left side
Kit for the right side
No.
Description
Cat.no.
Pcs
No.
Description
Cat.no.
Pcs
1
Left mounting plate
678
1
1
Right mounting plate
679
1
2
Clamp spacer 22mm
680
1
2
Clamp spacer 22mm
680
1
3
Thread clamp 22mm
682
1
3
Thread clamp 22mm
682
1
4
Clamp spacer 16mm
681
1
4
Clamp spacer 16mm
681
1
5
Thread clamp 16mm
683
1
5
Thread clamp 16mm
683
1
6
Bolts M6x35 button head
989
4
6
Bolts M6x35 button head
989
4
7
Dural.spacer
15
1
7
Dural.spacer
15
1
8
Dural. slider holder
537
1
8
Dural. slider holder
537
1
9
Bolt M10x90
880
1
9
Bolt M10x90
880
1
10
Bolt M8x25
815
2
10
Bolt M8x25
815
2
11
Washer spring M8
800
2
11
Washer spring M8
800
2
1
6
6
5
5
4
3
2
1
4
3
2
8
26
6
7
9
7
66
6
9
8
10
10
11
11

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.cz
2
Instructions:
1. Remove fairing of motorcycle.
2. Place the clamp spacer ID.2 and ID.4.
3. Place the appropriate threaded clamps ID.3 and ID.5 around the frame and secure
using the M6x35 bolts ID.6.
4. Bolt ID.9 insert through the dural. holder ID.8 and dural. spacer ID.7.
5. This kit assembly into the threaded hole in the mounting plate ID.1 and tighten
ensuring.
6. Slider position must be as shown on the picture.
7. Place slider and tighten it by bolts ID.10 and washers ID.11.
Warning –we recommend to use safety glue on threads of all bolts (moderate
strong –blue colour).
