Rointe D SERIES User manual

Instruction Manual
Assembly, installation, start-up
and operating instructions
D series with
Towel Rails
DELTA Ultimate
technology
Class II

Many thanks for your confidence in our Rointe products. Before
you start to use the low-consumption digital electrical D series with
Delta Ultimate technology towel rails we recommend that you read
this manual carefully in order to use the product correctly with the
maximum guaranteed results.
Thank you.

3
INDEX OF CONTENTS
1. DESCRIPTION OF THE D SERIES TOWEL RAILS ...................4
1.1. Description of the front panel ..............................................5
1.2. Switch On and Off (Stand By).............................................8
1.3. Select Temperature.............................................................9
1.4. Lock the Control Panel........................................................9
1.5. Adjust Date and Time........................................................10
1.6. Main Menu ........................................................................ 11
1.7. Open Window Function .....................................................27
2. INSTALLATION AND MOUNTING INSTRUCTIONS ...............28
3. PRODUCT DIMENSIONS .......................................................29
4. CONNECTION INSTRUCTIONS.............................................30
4.1. Special Rules for Bathrooms.............................................31
5. MAINTENANCE AND CLEANING...........................................32
5.1. S afe t y ................................................................................32
6. GUARANTEE ..........................................................................33

4
1. DESCRIPTION OF THE D SERIES TOWEL RAILS

5
D series with DELTA Ultimate technology
1.1. Description of the front panel
1.1.1 Parts of the TFT screen
ICON INDICATION
On / Off - Accept
Decrease temperature - Move left
Increase temperature - Move right
Access / Return to Menu - Move up
Access programming Menu - Move down
1
2
3
4
11 10
9
8
7
6
5
D Series

6
NUM. INDICATION
1 Hours programmed - AUTO
2 Days of the week
3Time
4Selected temperature
5Locking the control panel
6 Manual / Automatic / Pilot wire functions
7 Comfort / Economy / Anti-frost modes
8Net connection status
9Heating Element in operation
10 Consumption behaviour indicator
11 Open Window function
ICON DESCRIPTION
Open Window function active - No detection
Open Window function - Detected

7
D series with DELTA Ultimate technology
Consumption indicator – green / yellow / red
Towel Rail Heating element on
Connected to the router and server
- sending and receiving
Connected to the router and server
- maximum internet signal
Connected to the router and server
- minimum internet signal
Connected to router but not connected
to server nor internet
Not connected to server. Not connected to the router
Comfort Mode activated
Eco mode activated
Anti-frost mode activated
Automatic mode activated
Manual mode activated
Pilot Wire Control mode activated
Not available in UK. Only upon demand
Automatic function activated in USER mode
Manual function activated in USER mode

8
Pilot Wire Control function activated in USER mode
Not available in UK. Only upon demand
Product locked via towel rail control panel
Product locked via Air Control remote
control or Rointe Connect App
1.2. Switch On and Off (Stand-by)
The D series with DELTA Ultimate technology
towel rail is switched on or off using the
button. The following welcome appears on the
TFT screen when the towel rail is switched on.
DELTA Ultimate
The main temperature screen will appear after
5 seconds.
If you press the button again when the towel
rail is switched on it will revert to stand-by mode
and the words “Stand-By” will appear.
5 seconds later and the Rointe logo will appear.

9
D series with DELTA Ultimate technology
1.3. Temperature selection
You can change the desired temperature using
the keys or . If the temperature of the room
is less than is desired then the towel rail will begin
to heat up and the symbol will appear.
1.4. Locking the control panel
You can lock the product from the actual control panel of the towel
rail or remotely via the Rointe Connect App or the Air Control
remote control.
On the product control panel you can lock the
keypad by pressing and holding down the
and buttons at the same time for 3 seconds.
The locked icon will appear. When you press
any button the image on the right will appear on
the screen. You can unlock the product again
by pressing and holding down the and
buttons for 3 seconds.

10
If we lock the product via the application or
remote control then the remote locked icon will
appear on the screen . When you press any
button on the towel rail control panel, the image
on the right will appear on the screen. If the
product is locked in this way, you can only
unlock the towel rail via the Rointe Connect app
or the Air Control remote control.
1.5. Adjusting time and date
It is possible to change the time on the towel rail from the control
panel. However it is better to wait for the automatic synchronization
once the product has been paired with the Rointe Connect app
and the product is connected to the E-Life technology servers.
Here we explain how to change the time from the towel rail control
panel.
Press the menu button to access the main
menu. Select the sub-menu by using the
and buttons then press to access.
In the configuration sub-menu, use the and
buttons to select the clock then press
to access.

11
D series with DELTA Ultimate technology
By pressing the button, the hours, minutes
and days will flash depending on the number of
times the button is pressed (1 for hours, 2 for
minutes and 3 for the day of the week).
We can change any of these by pressing the
or buttons. To confirm, press the button.
To exit the time/day mode wait 30 seconds or press the button
after selecting the day of the week.
1.6. Main menu
Press the button to access the main menu
of your D series with DELTA Ultimate technology
towel rail. You can move between the different
options on the menu by pressing the and
buttons. The sub-menu which you have selected
will be highlighted with a frame. The following
icons allow you to access different sub-menus
which we will now explain:
Configuration
Sub-Menu
Energy
Sub-Menu
Balance
Function
Programming
Sub-Menu

12
1.6.1. Configuration sub-menu
The configuration sub-menu consists of 4
technical parameters of the product.
To access this menu, press on the main menu
screen. The screen on the right will appear and
we can move between the various options of the
sub-menu by using the and buttons. We
can access the various sub-menus, which we
can now explain, using the following icons:
Screen
backlight
Internet
settings Language Adjust day / time
• Screen backlight function
This function allows you to change the brightness
of the screen in the STAND-BY and BACKLIGHT
(ON) modes. We can change between the 2
modes by using the and buttons.
We can increase or decrease the brightness by
using the and buttons.
The cursor shows the intensity of the light within
the range. Press the button to confirm and
to exit.

13
D series with DELTA Ultimate technology
• Internet Settings
This option prepares the product to communicate
with a special network enabling it to be paired.
Press the internet settings option to access
this mode.
On the next screen the name of the WIFI network
(NET) and password (PIN) which have been
created will appear.
Exit the PAIRING mode by pressing the
button which will allow us to return to the main
screen.
ROT
Pairing your product with the
Rointe Connect App
In order to pair your Rointe D
series with DELTA Ultimate
technology product(s) with your
local WI-FI signal, please follow
the instructions in the attached
document “Delta Ultimate
technology. Quick set-up guide.

14
• Language
You can select the language you wish using this
function. Select the language you wish by pressing
the and buttons. Press the button to
confirm the language highlighted.
LANGUAGE
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
• Adjust date / time
This function allows you to change the hour,
minutes and day of the week on the product
control panel. To adjust the time/date please
revert to section 1.5.
1.6.2. Energy Sub-menu
The Energy Sub-menu allows access to the
functions relating to the energy management of
the product. Select the icon from the main
menu by using the and buttons. Press
to access this screen. The following icons
allow you to access distinct sub-menus:
Open window
function
Two-hour
Boost mode
Effective
power
function
Information

15
D series with DELTA Ultimate technology
• Open Window Function
This option allows you to turn on or turn off the
Open Window function. Select ON to activate it
or OFF to deactivawte it by using the and
buttons. To confirm the desired option and exit,
press the button. To learn more about this
function please see section 1.7 of this manual.
This function activates the Anti-Frost mode (7ºC) when
the towel rail sensor detects a drop of at least 4ºC in 30
minutes.
• Two-hour Boost Mode
This function sets the towel rail to work for two
hours at maximum power, regardless of any
other mode. This mode takes priority over any
other.
When the heated towel rail is set on the two-hour
mode, the screen will show this image.

16
Once the towel rail is set on the two-hour mode,
and until the two hours have finished or the key is
pressed again, the display will show this image.
• Effective Power Function
This function shows the working time
and total time that the product has
been connected on the main screen.
The nominal and effective power will
appear on the screen after 6 seconds
without pushing any buttons.
The effective power is the actual consumption of our product
during the total time it is switched on.

17
D series with DELTA Ultimate technology
• Information
This option shows the software version, the
release date and the nominal power of the
product.
Select the icon by using the and
buttons, then press the button to confirm. To
exit from the information screen, press .
POWER 750W
This option shows the status of the WIFI
connection, the IP address, subnet mask and
connection port.
Select the icon by using the and
buttons then press the button to confirm. To
exit from the information screen, press .
WIFI STATUS
dhcp:assigned
IP, NM, GW:
xxx.xxx.x.xxx
xxx.xxx.xxx.x
xxx.xxx.x.xxx
This option shows the MAC and RSSi address
and signal strength which is measured in dbm.
Select the icon by using the and
buttons then press the button to confirm. To
exit from the information screen, press .
WIFI STATUS
MAC:
0 :50:93
C4:03:F6
RSSI:-70

18
1.6.3. Balance Sub-menu
The balance sub-menu forces the towel rail to
work in manual mode at a constant 19ºC.
Select the icon from the main menu using
the and buttons.
Press the button to confirm. By pressing this
button the towel rail will return to the main screen
with a set temperature of 19ºC and the “Manual”
icon will appear.
1.6.4. Programming sub-menu
In this section we will explain the aspects of the towel rails in
relation to how they work in their various functions and modes.
The programming sub-menu provides access
to the functions related to programming the
product. Select the icon from the main menu.
The icons shown below allow access to the
distinct sub-menus which we will describe later:
/
Manual /
Automatic
Function
Start
Programming User Function
Pilot Wire Mode
(Only upon
demande)

19
D series with DELTA Ultimate technology
What are the manual, automatic and pilot wire modes?
Manual Mode
This mode allows you to change between comfort, eco and
anti-frost modes changing the temperature as described in
section 1.3.
Automatic Mode
This mode activates the programming which has been set
in the towel rail.
Pilot Wire Mode Not available in UK. Only upon demand
This mode allows you to control the towel rail via a central
control.
What are the comfort, Eco and Anti-Frost modes?
These modes represent different ranges of temperatures
available within the products.
Icon Mode Temperature Range
Comfort From 19ºC to 30ºC
Eco From 7.5ºC to 18.5ºC
Anti-Frost 7ºC

20
• Manual/Automatic Function
Press the button to change
between the Manual and
Automatic modes.
On the main screen the symbol
will appear in Automatic
mode and the symbol will
appear in Manual mode.
The Automatic Mode will activate the programming which
you have already set in the product.
• Start Programming
To start programming, use the and
buttons to choose the icon and confirm by
pressing the button.
Use the and keys to select the COMFORT
temperature, between 19ºC and 30ºC. The
symbol and the temperature will flash. Once
selected, press to confirm.
Select the COMFORT temperature
1
