ReelCraft 5005 Series User manual

1. Do not use reel at higher pressures or temperatures than listed on
the back of this bulletin.
2. Remove all spring tension before beginning dissassembly process.
SAFETY
INSTALLATION: A flexible hose connection must be used between the hose reel inlet and the source of supply to prevent possible
misalignment and binding.
LUBRICATION: Hose reel spring and bearings are factory lubricated and require no further lubrication.
REPLACING HOSE: 1. Wind spool flange clockwise-facing swivel-until spring is tight.
2. Back off three turns and latch.
3. Insert hose through roller guide.
4. Connect hose fitting to swivel joint and secure hose with clamps.
ADJUSTMENTS: To adjust spring tension, add or remove wraps of hose from the spool, one wrap at a time until desired tension is
obtained.
REPAIRS: Extensive repairs should be performed only by an authorized serviceman or factory to avoid damage which may
void your warranty. Remove all spring tension before beginning disassembly process.
5605 OLP 5605 OMP 5405 OHP
5650 OLP 5435 OHP
Four 5/16” diameter mounting holes
Operating Instructions
Series 5005 Spring Driven Hose Reels
Low, Medium and High Pressure Model Numbers:
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: [phone]
[email protected] • www.reelcraft.com
Form# 519-287 Rev: 4/2010
MOUNTING: The hose reel is equipped with a universal mounting bracket so that it can be mounted on the floor, wall or
ceiling; whichever place is convenient. The hose guide arm can be moved to the position desired by removing
the screws fastening the guide bracket to the reel base. Shift the guide arm bracket so the hose comes off the
reel at the desired position and replace the screws.
Dimensions
A 17 1/2”
B 16 1/2”
C 9 3/4”
D 2 1/2”
E 6”
A
B
C
DE

Series 5005 Spring Driven Hose Reels
Page 2 www.reelcraft.com
Item # Part # # Req. Description Item # Part # # Req. Description Item # Part # # Req. Description
1 300031 2 1” Snap Ring 10 500107 1 Guide Arm Ass’y 18 400012 1 Latch Bushing
2 300034 3 Spacing Washer 11 300011 9 Hex Lock Nut 19 400018 1 Latch Spring
3 S295-102 3 Hex Screw 12 261360 1 Spring Case Stud 20 400020 1 O-ring
4 260149 1 Reel Flange 13 300006 1 3/8-16 x 1/2” Set Screw 21 400109 1 Latch Plate Ass’y
5 260151 1 Sheave Disk 14 600094 1 Spring Case & Hub Ass’y 22 2-117440 1 U-Bolt Hose Clamp
6 500019 1 Latch Cam 16 600029 1 Base Ass’y 24 261650-1 2 1/4-20 Nylock Nut
7 260648 1 Spring Arbor 17 400021 1 Latch Bumper 30 S82-15 1 Nyloc Nut 10-32 x 3/8”
Item # Description # Req. Model
5605 OLP Model 5650 OLP Model 5605 OMP Model 5405 OHP Model 5435 OHP
8 Hose Bumper Ass’y 1 None 1-HR1004 None None 1-HR1004
9 Hose Ass’y 1 None 601013-50 None None 20-260044
15 Drive Spring Ass’y 1 600050 600050 600050 600050 600020
25 Main Shaft 1 400015 400015 500008 500015 500015
26 Swivel & Ell Ass’y 1 None None 600358 600034 600034
27 90° Elbow 1 None None S257-72 S257-10 S257-10
28 90° Elbow 1 None None S257-25 None None
29 Swivel Ass’y 1 600886 600886 602032 260042 260042
Hose I.D. and Length None 3/8” x 50’ None None 1/4” x 35’
Reel Inlet Connection 3/8” F.P.T. 3/8” F.P.T. 3/8” F.P.T. 1/4” F.P.T. 1/4” F.P.T.
Max. Operating Pressure 500 P.S.I. 300 P.S.I. 3000 P.S.I. 5000 P.S.I. 5000 P.S.I.
Max. Operating Temperature 210°F 150°F 210°F 210°F 210°F
9
8
7
6
5
10 11 12
13
11
14
15
16
17
18
19
20
21
30
22
24
25
27
26
27
28
29
1
2
3
4
