Reliable F1 LO User manual

Reliable Automatic Sprinkler Co., Inc., 103 Fairview Park Drive, Elmsford, New York 10523
Bulletin 117 Rev. X
Bulletin 117 Rev. X
Model F1 LO
Model F1 LO Recessed
Standard Response
Sprinklers
The Designer®Model F1 LO Sprinkler
Standard Upright
Standard Pendent
Extended Coverage Pendent
Conventional
The Designer®II Model F1 LO Recessed Sprinkler
Recessed Pendent
Recessed Extended Coverage Pendent
For Model F1 ½” K 5.6 (80), 4.2 (60) & 2.8 (40) Sprinkler
Types refer to Bulletin 013, 024 or 027 for technical speci-
fications and approvals.
Approval Organizations
1. Underwriters Laboratories Inc. (UL)
2. Underwriters’ Laboratories of Canada (ULC)
3. Factory Mutual Approvals (FM)
4. Loss Prevention Council (LPCB, UK)
5. Verband der Schadenversicherer Gmbh
6. EC Certificate: 1438-CPD-0041 (R1712)
1438-CPD-0040 (R1722)
UL Listing Category
Sprinklers, Automatic & Open (VNIV)
Product Description
The F1 LO Glass Bulb Sprinkler combines the durability
of a standard sprinkler with the attractive low profile of a
decorative sprinkler. Whether installed on exposed pip-
ing or in an office ceiling, it is functional and attractive.
Beautifully versatile is the description for the Reliable
Model F1 LO Recessed Designer glass bulb sprinkler.
Recessing The Designer®enhances its already low pro-
file decorative appearance, and facilitates a rapid and
perfect installation.
Model F1 LO Recessed Designer’s escutcheon is high-
ly adjustable. The two piece construction makes field
installation a very easy and rapid task. This also allows
ceiling panels to later be removed without shutting down
the fire protection system, thus facilitating maintenance
of above ceiling services.
The Designer®Automatic Sprinkler utilizes a frangible
glass bulb. The glass bulb consists of an accurately con-
trolled amount of special fluid hermetically sealed inside
of a precisely manufactured glass capsule. This glass
bulb is specially constructed to provide fast thermal re-
sponse.
Upright
At normal temperatures, the glass bulb contains the
fluid in both the liquid phase and in the vapor phase. The
vapor phase can be seen as a small bubble. As heat is
applied, the liquid expands forcing the bubble smaller
and smaller as the liquid pressure increases. Continued
heating forces the liquid to push out against the bulb,
causing the glass to shatter, opening the waterway and
allowing the deflector to distribute the discharging wa-
ter.
The F1 LO Sprinkler temperature rating is identified by
the color of the glass bulb capsule as well as frame color
where applicable.
Pendent
Conventional Recessed Pendent
Extended Coverage
Pendent
Recessed Extended
Coverage Pendent

Technical data:
Models Response Deflector
Orientation
Discharge
Coefficient
Thread
Size
Max.
Working
Pressure
Min.
Working
Pressure
Temperature
Rating Finish
F1 LO Standard
Upright
Pendent
Conventional
K 8.0
3/4” NPT
(R3/4) 175 PSI 7 PSI
See
“Temperature
Ratings” Table
See
“Finish Table”
Material Data:
Frame Deflector Load Screw Cup Washer Bulb
DZR Brass
QM Brass CDA Alloy 510
CDA Alloy 210, 220, 314, 316, 360
or
CDA Alloy 544
CDA Alloy 314
or
CDA Alloy 353
Nickel Alloy 440 or Alloy 360
coated with PTFE Adhesive Tape Glass
See “Installation Data” table and from page for more details
2.

3.
Model F1 LO Upright, Pendent & Conventional Sprinklers
Installation Wrench: Model D Sprinkler Wrench
Installation Data:
Nominal
Orifice Thread Size Nominal K Factor Sprinkler Height
Approval
Organization
Sprinkler Identification
Numbers (SIN)
US Metric Upright Pendent
Standard-Upright (SSU) and pendent Deflectors Marked to Indicate Position
17/32” (20mm) ¾” NPT (R3/4) 8.0 115 2.3” (58mm) 1,2,3,4 (1) R1722(4)(5)(6) R1712(5)(6)
Conventional-Install in Upright or Pendent Position
20mm ¾” NPT (R3/4) 8.0 115 58.1mm 4 R1772
(1) LPCB Approval up to 286°F (141°C)
(2) FM Approval for SSU up to and including 200°F (93°C).
(3) (F1S5) VdS Approval for Intermediate Response 155°F (68°C) only.
(4) Polycoated upright UL and ULC listed corrosion resistant R1722.
(5) FM Approved for polycoated sprinklers R1722, R1712.
(6) Electroless Nickel PTFE (Teflon®)* Plated - cULus listed Corrosion Resistant.
Upright Pendent Conventional
Installation Data:
Nominal Orifice Thread Size Nominal K Factor Sprinkler Height Approval
Organization
Sprinkler Identification
Numbers (SIN)
US Metric
17/32” (20mm) ¾” NPT (R3/4) 8.0 115 2.3” (58mm) 1,2,3,4,8 R1712(1)(3)
(1) LPCB Approval is for 57°C through 93°C ratings.
(2) (F1S5) VdS Approval for Intermediate Response 155F (68°C) only.
(3) Electroless Nickel PTFE (Teflon®)* Plated - cULus listed Corrosion Resistant.
Recessed Pendent
(1) When installed directly into a tee, the escutcheon dimension’s adjustment will be reduced.
Model F1 LO Recessed Pendent Sprinkler
Installation Wrench: Model GFR2 Sprinkler Wrench
*DuPont Registered Trademark

4.
Model F1 LO Extended Coverage Pendent Sprinkler
Deflector: EC Pendent
Installation Wrench: Model D Sprinkler Wrench
Approval Type: Extended Coverage - Light Hazard Occupancy
Installation Data:
Nominal
Orifice
Thread
Size
Nominal K Factor Sprinkler
Height
Approval
Organization
Temperature Rating Sprinkler
Identification
Numbers (SIN)
US Metric °F °C
17/32”
(20mm)
¾” NPT
(R3/4) 8.0 115 2.2” (56mm) 1,2 135, 155 57, 68 R1742(1)
(1) Electroless Nickel PTFE (Teflon®)* Plated - cULus listed Corrosion Resistant.
Installation Data:
Nominal
Orifice
Thread
Size
Nominal K Factor Sprinkler
Height
Approval
Organization
Temperature Rating Sprinkler
Identification
Numbers (SIN)
US Metric °F °C
17/32”
(20mm)
¾” NPT
(R3/4) 8.0 115 2.2” (56mm) 1,2 135, 155 57, 68 R1742(1)
(1) Electroless Nickel PTFE (Teflon®)* Plated - cULus listed Corrosion Resistant.
Recessed Pendent
(1) When installed directly into a tee, the escutcheon dimension’s adjustment will be reduced.
Coverage Area
Flow
Rate
Pressure Nominal
K=8.0 (115)
Max. Area
Width x Length
gpm L/min psi bar ft. x ft. m x m
26 98.4 10.6 0,7 16 x 16 4.9 x 4.9
33 125.0 17.0 1,2 18 x 18 5.5 x 5.5
40 151.4 25,0 1,7 20 x 20 6.0 x 6.0
Coverage Area
Flow
Rate
Pressure Nominal
K=8.0 (115)
Max. Area
Width x Length
gpm L/min psi bar ft. x ft. m x m
26 98.4 10.6 0,7 16 x 16 4.9 x 4.9
33 125.0 17.0 1,2 18 x 18 5.5 x 5.5
40 151.4 25,0 1,7 20 x 20 6.0 x 6.0
Model F1 LO Recessed Extended Coverage Pendent Sprinkler
Deflector: EC Pendent
Installation Wrench: Model GFR2 Sprinkler Wrench
Approval Type: Extended Coverage - Light Hazard Occupancy
Extended Coverage Pendent
*DuPont Registered Trademark

Model F1 LO & F1 LO Recessed Sprinklers
Application
Model F1 LO and F1 LO Recessed sprinklers are used in
fixed fire protection systems: Wet, Dry, Deluge or Preaction.
Care must exercised that the orifice size, temperature rat-
ing, deflector style and sprinkler type are in accordance with
the latest published standards of the National Fire Protection
Association or the approving Authority Having Jurisdiction.
Installation
Model F1 LO sprinklers are standard response sprinklers
intended for installation as specified in NFPA 13. They must
also be installed with the Model D Sprinkler Wrench specifi-
cally designed by Reliable for use with these sprinklers.
The Model F1 LO Recessed Sprinklers are to be installed
with a maximum recess of ¾ inch (19mm). The Model F1
Escutcheon illustrated is the only recessed escutcheon to
be used with the Model F1 LO Pendent and EC Sprinklers.
The use of any other recessed escutcheon will void all ap-
provals and negate all warranties. When installing Model F1
LO Recessed Pendent and EC Pendent Sprinklers, use the
Model GFR2 Sprinkler Wrench. Any other type of wrench
may damage these sprinklers. Note: A leak tight 1/2” NPT
(R1/2) sprinkler joint can be obtained with a torque of 8 - 18
ft-lbs (10.8 - 24.4 N-m). Do not tighten sprinklers over maxi-
mum recommended torque. It may cause leakage or impair-
ment of the sprinklers.
Glass bulb sprinklers have orange covers to protect the
bulb during the installation process. REMOVE THIS PRO-
TECTION ONLY AFTER THE SYSTEM HAS BEEN HYDRO-
STATICALLY TESTED AND, WHEN APPLICABLE, THE ES-
CUTCHEONS HAVE BEEN INSTALLED. RASCO wrenches
are designed to install sprinklers when covers are in place.
Maintenance
The Models F1 LO and F1 LO Recessed Sprinklers should
be inspected and the sprinkler system maintained in ac-
cordance with NFPA 25. Do not clean sprinklers with soap
and water, ammonia or any other cleaning fluid. Remove
any sprinkler which has been painted (other than factory ap-
plied) or damaged in any way. A stock of spare sprinklers
should be maintained to allow quick replacement of dam-
aged or operated sprinklers. Prior to installation, sprinklers
should be maintained in the original cartons and packaging
until used to minimize the potential for damage to sprinklers
that would cause improper operation or non-operation.
Ordering Information
Specify:
1. Sprinkler Model
2. Sprinkler Type
3. Orifice Size
4. Deflector Type
5. Temperature Rating
6. Sprinkler Finish
7. Escutcheon Finish (where applicable)
Temperature Ratings
Classification
Sprinkler
Temperature
Maximum
Ambient
Temperature
Bulb
Color
°F °C °F °C
Ordinary 135 57 100 38 Orange
Ordinary 155 68 100 38 Red
Intermediate 175 79 150 66 Yellow
Intermediate 200 93 150 66 Green
High(1) 286 141 225 107 Blue
Extra High(1) 360 182 300 149 Mauve
(1) Not Available for F1 LO Recessed
Finishes(1)
Standard Finishes
Sprinkler Escutcheon
Bronze
Chrome
Polyester Coated(6)(7)
Brass
Chrome
White Painted
Special Application Finishes
Sprinkler Escutcheon
Electroless Nickel
PTFE(Teflon®)*(8)
Bright Brass(2)
Black Plated
Black Paint(3)(4)
Off White(3)
Chrome Dull
Lead Plated(3)(4)
Wax Coated(3)(4)(5)
Wax Over Lead(3)(4)
Electroless Nickel
PTFE (Teflon®)*
Bright Brass
Black Plated
Black Paint
Off White
Chrome Dull
(1) Other colors and finishes are available on special order.
Consult factory for details. Custom color painted sprin-
klers may not retain their UL Corrosion resistance list-
ing.
(2) 200°F (93°C) maximum.
(3) UL and ULC listed, and NYC approved only.
(4) 155°F to 200°F (68°C to 93°C) ratings only.
(5) 286°F (141°C) sprinklers may be coated for ambient
conditions not exceeding 150°F (66°C).
(6) UL listed corrosion resistant SIN number:
R1722 in standard Black or White. Corrosion resistance
in other polyester colors is available upon request.
(7) FM Approved for SIN R1722, R1712.
(8) cULus listed Corrosion Resistant SIN R1722, R1712 &
R1742 in Electroless Nickel PTFE (Teflon®)* Plated.
5.
*DuPont Registered Trademark

Reliable Automatic Sprinkler Co., Inc.
[phone] Sales Offices
[phone] Sales Fax
[phone] Corporate Offices
www.reliablesprinkler.com Internet Address
Manufactured by
Recycled
Paper
Revision lines indicate updated or new data.
EG. Printed in U.S.A. 09/14 P/N 9999970011
The equipment presented in this bulletin is to be installed in accordance with the latest published Standards of the National Fire Protection Association, Factory
Mutual Research Corporation, or other similar organizations and also with the provisions of governmental codes or ordinances whenever applicable.
Products manufactured and distributed by Reliable have been protecting life and property for over 90 years, and are installed and serviced by the most highly
qualified and reputable sprinkler contractors located throughout the United States, Canada and foreign countries.
• Automatic sprinklers
• Flush automatic sprinklers
• Recessed automatic sprinklers
• Concealed automatic sprinklers
• Adjustable automatic sprinklers
• Dry automatic sprinklers
• Intermediate level sprinklers
• Open sprinklers
• Spray nozzles
• Alarm valves
• Retarding chambers
• Dry pipe valves
• Accelerators for dry pipe valves
• Mechanical sprinkler alarms
• Electrical sprinkler alarm switches
• Water flow detectors
• Deluge valves
• Detector check valves
• Check valves
• Electrical system
• Sprinkler emergency cabinets
• Sprinkler wrenches
• Sprinkler escutcheons and guards
• Inspectors test connections
• Sight drains
• Ball drips and drum drips
• Control valve seals
• Air maintenance devices
• Air compressors
• Pressure gauges
• Identification signs
• Fire department connection
Reliable offers a wide selection of sprinkler components. Following are some of the many
precision-made Reliable products that guard life and property from fire around the clock.
Reliable...For Complete Protection
