Rielta chrana ORLAN-SH User manual

COMBINED PIR + GLASS
BREAK DETECTOR
«ORLAN-SH»
General Information
Combined PIR + glass break detector «Orlan-Sh» (hereinafter,
the Detector) is designed for application as a component of security
systems.
The Detector has the following two independent detection channels:
- Glass break channel (hereinafter, GB channel);
- Passive infrared channel (hereinafter, PIR channel).
GB channel is intended for detecting destruction of engineering
structures made of plate glasses as well as glass bricks.
PIR channel is assigned for detecting intrusion into protected area
of closed premises.
The Detector provides protection against case tampering by
microswitch contacts opening.
The Detector is resistant to the impacts of ambient light, radio noise,
as well as disturbance from small animals: mice, rats, birds in cages
if a distance to them is not less than 2.5 m.
The Detector can be installed on the wall or in the corner of the
room. Wall or ceiling mounting by means of swivel bracket (supplied)
is also possible.
Features
- Sensing element of detection channels:
- PIR channel – dual-element pyrodetector;
- GB channel – microphone.
- Microprocessor-based signal processing.
- Self-test mode.
- Alarm at PIR and GB channels memorization (alarm memory).
- Possibility of PIR and GB channels sensitivity modes choosing.
- Possibility of LED indication disabling.
- Protection against ingress of insects to the pyrodetector.
- Possibility of swivel bracket using for the detection zone position
alignment.
Specifications
Table 1
Parameter Value
Maximum PIR channel detection range not less than 10 m
Maximum detection range GB channel 6 m
Output PIR and GB relay contacts voltage up to 72 V,
current up to 30 mA
GB channel sensitivity (HF) minimum /+7 dB/+14 dB/+21dB
Alarm message duration, not less than 2 sec
Minimum controlled glass area 0.1 m2
Warm-up time after energizing, not
more than 60 sec
Operating temperature minus 20 °С … +45 °С
Relative humidity at +25 °C without
moisture condensation 90 %
Dimensions, max 110 х 58 х 45 mm
Weight, not more 0.15 kg
PIR channel detection zone pattern is shown in Figure 1, GB channel
detection pattern – in Figure 2.
Scope of Delivery
Each Detector unit package contains items listed in Table 2.
Table 2
Name QNT
Combined PIR + glass break detector «Orlan-Sh»
Accessories set:
Swivel bracket
Screw nut «SORMAT» 5х25
Screw 3-3х30.016
Testing ball
Combined PIR + glass break detector «Orlan-Sh». Installation
Guide
1 pc.
1 pc.
2 pcs.
2 pcs.
1 pc.*
1 copy
* Supplied optionally
Choosing Place of Installation
When choosing the Detector installation place, it is advisable to
take note of the fact that the detection zone may be screened by
non-transparent objects (curtains, houseplants, cabinets, bookcases,
etc.), as well as by glass and mesh partitions. There must be no
windows, air conditioners, space heaters or heating radiators in the
PIR detection zone.
Distance between the Detector and the farthest point of the
monitored glass should not exceed 6 m. The Detector microphone
should be oriented strictly towards the protected surface of a glass
construction.
In case of 1 m2area monitoring maximal distance to the Detector
should be increased up to 9 m. Recommended installation height
is 2.3 m. In case of swivel bracket usage, installation height is
2.3 – 3.0 m provided that PIR detection zone is aligned.
The Detector wires should be laid at a distance not less than 0.5 m
from power supply cables.
Installation of the Detector
- Put off access hole of the Detector (2).
- Remove cover with the printed circuit board (PCB) (4, 3) from the
base (1) by pulling towards yourself and downward.
- Open holes in the base for the Detector wiring and fastening the
base.
- Choose the place of installation, mark the places for mounting
holes with regard to the openings on the detector base, drill holes in
the place of installation.
- Pass the wire through the mounting holes in the base, leaving
enough length of the wire for hooking up to the Detector terminals.
- Fix the base of the detector (swivel bracket) on the chosen place.
- In case of swivel bracket using, reverse the cap screw (5) from
the swivel bracket sphere. Fit the square bulge of the swivel bracket
external sphere with the corresponded opening on the detector base.
Plug in the screw to the opening in the top of the detector base and
fix the connection by the screw without tightening.
- Set the base in desired position and tighten the screw to ensure
the base stable fastening.
Installation Guide
Figure 3 – Design of the Detector
2
3
1
4
5
Swivel bracket
Figure 2 – GB channel detection zone pattern
6 m Microphone
positioning
Top view
R
Side view
90о
R
6 m
180
о
Zone of reliable
detection
Figure 1 – PIR channel detection zone pattern
PIR channel
detection zone
space pattern
10 m
6о
60
о
10 m
2.3 m
0
1 m
1 m
5 m 60о
60о

be increased by means of «1» and «2» DIP-switches with further GB
testing procedure repetition.
Table 5
Glass thickness, mm <3 3–4 4–5 5–6 6–7 >7
Ball deflection angle for ordinary, armed
and ornamental glass, 030 35 40 45х) 50 55
Ball deflection angle for hardened and
laminated glass, 045 50 55 60 65 70
х) – Inclination angle for glass blocks
Fulfill the same testing by delivering blows to different places of the
other monitored glasses (after each blow green LED indicator should
blink twice). If it is necessary, repeat sensitivity adjustment.
Note – For the detector adjustment of sensitivity to impacts on
multilayer glass, small-area or double-glass, it is possible to use
glass-break simulator.
Alarm Memory Mode
Set the DIP-switch «4» in ON position. In this mode in 5 min after
alarm in GB channel and relevant alarm message generation, red and
green LEDs alternately blink at a 1 Hz frequency, and in case of alarm
in PIR channel – yellow and red LEDs blink at a same frequency.
Indication duration is 15 min.
Self-Testing Mode
The Detector fulfills self-testing automatically. During self-testing
ambient temperature and power supply voltage value is checked. In
ambient temperature range is close to 36 °C, PIR-channel detectability
is improved (temperature compensation is provided).
If power supply voltage drops lower than 9-1 V, «Failure» message
is generated by GB and PIR channels relay contacts opening. The
message is repeated by red LED indicator lighting at 1Hz frequency
with yellow and green LEDs blinking. The «Alarm» message duration
is 15 min.
LED Indicator Disabling
For the Detector operation masking, possibility of indication disabling
is provided by setting DIP-switch «5» to OFF position. In this mode
indicator operation is provided during 1 min after Detector energizing,
as well as in Alarm Memory or Failure modes.
ATTENTION! The Detector must be checked at least annually in
order to test it’s performance.
Manufacturer’s Guarantees
The manufacturer guarantees conformity of the Detector to it’s
Technical Specifications if provided that the transportation, storage,
installation and operation conditions are observed.
The guaranteed shelf life of the Detector is 63 months since the
date of manufacture.
The guaranteed useful life is 60 months since the day of putting
into operation within the guaranteed shelf life.
The Detectors that are found non-conforming to the Technical
Specifications shall be repaired by the manufacturer, provided the
installation and operation rules have been complied with.
Storage and Transportation
The Detectors in their original packaging may be transported by
any means of transportation in closed vehicles over any distances in
compliance with the existing shipping rules concerning the respective
means of transportation.
The storage premises should not contain any current-conducting
dust, acid and alkali fumes, or corrosive or destroying insulation gases.
The Detectors in transport packaging should be stored no longer,
than 3 months. Otherwise they should be released from transport
packaging.
Acceptance and Packing Certificate
Combined PIR + glass break detector «Orlan-Sh»,
serial number ____________,
has been manufactured in compliance with the active technical
documentation and classified as fit for operation and packed by
«RIELTA» JSC.
Person in charge of acceptance and packing
QC representative_________________ __________________.
day, year, month
Connection
- Terminals for wire hooking up are located at the top of the PCB.
- Fulfill connections in accordance with Figure 4.
Figure 4 – The Detector connection pattern
- Set operation mode by means of DIP-switches «1», «2», «3», «4» and
«5» in accordance with particular application conditions (see Table 2).
- Install the access hole.
Table 2
Mode DIP-switch
DIP-switch position
ON OFF
GB channel sensitivity «1» +14 dB min
GB sensitivity sensitivity «2» +7 dB min
PIR channel sensitivity «3» high normal
Alarm memory (AM) «4» AM No AM
LED indication «5» ON OFF
LED Indication
LED indication modes are listed in Table 4.
Table 4
Message Channel LED color
yellow red green
Warm-up time * +/- *
Norm – – –
Indication of
Interferences
First GB frequency – –++
Second GB frequency – – +
PIR + – –
Alarm GB – * *
PIR * * –
Alarm memory
GB – -/+ +/-
PIR +/- -/+ –
Failure Power supply * - -/++ *
Notation: * LED is ON;
– Indication is OFF; + single-shot blinks;
++ double-shot blinkings;
+/-,-/+ LED is blinking at 1 Hz frequency;
--/++ LED is blinking at 2 Hz frequency.
Switching On and Testing
After energizing the Detector is starting operation in standby mode
during 1 min. It is displayed by yellow and green LEDs lighting and
red LED indicator blinking at 1 Hz frequency. Green LED indicator
switches off in 3 – 5 sec, red and yellow LEDs – in 50 – 57 sec, thus
confirming the Detector both channels availability and it’s proceeding
to the standby mode.
Functional Testing
During operation in standby mode, the Detector generates «Norm»
message (by GB and PIR channels relay contacts closing). For
correctness of the installation place choice checking, it is necessary
to fulfill functional testing of GB and PIR channels.
1) PIR Channel Testing
Get off the detection zone, energize the detector and wait for
1 min before test starting. Make sure that LED indicators are switched
off. In presence of interferences (see Table 4), find out and eliminate
the cause of it, if it is possible. Moving across the sensing zones at
a speed 0.5 – 1 m/sec, define the border of PIR channel detection
zone by yellow LED indicator switching on. After it move at speeds
0.3 m/sec and 3 m/sec and check the Detector sensitivity by red
and yellow indicators switching on. «Alarm» message is generated
after 2 – 4 steps inside the detection zone. If it is necessary, change
the zone alignment by turning the Detector on the swivel bracket in
vertical or (and) horizontal plane (swivel bracket ensures changing the
detection zone position on ± 45° in horizontal plane and it’s tilt angle
up to 20° in vertical plane). After it fulfill the detection zone alignment
and sensitivity check once more.
2) GB Channel Testing
Set DIP-switches «1» and «2» at OFF position (minimum sensitivity
level).
Suspend a steel ball (21.5 ± 0.5) mm in diameter weighting
(40 ± 8) g on a 35 cm long thread near the monitored glass standing
clear of it, deflect it at an angle of 30 – 70° (see Table 4). Deliver a test
blow to the remote section of the protected glass. Don’t occlude the
Detector during blow delivering. If the test blow is not accompanied by
green LED indicator two-shot blinking, the Detector sensitivity should
GB channel control
Case tampering
AL PIR Tamper AL GB +12V-
Power supply
PIR channel control
Rev. 2 of 10.11.14
№00096
«RIELTA» JSC, www.rielta.com,
Chapaeva Str. 17, Saint Petersburg, Russia, 197101, [email protected],
Tel./fax. [phone],
Technical support, tel. [phone], [email protected].
Made in Russia
