RDMOTO H63S User manual

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.eu
1
H63S
Honda CB650R Neo Sport Café 2019-
Mounting Kit Left Side: Mounting Kit Right Side:
ID
Description
Cat.No
Pcs.
1
Steel Adapter
740
1
2
Dural. roller d=30
82
1
3
Dural. roller d=28
1151
1
4
Bolt M10x65x1,25
945
1
5
Allen Bolt Insert M10
X115
1
6
Slider Adapter
292
1
7
Bolt M10x30
882
1
8
Bolt M12x95x1,25
900
1
9
Allen Bolt Insert M12
X116
1
10
Plastic Cover M10
X4
1
11
Plastic Cover M12
X60
1
12
Bolt 6x25
877
3
13
Bolt m4x16
876
2
ID
Description
Cat.No
Pcs
1
Steel Adapter
741
1
2
Dural. roller d=28
1151
1
3
Bolt M10x65x1,25
945
1
4
Allen Bolt Insert M10
X115
1
5
Slider Adapter
292
1
6
Bolt M10x30
882
1
7
Bolt M12x50x1,25
990
1
8
Allen Bolt Insert M12
X116
1
9
Plastic Cover M10
X4
1
10
Plastic Cover M12
X60
1
11
Bolt 6x25
877
3
12
Bolt m4x16
876
2
7+8
8+9
6
5
8+9
2
3+4
2
3
8+9
7+5
6
7
12
11
13
12

RDMOTO CZECH REPUBLIC
[e-mail]
www.rdmoto.eu
2
Mounting Instructions Left Side:
1. Dismount the original M12 and M10 bolts connecting frame with the engine
(see photos).
2. Attach the steel adapter to motorcycle frame. In front part of the ID.1 steel
adapter insert ID.2 dural. roller in between the frame and adapter and tighten
with ID.8 bolt using tightening torque of 55Nm.
3. In rear part, insert fully fitted ID.3 dural. roller under the adapter. Here, use
the ID.4 bolt and ID.5 insert, tightening with torque of 40 Nm.
4. Mount the ID. 6 SL adapter using ID.7 Bolt onto the ID.1 adapter.
5. Finally, use ID.12 bolts to attach the slider and ID.13 bolt to attach the dural.
plate.
Mounting Instructions Right Side:
1. Dismount the original M12 and M10 bolts connecting frame with the engine
(see photos).
2. Attach the steel adapter to the motorcycle frame. Use ID. bolt and tightening
torque of 55 Nm.
3. In rear part, put the fitted dural. roller ID.2 under the adapter using ID.3 bolt
and ID.4 insert, tightening torque of 40 Nm.
4. Attach the SL adapter ID.5 onto the ID.1 adapter using ID.6 bolt.
5. Finally, use the ID.11 bolts to mount the slider and ID.12 bolt to mount the
dural. plate.
Note: We recommend using medium strenght thread glue during assembly (blue
color).
Bolt M12 ID.7 +
Insert ID.8 + Cover
M12 ID.10
Adapter ID.1 + Bolt M10
ID.6 + Adapter ID.5 +
Bolt M6 ID.11 + Bolt M4
ID.12
Bolt M10 ID.3 + Dural.
roller ID.2 + Insert M10
ID.4 + Plastic Cover M10
ID.9
Bolt M12 ID.8 +
Roller ID.2 Insert
ID.9 + Cover M12
ID.11
Bolt M10 ID.4 +
Dural. roller ID.3 +
Insert M10 ID.5 +
Plastic Cover M10
ID.10
Adapter ID.1 + Bolt M10
ID.7 + Adapter ID.6 + Bolt
M6 ID.12 + Bolt M4 ID.13 .
