ResMed AIRMINI User manual

User guide
User guide
English

ResMed.com/AirMiniApp

English 1
ENGLISH
Welcome
The AirMini™system combines ResMed’s AirMini self-adjusting
pressure machine, masks and the AirMini app.
WARNING
Read this entire guide before using the machine.
CAUTION
In the US, Federal law restricts this device to sale by or on the order
of a physician.
Indications for use
The AirMini self-adjusting system is indicated for the treatment of
obstructive sleep apnea (OSA) in patients (female patients with mild to
moderate OSA when using AutoSet for Her treatment mode) weighing
more than 66 lb (30 kg).
It is intended for home and hospital use.
Contraindications
Positive airway pressure therapy may be contraindicated in some
patients with the following pre-existing conditions:
•severe bullous lung disease
•pneumothorax
•pathologically low blood pressure
•dehydration
•cerebrospinal fluid leak, recent cranial surgery, or trauma.

2
Adverse effects
You should report unusual chest pain, severe headache, or increased
breathlessness to your prescribing physician. An acute upper respiratory
tract infection may require temporary discontinuation of treatment.
The following side effects may arise during the course of therapy with
the machine:
•drying of the nose, mouth, or throat
•nosebleed
•bloating
•ear or sinus discomfort
•eye irritation
•skin rashes.
At a glance
The AirMini system includes the following:
•AirMini: the AirMini machine, power supply unit, drawstring bag
and one of the following:
•AirMini setup pack - F20: Air tubing, F20 connector OR
•AirMini setup pack - N20: Air tubing, N20 connector, HumidX™,
HumidX Plus OR
•AirMini mask pack for P10: Air tubing, AirFit P10 for AirMini mask
(M), P10 cushion (S), P10 cushion (L), HumidX, HumidX Plus, AirFit
P10 headgear clips.

English 3
Your AirMini system
Your AirMini system is comprised of the AirMini machine and one mask
pack or one setup pack.
A AirMini machine 6 20W power supply unit
B F20 connector for AirMini and air
tubing
7 F20 connector for AirMini
C N20 connector for AirMini and air
tubing
8 Vent
D AirFit P10 for AirMini and tubing 9 Vent module
1 Start/Stop button 10
Anti Asphyxia Valve (AAV)
2 Power inlet 11 N20 connector for AirMini
3 Air outlet 12 AirFit P10 for AirMini
4 Air filter cover 13 Heat moisture exchanger - HumidX
(blue) and HumidX Plus (gray)
5 Bluetooth™button 14 AirMini tubing
Your machine is compatible with ResMed's F20 and N20 series masks
and with the AirFit P10 for AirMini. Make sure all parts and accessories
used with the machine are compatible. For compatibility information,
refer to www.resmed.com for more information.

4
Your AirMini machine is designed to work with ResMed’s AirMini app.
However, the AirMini app is not essential to operate the machine. For
more information on the AirMini app, refer to Using your machine with
the AirMini app or the AirMini app Patient eHelp.
HumidX and HumidX Plus
The HumidX and HumidX Plus are waterless humidifiers. These are
designed to provide more comfort by improving the moisture level in
the air you breathe and offering relief from possible dryness.
The HumidX is a good starting point for finding the right level of
humidification. The HumidX Plus will improve the humidity level further
and is useful when the ambient humidity level is very low (eg, high
altitudes, on an aircraft).
The HumidX and HumidX Plus can be used with the N20 connector for
AirMini and AirFit P10 for AirMini only.
The HumidX and HumidX Plus must be replaced within 30 days of
opening the HumidX/HumidX Plus pack.
Setting up and starting therapy
Using your mask
Before you set up your machine, make sure you use a compatible
mask. For a full list of compatible masks for this device, see the
Mask/Device Compatibility List on
www.resmed.com/downloads/masks. If you do not have internet
access, please contact your ResMed representative.
For information on fitting your mask, refer to the mask user guide.
Use your AirMini machine only as directed by your physician or
healthcare provider.

English 5
Set up your machine
1. Plug the power supply unit
into the machine and the
power outlet. The connector
has an angled edge so that
the power cord can only be
inserted into the machine
one way.
2. Connect the gray end of the
AirMini tubing firmly to the
air outlet.
Add optional humidification
(for N20 or AirFit P10 for
AirMini only)
To insert the HumidX or HumidX
Plus:
1. Open the connector by
gently twisting it.
2. Hold the HumidX/HumidX
Plus at the sides, with the
colored side pointing down
and insert it.
3. Gently push together the
connector and twist until it
locks in place.

6
Connect your mask
1. Fit your mask as instructed in the mask user guide.
2. Attach the connector to your mask.
F20 Series N20 Series AirFit P10 for AirMini
Start therapy
1. Start therapy by pressing
the Start/Stop button or
breathe normally if
SmartStart™ is enabled.
Stop therapy
1. Remove your mask.
2. Press the Start/Stop button or wait until the machine stops if
SmartStop is activated.
Comfort features
Ramp Time, Pressure Relief and SmartStart are enabled on your
machine by default. For more information or to change these settings,
refer to the AirMini app Patient eHelp.

English 7
Using your machine with the AirMini app
Your AirMini machine can be used with ResMed’s AirMini app. Once
you have paired and connected your machine to your smart device via
Bluetooth, you can start and stop therapy, change comfort settings and
view your therapy data via the AirMini app. Data sent via Bluetooth is
encrypted to protect your privacy.
Connecting your machine and smart device
Before you start, ensure that the latest version of the AirMini app is
installed on your smart device. If not, download the app from the App
Store™or Google Play™.
1. Ensure your machine is set up correctly and plugged into a power
source.
2. On your smart device, enable Bluetooth.
3. Open the AirMini app.
The first time you open the AirMini app you will be asked to consent
to the use of cookies and to accept ResMed's Terms and Conditions
and Privacy Policy.
4. Check the boxes on the Welcome screen and then tap Continue.
5. On your machine, press the Bluetooth button when prompted by
the AirMini app.
When the light starts to flash blue , Bluetooth is enabled and your
machine is ready to connect.
6. On your smart device, tap Connect.
When your machine is discovered, the machine name appears in the
machine selection list.
7. Select the machine name from the list to connect.
8. The first time you pair your machine with your smart device, you will
need to perform the authentication procedure.
When prompted by the AirMini app, authenticate by entering the
four-digit key located on the back of your machine.

8
Alternatively, you can tap Scan code. You will be prompted to allow
the use of your smart device's camera and then to position the
machine’s QR code within the camera's viewing frame. The QR
code is found on the back of your machine.
9. Tap Continue to close the window.
When successfully connected, the Bluetooth connection icon
is displayed in the top right corner of the app.
Bluetooth status indicators
Bluetooth indicator light is flashing
blue.
Your machine is in discoverable mode and
ready for pairing.
Bluetooth indicator light is constantly
blue.
Your machine is connected to your
smartphone.
Bluetooth indicator light is constantly
white (airplane mode).
Bluetooth on your machine is disabled.
Bluetooth indicator light is off. Your machine is not connected to your
smartphone.
Note: Once therapy starts, the indicator light will start to fade.
Cleaning and maintenance
It is important that you regularly clean your AirMini machine to make
sure you receive optimal therapy. The following sections will help you
with disassembly, cleaning and checking your machine.

English 9
WARNING
•As part of good hygiene, always follow cleaning instructions.
Some cleaning products may damage the air tubing and affect
its function, or leave harmful residual vapours that could be
inhaled if not rinsed thoroughly.
•The AirMini connectors and AirFit P10 for AirMini contain a vent
system to prevent carbon dioxide build-up in the mask. The vent
system must be kept clean and clear of contamination in order
to function correctly. Blocking or modifying the vent system
may result in excessive carbon dioxide rebreathing.
•Regularly clean your AirMini tubing, connectors and mask
components to receive optimal therapy and to prevent the
growth of germs that can adversely affect your health.
•Regularly inspect the HumidX/HumidX Plus and follow the
cleaning and maintenance instructions to prevent the growth of
germs that can adversely affect your health.
CAUTION
If any visible deterioration of a system component is apparent
(cracking, discoloration, tears etc.), the component should be
discarded and replaced.
Disassembling
Remove the connector (F20 and N20 only)
1. Remove the connector
from the mask by
pressing the side buttons
and pulling it away

10
Disconnect the AirMini tubing (F20 only)
1. Disconnect the F20
connector from the AirMini
tubing by gently twisting it
and pulling it apart
Disconnect the AirMini tubing (N20 and AirFitP10 for AirMini only)
1. Disconnect the vent module
from the AirMini tubing by
gently twisting it and pulling
it apart.
Remove the HumidX/HumidX Plus (N20 and AirFit P10 for AirMini
only)
1. Disconnect the mask tube
from the vent module by
gently twisting it and pulling
apart. If you are using
HumidX or HumidX Plus,
remove it from the vent
module.
Note: The HumidX/HumidX Plus
cannot be washed.

English 11
Unplug the machine
1. Disconnect the AirMini
tubing from the machine
by pressing the side
buttons on the cuff and
pulling it away.
2. Unplug the power supply
unit from the power
outlet and the machine.
For mask disassembly instructions, see your mask user guide.
Cleaning and replacing parts
Detach all components according to the disassembly instructions and
make sure that the HumidX/HumidX Plus is removed and stored in a
clean, dry location.
Inspect the HumidX/HumidX Plus
1. Check daily for any signs of damage or blockages caused by dirt or
dust.
2. It must be replaced within 30 days after opening.
3.
When the HumidX/HumidX Plus is not being used, store it in a clean,
dry location.
Note: HumidX/HumidX Plus cannot be washed.

12
Clean the AirMini tubing
1. Clean and check the air tubing each week. AirMini tubing should be
replaced at least every six months.
2. Wash the AirMini tubing in warm water using a mild liquid
detergent, for example Ultra Joy dishwashing liquid.
3. Rinse thoroughly and allow to dry out of direct sunlight and/or heat.
4. Check the AirMini tubing and replace it if there are any holes, tears
or cracks.
Note: Do not wash the AirMini tubing in a dishwasher or washing
machine.
Clean the F20 connector for AirMini
1. Clean and check the F20 connector daily. The connector should be
replaced at least every six months.
2. Wash in warm water using a mild liquid detergent, for example Ultra
Joy dishwashing liquid.
3. Clean with a soft bristle brush paying particular attention to the vent
holes.
4. Rinse well under running water. Shake to remove excess water and
allow to dry out of direct sunlight.
5. Check that there is no dirt or dust in the vent holes.
Note: Do not wash in a dishwasher or washing machine.

English 13
Clean the N20 connector for AirMini
1. Clean and check the N20 connector daily. The connector should be
replaced at least every six months.
2.
Wash the connector in warm water using a mild liquid detergent, for
example Ultra Joy dishwashing liquid.
3. Clean with a soft bristle brush paying particular attention to the vent
holes inside the connector.
4. Rinse well under running water. Shake to remove excess water and
allow to dry out of direct sunlight.
5. Check that there is no dirt or dust in the vent holes.
Note: Do not wash in a dishwasher or washing machine.
Clean the AirFit P10 for AirMini
Refer to your mask guide for cleaning instructions.

14
Change the air filter
Replace at least every 6 months. It cannot be washed.
Check and replace it more often if there are any holes or blockages
caused by dirt or dust.
To change the air filter:
1. Slide the air filter cover off and remove the old air filter.
2. Insert a new air filter and replace the air filter cover.
Note:
•Make sure the air filter cover is fitted at all times to prevent water
and dust from entering the machine.
•The use of ResMed approved hypoallergenic filter will result in a
small reduction in the accuracy of the delivered pressure at high
leaks.
Cleaning the machine
1. Wipe the exterior with a dry cloth each week.
Reprocessing
The AirMini tubing, AirMini connectors, vent module and
HumidX/HumidX Plus must be discarded and replaced, as they can not
be disinfected and can not be used between other patients.
For mask cleaning instructions, see your mask user guide.

English 15
Traveling
You can take your AirMini machine with you wherever you go. Make
sure you have the appropriate power supply for the region you are
traveling to. For information on purchasing, contact your care provider.
Traveling by airplane
For some airlines, medical devices do not count toward carry-on
luggage limits. Please check with your airline for their policy regarding
medical equipment.
You can use your AirMini machine on a plane as it meets the Federal
Aviation Administration (FAA) requirements. Air travel compliance
letters can be downloaded and printed from www.resmed.com.
When using the machine on an airplane:
•When connected to power, disable Bluetooth (enter airplane mode)
by pressing and holding the Bluetooth button for at least ten
seconds until the indicator light is white.
•Do not use the AirMini app.
•Use the Start/Stop button on your machine to start therapy,
•To reconnect Bluetooth (exit airplane mode), press the Bluetooth
button.
Troubleshooting
If you have any problems, have a look at the following troubleshooting
topics. If you are not able to fix the problem, contact your care provider
or ResMed. Do not try to open the machine.
Problem/possible cause
Solution
Air is leaking from around my mask / Mask is too noisy
Mask may be fitted incorrectly. Make sure your mask is fitted correctly.
See your mask user guide for fitting
instructions or run the Mask Fit function
using the AirMini app to check your mask
fit and seal.

16
Problem/possible cause
Solution
The AirMini system may be assembled
incorrectly.
Make sure your AirMini system is correctly
assembled. Refer to Setting up and starting
therapy for more information.
Air pressure in my mask seems too low / It feels like I am not getting enough air
Ramp may be in progress. Using the AirMini app, confirm the Ramp
function has been enabled. If so, wait for
air pressure to build up or turn Ramp Time
off using the AirMini app.
HumidX or vent might be blocked. Inspect the HumidX and vent for blockages
or damage. Refer to Cleaning and
maintenance for more information.
HumidX may be wet. The HumidX should be dry when starting
therapy. Check if HumidX is wet and
replace as necessary.
I cannot start therapy
Power may not be connected. Connect the power supply unit and make
sure the plug is fully inserted. The green
indicator light on the power supply unit
should be illuminated.
Check that the green indicator light above
the Start/Stop button on the machine is
also illuminated.
My therapy has stopped
The air tubing may be disconnected. Ensure that the air tubing is properly
connected. Press the Start/Stop button to
continue therapy.
You may have high leak and SmartStop
enabled.
Make sure your mask is fitted correctly.
Alternatively, disable SmartStop.

English 17
Problem/possible cause
Solution
The Bluetooth indicator light is constantly white. I cannot pair to my machine
Bluetooth is disabled. Press the Bluetooth button for 3 seconds.
When the Bluetooth indicator light flashes
blue, the machine is ready for pairing.
I cannot scan the QR code to pair my machine
The camera is not focused or broken, or
the QR code label is damaged.
You can pair your machine manually by
entering into your smart device the four-
digit key found on the back of your
machine.
The QR code label is unreadable. Contact your care provider.
The light above the Start/Stop button is flashing green
An error has occurred on the machine. Unplug your machine. Wait a few seconds
and then plug it back in.
If the problem persists, contact your care
provider. Do not open the machine.
I am experiencing dryness (dry or blocked nose)
Mask may be fitted incorrectly Adjust and refit your mask to improve seal.
Check that there is no air leaking from the
mask.
If mask seal is good, try the HumidX Plus.
Humidification may be required Try therapy using the HumidX

18
Problem/possible cause
Solution
I am using the HumidX/HumidX Plus and I am getting uncomfortable droplets of
water on my nose, mask or air tubing
Humidity level is too high If using the HumidX: Remove the HumidX
and try therapy without humidification.
If using the HumidX Plus: Try the Humid X
instead. This will help to reduce the water
droplets.
If you are still experiencing problems,
contact your care provider.
Note: You may need to use the
HumidX/HumidX Plus when ambient
humidity conditions change.
General warnings and cautions
WARNING
•Make sure that you arrange the air tubing so that it will not twist
around the head or neck.
•Keep the power cord away from hot surfaces.
•Make sure the power cord and plug are in good condition and
the equipment is not damaged.
•If you notice any unexplained changes in the performance of the
machine, if it is making unusual sounds, if the machine or the
power supply are dropped or mishandled, or if the enclosure is
broken, discontinue use and contact your care provider or your
ResMed Service Center.
•Do not open or modify the machine. There are no user
serviceable parts inside. Repairs and servicing should only be
performed by an authorized ResMed service agent.
