FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-665c
I1200S
Wood Insert
11/24/14
Owners & Installation Manual
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-re.com

2I1200 Regency Wood Insert
Thank-you for purchasing a
REGENCY FIREPLACE PRODUCT.
The pride of workmanship that goes into each of our products will give you years of trouble-free
enjoyment. Should you have any questions about your product that are not covered in this manual,
please contact the REGENCY DEALER in your area.
Keep those REGENCY FIRES burning.
SAFETY NOTE: If this Insert is not properly installed, a house re may result. For your safety,
follow the installation instructions, contact local building or re ofcials about restrictions and
installation inspection requirements in your area.
The authority having jurisdiction (such as municipal building department, re department,
re prevention bureau, etc.) should be consulted before installation to determine the need
to obtain a permit.

I1200 Regency Wood Insert 33
TABLE OF CONTENTS
SAFETY LABEL
Safety Label...................................................................4
UNIT DIMENSIONS
With standard ue adaptor ............................................5
With offset ue adaptor..................................................6
INSTALLATION
Before Installing Your Insert...........................................7
Chimney Specications .................................................7
Fireplace Specications.................................................7
Masonry And Factory Built Fireplace Clearances .........8
How To Determine If Alternate.......................................8
Floor Protection Materials Are Acceptable.....................8
Installing Your Insert ......................................................9
Installation Into a Masonry Fireplace...........................10
Installation Into a Factory Built Fireplace.....................10
Stainless steel smoke deector Installation................. 11
Faceplate, Trim & Optional..........................................12
Bottom Faceplate & Fan Support Installation..............12
Fan / Blower ................................................................16
Door Handle ................................................................17
Firebrick Assembly ......................................................17
Draft Control ................................................................17
Brick Flue Bafe & Secondary Air Tube Installation ....17
Screen Door ................................................................18
OPERATING INSTRUCTIONS
First Fire ......................................................................18
Fan Operation..............................................................19
Ash Disposal................................................................19
Some Safety Guidelines..............................................19
MAINTENANCE
Creosote......................................................................19
Maintenance Of Gold-plated Doors.............................20
Door Gasket ................................................................20
Door Latch Adjustment ...............................................20
Glass Cleaning ............................................................20
Glass Replacement .....................................................20
Glass Removal ............................................................20
PARTS LIST
Main Assembly ............................................................21
Faceplates...................................................................22
Firebrick.......................................................................23
WARRANTY
Warranty ......................................................................27
http://oee.nrcan.gc.ca/residential/personal/retrot-homes/retrot-qualify-grant.cfm

4I1200 Regency Wood Insert
SAFETY LABEL
This is a copy of the label that accompanies each
I1200S Wood Insert. We have printed a copy
of the contents here for your review.
NOTE: Regency units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is
the correct one.
Part #: 918-666b
Colour: Black on grey, except for selected items which are printed red.
Size: File is at 100%. 9.58" W x 3.11" H
Apr. 26/07: Created artwork to be 100% for printing.
Apr. 7/11: Updated yr. of manufacture/ added 5.5" liner
Oct.3/13: Rev. A - Updated yr of manufacture
Nov.25/14: Rev. B - Updated ETL logo
LISTED FACTORY BUILT FIREPLACE INSERT
CERTIFIED FOR USE IN CANADA AND U.S.A.
MODEL: I1200S
TESTED TO:
ULC S628-M93 / UL 1482-1998 / ULC S627-00 / UL 737-2000 REPORT NO. 632-3198 (SEPT.1993)
DO NOT REMOVE THIS LABEL
326
COMPONENTS REQUIRED FOR INSTALLATION: 5.5" (140mm) or 6" (152mm)STAINLESS STEEL LINER.
STANDARD ADAPTOR (171-932) OR OFFSET ADAPTOR (171-936).
OPTIONAL COMPONENT: FAN (170-915), ELECTRICAL RATING: VOLTS 115, 60 HZ, 0.6 AMPS, SCREEN DOOR (846-101)
DO NOT REMOVE BRICKS OR MORTAR IN MASONRY FIREPLACE. FOR USE WITH SOLID WOOD FUEL ONLY. DO NOT USE GRATE
OR ELEVATE FIRE. BUILD WOOD FIRE DIRECTLY ON HEARTH. OPERATE WITH FEED DOOR CLOSED, OPEN TO FEED FIRE ONLY.
REPLACE GLASS ONLY WITH CERAMIC GLASS (5MM). INSPECT AND CLEAN CHIMNEY FREQUENTLY. UNDER CERTAIN CONDITIONS
OF USE CREOSOTE BUILDUP MAY OCCUR RAPIDLY. DO NOT OVERFIRE, IF INSERT GLOWS YOU ARE OVER-FIRING.
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS (MEASURED FROM INSERT BODY)
INSTALL ONLY ON A NON-COMBUSTIBLE HEARTH RAISED (F) 1.5IN / 38MM
ABOVE AN ADJACENT COMBUSTIBLE FLOOR. COMBUSTIBLE FLOOR
MUST BE PROTECTED BY NON-COMBUSTIBLE MATERIAL EXTENDING
(E) 16 IN / 405MM TO FRONT AND (G) 8IN / 205MM TO SIDES FROM FUEL
DOOR.
918-666b
MANUFACTURED BY:
FPI FIREPLACE PRODUCTS
INTERNATIONAL LTD.
6988 VENTURE ST.
DELTA, BC V4G 1H4
HOT WHILE IN OPERATION
DO NOT TOUCH. KEEP CHILDREN,
CLOTHING AND FURNITURE AWAY.
CONTACT MAY CAUSE SKIN BURNS.
READ ABOVE INSTRUCTIONS.
CAUTION
ADJACENT SIDEWALL A) 15in / 380mm
MANTLE B) 20in / 510mm
TOP FACING C 14in / 355 mm
SIDE FACING D) 7.375in / 185mm
INSTALL AND USE ONLY IN ACCORDANCE WITH THE MANUFACTURER'S INSTALLATION AND OPERATING INSTRUCTIONS. INSTALL AND USE ONLY
IN MASONRY FIREPLACE OR FACTORY BUILT FIREPLACE.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION IN YOUR AREA.
UNITED STATES ENVIRONMENTAL PROTECTION
AGENCY CERTIFIED TO COMPLY WITH JULY 1990,
PARTICULATE EMISSION STANDARDS.
JAN FEB MAR APR MAY JUN JUL AUG SEPT OCT NOV DEC
2015 2016 2017
(Duplicate Serial #)
DATE OF MANUFACTURE
MADE IN CANADA
326

I1200 Regency Wood Insert 5
DIMENSIONS
WITH STANDARD FLUE ADAPTOR
6" (152mm) Diameter
STANDARD FLUE ADAPTOR (171-932)
Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) ue.

6I1200 Regency Wood Insert
DIMENSIONS
WITH OFFSET FLUE ADAPTOR
14-3/16” (360mm)
12-3/4” (324mm)
17-3/4” (451mm)
22-3/4” (578mm)
18-3/4” (476mm)
19-1/2” (496mm)
22-3/4” (578mm)
21-3/8” (543mm)
22-3/4” (578mm)
21-1/4” (540mm)
16-7/8” (428mm)
20-1/8” (511mm)
6" (152mm) Diameter
OFFSET FLUE ADAPTOR (171-936)
12-3/4” from flue centerline to rear of
faceplate
16-15/16” (430mm)
Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) ue.

I1200 Regency Wood Insert 7
INSTALLATION
CHIMNEY
SPECIFICATIONS
Before installing, check and clean your chimney
system thoroughly. If in doubt about its condi-
tion, seek professional advice. Your Regency
Insert is designed for installation into a masonry
replace that is constructed in accordance with
the requirements of "The Standard for Chimneys,
Fireplaces, Vents, and Solid Fuel Burning Ap-
pliance", N.F.P.A. 211, the National Building
Code of Canada, or the applicable local code
requirements.
The appliance, when installed, must be electri-
cally grounded in accordance with local codes or,
in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical code, CSA C22.1.
Regency Inserts are designed to use either a
5.5" (140mm) or 6" (152mm) ue.
This insert must be connected to a code-ap-
proved masonry chimney or listed factory-built
replace chimney with a direct ue connector
into the rst chimney liner section. The chimney
size should not be less than or more than three
times greater than the cross-sectional area of
the ue collar.
Requirements for Installing
Solid-fuel Inserts in Factory-built
Fireplaces.
1) The insert must be tested and meet the
requirements of UL 1482 (U.S.) and or ULC
S628 (Canada) when tested in a masonry
replace built per ULC S628.
2) The factory-built replace must be listed per
UL 127 or ULC S610.
3) Clearances obtained from the masonry re-
place tests are also relevant for installation
in factory-built replaces.
4) Installation must include a full height listed
chimney liner type HT requirements (2100
degree F.) per UL 1777 (U.S.) or ULC
S635 (Canada). The liner must be securely
attached to the insert ue collar and the
chimney top.
5) Means must be provided to prevent room
air passage to the chimney cavity of the
replace. This may be accomplished by
sealing the damper area around the chimney
liner, or sealing the replace front.
Regency Inserts are constructed with the high-
est quality materials and assembled under strict
quality control procedures that ensure years of
trouble free and reliable performance.
It is important that you read this manual thor-
oughly and fully understand the installation and
operating procedures. Failure to follow instruc-
tions may result in property damage, bodily injury
or even death. The more you understand the
way your Regency Insert operates, the more
enjoyment you will experience from knowing that
your unit is operating at peak performance.
BEFORE INSTALLING
YOUR INSERT
1) Read all instructions before installing and
using your replace insert. Install and use
only in accordance with manufacturer’s
installation and operating instructions.
2) Check your local building codes - Build-
ing Inspection Department. You may
require a permit before installing your
insert. Be aware that local codes and
regulations may override some items in
the manual.
WARNING: Careless installation is the
major cause of safety hazard. Check all
local building and safety codes before
installation of unit.
3) Notify your home insurance company that
you plan to install a replace insert.
4) Your replace insert is heavy and requires
two or more people to move it safely. The
insert and surrounding structure can be
badly damaged by mishandling.
5) If your existing replace damper control
will become inaccessible once you have
installed your Regency Insert, you should
either remove or secure it in the open posi-
tion.
6) Inspect your replace and chimney prior
to installing your insert to determine that it
is free from cracks, loose mortar or other
signs of damage. If repairs are required,
they should be completed before installing
your insert. Do not remove bricks or mortar
from your masonry replace.
7) Do not connect the insert to a chimney
ue servicing another appliance or an air
distribution duct.
6) Alteration of the replace in any manner is not
permitted with the following exceptions;
a. external trim pieces which do not affect
the operation of the replace may be
removed providing they can be stored
on or within the replace for re-assembly
if the insert is removed.
b. the chimney damper may be removed
to install the chimney liner.
7) Circulating air chambers (i.e. in a steel
replace liner or metal heat circulator) shall
not be blocked.
8) Means must be provided for removal of the
insert to clean the chimney ue.
9) Inserts that project in front of the replace
must be supplied with appropriate supporting
means.
10) Installer must mechanically attach the sup-
plied label to the inside of the rebox of the
replace into which the insert is installed.
FIREPLACE
SPECIFICATIONS
Your replace opening requires the following
minimum sizes:
Height: 19" (483mm)
Width: 23" (584mm)
Depth:
(w/ standard ue adaptor) 13-3/4" (349mm)
(w/ offset ue adaptor) 16-1/2" (419mm)
Two faceplates are available to seal the
replace opening:
Standard 38" W x 26" H
Oversize 44" W x 30" H
Emissions from burning wood or gas could
contain chemicals known to the State of Cali-
fornia to cause cancer, birth defects or other
reproductive harm.
"WARNING: This replace has been converted
for use with a wood insert only and cannot be
used for burning wood or solid fuels unless
all original parts have been replaced, and the
replace re-approved by the authority having
jurisdiction."

8I1200 Regency Wood Insert
INSTALLATION
Clearance diagram for installations
Side and Top facing is a maximum of 1.5" thick.
Floor protection must non-combustible, insulative
material with an R value of 1.1 or greater.
* If the hearth extension is ush with the oor (F)
it must extend 19.5" in front of the body face
(E).
Note: Hearth Extension Width (G) is measured
from edge of fuel door to side of hearth.
** A non-combustible mantel may be installed
at a lower height if the framing is made of
metal studs covered with a non-combustible
board.
*** Mantel depth, maximum of 10" (254mm).
MASONRY AND FACTORY BUILT FIREPLACE CLEARANCES
The minimum required clearances to combustible materials when installed into a masonry or factory built replace are listed below.
H
HOW TO DETERMINE IF ALTERNATE
FLOOR PROTECTION MATERIALS ARE ACCEPTABLE
The specied oor protector should be 3/8"
(18mm) thick material with a K - factor of
0.84.
The proposed alternative is 4" (100mm) brick
with a C-factor of 1.25 over 1/8" (3mm) mineral
board with a K-factor of 0.29.
Step (a):
Use formula above to convert specication
to R-value.
R = 1/k x T = 1/0.84 x .75 = 0.893.
Step (b):
Calculate R of proposed system.
4" brick of C = 1.25, therefore
Rbrick = 1/C = 1/1.25 = 0.80
1/8" mineral board of k = 0.29, therefore
Rmin.bd. = 1/0.29 x 0.125 = 0.431
Total R = Rbrick + Rmineral board =
0.8 + 0.431 = 1.231.
Step (c):
Compare proposed system R of 1.231 to
specied R of 0.893. Since proposed system
R is greater than required, the system is
acceptable.
DEFINITIONS
Thermal Conductance:
C = Btu = W
(hr)(ft2 )(oF) (m2))(K)
Thermal Conductivity:
k = (Btu)(inch) = W = Btu
(hr)(ft3)(oF) (m)(K) (hr)(ft)(oF)
Thermal Resistance:
R = (ft2)(hr)(oF) = (m2)(K)
Btu W
Floor Protection
Please check to ensure that your oor protection and hearth will meet the standards for
clearance to combustibles. Your hearth extension must be made from a non-combustible
material.
Thermal oor protection is not required if the unit is
raised 3.5" minimum (measured from the bottom of
the stove). However, standard ember oor protection
is required. It will need to be a non-combustible mate-
rial that covers 16" (406 mm) in the US and 18" (450
mm) in Canada to the front of the unit and 8" (200
mm) to the sides.
If the unit is not raised, thermal oor protection required
is 18" (450 mm) in the US and Canada.
Unit Adjacent
Side Wall
(to Side)
A
Mantle **
(to Top)
B
Top
Facing
(to Top of Unit)
C
Side
Facing
(to Side of Unit)
D
Minimum
Hearth
Extension*
E
Minimum
Hearth
Thickness
F
Minimum
Hearth Side
Extension*
G
From Top of
Unit
H
I1200S 15" (381mm) 20" (508mm) 14" (356mm) 7-3/8"(187mm) 16" (406mm) 1.5" (38mm) 8" (203mm) 18-3/4"(476mm)

I1200 Regency Wood Insert 9
INSTALLATION
INSTALLING
YOUR INSERT
SAFETY NOTE: The insert is very heavy and
will require two or three people to move it into
position. The insert can be made a little lighter
by removing the cast iron door by opening it and
lifting it off its hinges. Be sure to protect your
hearth extension with a heavy blanket or carpet
scrap during the installation.
NOTE: You will be required to purchase either
the standard or offset 6" diameter (152mm)
ue adaptor that is best suited for the specic
installation.
List of Tools needed;
- Pull Rod (included with insert)
- 1/2” socket / ratchet
- 3/8 open face wrench
1) Install ex liner into existing chimney as
per liner manufacturer’s specications. See
diagram 1.
2) Install the required ue adaptor onto the end
of the ex liner. Secure the adaptor using
3 screws - 1 on the front, left and right side
as shown in diagram 2.
Alignment of the ue adaptor can be critical
during the install, it is recommended that the
ex liner be left as compressed as possible.
Before inserting the unit the adaptor should
hang, when level, slightly above the required
height.
Secure adaptor using 3 screws - 1 in the
front and 1 each on the left and right side.
3) Install the unit by rst setting the rear of
the unit into the replace. See diagram
3. Ensure that the unit is centered in the
existing replace and lined up with the ue
adaptor.
4) Slide the unit back until the ue adaptor is
slightly engaged.
5) At this point it is recommended to level the
unit and ensure that the leveling bolts rest
on the surface of the replace. This will keep
the adaptor from binding as the unit is slid
into position.
6) Insert the provided pull rod through the
hole in the top center of the unit. Secure
the threaded end into the ue adaptor as
shown in diagram 4. While sliding the unit
into place pull on the rod to ensure that
the ue adaptor is properly engaged. See
diagram 5.
Pull Rod
7) Ensure that the unit is still level.
8) To complete the installation and to ensure a
secure t and connection of the ue adaptor
to the insert, it is essential that the two bolts,
at washers and lock washers (supplied
with packaged manual) be installed and
tightened using a 1/2" socket as shown in
diagram 6. This prevents the possibility of
creosote drip and exhaust gas leakage.
9) Remove the pull rod from the top center of
the replace. See diagram 7.
10) Re-install the door if removed prior to
installation.
NOTE: The pull rod should not be thrown
away. It should be kept if the stove
is ever needed to be removed from
the replace.
Flex Liner
Pull Rod In Place
Pull Rod
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Diagram 7
Flue Adaptor

10 I1200 Regency Wood Insert
INSTALLATION
1) Positive Flue
Connection
with Cleanout
2) Direct Flue
Connection
with Cleanout
3a) Full Flue Liner
(No Cleanout
Required)
Note: A clean-out door is sometimes
required, by your inspector, to be
installed when either the Positive ue
connection or Direct ue connection
method is used.
The use of one of the connection methods listed
on this page not only increases the safety of your
insert by directing the hot gases up the ue, but
will also help increase the unit's efciency and
decrease creosote deposits in the chimney.
When a connected ue or liner is in use, the
insert is able to “breathe” better by allowing a
greater draft to be created. The greater draft can
decrease problems such as, difcult start-ups,
smoking out the door, and dirty glass.
INSTALLATION INTO A
FACTORY BUILT
FIREPLACE
1) When installed in a factory built replace, a
full stainless steel rigid or exible ue liner
is mandatory, for both safety and perform-
ance purposes. When a ue or liner is in
use, the insert is able to breathe better by
allowing a greater draft to be created. The
greater draft can decrease problems such
as, difcult start-ups, smoking out the door,
and dirty glass.
2) In order to position the ue liner, the exist-
ing rain cap must be removed from your
chimney system. In most cases the ue
damper should also be removed to allow
passage of the liner.
3) In most cases opening the existing spark
screens fully should give enough room for
the insert installation. If it does not, remove
and store.
When referencing installation or connec-
tion to masonry replaces or chimneys, the
masonry construction must or shall be code
complying.
INSTALLATION INTO A
MASONRY FIREPLACE
The insert must be installed as per the require-
ments of your local inspection authority. Three
methods of ue connection are acceptable in
most areas, these include:
1) Positive ue connection, where a large
blocking plate and a short connector pipe
is used.
2) Direct ue connection, where a smaller
blocking plate and a connector pipe to the
rst ue liner tile is used.
3) Full ue liner, where a stainless steel rigid
or exible liner pipe is routed from the insert
outlet collar to the top of the chimney.
Regency highly recommends the use of a full
liner as the safest installation and provides the
most optimum performance. Your retailer should
be able to help you decide which system would
be the best for your application.
In Canada this replace insert must be
installed with a continuous chimney liner
of 5.5" (140mm) or 6" (152mm) diameter
extending from the replace insert to the
top of the chimney. The chimney liner must
conform to the Class 3 requirements of
CAN/ULC-S635 or CAN/ULC-S640, Stand-
ard for Lining Systems for New Masonry
Chimneys.
4) If the oor of your replace is below the
level of the replace opening, adjust the
insert's levelling bolts to accommodate the
difference. When additional shimming is
required, use non-combustible masonry or
steel shims.
5) Measure approximately the alignment of the
ue liner with the position of the smoke outlet
hole on the insert to check for possible offset.
If an offset is required, use the appropriate
offset adaptor in your installation.
6) Once the above items have been checked,
slide your insert into position after rst po-
sitioning and securing the ue liner to the
offset adaptor.
Attach the rod to the adaptor and slide the
adaptor onto the unit as the unit is slid into
position. Ensure a positive connection.
Secure the adaptor to the unit by using 2
bolts, at washers, lock washers and one
screw in the front.
Re-install raincap at completion of installa-
tion.

I1200 Regency Wood Insert 11
INSTALLATION
The stainless smoke deector is located in the upper front area of the rebox. The deector is held in place with 2 bolts
Prior to the rst re, ensure deector is seated properly and secured with 2 hand tightened bolts.
To replace the deector, loosen o both bolts and slide defector upward and out. Install new defector and hand tighten bolts. Ensure positive location of
the defector prior to hand tightening.
WARNING: Operation of the unit with out proper installation of smoke deector will void warranty.
Smoke deector is installed through the door
opening in location shown in diagram
Smoke deector
Ensure defector is seated so bolts are situated
at the top of the keyhole before tightening.
STAINLESS STEEL SMOKE DEFLECTOR ADJUSTMENT / REPLACEMENT

12 I1200 Regency Wood Insert
INSTALLATION
FACEPLATE, TRIM & OPTIONAL
BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION
918-676c 01/28/08
1
I1200
FACEPLATE, TRIM, FAN & OPTIONAL
BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION
Regular Faceplate Dimensions:
Oversize Faceplate Dimensions:

I1200 Regency Wood Insert 13
INSTALLATION
918-676c 01/28/08
2
I1200
Regular/Oversize Faceplate Installation:
1) Thread the black 1/4" x 3/4" long hex bolts into the faceplate mount-
ing bracket as shown in Diagram 1, leaving them approximately 1/4"
out.
2) Fasten the faceplate mounting bracket to the side of the insert using 2
bolts for the top and bottom, see Diagram 1. Repeat for other side.
NOTE: The bolt and washer come attached to the side of the insert
and need to be removed and reused for fastening.
Diagram 1
3) Assemble the faceplate sides and top using the 1/4" x 1/2" long hex
bolts, lock washers and nuts provided. See Diagram 2.
Diagram 2
Rear View
4) Position the assembled faceplate side and top to the insert. Ensure
to align the draft rod into the opening of the faceplate as well as the
side faceplate slots with the bolts in the mounting brackets as shown
in Diagram 3.
5) Measure the height between the hearth and the bottom of the side
faceplate.
6) Cut the bottom faceplate to the measured height using a metal cutting
blade.
7) Remove the faceplate assembly from the insert and attach the cut
bottom faceplate to the faceplate sides using the 1/4" x 1/2" long hex
bolts, lock washers and nuts provided as shown in Diagram 4.
Diagram 3
Rear View
Diagram 4
Optional Regular/Oversize Bottom Faceplate
Installation:
If the insert is going to sit on the hearth
proceed to "Faceplate Trim Installation"
(step 8) otherwise continue on to "Bottom
Faceplate Installation" (step 4).

14 I1200 Regency Wood Insert
INSTALLATION
918-676c 01/28/08
3
I1200
8) Assemble the left and right side trim to the top trim using the trim clips
provided as shown in Diagram 5.
9) Fit the trim assembly over the faceplate assembly. See Diagram 6.
10) Drill two 5/32" diameter holes through the trim and side panels and
screw the trim to the panels using the self tapping screws provided
as shown in Diagram 6.
11)Mount the completed faceplate / trim assembly to the insert. Ensure
to align the side faceplate slots with the hex bolts in the mounting
brackets and tighten to secure in place.
Diagram 5
Diagram 6:
Shown with Optional Bottom Faceplate
Regular/Oversize Faceplate Trim Installation:
(Black Trim included with Regular/Oversize Faceplate
or Optional Brass Trim)
Fan Installation:
12) Install the fan assembly to ash lip of insert as shown in Diagram 7.
Diagram 7
13) To install the optional fan support, measure the distance between
the hearth and the bottom surface of the fan housing as shown in
Diagram 8.
Diagram 8: Side View
a) Align the fan with the offset clips on the bottom of the ashlip.
b) Slide the supports into the clips. The tension holding the clips
in place may be adjusted by increasing or decreasing the offset
spacing of the clips.
c) Ensure that the power cord is not in contact with any hot stove
surfaces.
Optional Fan Support / Bottom Faceplate Installation:

I1200 Regency Wood Insert 15
INSTALLATION
918-676c 01/28/08
4
I1200
14) Cut the bottom edge of the fan support and bottom faceplate (using
a metal cutting blade) to the length measured in step 13.
15) Remove the fan assembly from the ash lip of the insert and position
the fan support to the bottom of the fan assembly.
16) Drill 4 x 5/32" holes to the underside of the fan assembly using the
holes in the fan support as a guide. See Diagram 9.
17) Secure the fan support to the fan assembly using 4 self tapping
screws. See Diagram 9.
Diagram 9: Rear / Bottom View
18) Secure the bottom faceplate to the 3-sided faceplate using the 4
supplied bolts/washers.
19) Discard both side trims that were included with the regular/oversize
faceplate and replace with the new extended trims supplied with the
fan support/bottom faceplate. Cut to desired length.
20) Fit the trim assembly over the faceplate assembly. See Diagram 6.
21) Drill two 5/32" diameter holes through the trim and side panels and
screw the trim to the panels using the self tapping screws provided
as shown in Diagram 6.
22) Re-attach the fan/fan support assembly to the ash lip of the insert.
Completed Faceplate Assembly

16 I1200 Regency Wood Insert
INSTALLATION
Ground
Fan Fan
Ground Green
Neutral
Live
White
Fan
Switch
Manual/
Auto
Switch
Black Black
High (Black)
Low (Red)
Black
Fan Thermodisc
(normally open)
120V AC
60 Hz
Blower / Fan Wiring Diagram
FAN / BLOWER
Your fan should only be installed once the unit
is in place in order to prevent any damage to
the fan.
1) Align the fan support with the offset clip on
the bottom of the ashlip.
2) Slide the supports into the clips. The tension
holding the clips in place may be adjusted by
increasing or decreasing the offset spacing
of the clips.
3) Ensure that the power cord is not in contact
CAUTION: Label all wires prior
to disconnection when servic-
ing controls. Wiring errors can
cause improper and dangerous
operation.
WARNING:
Electrical Grounding Instructions
This appliance is equipped with a
three pronged (grounding) plug for
your protection against shock hazard
and should be plugged directly into
a properly grounded three-prong
receptacle. Do not cut or remove the
grounding prong from this plug.
with any hot stove surfaces.
Do not turn fan ON until your insert has
reached operating temperature or at least
30 minutes after starting re.
Installer: Please record unit serial number here before installing blower.
Serial No.______________________________

I1200 Regency Wood Insert 17
INSTALLATION
BRICK FLUE BAFFLE &
SECONDARY AIR TUBE
INSTALLATION
The ue bafe system located in the upper area
of the rebox is removable to make cleaning
your chimney system easier. The brick bafes
must be installed prior to your rst re. Smoke
spillage and draft problems may occur if the
bafes are improperly positioned. Check the
position of the brick bafes on a regular basis as
they can be dislodged if too much fuel is forced
into the rebox.
FIREBRICK ASSEMBLY
Firebrick is included to extend the life of your
insert and radiate heat more evenly. Check to
see that all rebricks are in their correct posi-
tions and have not become misaligned during
shipping.
DOOR HANDLE
Attach spring handle by rotating counter clock-
wise onto rod. Ensure that the rod ts into the
entire length of the spring handle.
Left = Open Right = Closed
Side View
Front View
Draft Rod
Front View
DRAFT CONTROL
Before establishing your rst re, it is important
that your fully understand the operation of you
draft control. The draft rod is on the left side
of the Insert and it controls the intensity of the
re by increasing or decreasing the amount of
air allowed into the rebox. To increase your
draft - slide left, and to decrease - slide right.
As well as a primary and glass wash air system,
1) If the two air tubes are installed continue
on to Step 2), if not, follow the instructions
below. Install the air tube into the holes in the
side channels. The notch goes on the right
hand side with the air holes facing toward
the door. Slide the tube into the left hand
side, as far as possible and then bring it back
into the hole on the right hand side until it
locks into position. If the tube will not slide
in easily simply use a pair of vise grips or
pliers and tap it into place with a hammer. A
tighter t will ensure the tube will not move
when the unit is burning.
2) Slide the left bafe brick over the front air
tube and then slide it back over the rear air
tube.
3) Tilt the left bafe brick up on top of the side
channel and it will leave enough room to
position the right bafe brick in the same
manner as Step 1) above. Then reposition
the left bafe brick at on the air tube.
4) Important: push both bafe bricks so
they are tight against the side walls and
to the back.
Note: When getting the chimney cleaned,
remove the bafe bricks for access
to the ue, then replace them when
cleaning is completed.
the unit has a full secondary draft system that
allows air to the induction ports at the top of the
rebox, just below the ue bafe.
WARNING: To build a re in ignorance or
to disregard the information contained in
this section can cause serious permanent
damage to the unit and void your warranty.

18 I1200 Regency Wood Insert
INSTALLATION
FIRST FIRE
When your installation is completed and in-
spected, you are ready for your rst re.
1) Open draft control fully.
2) Open rebox door and build a small re using
paper and dry kindling, wait a few minutes
for a good updraft in the ue to establish the
re. Leaving the door slightly open will help
your re start more rapidly.
CAUTION: Never leave unit unattended
if door is left open. This procedure is for
re start-up only, as unit may over-heat
if door is left open for too long.
3) With the draft still in the fully open position,
add two or three seasoned logs to your re.
Form a trench in the ash bed to allow air to
reach the rear of the rebox prior to closing
the door.
4) After about 15 to 20 minutes, when your
wood has begun to burn strongly, adjust
your draft control down to keep the re at a
moderate level.
WARNING: Never build a roaring re in
a cold stove. Always warm your stove
up slowly!
5) Once a bed of coals has been established,
you may adjust the draft control to a low
setting to operate the unit in its most efcient
mode.
6) During the rst couple of hours, keep the
combustion rate at a moderate level and
avoid a large re until the paint is cured.
Only then can you operate the insert at its
maximum setting, and only after the metal
has been warmed.
7) For the rst few hours, the insert will give
off an odour from the paint. This is to be
expected as the high temperature paint
becomes seasoned. Windows and/or doors
should be left open to provide adequate
ventilation while this temporary condition
exists. Burning the insert at a very high
temperature the rst few times may damage
the paint. Burn res at a moderate level the
rst few days.
8) Do not place anything on the insert top
during the curing process. This may result
in damage to your paint nish.
9) During the rst few hours it may be more
difcult to start the re. As you dry out
your re brick and your masonry ue (if
applicable), your draft will increase.
10) For those units installed at higher elevations
or into sub-standard masonry replaces,
drafting problems may occur. Consult an
experienced dealer or mason on methods
of increasing your draft.
11) Some cracking and popping noises may be
experienced during the heating up process.
These noises will be minimal when your unit
reaches temperature.
12) Before opening your door to reload, open
draft fully for approximately 10 to 15 seconds
until re has been re-established. This will
minimize any smoking.
13) All fuel burning appliances consume oxygen
during operation. It is important that you
supply a source of fresh air to your unit
while burning. A slightly opened window is
sufcient for this purpose.
CAUTION: If the body of your unit starts
to glow you are overring. Stop loading
fuel immediately and close the draft
control until the glow has completely
subsided.
14) Green or wet wood is not recommended for
your unit. If you must add wet or green fuel,
open the draft control fully until all moisture
has been dispersed by the intense re.
Once all moisture has been removed, the
draft control may be adjusted to maintain
the re.
15) If you have been burning your insert on a
low draft, use caution when opening the
door. After opening the damper, open the
door a crack, and allow the re to adjust
before fully opening the door.
16) The controls of your unit should not be
altered to increase ring for any reason.
FAN OPERATION
SCREEN DOOR
Hook screen to the inside on the right side
of the rebox door opening. Lock in place by
turning handle.
Back Side of Screen Shown
WARNING
Operate with doors fully open or fully
closed. If doors are left partly open,
gas and ame may be drawn out of
the opening, creating risks from both
re and smoke.
When operated with doors fully open
the manufacturer supplied screen
must be used.
NOTE: The handle must be positioned at 10
o'clock when closed to avoid the handle from
getting hot and to ensure the screen stays in
place.
Handle Lock
Hooks
Handle at 10 o'clock position.
How to Light & Maintain a Wood Stove Fire

I1200 Regency Wood Insert 1919
INSTALLATION
OPERATING INSTRUCTIONS
16) Do not burn salt drift wood as it will corrode
your unit and void the warranty.
17) Do not strike or slam the glass door shut as
this may cause the glass to break.
18) Do not operate the unit if the glass is broken
or missing. Do not operate the unit if the
gasketing is worn out and not sealing the
door or the glass.
It is very important to carefully maintain your
insert, including burning seasoned wood and
maintaining a clean stove and chimney system.
Have the chimney cleaned before the burning
season and as necessary during the season, as
creosote deposits may build up rapidly. Moving
parts of your insert require no lubrication.
CREOSOTE
When wood is burned slowly, it produces tar and
other organic vapors, which form creosote when
combined with moisture. The creosote vapors
condense in the relatively cool chimney ue of a
slow-burning re. As a result, creosote residue
accumulates on the ue lining. When ignited, this
creosote can make an extremely hot re.
Removal for Cleaning etc.
Removal of your insert for cleaning purposes
is usually not required if a proper installation
has been done. In the event that removal is re-
quired, be sure not to damage any parts needed
for re-installation. In most cases removal and
replacement of the bafe system should allow
full access for cleaning.
WARNING: Things to remember in case
of chimney re:
1) Close draft control
2) Call the Fire Department
Ways to Prevent and
Keep Unit Free of Creosote
1) Burn insert with draft control wide open for
about 15 minutes every morning during burn-
ing season. This helps to prevent creosote
deposits within the heating system.
2) Burn insert with draft control wide open for
about 10 - 15 minutes every time you add
fresh wood. This allows the wood to achieve
the charcoal stage faster and burns up any
wood vapors which might otherwise be
deposited within the system.
3) Only burn seasoned wood! Avoid burning
wet or green wood. Seasoned wood has
The fan is to be operated only with the draft
control rod pulled out at least 1/2" from the
fully closed position. The fan is not to be
operated when the draft control rod is in the
closed position (pushed in). The fully closed
position is the low burn setting.
The fan must not be turned on until a re has
been burning for at least 30 minutes. Also note
it is recommended that the fan be turned off
before each fuel loading and again wait for 30
minutes before the fan is turned on again. This
is too allow the stove to reach it's optimum
temperature.
To operate fan automatically, push switch on
side of fan housing to "Auto" and second switch
to either "High" or "Low" for fan speed. The
automatic temperature sensor will engage the
blower when the unit is at temperature and will
shut off the blower once the re has gone out
and the unit has cooled to below a useful heat
output range.
To manually operate the fan system, push the
rst switch to "Man" and second switch to either
"high" or "Low". This will bypass the sensing
device and allow full control of the fan. Switching
from "Auto" to "Manual" or "High" to "Low" may
be done at any time.
ASH DISPOSAL
During constant use, ashes should be removed
every few days. Please take care to prevent the
build-up of ash around the start-up air housing
located inside the rebox, under the loading
door lip.
DO NOT ALLOW ASHES TO BUILD UP TO
THE LOADING DOORS.
Only remove ashes when the re has died down.
Even then, expect to nd a few hot embers.
Always leave 1 to 2 inches of ash in the bottom
of the rebox. This helps in easier starting and
a more uniform burn of your re.
Ashes should be placed in a metal container with
a tight tting lid. The closed container of ashes
should be placed on a noncombustible oor or
on the ground, well away from all combustible
materials, pending nal disposal. If the ashes
are disposed of by burial in soil or otherwise
locally dispersed, they should be retained in the
closed container until all cinders have thoroughly
cooled. Other waste should not be placed in
the ash container.
SOME SAFETY
GUIDELINES
1) Never use gasoline, gasoline type lantern fu-
els, kerosene, charcoal lighter fuel, or similar
liquids or chemicals to start or ‘freshen up’ a
re in your insert. Keep all such liquids well
away from the heater while it is in use.
2) Never use alternate fuels such as charcoal
that have the possibility of generating carbon
monoxide.
3) Keep the door closed during operation and
maintain all seals in good condition.
4) Do not burn large quantities of paper in your
insert.
5) Do not burn garbage or ammable uids.
6) If you have smoke detectors, prevent smoke
spillage as this may set off a false alarm.
7) Do not overre your insert. If the insert or its
ue bafe begin to glow, you are overring.
Stop adding fuel and close the draft control.
Overring can cause extensive damage to
your stove including warpage and premature
steel corrosion. Overring will void your
warranty.
8) Do not permit creosote or soot buildup in the
chimney system. Check and clean chimney
at regular intervals.
9) Your Regency Insert can be very hot. You
may be seriously burned if you touch the
insert while it is operating. Warn children of
the burn hazard. Keep furniture and clothing
away.
10) The insert consumes air while operating,
provide adequate ventilation with an air
duct or open a window while the insert is in
use.
11) Do not use grates, irons or other methods
for supporting fuel. Burn directly on the
bricks.
12) Open the draft control fully for 10 to 15
seconds prior to slowly opening the door
when refuelling the re.
13) Do not connect your unit to any air distribu-
tion duct.
14) Your insert should burn dry, standard re-
wood only. The use of “mill ends” is discour-
aged as this fuel can easily overheat your
insert. Evidence of excessive overheating
will void your warranty. As well, a large por-
tion of sawmill waste is chemically treated
lumber, which is illegal to burn in many areas.
Chemically treated re logs also must not
be burned in your insert.
15) Do not store any fuel closer than 2 feet from
your unit.

20 I1200 Regency Wood Insert
MAINTENANCE
been dried at least one year.
4) A small hot re is preferable to a large
smouldering one that can deposit creosote
within the system.
5) Check the chimney at least twice a month
during the burning season for creosote
build-up.
6) Have chimney system and unit cleaned by
competent chimney sweeps twice a year
during the rst year of use and at least once
a year thereafter or when needed.
MAINTENANCE OF
GOLD-PLATED DOORS
The gold electroplated nish on the doors
requires little maintenance, and need only be
cleaned with a damp cloth. DO NOT use abrasive
materials or chemical cleaners, as they may
harm the nish and void the warranty.
DOOR GASKET
If the door gasket requires replacement, 7/8"
diameter material must be used. A proper high
temperature gasket adhesive is required. A
gasket repair kit, Part # 846-570 is available
from your local Regency dealer.
DOOR LATCH
ADJUSTMENT
The door latch may require adjustment as the
door gasket material compresses over time.
Removal of the spacer washer, shown in the
diagram below, will allow the latch to be moved
closer to the door frame, causing a tighter seal.
Remove and replace the nuts, washer as shown.
GLASS CLEANING
Do not attempt to clean the glass when it is hot,
allow the glass to cool before cleaning.
Do not use abrasive cleaners to clean the glass.
Your local retailer can supply you with special
glass cleaner if plain water and a soft cloth does
not remove all deposits.
GLASS
REPLACEMENT
Your Regency Insert is supplied with 5 mm.
Neoceram ceramic glass that will withstand
the highest heat that your unit will produce. In
the event that you break your glass by impact
- purchase your replacement from an authorized
Regency dealer only, and follow our step-by-step
instructions.
GLASS REMOVAL
Allow the stove to cool before removing or replac-
ing glass. Remove the door from the insert and
remove the glass retainer. Use caution when
removing broken glass to prevent injury.
When placing the replacement glass in the
door, make sure that the glass gasketing will
properly seal your unit. Replace the retainer
and tighten securely, but do not wrench down
on the glass as this may cause breakage. Do
not substitute materials. If your glass door does
break, do not continue to use your unit until it
has been replaced.
Cleaning & Maintaining Your Wood Stove
