Ricoh IS330DC - IS - Flatbed Scanner User manual



 

 
  

 
 

    
   
    
    
  
     
    
   
   
 
     
     
   
   
  
    
     
    
  
  
    
    
     
     
    
  
 
   
               
               
    
     
    
      
     
 
 
 
    
      
      
    
 
            
  
 
  
  
  
    
            
        
  
            
           
 
  
             
         
   


 
   
 
                       
  
                   
  

     
  
                
            
         

 
 
 
               
        
  
           
         
           
              
            
     
    
   

   
 
    
        
    
       
        
         
 

          
       
         
          
      
      
       
      

Color Scanner
Operating Instructions
Scanner Reference
ZDLH001E.eps
Read this manual carefully before you use this product and keep it handy for future
reference.
For safety, please follow the instructions in this manual.

Introduction
This manual contains detailed instructions on the operation and maintenance of this machine. To get
maximum versatility from this machine all operators should carefully read and follow the instructions in
this manual. Please keep this manual in a handy place near the machine.
Please read the Safety Information before using this machine. It contains important information related
to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
Power Source
Color Scanner: 120 V, 60 Hz, 10A or more
Please be sure to connect the Power Cord to a power source as above.
Two kinds of size notation are employed in this manual. With this machine refer to the inch version.
Important
Parts of this manual are subject to change without prior notice. In no event will the company be liable
for direct, indirect, special, incidental, or consequential damages as a result of handling or operating
the machine.
Caution:
Use of controls or adjustment or performance of procedures other than those specified in this manual
might result in hazardous radiation exposure.
Do not attempt any maintenance or troubleshooting other than that mentioned in this manual. This
scanner contains a laser beam generator and direct exposure to laser beams can cause permanent
eye damage.
Two kinds of size notation are employed in this manual. With this machine refer to the inch version.
Ricoh shall not be responsible for any damage or expense that might result from the use of parts other
than genuine Ricoh parts in your Ricoh office product.

i
Trademarks
Microsoft®, Windows®and Windows NT®are registered trademarks of Mi-
crosoft Corporation in the United States and/or other countries.
Other product names used herein are for identification purposes only and might
be trademarks of their respective companies. We disclaim any and all rights in
those marks.
Notes:
Some illustrations might be slightly different from your machine.
Certain options might not be available in some countries. For details, please con-
tact your local dealer.
Note
The proper names of the Windows operating systems are as follows:
•Microsoft
®Windows®95 operating system
•Microsoft
®Windows®98 operating system
•Microsoft
®Windows®Millennium Edition (Windows Me) operating system
•Microsoft
®Windows®2000 Professional
•Microsoft
®Windows®2000 Server
•Microsoft
®Windows NT®Server operating system Version 4.0
•Microsoft
®Windows NT®Workstation operating system Version 4.0
•Microsoft
®Windows NT®Server network operating system version 3.51
•Microsoft
®Windows NT®Workstation operating system version 3.51

ii
Safety Information
When using your scanner, the following safety precautions should always be
followed.
Safety During Operation
In this manual, the following important symbols are used:
RWARNING:
R
WARNING:
Indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
Indicates a potentially hazardous situation which, if instructions are
not followed, may result in minor or moderate injury or damage to
property.
•Connect the Power Cord directly into a wall outlet and never use an extension cord.
•Disconnect the power plug (by pulling the plug, not the cable) if the power cable or plug
becomes frayed or otherwise damaged.
•To avoid hazardous electric shock or laser radiation exposure, do not remove any covers
or screws other than those specified in this manual.
•Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if
any of the following conditions exists:
•You spill something into the equipment.
•You suspect that your equipment needs service or repair.
•Your equipment's cover has been damaged.
•Disposal can take place at our authorized dealer or at appropriate collection sites.

iii
RCAUTION:
Lithium Batteries (Memory Back-up)
RWARNING:
•Protect the equipment from dampness or wet weather, such as rain, snow, and so on.
•Unplug the Power Cord from the wall outlet before you move the equipment.
While moving the equipment, you should take care that the Power Cord will not be dam-
aged under the equipment.
•When you disconnect the power plug from the wall outlet, always pull the plug (not the
cable).
•Do not allow paper clips, staples, or other small metallic objects to fall inside the equip-
ment.
•For environmental reasons, do not dispose of the equipment or expended supply waste
at household waste collection points. Disposal can take place at an authorized dealer or
at appropriate collection sites.
•The inside of the machine could be very hot. Do not touch the parts with a label indicating
the "hot surface". Otherwise it could cause a personal burn.
•Our products are engineered to meet high standards of quality and functionality, and we
recommend that you only use the expendable supplies available at an authorized dealer.
•Do not try to replace the lithium batteries by yourself. A battery of this type can explode
if incorrectly replaced. If the lithium batteries need to be replaced, contact an authorized
dealer to request servicing.
•Never dispose of the lithium batteries by incineration. This can cause them to rupture re-
sulting in injury.
Note
❒Please return used NIC boards to our authorized dealer or service representative.
Your cooperation with our recycling activities is appreciated.
❒NIC boards are equipped with a lithium battery. In the case NIC boards are disposed
of by the customer, please dispose them in accordance with national or local regula-
tions after separating the lithium batteries from the NIC board.

iv
Energy Star Program
❖
❖❖
❖Energy Saver mode
This unit automatically lowers its power consumption at a predetermined
time (approximately 15 minutes) after the last operation was performed. To
operate the unit from this mode, see the instructions below.
•Method for clearing
•Put a document on the Document Tray.
•Open the cover of the Automatic Document Feeder (ADF).
•Open the White Sheet cover.
•Follow the instructions from the PC.
Note
❒The Energy Saver mode does not work in the following conditions.
•When an optional device is attached.
•When an error occurs.
•When a document is placed on the Document Tray.
❖
❖❖
❖Specifications
As an ENERGY STAR Partner, we have determined
that this machine model meets the ENERGY STAR
Guidelines for energy efficiency.
The ENERGY STAR Guidelines intend to establish an international energy-saving system for
developing and introducing energy-efficient office equipment to deal with environmental is-
sues, such as global warming.
When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall
place the ENERGY STAR logo onto the machine model.
This product was designed to reduce the environmental impact associated with office equip-
ment by means of energy-saving features, such as Low-power mode.
Energy Saver mode Power Consumption Approx. 11W
Default Time 15 minutes

v
Manuals for This Scanner
Manuals for This Scanner
The following manuals describe the operational and maintenance procedures of
this machine.
To enhance safe and efficient operation of this scanner, all users should read and
follow the instructions carefully.
❖
❖❖
❖Quick Installation Guide
Describes how to install the scanner.
❖
❖❖
❖Setup Guide
Provides information about setting up the scanner and its options. This man-
ual is provided as a printed manual, and also as a PDF file on the CD-ROM.
❖
❖❖
❖Scanner Reference(this manual)
Provides information about using the scanner. This manual is provided as a
PDF file.
❖
❖❖
❖Network Interface Kit Installation Guide
Describes how to install the Network Interface Kit (Network Interface Board
Type S and Operation Unit).
Note
❒There is a CD-ROM that comes with this scanner.

vi
How to Read This Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury or damage to property.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before op-
erating.
Note
This symbol indicates precautions for operation, or actions to take after misop-
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[]
Keys that appear on the machine's panel display.
Keys and buttons that appear on the computer's display.
{}
Keys built into the machine's operation panel.
Keys on the computer's keyboard.

vii
TABLE OF CONTENTS
1.Setting the Document
Size of Documents that can be Set.......................................................... 1
Document Sizes that can be Scanned Automatically.................................... 1
Documents that Require Special Care.......................................................... 4
Placing the Document on the Contact Glass.......................................... 5
Setting Documents in the Automatic Document Feeder (ADF) ............ 6
Simples Scanning ......................................................................................... 7
Duplex Scanning........................................................................................... 8
2.Scanning Documents
General Scanning Method........................................................................ 9
Manual Scanning..................................................................................... 10
The Relationship between the Data Size and the Scanning Area, as well
as the Resolution................................................................................... 11
When in [Binary] [half-tone] is Selected...................................................... 11
When [gray-scale] is Selected..................................................................... 12
When [8 Colors] [8 Colors (half-tone) is Selected....................................... 13
When [256 colors] is Selected..................................................................... 14
When [16,770,000 colors] is selected......................................................... 15
3.Troubleshooting
When Scanning does not Start .............................................................. 17
When Scanning is not Performed as Expected.................................... 18
When the Indicators Show an Error Reading ....................................... 19
When a Document is Jammed inside the Automatic Document Feeder
(ADF)....................................................................................................... 20
Cleaning ................................................................................................... 21
Cleaning the Contact Glass, ADF Contact Glass, White Sheet, and White
Plate ......................................................................................................... 21
Cleaning the Feed Roller ............................................................................ 22
Cleaning the Document Roller ................................................................... 22
Cleaning the Document Rolling Unit........................................................... 23
4.Appendix
Setting of the DIP Switches.................................................................... 25
Moving and Transporting the Scanner.................................................. 26
Moving Over Short Distances ..................................................................... 26
Transporting the Scanner............................................................................ 27

viii
Discarding the Unit.................................................................................. 28
Precautions Concerning the IEEE1394 Interface ................................. 29
Specifications.......................................................................................... 30
Options..................................................................................................... 31
INDEX........................................................................................................ 32

1
1. Setting the Document
This chapter describes the methods used for setting documents on this unit for
scanning.
The document can be set on the Contact Glass or the Automatic Document Feed-
er (ADF). For scanning multiple documents in a row, the Automatic Document
Feeder (ADF) is convenient.
Size of Documents that can be Set
Document Sizes that can be Scanned Automatically
The sizes of documents that this unit can automatically detect and scan are as
follows.
❖
❖❖
❖Contact Glass (Metric version)
Position for
setting docu-
ment
Size of document Document weight
Contact Glass Maximum A3 , 11×17 (DLT) No restrictions
Automatic
Document
Feeder (ADF)
❖
❖❖
❖Standard size
Max. A3L, 11”×17”L
Min. A5L, 8.5”×5.5”(HLT)L
❖
❖❖
❖Non-standard size
Max:297mm(11.7”)×2000mm(78.8
”)(when scanning in binary),
297mm(11.7”) ×630mm(24.9”)
(when scanning in color)
Min: 105mm(4.1”) ×128mm(5.0”)
41(1.4oz)∼128g(4.5oz)/m2
(35∼110Kg(77.2∼242.5lb))
Feed direction Size (mm)
A3 K297 ×420
B4 K257 ×364
A4 K210 ×297
L297 ×210
B5 K182 ×257
L257 ×182

Setting the Document
2
1
❖
❖❖
❖Contact Glass (Inch version)
❖
❖❖
❖Automatic Document Feeder (ADF)(Metric version)
Foolscap
(F4, 8.5" ×13")
K216 ×330
F/GL (8" ×13") K203 ×330
Note
❒F/GL size is detected same as the F4 size.
Feed direction Size (inch)
Double Letter
(DLT)
K11" ×17"
11”×15”K11" ×15"
Note
❒This size is detected same as DLT size.
10”×14”K10" ×14"
Legal (LG) K8.5"×14"
Letter (LT) K8.5" ×11"
L11" ×8.5"
8”×10”K8" ×10"
Feed direction Size (mm)
A3 K297 ×420
B4 K257 ×364
A4 K210 ×297
L297 ×210
B5 K182 ×257
L257 ×182
Feed direction Size (mm)

Size of Documents that can be Set
3
1
❖
❖❖
❖Automatic Document Feeder (ADF)(Inch version)
A5 K148 ×210
L210 ×148
Foolscap (F4, 8.5" ×
13")
K216 ×330
Note
❒Foolscap size is detected same as the F/GL
size.
F/GL (8" ×13") K203 ×330
Feed direction Size (inch)
Double Letter (DLT) K11" ×17"
11”×15”K11" ×15"
Note
❒This size is detected same as the DLT size.
10”×14”K10" ×14"
Legal (LG) K8.5"×14"
F/GL K8"×13"
Note
❒This size is detected same as the LG size.
Letter (LT) K8.5" ×11"
L11" ×8.5"
8”×10”K8" ×10"
Note
❒This size is detected same as the LT size.
Half Letter(HLT) K5.5" ×8.5"
L8.5" ×5.5"
Feed direction Size (mm)

Setting the Document
4
1
Documents that Require Special Care
Make sure to take care in setting the document according to the following in-
structions when scanning the following types of documents.
❖
❖❖
❖Documents whose size is difficult to scan
As the following documents are difficult to scan their size, the correct size will
not be selected, even if the automatic size detection has been set. The sizes for
these documents should be manually set.
•Documents with projecting parts such as indices or attached lines
•Document with a high degree of transparency such as tracing paper or
OHP film
•Documents which are fully dark in color or which have a high content of
character or graphic patterns
•Documents with partially adhesive areas
•Documents with surrounding adhesive areas
❖
❖❖
❖Documents that cannot be set into the Automatic Document Feeder (ADF)
The following types of documents should not be set into the Automatic Doc-
ument Feeder (ADF) as these can cause paper jams, damage to the original
document, or black and white lines. If these types of documents are to be
used, use the Contact Glass of the scanner.
•Documents with staples or paper clips
•Documents with holes and rips
•Documents with bends, folds or wrinkles
•Pasted documents
•Thermal paper, art paper, aluminum foil, carbon paper, or processed pa-
per with conductive paper on the back
•Perforated paper
•Documents with projecting parts such as indices or attached lines
•
Documents that do not slide easily such as tracing paper (translucent paper)
•Documents that are thin and soft, such as registration paper
•Documents that have an unsuitable thickness such as postcards
•Documents that are bound such as books
•Documents that have a high transparency rate such as OHP film or tracing
paper
•Documents with not completely dried ink or correction liquid

Placing the Document on the Contact Glass
5
1
Placing the Document on the Contact Glass
Important
❒Take care that your fingers do not
get caught when closing the Auto-
matic Document Feeder (ADF).
AOpen the Automatic Document
Feeder (ADF).
BPlace documents face down and
aligned with the scale.Documents
should conform to the setting
standards.
Important
❒Do not forcefully press down on
the Contact Glass. If a strong
force is applied to a small area,
the glass may be break.
CCarefully close the Automatic
Document Feeder (ADF).
ZDLH180E
PS

Setting the Document
6
1
Setting Documents in the Automatic
Document Feeder (ADF)
Multiple documents can be set in the
automatic document feeder(ADF). In
this manual, documents that can be
set in the Automatic Document Feed-
er (ADF) are called "sheet docu-
ments". Not only can documents set
in the Automatic Document Feeder
(ADF) be scanned on one side, they
can be scanned on both sides.
❖
❖❖
❖Documents that cannot be set in the
Automatic Document Feeder (ADF)
•Documents that do not match
the size and paper weight of
documents that can be set
•Documents with staples, clips,
glue, etc.
•Documents with holes and rips
•Documents with bends, folds,
and wrinkles
•Pasted documents
•Wet documents
•Documents not made of paper
•
Documents with coating (CFF,
etc.)
•Photos, documents that are
prints or printed photos
•Thermal fax paper, art paper,
aluminum foil, carbon paper,
processed paper with conduc-
tive paper on the back
•
Documents with projecting parts
such as indices or attached lines
•Documents that do not slide
easily such as tracing paper
(translucent paper)
•Documents that are thin and
soft, such as registration paper
•Documents that have an unsuit-
able thickness such as postal
cards
•
Documents that are bound, such
as books
• Documents that are transparent
such as OHP film,or tracing paper
• Documents that have curls such
as shown in the illustration below
Important
❒Setting documents that should
not be set in the Automatic Doc-
ument Feeder (ADF) can cause
jams and break downs. Place
these documents on the Contact
Glass.
❖
❖❖
❖Advice when Setting documents in
the Automatic Document Feeder
(ADF)
•Do not set more documents
than indicated.
•For document sizes that can be
automatically detected, refer to
P.1 “Document Sizes that can be
Scanned Automatically”.
5mm(0.2") or more
10mm(0.4") or more
