RIDGID RP 340 Assembly instructions

Pressing Tool
•Français – 13
•Castellano – pág. 27
RP 340Manual
WARNING!
Read this Operator’s Manual
carefully before using this
tool. Failure to understand
and follow the contents of
this manual may result in
electrical shock, fire and/or
serious personal injury.

ii
RP 340 Press Tool
Table of Contents
Recording Form for Machine Serial Number..............................................................................................................1
Safety Symbols..............................................................................................................................................................2
General Power Tool Safety Warnings
Work Area Safety........................................................................................................................................................2
Electrical Safety ..........................................................................................................................................................2
Personal Safety ..........................................................................................................................................................3
Power Tool Use and Care ..........................................................................................................................................3
Battery Tool Use and Care ........................................................................................................................................3
Service........................................................................................................................................................................3
Specific Safety Information
Press Tool Safety........................................................................................................................................................4
Description and Specifications
Description..................................................................................................................................................................4
Specifications..............................................................................................................................................................5
Electromagnetic Compatibility (EMC) ........................................................................................................................5
Tool Inspection..............................................................................................................................................................5
Tool and Work Area Set-Up..........................................................................................................................................6
Operating Instructions
Preparing the Connection ..........................................................................................................................................7
Pressing A Fitting With Typical Scissor Jaw Set ........................................................................................................7
Pressing A Fitting With Typical Actuator And Press Ring Set ....................................................................................8
Inspecting The Pressed Connection ..........................................................................................................................9
Maintenance Instructions
Cleaning and Lubrication ............................................................................................................................................9
Required Maintenance at RIDGID Authorized Service Center ..................................................................................9
Accessories ..................................................................................................................................................................9
Storage ........................................................................................................................................................................10
Service and Repair......................................................................................................................................................10
Disposal ......................................................................................................................................................................10
Troubleshooting..........................................................................................................................................................11
RP 340 Diagnostic Codes ..........................................................................................................................................12
Lifetime Warranty ........................................................................................................................................Back Cover

RP 340 Press Tool
Record Serial Number below and retain product serial number which is located on nameplate.
Serial
No.
Press Tool
RP 340

2
RP 340 Press Tool
General Power Tool Safety
Warnings*
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE!
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work Area Safety
•Keep your work area clean and well lit. Cluttered or
dark areas invite accidents.
•Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
•Keep children and by-standers away while oper-
ating a power tool. Distractions can cause you to lose
control.
Electrical Safety
•Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adap-
ter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
•Avoid body contact with earthed or grounded sur-
faces such as pipes, radiators, ranges and refrig-
erators. There is an increased risk of electrical shock
if your body is earthed or grounded.
•Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the risk
of electrical shock.
•Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
•When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of elec-
tric shock.
•If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of a GFCI reduces
the risk of electric shock.
Safety Symbols
In this operator’s manual and on the product, safety symbols and signal words are used to communicate important safe-
ty information. This section is provided to improve understanding of these signal words and symbols.
DANGER
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE indicates information that relates to the protection of property.
This symbol means read the operator’s manual carefully before using the equipment. The operator’s manual contains
important information on the safe and proper operation of the equipment.
This symbol means always wear safety glasses with side shields or goggles when handling or using this equipment to reduce
the risk of eye injury.
This symbol indicates the risk of hands, fingers or other body parts being crushed.
This symbol indicates the risk of electrical shock.
NOTICE
* The text used in the General Power Tool Safety Warnings section of this manual is verbatim, as required, from the applicable UL/CSA 60745 standard. This
section contains general safety practices for many different types of power tools. Not every precaution applies to every tool, and some do not apply to this tool.

3
Personal Safety
•Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol, or medication. A mo-
ment of inattention while operating power tools may
result in serious personal injury.
•Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
•Prevent unintentional starting. Ensure the switch
is in the OFF-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energizing power tools that have the switch
ON invites accidents.
•Remove any adjusting key or wrench before turn-
ing the power tool ON. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
•Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations.
•Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing, and gloves away
from moving parts. Loose clothes, jewelry, or long
hair can be caught in moving parts.
•If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Power Tool Use and Care
•Do not force power tool. Use the correct power tool
for your application. The correct power tool will do the
job better and safer at the rate for which it is designed.
•Do not use power tool if the switch does not turn it
ON and OFF. Any power tool that cannot be con-
trolled with the switch is dangerous and must be
repaired.
•Disconnect the plug from the power source and/or
the battery pack from the power tool before mak-
ing any adjustments, changing accessories, or
storing power tools. Such preventive safety mea-
sures reduce the risk of starting the power tool acci-
dentally.
RP 340 Press Tool
•Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the pow-
er tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of
untrained users.
•Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s op-
eration. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
•Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
•Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations dif-
ferent from those intended could result in a hazardous
situation.
Battery Tool Use and Care
•Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
•Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
•When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a fire.
•Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acciden-
tally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
Service
•Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.

– The instructions for any other equipment used with
this tool,
Failure to follow all instructions and warnings may
result in property damage and/or serious injury.
The EC Declaration of Conformity (890-011-320.10) will
accompany this manual as a separate booklet when
required.
If you have any question concerning this RIDGID®product:
– Contact your local RIDGID distributor.
– Visit www.RIDGID.com or www.RIDGID.eu to find
your local RIDGID contact point.
– Contact Ridge Tool Technical Service Department at
[email protected], or in the U.S. and
Canada call [phone].
Description and Specifications
Description
The RIDGID®RP 340 Press Tool, when used with appro-
priate jaw sets, is designed to mechanically press fit-
tings onto tubing to create a water-tight and permanent
seal. When the switch on the RP 340 is depressed, an
internal electric motor powers a hydraulic pump which
forces fluid into the cylinder of the tool, forcing the ram for-
ward and applying thousands of pounds of pressing force
onto specially designed fittings. Attachments are also
available for other uses.
The entire cycle duration is approximately five (5) seconds.
Once the cycle begins to deform a fitting, it will automat-
ically continue until completion, even if the trigger switch
is released. The LED displays on the top of the tool indi-
cate problems such as improper temperature, open jaw
mounting pin or maintenance required.
Figure 1 – RP 340 Press Tool and Jaw Set
The tool is equipped with a bright LED work light that lights
up when the trigger is pulled and remains lit four (4) min-
Specific Safety Information
WARNING
This section contains important safety information
that is specific to this tool.
Read these precautions carefully before using the
RP 340 Press Tool to reduce the risk of electrical
shock or serious personal injury.
SAVE THESE INSTRUCTIONS!
A compartment in the RP 340 carrying case is included to
keep this manual with the machine for use by the operator.
Press Tool Safety
•Use the RP 340 Press Tool only with RIDGID®
standard pressing attachments (jaw set, press
ring, actuator, etc.). Other uses or modifying the RP
340 Press Tool for other applications may damage
the press tool, damage the attachments and/or cause
personal injury.
•Keep your fingers and hands away from attach-
ments during press cycle. Your fingers or hands
can be crushed, fractured or amputated if they become
caught in the attachments or between these compo-
nents and any other object.
•Never attempt to repair a damaged jaw set, press
ring, actuator or other attachment. An attachment
that has been welded, ground, drilled or modified in
any manner can shatter during pressing resulting in
serious injury. Discard the entire damaged attach-
ment. Replace with a new jaw set. Never replace
individual components except for damaged jaw return
springs. Please call Ridge Tool Technical Service
Department for availability.
•Large forces are generated during product use
that can break or throw parts and cause injury.
Stand clear during use and wear appropriate protective
equipment, including eye protection.
•Only use RIDGID Press Tools and Jaws when
specified by the press fittings manufacturer. Use of
incorrect equipment and methods can cause incom-
plete joints, damage the equipment, void warranties or
cause severe personal injury or death.
•Before operating a RIDGID RP 340 Press Tool,
read and understand:
– This operator’s manual,
– The attachment instructions,
– The battery/charger manual,
– The RPA 120/220 AC Power (Mains) Adapter In-
structions,
– The fitting manufacturer’s installation instructions,
4
RP 340 Press Tool
LED Display
Panel
Scissor Style
Jaw Set
Jaw Arm Attachment
Mounting Pin
Battery
Tool Housing Switch
Handle
Jaw
Sideplate
Pressure
Release
Button
ON/OFF
Button Warning
Label
LED
Work Light

Electromagnetic Compatibility
(EMC)
The term electromagnetic compatibility is taken to mean
the capability of the product to function smoothly in an
environment where electromagnetic radiation and elec-
trostatic discharges are present and without causing elec-
tromagnetic interference to other equipment.
The RIDGID Model RP 340 Press Tool con-
forms to all applicable EMC standards. However, the
possibility of it causing interference in other devices can-
not be precluded.
Tool Inspection
WARNING
Daily before use, inspect your press tool and correct
any problems to reduce the risk of serious injury
from electric shock, crushing injures, attachment
failure and other causes, and prevent tool damage.
1. Make sure that the press tool is unplugged or the bat-
tery is removed. If using an AC Power Adapter,
inspect the AC Power Adapter power cord and plug
for damage or modifications. If a battery tool, inspect
the battery for damage. If any damage or modifica-
tions are found, do not use the tool until the cord or
battery has been properly repaired or replaced.
2. Clean any oil, grease or dirt from the equipment,
especially the handles and controls. This helps to
prevent the machine or controls from slipping from
your grip.
3. Inspect the press tool for any of the following:
• Proper assembly, maintenance and completeness.
• Any broken, worn, missing, misaligned or binding
parts.
• Make sure that the attachment mounting pin moves
smoothly between the fully open and full closed
position and locks into each. Confirm that the
switch moves freely and does not bind or stick.
• Presence and readability of warning labels. See
Figure 3.
• Any other condition which may prevent safe and nor-
mal operation.
utes after the trigger is released. This allows the user to
easily illuminate the work area.
Specifications
RP 340 Press Tool:
Motor
Voltage ...................18 V
Amperage ...............27.2 Amp
Power .....................490 Watts
Weight........................5.75 lbs. (2.61 kg)
Ram Force .................7,200 lbs. (32kN)
Operating Temperature
Range ...........................15°F to 122°F (-10°C to 50°C)
Duty Cycle...................3 Crimp /min.
The Press Tool serial number plate is located at the bot-
tom of the handle as shown in
Figure 2. The last 4 digits
indicate the month and year of the manufacture. (04 =
month, 10 = year).
Figure 2 – Press Tool Serial Label
NOTE! RIDGID jaw sets are offered in two “series”
• Standard Series
• Compact Series
These jaw sets are not interchangeable. These
series are not interchangeable. Standard series
jaw sets will only work with standard series tools
(RP 340, RP 330, 320-E, CT-400). Compact
series jaw sets will work with compact series
tools (RP 200, RP 210, 100B).
Selection of appropriate materials and joining
methods is the responsibility of the system designer
and/or installer. Before any installation is attempted, care-
ful evaluation of the specific service environment, includ-
ing chemical environment and service temperature, should
be completed. Consult Press Fitting System manufacturer
for selection information.
5
RP 340 Press Tool
NOTICE
NOTICE

If any problems are found, do not use the press tool
until the problems have been repaired.
4. Inspect and maintain the tool attachments, battery
charger, AC Power Adapter and any other equip-
ment or material in use as directed in their instructions.
Figure 3 – Press Tool Labels
5. With dry hands, plug an inserted AC Power Adapter
into a properly grounded outlet or insert a fully
charged battery. Press the ON/OFF button on the
LED panel one time to turn the press tool ON. The
green, red and yellow LED on the display panel
should all blink one time on power up, and then the
green LED will remain on to indicate that the tool is
ready for use. If any other conditions exist, use the
Diagnostic Codes information on page 12 to deter-
mine the next step and do not use the tool until it is
working properly. With your hands and fingers away
from the tool ram, test the switch to confirm proper
operation. When used with an attachment, once the
tool sees enough load it will lock on to ensure that a
complete press is made.
6. Once the operation has been checked, with dry
hands unplug the tool or remove the battery.
Tool and Work Area Set-Up
WARNING
Set up the press tool and work area according to
these procedures to reduce the risk of injury from
electric shock, fire, crushing injuries and other
causes, and prevent tool and system damage.
1. Check work area for:
• Adequate lighting.
• Flammable liquids, vapors or dust that may ignite.
If present, do not work in area until sources have
been identified and corrected. The press tool is not
explosion proof and can cause sparks.
• Clear, level, stable dry place for operator. Do not
use the machine while standing in water.
• Clear path to electrical outlet that does not contain
any potential sources of damage for the power
cord.
2. Inspect the work to be done and determine the correct
RIDGID tool and attachment(s) for the application.
Using an incorrect attachment for an application can
cause injury, damage the tool and make incomplete
connections. For a complete listing of RIDGID attach-
ments available for this tool, see the Ridge Tool Cat-
alog on line at www.RIDGID.com or call Ridge Tool
Technical Service Department [phone]. Make
sure that the tool and attachment have been inspect-
ed as directed in the instructions.
3. Evaluate the work area and determine if any barriers
are needed to keep bystanders out. Bystanders can
distract the tool operator during use.
4. Confirm that the tool is unplugged or the battery is
removed and fully open the attachment mounting
pin. See Figure 4. If there is an attachment in the tool,
slide it out of the tool.
5. Slide the correct attachment into the press tool as
shown in Figure 5 and fully close the attachment
mounting pin. The tool will not operate unless the
mounting pin is fully closed. Rings must use the
appropriate matching actuator.
Figure 4 – Fully Open Attachment Mounting Pin
6
RP 340 Press Tool
Warning Label ON/OFF Button LED Display Panel

7
lation instructions. Failure to follow the specific attachment
and fitting installation instructions may result in improper
press connections that can lead to extensive property
damage.
1. Make sure that the work area is free of bystanders
and other distractions and that the tool and work
area has been properly set up.
2. Prepare the connection according to the fitting man-
ufacturer’s instructions.
3. Depress ON/OFF button on display panel one time to
turn tool ON. All three light emitting diodes (LED’s) will
blink once. Then, the green LED should be solidly
illuminated indicating the tool is ready to press.
4. Make sure the tubing is inserted to the proper depth in
fitting, as specified in the appropriate fitting system’s
operator's manual.
Pressing A Fitting With Typical Scissor
Jaw Set
1. Squeeze jaw arms to open the jaw set (Figure 6).
2. Place open jaws around the fitting. Make sure the con-
tour of the jaw set is properly aligned with the contour
of the fitting as specified in Fitting Manufacturer's
Installation Instructions . Do not hang the jaw set and
tool from fitting. Tool could unexpectedly drop and
cause serious injury or death.
Figure 6 – Opening The Scissor-Style Jaw Set
Figure 5 – Slide Attachment Into Tool
6. If using a battery tool, with dry hands insert the battery
into the tool. If using an AC Power Adapter, with dry
hands insert the AC Power Adapter into the tool, run
the cord along the previously identified clear path,
and with dry hands plug the AC Power Adapter in.
Keep all connections dry and off the ground. If the
power cord is not long enough, use an extension
cord that:
• Is in good condition
• Is appropriately rated for the use
• Has sufficient wire size (16 AWG for 50' or less, 14
AWG for 50' to 100'). Undersized wires can over-
heat, melting the insulation or causing fire or other
damage.
Operating Instructions
WARNING
Always wear eye protection to to reduce the risk
of eye injury.
Keep your fingers and hands away from the tool
attachment during the press cycle. Your fingers or
hands can be crushed, fractured or amputated in
the attachment or tool or between the attach-
ment, work piece and other objects.
Follow operating instructions to reduce the risk of
injury from crushing and other causes and to pre-
vent tool damage.
Preparing the Connection
These instructions are generalized practices
for several types of press tool attachments. Always follow
the specific instructions for the press tool attachment
being used and the fitting manufacturers’ specific instal-
RP 340 Press Tool
NOTICE

Figure 7 – RP 340 Tool Square To Tubing
3. Make sure the jaw set and tool are square to the
tubing and depress the tool switch (Figure 7). Keep
fingers and hands away from the jaw set to avoid
crushing injuries in jaw set and between jaw set and
surroundings. The press cycle takes about five (5)
seconds. Once a press cycle begins and the rollers
contact the jaw arms, the tool will lock-on and auto-
matically complete the press cycle. Releasing the
switch will not stop the tool once the pressing process
has begun. This assures consistent, repeatable press
joint integrity.
4. Press jaw arms to open the jaw set.
5. Remove the RP 340 and jaw set from tube. Avoid
sharp edges that may have formed on the fitting dur-
ing the pressing operation.
Pressing A Fitting With Typical
Actuator And Press Ring Set
1. Open the appropriate press ring and place at right
angle onto the fitting (Figure 8). Align ring with fitting
according to fitting manufacturer’s Installation Instruc-
tion. Recheck insertion depth before completing press
process.
2. Squeeze actuator arms to open the actuator assem-
bly. Engage actuator ends into the actuator pockets
in the press ring (Figure 9) . Make sure actuator ends
are fully engaged in pockets. Do not attempt to hang
tool and actuator from press ring. Tool could unex-
pectedly drop causing serious injury or death.
Depress the tool switch. The press cycle takes about
five (5) seconds. Once a press cycle begins and the
rollers contact the actuator arms, the tool will lock-on
and automatically complete the press cycle. Releasing
the trigger will not stop the tool once the pressing
process has begun. This assures consistent, repeat-
able press joint integrity. To avoid pinch point injuries,
keep fingers away from actuator and press ring during
the press cycle.
Figure 8 – Installing Press Ring Onto Fitting
Figure 9 – Attaching Actuator to Press Ring
3. After cycle is complete, squeeze actuator arms to
open and separate actuator from press ring. Remove
the press ring from fitting by manually grasping ring
halves and opening assembly. Avoid any sharp edges
which may have formed on fitting during pressing
operation.
The RP 340 Press Tool will turn OFF auto-
matically if the battery is too low to successfully com-
plete a pressed connection. This will be indicated by
blinking of the green LED. A fully charged battery should
be inserted in the tool and the pressed connection should
be repeated as indicated above. To retract the rollers
and remove the tool from the fitting if battery dies or tool
malfunctions during pressed connection, it is necessary to
press the red pressure release button on the left hand side
of the tool. (Figure 10)
8
RP 340 Press Tool
NOTICE

3. Check return springs in attachments with each use.
Attachments should open and close freely with only
moderate finger effort required.
Required Maintenance at RIDGID
Authorized Service Center
After 40,000 cycles, the tool will show a blinking yellow
LED on the display panel as long as the tool is turned on
to indicate that it is time for maintenance and recalibration.
The tool will not run if it is not maintained within 2,000
more cycles after the yellow blinking LED begins.
Accessories
WARNING
The following tool accessories have been designed
to function with the RP 340 Press Tools. Other
accessories suitable for use with other tools may
become hazardous when used on the RP 340. To
prevent serious injury, use only the accessories
specifically designed and recommended for use
with the RP 340, such as those listed below.
Ridge Tool Company provides Standard Pressing
attachments designed specifically for use with
RIDGID Standard Press tools. Only use attachments
that are specifically designed to press the fitting
system you are installing. For a complete listing of
RIDGID attachments available for this tool, see the
Ridge Tool Catalog on line at www.RIDGID.com or
call Ridge Tool Technical Service Department (800)
519-3456.
Figure 10 – Pressure Release Button
Inspecting The Pressed Connection
1. Inspect the pressed fitting. If the fitting is supplied with
a control ring and/or a control label by the fitting
manufacturer, remove it. Control rings and label are
supplied by the manufacturer to indicate that the fitting
has not yet been pressed.
Look for the following:
• Excessive misalignment of the tubes. Note that a
slight amount of misalignment at the pressed con-
nection is considered normal.
• Tubes that are not fully inserted into the fitting –
double check the insertion marks made on the
tube to see that they are still aligned with the end of
the fitting.
• Incorrect jaw or ring alignment with the fitting con-
tour, distorted or deformed fitting.
• Any other issues per the fitting manufacturer.
If any of these problems are found, then removal of
the fitting is required and a new fitting and tube will
need to be prepared and pressed in its place.
2. Test system in accordance with normal practice and
local codes.
Maintenance Instructions
WARNING
Make sure AC Battery Adapter is unplugged and
removed or battery is removed from tool before
performing maintenance or making any adjustment.
Cleaning and Lubrication
1. Daily wipe the tool clean with a clean dry cloth.
2. Inspect the attachment mounting pin and lubricate the
pin with silicone lubricant as needed.
9
RP 340 Press Tool
Pressure Release
Button
RP 340 Press Tool Accessories
Catalog
No. Capacity Region
44693 18V 2.0 Ah North & Latin America, Australia
44698 18V 4.0 Ah North & Latin America, Australia
43323 18V 2.0 Ah Europe & China
43328 18V 4.0 Ah Europe & China
31013 18V 1.1 Ah North & Latin America, Australia
32743 18V 2.2 Ah North & Latin America, Australia
31018 18V 3.3 Ah North & Latin America, Australia
32473 18V 1.1 Ah Europe & China
28218 18V 2.2 Ah Europe & China
28448 18V 3.3 Ah Europe & China
Battery Packs
All listed batteries will work with any model RBC 20 charger. The difference
between batteries for different regions is in label markings.
Catalog Plug
No. Voltage Product Region Type
44823 120V China AC Power Adapter A
43338 220V Europe AC Power (Mains) Adapter C
44468 120V North America AC Power Adapter A
27933 — Carrying Case (Plastic) —

For information on your nearest RIDGID Independent
Service Center or any service or repair questions:
• Contact your local RIDGID distributor.
• Visit www.RIDGID.com or www.RIDGID.eu to find
your local RIDGID contact point.
• Contact Ridge Tool Technical Service Department at
[email protected] or in the U.S. and
Canada call [phone]
Disposal
Parts of the RIDGID RP 340 Press Tool contain valuable
materials and can be recycled. There are companies
that specialize in recycling that may be found locally.
Dispose of the components in compliance with all appli-
cable regulations. Contact your local waste management
authority for more information.
For EC Countries: Do not dispose of elec-
trical equipment with household waste!
According to the European Guideline 2002/-
96/EC for Waste Electrical and Electronic
Equipment and its implementation into nation-
al legislation, electrical equipment that is no
longer usable must be collected separately and disposed
of in an environmentally correct manner.
10
RP 340 Press Tool
Storage
Remove the battery or AC Power Adapter from the tool
and place in its carrying case. Avoid storing the tool, bat-
teries, AC Power Adapter or charger in extreme heat or
cold. The tool temperature sensor will not allow the tool to
turn on if oil temperature is not within the temperature
range of 15°F (-10°C) to 122°F (50°C). This will be indi-
cated by a red glowing LED on the display panel. It may
be necessary to allow the tool to warm or cool to a tem-
perature within the operating range by placing it in a con-
ditioned area before use.
Store the carrying case in a dry, secured,
locked area that is out of reach of children and people
unfamiliar with the RP 340 Press Tool. The tool is dan-
gerous in the hands of untrained users.
Service and Repair
WARNING
Improper service or repair can make machine
unsafe to operate.
Service and repair on this RP 340 Press Tool must be per-
formed by a RIDGID Authorized Service Center. The
tool fasteners have been marked to indicate if service has
been performed by unauthorized individuals.
For any repairs or maintenance, contact the Ridge Tool
Technical Service Department at [phone] or
www.RIDGID.com for nearest authorized press tool ser-
vice outlet.
WARNING
Catalog Plug
No. Voltage Region Type
43458 120V North America A
43333 230V Europe C
43468 120V China A
44418 230V Australia & Latin America I
44793 100V Japan A
44833 230V United Kingdom G
44798 — North America Charger Cord A
44808 — Europe Charger Cord C
44803 — China Charger Cord A
44813 — Australia & LA Charger Cord I
44818 — Japan Charger Cord A
44828 — United Kingdom Charger Cord G
RBC 20 Advanced Lithium Battery Chargers & Cords

11
RP 340 Press Tool
SYMPTOM POSSIBLE REASONS SOLUTION
Tool will not turn ON
when ON/OFF button on
display panel is pressed.
Tool will not run when
trigger is depressed.
Green light flashes.
Tool turns OFF either
when trigger is
depressed or in the
middle of a press cycle.
Red LED glows.
Yellow LED blinks repeat-
edly as long as tool is
turned ON and tool func-
tions properly.
Yellow LED glows con-
tinuously and tool will
not begin press cycle
when trigger switch is
depressed.
Red LED blinks repeated-
ly and tool will not begin
press cycle when trigger
switch is depressed.
Yellow LED glows when
tool is turned ON.
Jaws are locked onto
fitting.
The pressed connections
produced are not com-
plete.
Troubleshooting
Electric cord damaged.
Battery is completely discharged or battery has
failed or power cord not properly inserted into
outlet.
Battery or AC Power Adapter not properly inserted
into handle of tool.
Battery is too low.
Tool, AC Power Adapter or battery is too cold or too
hot.
Scheduled maintenance/recalibration is required
after 40,000 presses.
Scheduled maintenance/recalibration is manda-
tory after 42,000 presses. Tool is “locked” and
will not function until tool is serviced.
Accessory mounting pin not fully closed.
Tool malfunction detected.
Press was not successfully completed.
Used wrong jaw set for the tube size or material.
The tool was not square to the tube.
Jaw contour was not aligned with the fitting contour.
Tool is in need of repair.
Inspect the cord and replace if necessary.
Insert fully charged battery/recharge dead battery
or unplug and replug power cord.
Check to assure battery or AC Power Adapter is
fully inserted.
Insert fully charged battery/recharge dead battery.
Bring tool, AC Power Adapter or battery to cor-
rect operating range between 15°F (-10°C) to
122°F (50°C) by allowing the tool to sit in a con-
ditioned room.
NOTE! Fitting must be repressed if tool stops
in the middle of a press cycle. Failure
to do so may result in a leaking fitting.
Contact Ridge Tool Technical Service Department
[phone] for nearest Authorized Service out-
let.
Contact Ridge Tool Technical Service Department
at [phone] for nearest Authorized Service
outlet.
Insert accessory mounting pin to the fully closed
position.
Unplug and replug power cord or remove and rein-
sert fully charged battery. Be sure to repress fitting.
If LED continues to glow, contact Ridge Tool
Technical Service Department at [phone] for
nearest Authorized Service outlet.
Push pressure release button to remove jaws from
fitting. Inspect and repress fitting.
Install the correct jaw set.
Redo the joint with new fitting and new tube. Make
sure that the tool is square to the tube.
Redo the joint with new tube and new fitting. Make
sure the jaw contour is aligned with the fitting con-
tour.
Contact Ridge Tool Technical Service Department
at [phone] for nearest Authorized Service
outlet.

12
RP 340 Press Tool
RP 340 Diagnostic Codes
LED Status Description Icon
Green Glows Tool ON.
Blinks Out of acceptable voltage range
— Tools using a battery: Replace battery with a fully charged battery.
— Tools using an AC Power Adapter: Connect tool to a reliable voltage supply.
If using extension cord, use 16 AWG for 50' or less, 14 AWG for 50' to 100'.
Red Glows Out of temperature range 15°F (-10°C) to 122°F (50°C).
Blinks Jaws mounting pin not fully engaged. Insert pin.
Yellow Glows Service indicator after 40,000 cycles. NOTE: Tool will lock after 42,000 cycles.
Blinks Machine is locked – Service after 42,000 cycles or after a malfunction.

Sertisseuse
RP 340
AVERTISSEMENT
Familiarisez-vous avec cette notice
avant d’utiliser l’appareil. Tout
manque de compréhension ou de
respect des consignes ci-présentes
augmenterait les risques de choc
électrique, d’incendie et/ou de
grave blessure corporellee.
Sertisseuse RP 340
Notez ci-dessous pour future référence le numéro de série indiqué sur la plaque signalétique
de l’appareil.
N° de
série

14
Sertisseuse RP 340
Table des matières
Formulaire Fiche d’enregistrement du numéro de série de l’appareil ..................................................................13
Symboles de sécurité ................................................................................................................................................15
Consignes générales de sécurité des appareils électriques
Sécurité de l’espace de travail..................................................................................................................................15
Sécurité électrique ....................................................................................................................................................15
Sécurité individuelle..................................................................................................................................................16
Utilisation et entretien des appareils électriques ......................................................................................................16
Utilisation et entretien des appareils à batterie ........................................................................................................16
Service après-vente..................................................................................................................................................17
Consignes de sécurité spécifiques
Sécurité de la sertisseuse ........................................................................................................................................17
Description et caractéristiques techniques
Description................................................................................................................................................................18
Caractéristiques techniques......................................................................................................................................18
Compatibilité électromagnétique (EMC) ..................................................................................................................18
Inspection de l’appareil ..............................................................................................................................................19
Préparation de l’appareil et de l’espace de travail ..................................................................................................19
Mode d’emploi
Préparation des raccordements................................................................................................................................21
Sertissage d’un raccord à l’aide de mâchoires à ciseaux traditionnelles..................................................................21
Sertissage d’un raccord à l’aide d’un actionneur et de bagues de sertissage traditionnels......................................21
Inspection des raccordements sertis ........................................................................................................................22
Instructions de maintenance
Nettoyage et lubrification ..........................................................................................................................................22
Maintenance obligatoire dans un centre de services RIDGID agréé........................................................................23
Accessoires ................................................................................................................................................................23
Stockage ......................................................................................................................................................................23
Entretien et réparation................................................................................................................................................24
Mise au rebut ..............................................................................................................................................................24
Dépannage ..................................................................................................................................................................25
Codes de diagnostic de la RP 340 ............................................................................................................................26
Garantie à vie ..........................................................................................................................................Page de garde

15
Sertisseuse RP 340
Consignes générales de sécu-
rité des appareils électriques*
AVERTISSEMENT
Familiarisez-vous avec l’ensemble des consignes de
sécurité et d’utilisation ci-présentes afin d’éviter les
risques de choc électrique, d’incendie et/ou de
grave blessure corporelle.
CONSERVEZ L’ENSEMBLE DES CONSIGNES
DE SECURITE ET D’UTILISATION POUR
FUTURE RÉFÉRENCE!
Le terme « appareil électrique » dans les consignes se
rapporte à votre appareil électrique alimenté par secteur
(avec cordon) ou à votre appareil électrique alimenté par
batterie (sans cordon).
Sécurité du chantier
•Assurez-vous de la propreté et du bon éclairage
des lieux. Les lieux de travail encombrés ou mal
éclairés sont une invitation aux accidents.
•N’utilisez pas d’appareils électriques en présence
de substances volatiles telles que liquides, gaz
ou poussières ombustibles. Les appareils élec-
triques produisent des étincelles susceptibles ’enflam-
mer les poussières et émanations combustibles.
•Eloignez les enfants et les curieux durant l’uti-
lisation des appareils électriques. Les distractions
risquent de vous faire perdre le contrôle de l’appareil.
Sécurité électrique
•La fiche électrique de l’appareil doit correspondre
à la prise de courant utilisée. Ne tentez jamais de
modifier la fiche. N’utilisez jamais d’adaptateur sur
une fiche électrique avec mise à la terre. Les fiches
intactes et adaptées aux prises de courant utilisées lim-
itent les risques de choc électrique.
•Évitez tout contact avec des surfaces reliées à la
terre ou à la masse, telles que tuyaux, radiateurs,
cuisinières ou réfrigérateurs. Les risques de choc
électrique augmentent lorsque votre corps est en con-
tact avec une masse.
•N’exposez pas les appareils électriques à la pluie
ou aux intempéries. Toute pénétration d’eau à
l’intérieur d’un appareil électrique augmente les risques
de choc électrique.
•Ne maltraitez pas le cordon d’alimentation de
l’appareil. N’utilisez jamais le cordon pour tran-
sporter, tirer ou débrancher l’appareil électrique.
Gardez le cordon à l’abri de la chaleur, de l’huile,
de bords tranchants et de pièces mobiles. Les
cordons endommagés ou enchevêtrés augmentent
les risques de choc électrique.
Symboles de sécurité
Les symboles et mots clés utilisés à la fois dans ce mode d’emploi et sur l’appareil lui-même servent à signaler d’importants
risques de sécurité. Ce qui suit permettra de mieux comprendre la signification de ces mots clés et symboles.
Ce symbole sert à vous avertir de risques d’accident potentiels. Le respect des consignes qui le suivent vous permettra d’éviter
les risques d’accidents graves ou mortelles.
Le terme DANGER signifie une situation dangereuse potentielle qui, faute d’être évitée, provoquerait la mort ou de graves
blessures corporelles.
Le terme AVERTISSEMENT signifie une situation dangereuse potentielle qui, faute d’être évitée, serait susceptible
d’entraîner la mort ou de graves blessures corporelles.
Le terme CAUTION signifie une situation dangereuse potentielle qui, faute d’être évitée, serait susceptible d’entraîner
des blessures corporelles légères ou modérées.
Le terme AVIS IMPORTANT signifie des informations concernant la protection des biens.
Ce symbole indique la nécessité de bien se familiariser avec le mode d’emploi avant d’utiliser ce matériel. Le mode
d’emploi renferme d’importantes consignes de sécurité et d’utilisation du matériel.
Ce symbole indique le port obligatoire de lunettes de sécurité équipées de protections latérales lors de la manipulation ou de
l’utilisation de l’appareil afin de réduire les risques de lésions oculaires.
Ce symbole signale un risque d’écrasement des mains, des doigts ou d’autres parties du corps.
Ce symbole signifie un risque de choc électrique.
* Le texte de la section Consignes générales de sécurité des appareils électriques de ce manuel dépend, si nécessaire, de la norme UL/CSA 60745 en vigueur.
Cette section contient des consignes générales de sécurité pour différents types d’appareils électriques. Toutes les précautions ne s’appliquent pas à tous les
appareils et certaines ne s’appliquent pas à cet appareil.
AVISO
PELIGRO
ADVERTENCIA
CUIDADO

16
Sertisseuse RP 340
•Lors de l’utilisation d’un appareil électrique à
l’extérieur, prévoyez une rallonge électrique ho-
mologuée pour usage extérieur. L’utilisation d’un
cordon adapté à un usage extérieur réduit les risques
de choc électrique.
•S’il est nécessaire d’utiliser un appareil électri-
que dans des lieux mouillés, prévoyez une source
d’alimentation protégée par disjoncteur différentiel.
L’utilisation d’un disjoncteur différentiel réduit les ris-
ques de choc électrique.
Sécurité individuelle
•Soyez attentif, concentrez-vous sur ce que vous
faites et faites preuve de bon sens lorsque vous
utilisez un appareil électrique. N’utilisez pas ce
type d’appareil électrique lorsque vous êtes fatigué
ou si vous êtes sous l’effet de médicaments, de
l’alcool ou de médicaments. Un instant d’inattention
peut entraîner des blessures graves lorsqu’on utilise un
appareil électrique.
•Prévoyez les équipements de protection indivi-
duelle nécessaires. Portez systématiquement une
protection oculaire. Le port d’équipements de pro-
tection individuelle, tels qu’un masque antipoussières,
des chaussures de sécurité à semelles antidérapantes,
un casque renforcé et/ou des protections auditives,
permet de réduire les risques de blessures corporelles.
•Evitez les démarrages accidentels en vous assu-
rant que l’interrupteur marche/arrêt de l’appareil se
trouve en position «arrêt» avant de le brancher, d’y
introduire le bloc-piles ou de prendre l’appareil
en main. Le transport d’appareils électriques en
posant le doigt sur l’interrupteur ou la mise sous ten-
sion d’appareils électriques dont l’interrupteur est déjà
en position de marche est propice aux accidents.
•Retirez toutes clés de réglage éventuelles avant de
mettre l’appareil en marche. Une clé laissée sur un
élément rotatif quelconque de l’appareil risque de
provoquer des accidents.
•Ne vous mettez pas en porte-à-faux. Maintenez
une bonne assise et un bon équilibre à tout mo-
ment. Ceci vous permettra de mieux maîtriser l’ap-
pareil électrique dans des situations imprévues.
•Habillez-vous de manière appropriée. Ne portez
pas de vêtements amples ni de bijoux. Éloignez
vos cheveux, vêtements et gants des pièces mo-
biles. Les vêtements amples, les bijoux et les cheveux
longs peuvent être happés par les pièces mobiles.
•En présence d’un système de récupération et
d’évacuation des poussières, assurez-vous que
celui-ci est correctement raccordé et utilisé. L’utili-
sation d’un système de dépoussiérage permet de
réduire les risques liés aux poussières.
Utilisation et entretien des appareils
électriques
•Ne forcez pas l’appareil électrique. Utilisez l’ap-
pareil électrique adapté au travail prévu. L’appareil
électrique approprié assurera un meilleur travail et
une meilleure sécurité s’il est utilisé au régime prévu.
•N’utilisez pas d’appareil électrique dont l’inter-
rupteur n’assure pas sa mise en marche ou son
arrêt. Tout appareil électrique ne pouvant pas être con-
trôlé par son interrupteur est dangereux et doit être
réparé.
•Retirez le bloc-piles de l’appareil avant tout ré-
glage, stockage ou changement d’accessoires.
De telles précautions réduisent les risques de démar-
rage accidentel de l’appareil.
•Rangez tout appareil non utilisé hors de la portée
des enfants et des individus qui n’ont pas été
familiarisés avec ce type de atériel ou son mode
d’emploi. Les appareils électriques sont dangereux
entre les mains d’utilisateurs non initiés.
•Entretenez les appareils électriques. Examinez-
les pour signes de grippage, de bris et de toute
autre anomalie qui risquerait de nuire à leur bon
onctionnement. Le cas échéant, fait réparer l’ap-
pareil avant de l’utiliser. De nombreux accidents
sont dus à des appareils électriques mal entretenus.
•Assurez le bon affûtage et la propreté des outils de
coupe. Les outils de coupe bien entretenus et bien
affûtés sont moins susceptibles de gripper et sont
plus faciles à contrôler.
•Servez-vous de l’appareil, de ses accessoires, de
ses mèches, etc. selon les consignes du mode
d’emploi et des conditions de ravail présentes.
L’utilisation d’un appareil électrique à des fins autres
que celles révues pourrait s’avérer dangereuse.
Utilisation et entretien des appareils
à batterie
•N’utilisez que le chargeur prévu par le fabricant.
L’utilisation d’un chargeur inadapté augmenterait les
risques d’incendie électrique.

17
Sertisseuse RP 340
•Ne jamais tenter de réparer des mâchoires, bagues
de sertissage, actionneurs ou autres accessoires
endommagés. Un accessoire soudé, relié à la terre,
percé ou modifié d’une quelconque manière peut
éclater pendant le sertissage et entraîner des blessures
graves. Mettez au rebut l’accessoire endommagé
dans son ensemble. Remplacez par des mâchoires
neuves. Ne remplacez jamais un composant seul, à
l’exception des ressorts de rappel de mâchoire endom-
magés. Contactez le service technique de Ridge Tool
Company pour connaître les disponibilités.
•Des forces importantes sont exercées pendant
l’utilisation de l’appareil, qui peuvent casser ou
briser des pièces et entraîner des blessures.
Éloignez-vous pendant l’utilisation et portez les
équipements de protection appropriés, notamment
des lunettes de protection.
•N’utilisez que les outils et mâchoires de sertis-
sage RIDGID indiqués par le fabricant des rac-
cords à sertir. L’utilisation d’équipements et de méth-
odes inappropriés peut entraîner des joints incomplets,
endommager l’équipement, annuler la garantie ou
entraîner des blessures corporelles graves, voire la
mort.
•Avant d’utiliser une sertisseuse RIDGID RP 340,
lisez et familiarisez-vous avec :
– ce manuel de l’opérateur,
– les instructions relatives à l’accessoire,
– le manuel de la batterie/du chargeur,
– les instructions relatives à l’adaptateur secteur
RPA 120/220 CA,
– les instructions d’installation du fabricant du raccord,
– les instructions de tout autre équipement utilisé
avec cet appareil.
Le non-respect de ces instructions et consignes peut
entraîner des dommages matériels et/ou des blessures
corporelles graves.
Lorsque cela sera nécessaire, la Déclaration de confor-mité
CE (890-011-320.10) sera jointe à ce manuel sous la
forme d’un livret distinct.
Pour toute question relative à cet appareil RIDGID :
– Contactez votre distributeur RIDGID local.
– Visitez le site www.RIDGID.com ou www.RIDGID.eu
pour trouver votre point de contact RIDGID local.
– Contactez le service technique Ridge Tool à l’adresse
[email protected], ou aux États-Unis et au
Canada, appelez le [phone].
•N’utilisez que le type de bloc-piles préconisé.
L’utilisation d’un bloc-piles inadapté augmenterait les
risques de blessure et d’incendie électrique.
•Eloignez les bloc-piles non utilisés de tout objet
métallique (trombones, pièces de monnaie, clés,
clous, vis, etc.) qui risqueraient de ponter une de
ses bornes à l’autre. Un court-circuit entre les bornes
du bloc-piles pourrait provoquer des brûlures ou un
incendie électrique.
•Des conditions abusives risquent d’entraîner des
projections d’électrolyte qu’il vaudrait mieux évi-
ter. En cas de contact accidentel, rincez à l’eau
courante. En cas de contact oculaire, consultez un
médecin. Ce liquide risque de provoquer des irrita-
tions ou des brûlures.
Révisions
•Confiez l’appareil à un réparateur qualifié se ser-
vant exclusivement de pièces de rechange d’ori-
gine. Cela vous assurera de la sécurité pérationnelle
de l’appareil.
Consignes de sécurité
spécifiques
AVERTISSEMENT
La section suivante contient d’importantes in-
formations sur ce type d’appareil particulier.
Lisez ces précautions soigneusement avant de
vous servir de la sertisseuse RP 340 afin de réduire
les risques de choc électrique ou de blessures cor-
porelles graves.
CONSERVEZ CES INSTRUCTIONS !
La mallette de transport de la RP 340 est équipée d’une
pochette destinée à garder le mode d’emploi à portée de
main de l’utilisateur.
Sécurité de la sertisseuse
•N’utilisez la sertisseuse RP 340 qu’avec les acces-
soires de sertissage standard RIDGID®(mâchoires,
bague de sertissage, actionneur, etc.). L’utilisation
d’autres accessoires ou la modification de la sertis-
seuse RP 340 pour d’autres usages peut endom-
mager la sertisseuse, endommager les accessoires
et/ou entraîner des blessures corporelles.
•Éloignez vos doigts et vos mains des accessoires
pendant le sertissage. Vos doigts et vos mains
risquent d’être écrasés, fracturés ou amputés s’ils
sont happés par les accessoires ou entre ces com-
posants et tout autre objet.

18
Sertisseuse RP 340
Température d’utilisation
Plage..........................15 à 122 °F (-10 à 50 °C)
Cycle ..........................3 sertissages /min.
La plaque du numéro de série de la sertisseuse se trouve
dans la partie inférieure de la poignée comme illustré
dans la Figure 2. Les 4 derniers chiffres indiquent le mois
et l’année de fabrication. (04 = mois, 10 = année).
Figure 2 – Étiquette du numéro de série de la sertisseuse
NOTA ! Les mâchoires RIDGID sont proposées en deux
« séries »
• Série standard
• Série compacte
Ces mâchoires ne sont pas inter-changeables.
Ces séries ne sont pas interchangeables. Les
mâchoires de la série standard sont compatibles
uniquement avec les appareils de la série stan-
dard (RP 340, RP 330, 320-E, CT-400). Les
mâchoires de la série compacte sont compatibles
avec les appareils de la série compacte (RP 200,
RP 210, 100B).
Le choix des matériaux et des méth-
odes de raccordement appropriés relève du concepteur
et/ou de l’installateur du système. Avant de procéder à
l’installation, une évaluation rigoureuse de l’environnement,
notamment des produits chimiques présents et de la
température d’utilisation, doit être réalisée. Consultez le
fabricant du système de sertissage pour obtenir plus
d’informations sur la sélection.
Compatibilité électro-
magnétique (EMC)
Le terme « compatibilité électromagnétique » correspond
à la capacité de fonctionnement de l’appareil dans un
environnement dans lequel un rayonnement électro-
magnétique et des décharges électrostatiques sont
présents et ceci, sans générer d’interférences électro-
magnétiques avec un autre équipement.
Description et caractéristiques
techniques
Description
La sertisseuse RIDGID®RP 340, lorsqu’elle est utilisée
avec les mâchoires appropriées, est conçue pour sertir
mécaniquement des raccords sur des tubes afin de créer
un joint étanche et permanent. Lorsque l’interrupteur de la
RP 340 est actionné, un moteur électrique interne alimente
une pompe hydraulique qui entraîne un fluide vers le
vérin de l’appareil, déplaçant ainsi le piston vers l’avant et
appliquant des milliers de kilogrammes de pression sur
des raccords conçus à cet effet. Des accessoires sont
également disponibles pour d’autres usages.
La durée du cycle est d’environ cinq (5) secondes. Lorsque
le cycle commence à déformer le raccord, il se poursuit
automatiquement jusqu’à sa fin, même si l’interrupteur
est relâché. L’affichage DEL situé sur la partie supérieure
de l’appareil signale les problèmes tels qu’une température
inappropriée, une goupille de sécurité de mâchoire ouverte
ou une maintenance obligatoire.
Figure 1 – Sertisseuse RP 340 et mâchoires
L’appareil est équipé d’un faisceau d’éclairage DEL qui
s’allume dès que l’on appui sur l’interrupteur et qui reste
allumé pendant quatre (4) minutes après l’avoir lâché
pour assurer l’éclairage de l’ouvrage.
Caractéristiques techniques
Sertisseuse RP 340 :
Moteur
Tension...................18 V
Ampérage ...............27,2 A
Puissance ...............490 Watts
Poids ..........................5,75 livres (2,61 kg)
Force du piston ..........7 200 livres (32 kN)
Affichage
DEL
Mâchoires
à ciseaux
Bras de
mâchoire Goupille de
sécurité
d’accessoire
Batterie
Boîtier de
l’appareil Interrupteur
Poignée
Plaque
latérale de
mâchoire
Bouton de
décharge
de pression
Bouton ON/OFF
(Marche/arrêt) Étiquette
d’avertissement
AVIS IMPORTANT
Faisceau
d’éclairage DEL
