Renz Renz ERW User manual

BINDING AND LAMINATING SYSTEMS
3:1
RW
SRW
SRW Comfort
ERW
max. 12 mm [1/2"]
up to 12 mm [1/2"] book thickness
binds up to 120 sheets
RENZ RING WIRE®
wire comb binding
3:1pitch
800-658-8788 www.abcoffice.com
abcoffice

OPEN HERE
4mm
8,47 mm
4 mm
3:1
SRWRW
The basic model for manual punching
and binding of all formats up to A4 [12"]
[3:1 pitch] [US model 11"]. Punching and
binding are done with a minimum of
effort due to the logically separated func-
tions of the convenient two-lever system
and the integrated binding part. Punches
up to 25 sheets [2.5 mm / 0.1"] and
binds up to 120 sheets.
Ring Wire binding machine [3:1] with
additional features: 38 punch pins that
can be individually disengaged and
adjustable margin control for perfect
format adjustment up to 34 cm [13.5"].
Punches up to 25 sheets [5 mm / 0.1"]
and binds up to 120 sheets. [other
features same as model RW]
3:1pitch opens flat and stays flat – 360° rotation
environmentally friendly and contemporary
secure and durable binding
smooth work flow
from top to bottom
up to 12 mm [1/2"] book thickness
for professional presentation of documents
easy insertion of the pages onto the open wire comb
accurate punching results with
minimal effort [manual versions].
With electrical machines, pun-
ching is done by pressing the
foot pedal.
3:1 pitch
34 loops on A4 size [12"],
32 loops on US size [11"],
RENZ RING WIRE®
available in 9 colors
[US = 8 colors]
Easy to use: step 1
The paper drops vertically into
the punching slot. Specially har-
dened punching stamps will
punch paper pads up to 2.5 mm
[0.1"] thick [2.0 mm/0.08" for
the SRW Comfort] and provide
800-658-8788 www.abcoffice.com
abcoffice

3:1 pitch
SRW Comfort ERW
12345678910111213141516171819202122232425262728293031323334
9/16"
1/2"
7/16"
3/8"
5/16"
1/4"
3/16"
14,3
12,7
11
9,5
8
6,9
5,5
The basic electrical model for Ring Wire
comb binding [3:1] – comfortable electric
punching and manual binding. An eco-
nomical solution for small to medium
quantities. The motor runs only when
the food pedal is pressed so that it uses
electricity only during the punching
cycle. [otherwise as model SRW].
Self-contained Ring Wire machine [3:1]
with professional punching process.
The powerful motor is fan-cooled and
is the professional solution for larger
quantities. Fast punching cycle takes
only approx. 1 second. [otherwise as
model SRW].
step 2
Select the wire comb, determined by the
number of sheets, and place it onto the
machine. Remove the punched paper from
the punch and place it directly into the
open wire comb. The horizontal closing
mechanism prevents the pages from slip-
ping out of the comb while closing.
step 3
Place the assembled book into
the open closing bars. Then pull
the closing lever to close the
wire.
step 4
Finished. Remove the bound
book.
Turn the adjustment knob to
select margin. For thicker books,
a larger margin is recommended
to prevent the pages from tea-
ring out.
integrated scale for easy determi-
nation of correct wire diameter
800-658-8788 www.abcoffice.com
abcoffice

Gestaltung Kunz Produkt und Grafik, Schwäbisch Gmünd, Telefon [phone]
Plister
WirePack
Order Nr. 49 472 0380
SPECIFICATIONS – AT A GLANCE
RENZ RING WIRE binding elements
are available in nine colors [US = 8 colors]
for book thicknesses up to 12 mm
[1/2"]. Front covers in transparent colors,
back covers in "chromolux" or in leather
finish, filing strips, ...
ACCESSORIES
Advantages of the WirePack packaging:
- each WirePack sheet is labeled with the
pitch and the diameter in inch and mm
- the wire elements can be removed from
the cardboard very easily using two fingers
- the elements do not entangle while being
taken off the WirePack sheet
- the wire elements will not fall off the
cardboard
Binding center with
4 WirePack sheets
or with 2 WirePack sheets
3:1pitch
Ask us about
machines in 2:1 pitch
*70/80 g/m2paper, 20# stock
RENZ SRW
36, 55, 19 cm
14" x 22" x 7.5"
13,5 kg [29.7 lb.]
yes [all]
up to 2.5 mm/ 0.1", 25 sheets*
yes
up to 12 mm [1/2"]
120 sheets*
up to 14.3 mm [9/16"]
up to 250 books/hr
up to max. 34 cm [13.5"]
38
3:1
34
32
up to 5,000 sheets/ hr
RENZ SRW Comfort
43, 57, 25 cm
17" x 22.5" x 10"
28,5 kg [62.7 lb.]
yes [all]
up to 2 mm/ 0.08", 20 sheets*
yes
up to 12 mm [1/2"]
120 sheets*
up to 14.3 mm [9/16"]
up to 280 books/hr
up to max. 34 cm [13.5"]
38
3:1
34
32
up to 10,000 sheets/ hr
230 V, 50 Hz/ 90 W
on request:
110V, 60 Hz/90 W
RENZ ERW
51, 55, 25 cm
20" x 22" x 10"
39 kg [85.8 lb.]
yes [all]
up to 2.5 mm/ 0.1", 25 sheets*
yes
up to 12 mm [1/2"]
120 sheets*
up to 14.3 mm [9/16"]
up to 300 books/hr
up to max. 34 cm [13.5"]
38
3:1
34
32
up to 20,000 sheets/ hr
230 V, 50 Hz/ 250 W
on request:
110V, 60 Hz/250 W
length, width, height
weight
disengageable
punch pins
punching thickness
adjustable margin
control
binding thickness
Ø of the wire element
binding capacity
up to max. size
number of punch pins
pitch
number of loops
on A4 size [12"]
on US size [11"]
punching capacity
motor
RENZ RW
36, 55, 19 cm
14" x 22" x 7.5"
13 kg [28.6 lb.]
no
up to 2.5 mm/ 0.1", 25 sheets*
no
up to 12 mm [1/2"]
120 sheets*
up to 14.3 mm [9/16"]
up to 250 books/hr
up to max. 30 cm A4 [12"] ,
US [11"]
34 [US model 32]
3:1
34
32
up to 5,000 sheets/ hr
