Rointe D SERIES User manual

INSTRUCTION MANUAL
Information, operation & installation
D Series
DIGITAL ELECTRONIC TOWEL RAIL
Class II

2
Contents:
1. Introduction.............................................................................................................................................. 3
2. Product information and operation .................................................................................................... 3
2.1. Control panel ............................................................................................................................... 3
2.2. Switching on and off (stand-by) ................... ............................................................................... 5
2.3. Adjust the day and time ............................................................................................................... 5
2.4. Adjust the temperature ................................................................................................................ 6
2.5. Lock the control panel ................................................................................................................. 6
2.6. Main Menu................................................................................................................................... 7
2.6.1. Settings sub-menu ............................................................................................................7
2.6.2. Energy sub-menu.............................................................................................................. 8
2.6.3. Equilibrium / Balance sub-menu .....................................................................................10
2.6.4. Program sub-menu......................................................................................................... 10
2.7. OPEN WINDOWS function......................................................................................................... 15
3. Installation and mounting ................................................................................................................. 16
3.1 Mounting instructions ................................................................................................................ 16
3.2 Installing and fixing the supports .............................................................................................. 16
3.3. Specific regulations for bathrooms.................................................................................................17
4. Maintenance and cleaning ............................................................................................................... 18
5. Installation and safety precautions ................................................................................................. 18
5.1. Installation precautions ............................................................................................................. 18
5.2. Safety precautions..................................................................................................................... 18
6. Rointe Product Guarantee................................................................................................................ 28
7. European Directive..................................................................................................................................21
8. Dimensions & Technical Characteristics.......................................................................................... 21
9. Certificate of Guarantee.........................................................................................................................23

3
D SERIES Towel Rail
1. Introduction
Designed with the user in mind, this product contains an exclusive electronic temperature program-
mer and is manufactured with high quality components. This product has passed the most demand-
ing quality controls to meet rigorous safety standards and efficiency requirements. This product is
designed for fixed installation only. The main features of this product are:
• 1.77” TFT Screen with personalisable background colours
• Safety thermostat
• Low consumption
• Integrated Wi-Fi module with E-Life technology
• Highly sensitive touch control panel
• Equilibrium function
• OPEN WINDOWS function
• BOOST function
IMPORTANT - Please read this Instruction manual carefully to ensure correct operation. It is
important that the installer reads and understands these instructions, and unpacks and familiarises
themselves with the equipment before commencing the installation. This manual must be left with the
product after installation. Failure to observe these installation instructions could render the guarantee
null and void.
2. Product information and operation
2.1. Control panel
2.1.1. Keypad
ICON DESCRIPTION
On / Off button
Accept / Confirm button
Decrease temperature button
Move left button
Increase temperature button
Move right button
Menu button
Move upwards button
MANUAL / AUTOMATIC button
Move downwards button

4
2.1.2. Display panel
* PILOT WIRE function not available in UK. Only on demand.
2.1.3. Icon information
ICON DESCRIPTION ICON DESCRIPTION
Heating element active PILOT WIRE function active*
OPEN WINDOWS function - active, detection AUTOMATIC function active when USER mode
active
OPEN WINDOWS function - active no
detection
MANUAL function active when USER mode
active
Energy consumption status - green / amber
/ red
PILOT WIRE function active* when USER
mode active*
COMFORT mode active Connected to the server and router - sending
and receiving.
ECO mode active Connected to the server and router -
maximum net signal.
ANTI-FROST mode active Connected to the server and router -
minimum net signal.
Control panel locked through keypad Connected to router. Not connected to the
server or to the internet.
Control panel locked through remote Not connected to the server or to the router.
AUTOMATIC function active * PILOT WIRE function not available in UK. Only on
demand.
MANUAL function active
NO. DESCRIPTION
1Programming
2Days of the week
3Time of day
4Temperature selected
5Control panel locked / unlocked
6MANUAL / AUTOMATIC / PILOT WIRE* function
indicator
7COMFORT / ECO / ANTI-FROST mode indicator
8Wi-Fi connection status indicator
9Heating element active indicator
10 Energy consumption indicator
11 OPEN WINDOWS function indicator

5
D SERIES Towel Rail
2.2. Switching on and off (stand-by)
To switch the product on, please press the button on the keypad once.
The image to the right will appear on the display panel when the product is
switched on.
DELTA Ultimate
After 5 seconds the temperature, time and days of the week will show on the
display panel.
To switch the product off, please press the button again once.
The product will go into stand-by mode with the word ‘STAND-BY’ displayed on
the display panel. After 5 seconds the Rointe logo will appear.
2.3. Adjust the day and time
You can manually set the time on the product from the control panel orit will automatically synchronise
when the product has been connected to Wi-Fi and Rointe Connect app.
To set the day and time, please press the button on the keypad to access
the Main Menu. Select the `Settings´ menu using the or buttons on
the keypad.
To move left press the button and to move right press the button. Once
the icon is highlighted on the display panel, press the button to access.
Now use the and buttons again to select the clock option and press
to access.
Use the and buttons to set the hour and then press to confirm.
Then use the and buttons to set the minutes and press to
confirm. Finally, use the and buttons to set the day (1 = Monday, 2 =
Tuesday etc.) and confirm by pressing the button.

6
2.4. Adjust the temperature
To change the temperature, please press the or button. To decrease
the temperature press the button and to increase the temperature press
the button.
When the room temperature is lower than the set temperature on the display
panel, the product will come on with the symbol appearing in the top right
of the display panel.
2.5. Lock the control panel
You can lock the keypad from the product or from a remote control* (optional).
To lock the keypad manually, please hold and press the button AND the
button TOGETHER for 3 seconds. The symbol will appear on the display
panel and the keys will not respond.
To unlock the keypad manually, please hold and press the button AND the
button TOGETHER for 3 seconds. To lock the keypad using a remote control,
please see the corresponding instruction manual for the remote control
separately.
Please note that if the product is locked using a remote control then it can only
be unlocked using the remote control. If the product is locked using a remote
control and you press the keypad on the product then the following image will
appear on the display panel.
2.6. Main Menu
The Main Menu is accessed by pressing the menu button. You can navigate
through the different options available on the menu by pressing the and
buttons to move left and right respectively and to scroll through all 4 options.
The selected sub-menu will be highlighted with a frame, as shown in the image
to the right on the `Settings´ section of the display panel.
The below icons displayed on the screen take you to the following sub-menus:
Settings Energy Equilibrium / Balance Program

7
D SERIES Towel Rail
2.6.1. Main Menu: Settings sub-menu
The ‘Settings’ sub-menu configures the technical parameters of your product.
To access, select the icon displayed in the Main Menu screen and press
to confirm.
Use the and buttons to move across the different options on the sub-
menu to choose your parameter and press to access.
The below icons displayed on the screen take you to the following parameters:
Display backlight
brightness Wi-Fi settings Language Time
• Adjust display backlight brightness
This allows you to change the brightness of the display panel in both the STAND-
BY and ON modes separately. To change the brightness of the display panel
ensure the icon is highlighted and press the button to confirm. Then
with the and buttons you can switch between the two modes.
With the and buttons you can increase or decrease the brightness as
you wish. The cursor indicates the intensity of the light. Once you have set the
required brightness press the button to save and exit.
• Wi-Fi settings
This prepares the product to communicate with the selected Wi-Fi network.
To start the PAIRING mode, ensure the icon is highlighted and press the
button to confirm. On the next screen the name of the network (NET) and
password (PIN) will appear. Press the button to exit the pairing mode and
return to the main screen.
ROT
Please note - to pair your product with your home internet network please follow the
instructions in the “D Series Heating System Quick Setup Guide” enclosed.

8
• Change the language
To change the language of your product, ensure the icon is highlighted in
the ‘Settings’ sub-menu and press the button to access.
Use the and buttons to move up or down respectively until your chosen
language is highlighted and confirm by pressing the button.
LANGUAGE
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
• Adjust the day and time
This option sets the hour, minutes and day of the week in your product. Please
refer to section 2.3.
2.6.2. Main Menu: Energy sub-menu
The ‘Energy’ sub-menu provides access to functions related to energy
management of the product. To access, select the icon displayed in the Main
Menu screen and press to confirm.
Use the and buttons to move across the different options on the sub-
menu to choose your function and press to confirm.
The below icons displayed on the screen take you to the following functions:
OPEN WINDOWS
function
Two Hour Boost
function
Effective Power
function Information
• OPEN WINDOWS function
To set the OPEN WINDOWS* function, ensure the icon is highlighted in the
‘Energy’ sub-menu and press the button to access. Use the and
buttons to move up or down respectively until your preference is highlighted and
confirm by pressing the button. *To learn more about this function, please
go to section 2.7.

9
D SERIES Towel Rail
• Two Hour Boost mode
The two hour BOOST mode will override any other set mode and will boost your
product to maximum power. To set the BOOST mode, ensure the icon is
highlighted in the ‘Energy’ sub-menu and press the button to access.
• Effective Power function
To check the Effective Power status of your product, ensure the icon is
highlighted in the ‘Energy’ sub-menu and press the button to access. The
display panel will then show a status according to the current state of consumption
of the product:
• Working Time
• Total Time
After 6 seconds, the display panel will then show:
• Nominal Power (w)
• Effective Power* (w)
*The effective power is the actual value of its nominal power that the product
consumes during periods of operation.
• Information
This function will display the software version, the date of this release and the
rated power of the product.
To access this information, ensure the icon is highlighted in the ‘Energy’
sub-menu and press the button to confirm. The information will then show
in the display panel. To exit press the button or press the button again
to move onto the next display in the Information function.
The next display in the Information function displays the Wi-Fi connection status,
the connection type, IP address, subnet mask and gateway.
To exit press the button or press the button again to move onto the next
display in the Information function.
WIFI STATUS
dhcp:assigned
IP, NM, GW:
xxx.xxx.x.xxx
xxx.xxx.xxx.x
xxx.xxx.x.xxx

10
The final display in the Information function displays the MAC and RSSI address,
signal strength measured in dbm.
To exit press the button.
WIFI STATUS
MAC:
0 :50:93
C4:03:F6
RSSI:-70
2.6.3. Main Menu: Equilibrium / Balance sub-menu
The ‘Equilibrium/Balance’ sub-menu/function returns the product to a constant
temperature of 19°C. To activate this function ensure the icon is highlighted
in the ‘Equilibrium/Balance’ sub-menu and press the button to confirm.
The product will return to the display panel in MANUAL function, with the
temperature set to 19ºC.
2.6.4. Main Menu: Program sub-menu
This section explains the operational aspects of your product in its various functions and modes.
What are the functions of MANUAL, AUTOMATIC and PILOT WIRE functions?
MANUAL This function allows you to change the product between the COMFORT, ECO
and ANTI-FROST modes and to change the temperature (see section 2.4.).
AUTOMATIC This function will activate the programming that has previously been set in the
product.
PILOT WIRE This function allows the product to be controlled by a central programmer.
* Not available in UK. Only on demand*
What are the COMFORT, ECO and ANTI-FROST modes?
COMFORT ECO ANTI-FROST
From 19ºC to 30ºC From 7.5ºC to 18.5ºC 7ºC

11
D SERIES Towel Rail
The ‘Program’ sub-menu provides access to functions related to programming
the product. To access, select the icon displayed in the Main Menu screen
and press to access.
Use the and buttons to move across the different options on the sub-
menu to choose your program and press to access.
The icons displayed on the screen take you to the following functions:
MANUAL /
AUTOMATIC functions
Programming
options USER mode
PILOT WIRE function
* Not available in UK. Only on
demand.*
• MANUAL / AUTOMATIC functions
To change or choose the MANUAL or AUTOMATIC function,
ensure the icon is highlighted in the `Program´
sub-menu and press the button to confirm. You can
change from AUTOMATIC to MANUAL and vice versa by
pressing the button again.
On the display panel, the symbol will appear for the
AUTOMATIC function and the symbol for the MANUAL
function.
• Programming options
To choose a program for your product you MUST be in AUTOMATIC mode.
Please see previous section for details on how to adjust to AUTOMATIC mode.
To access the ‘Programming’ options, ensure you are in the ‘Program’ sub-menu,
then select the icon by using the and buttons and then press the
button once the icon is highlighted.

12
• Start programming for AUTOMATIC function
To program the AUTOMATIC mode, see points above and ensure that START
PROGRAMMING is highlighted. Press the button to access and the display
panel will show a flashing screen.
STEP 1 - Select COMFORT mode temperature
COMFORT mode will be programmed first. Select the COMFORT mode
temperature between 19ºC and 30ºC using the and buttons. The
icon and the temperature will flash. Press the button to confirm.
STEP 2 - Select ECO mode temperature
ECO mode will be programmed next. Select the ECO mode temperature
between 7.5ºC and 18.5ºC using the and buttons.. The icon and the
temperature will flash. Press the button to confirm.
STEP 3 - Select the Days
The days of the week will start flashing on the display panel and show as DAY
1, DAY 2, DAY 3 etc.
Use the and buttons to move forwards or backwards through the days.
Press to select the day or days that you wish to include in your AUTOMATIC
program. The day will stop flashing once selected. Repeat for all the days you
wish to program and once all days are selected press the button to move
onto setting the hour.
STEP 4 - Select the Hours
Once step 3 has been completed, 0h appears on the display panel. 0h is equal
to midnight. Use the or buttons to select the hour you wish to change.
Use the button to change the mode (COMFORT, ECO or nothing) for the
hour you wish to modify. The corresponding icon for that mode will appear at
the top of the screen. To finish the programming press or leave for 30 seconds
without pressing any buttons. To change the programming go back to step 1
and proceed as described before.
*If you wish to have individual days with different programming within your
program you will need to modify each day separately, starting from the Main
Menu again for each day/days. Follow Steps 1 to 4 above to program multiple
differing days/hours/temperatures.
12h

13
D SERIES Towel Rail
• USER mode
To enter the USER function, ensure the icon is highlighted in the `Program´
sub-menu and press the button to access. A 4-digit PIN code is required in
order to access the menu. The default PIN is 0000.
To enter the PIN use the and and and buttons to move left,
right, up or down to select the correct numbers, pressing after each number
is highlighted to confirm. Once the full 4 digits have been entered, move to OK
on the display panel and press the button to confirm. Once the PIN number
has been entered correctly, the main USER function sub-menu will be shown.
The below icons displayed on the screen take you to the following functions:
ENABLE /
DISABLE
functions
Change PIN Upper
temperature limit
Lower
temperature
limit
• Enable / Disable functions
To access the Enable/Disable function, ensure the icon is highlighted in the
‘Program’ sub-menu and press the button to access.
Use the and buttons to move up and down respectively to select ON
to enable or OFF to disable. Once the desired option is highlighted press the
button to confirm. Use the button to go back to the main display panel or
leave for 30 seconds without pressing any buttons.
On the main screen you will see the icon in AUTOMATIC function, the
icon in MANUAL function and when in PILOT WIRE* function.
*PILOT WIRE function not available in UK. Only upon demand.*
USER
FUNCTION
ON
OFF

14
• Change the PIN code
To change the PIN code of your product, ensure the icon is highlighted in
the ‘Program’ sub-menu and press the button to access.
Use the and and and buttons to move left, right, up or down
to select the new numbers, pressing after each number is highlighted to
confirm.
Then move to OK on the display panel and press the button to confirm. The
screen will show PIN CHANGED.
Please remember your new PIN code for the future and store in a safe
place. In order to access the USER function menu again you will need
your new PIN code.
PIN
CHANGED
• Upper temperature limit
To set the upper temperature limit of your product ensure the icon is
highlighted in the ‘Program’ sub-menu and press the button to access.
Use the and buttons to decrease or increase your desired upper
temperature between 19ºC to 30ºC and press the button to confirm. You
will then return to the USER function screen. To exit press the button to go
back to the main display panel or leave for 30 seconds without pressing any
buttons.
• Lower temperature limit
To set the lower temperature limit of your product ensure the icon is
highlighted in the ‘Program’ sub-menu and press the button to access.
Use the and buttons to decrease or increase your desired lower working
temperature between 7.5ºC to 18.5ºC and press the button to confirm. You
will then return to the USER function screen. To exit press the button to go
back to the main display panel or leave for 30 seconds without pressing any
buttons.
LOWER
TEMPERATURE
LIMIT
10.0ºC

15
D SERIES Towel Rail
• PILOT WIRE function (*Not available in UK. Only on demand.*)
The PILOT WIRE function allows your heating only to be controlled via a pilot wire programmer.
To access the PILOT WIRE mode, ensure the icon is highlighted in the
‘Program’ sub-menu and press the button to access.
Use the and buttons to move up and down respectively to select ON
to enable or OFF to disable. Once the desired option is highlighted press the
button to confirm. Use the button to go back to the main display panel or
leave for 30 seconds without pressing any buttons.
On the main display panel the symbol will appear.
PILOT
WIRE
ON
OFF
2.7. OPEN WINDOWS function
This function is activated when the temperature sensor in the product detects a drop of 4ºC from the
set temperature within a 30 minute time period. The OPEN WINDOWS function will be active for 2
hours. If the button is pushed during this period the product will switch off. Pushing the button
again will switch on the product without the OPEN WINDOWS function being switched on.
When this function is activated by the sensor, the image to the right will appear
on the product display panel for 5 seconds.
When the OPEN WINDOWS function is activated, the product will move into
ANTI-FROST mode at 7ºC. The icon will appear on the product display panel
showing that the ANTI-FROST mode is active.

16
3. Installation instructions
3.1. Mounting instructions
Inside the box/packaging you will find a mounting kit:
1. Choose the right part of the wall.
2. Place the mounting stencil on the wall, marking the places for the holes.
3. Remove the stencil and make the holes in the wall.
4. Insert the rawl plugs in the holes made.
5. Screw the four metallic fasteners to the wall with the 6.3 x 50 mm screw.
6. Screw the four metallic cylinders to the product (see Figure 1).
7. Insert what you have assembled in Section 6 into the metallic fastener and fix well with the 2.9
x 9.5 mm stud bolt.
Figure 1:
NO. ITEM
110mm rawl plug
2Metallic fastener
3Screw 2.9 x 9.5mm
4Screw 6.3 x 50mm
5Metallic cylinder
6Product
3.2. Connecting instructions
Connection to the mains must be made observing the voltage stated on the product technical data label.
This product is designed to be permanently installed connected to fixed facilities. The product power
supply circuit must have an all-pole circuit breaker switch with a separation of at least 3 mm between
the contacts.
The product must be installed, if possible, away from any source of draughts (windows, doors) or any
other thing which may affect its functioning. In this way, the temperature will not be affected. Place any
object which might prevent the air flow (furniture, armchairs) 50 cm away from the front of the product.
The product must never be installed immediately below a power point.
The lower part of the control panel must be placed at least 15 cm from the floor.
For any product, if the power cable is damaged, it must be replaced by a specific cable. The replacement
of the cable must be done by the maker, its after-sales service or qualified personnel. The technical
specifications of your product appear on the technical data label.
5

17
D SERIES Towel Rail
IMPORTANT:
• This product must never be installed with its control panel at the top.
• This product must not be installed horizontally.
• During installation use wedges so that the control panel will not be in contact with the floor
• Please refer to Figure 2 for correct positioning.
Figure 2:
3.3. Specific Regulations for bathrooms
This product is in compliance with CLASS II safety regulations (double insulation). It can be installed
according to Figure 3 (in positions A and B in areas 2 and 3 only) whenever it observes the following
regulations:
• In bathrooms, the product must never be installed in such a way that the switches and other con-
trol products may be touched by persons in the bathtub or having a shower.
• In a kitchen or bathroom, the body of the product shall be placed at least 25cm from the floor.
• The product must not be earthed.
Figure 3:

18
4. Maintenance and cleaning
The product does not require any type of regular maintenance. However, we recommend that all
parts of the product are kept clean (behind, underneath, along the rails etc.). Do not use any abrasive
material/fluid on the product. Clean the product with a damp cloth and a pH neutral soap. Clean the
control panel with a dry cloth.
5. Installation and safety precautions (EN 60335 Standards)
Before switching on the product, please read the “Installation & Safety Precautions” in detail first to
ensure the correct operation of the product.
5.1. Installation precautions
The product is designed for household or residential use only. You are advised to have the product
installed by an authorized professional installer. Please contact Rointe by telephoning 0203 321 5928
to find your nearest installer. Make sure the product is properly connected to 230V.
5.2. Safety precautions
The product can be used by children aged from 8 years and above and by persons
with reduced physical sensory or mental capabilities or lack of experience and
knowledge, if they are supervised or have been given instruction concerning use
of the product in a safe way and understand the hazards involved. The product is
not a toy, children should not play with the product. Cleaning and user maintenance
should not be carried out by children without supervision. Children must be
supervised at all times to ensure that they do not interfere with the product.
If the power cable is damaged, it must be replaced by the manufacturer, its after-
sales service or authorized personnel in order to avoid any damage.
6. Rointe Product Guarantee
In this section, we hereby describe the guarantee conditions, which the buyer acquires, on buying this
product from ROINTE. These conditions comply with all the rights construed in the national legislation
in force, as well as any additional rights and guarantees, which are offered by ROINTE.
Any incident that you might detect in your ROINTE product can be sorted by the product seller or
quickly by the manufacturer. Please contact ROINTE by telephoning 0203 321 5929 for Technical
Support. Alternatively, you can email ROINTE at [e-mail], through which we will
instruct you on how to solve the incident.
You will need to state the product reference (located on the label indicating product features),
serial number, proof of purchase and the type of incident at hand when contacting us so that
we can check the guarantee. In addition, please attach a copy of the product invoice.

19
D SERIES Towel Rail
6.1. ROINTE guarantees that there are no material defects of design or manufacture at the time of
original acquisition and guarantees the main body for a period of 120 months and any electronic and
electrical components for 24 months, provided that they have not been modified in any way.
6.2. If during the guarantee period, the product does not work correctly under normal use, and any
design, material or manufacturing defect is found, ROINTE will repair or substitute the product as it
may see fit, in accordance with the terms and conditions as follows:
6.2.1. The guarantee is only applicable if the original guarantee is issued by the seller and when the
said guarantee is filled in correctly including product reference, series number (marked on the product’s
label indicating technical features), purchase date and the seller’s stamp, and either registered on our
website at www.rointe.co.uk or returned completed to ROINTE within 90 days of installation. ROINTE
reserves the right to reject the guarantee service when this information has been removed or modified
after the original product purchase.
6.2.2. The guarantee is only applicable if the product has been installed by a competent person in
accordance with this installation manual and all current regulations and codes of practice at the time
of installation.
6.2.3. The guarantee is only applicable to those cases that concern material, design and manufacturing
defects, and under no circumstances covers damage to the product for the following reasons:
6.2.3.1 Damage caused by negligence and/or misuse of the product, i.e. used for other
purposes that are not construed as its normal use or for not respecting the instructions of use and
maintenance given by ROINTE as well as incorrect installation or use of the product that may not
comply with the current technical standards of safety.
6.2.3.2. Corrosion of any part of the product caused by direct exposure to salt water. When
the product is installed no more than 200m from the coast the guarantee for damages caused by
corrosion the period will be reduced by 50%.
6.2.3.3. Any unauthorised modification of the product or repairs of the product carried out
by third parties or unauthorised technicians or opening of the product by third parties or unauthorised
people.
6.2.3.4. Any accidents that are deemed outside the control of ROINTE, such as (but not limited
to): lightning, fires, floods, natural disasters, public disorder, atmospheric or geologic phenomena etc.
6.2.3.5. Faults that result from an incorrect installation. Guidance can be found within the
recommendations for installation, by Rointe and in the installation manual. If in doubt, please contact
ROINTE.

20
6.2.4. Any repairs or substitutions that are included in this guarantee do not allow any additions or
new periods of guarantee.
6.2.5. Any repairs or substitutions covered under this guarantee must be parts that are functionally
equivalent. The defective parts or parts removed or replaced shall become the property of ROINTE.
6.2.6. The product must be installed in a way that allows access for our technicians should they
need to gain access to the product for repair or maintenance. The user/client is responsible for any
costs or organisation required to provide access to the products for their repair and/or substitution.
6.3. The Technical Service department of ROINTE will advise you if you need to purchase any parts
not covered under the guarantee or out of guarantee.
6.4. This guarantee will be null and void if the product: has been manipulated, modified and/or repaired
in any way and/or by unauthorised persons. This guarantee will also be void if the product is not
correctly installed.
6.5. This guarantee is not transferable and does not include claims due to frost or limescale damage.
6.6. Proof of purchase will be required to ROINTE for any claim.
6.7. This guarantee does not affect your statutory rights.
6.8. This guarantee does not affect the buyer’s legal rights stipulated in the current national legislation,
nor affects those rights against the distributor or installer that could come forth in compliance with
the purchase contract.
6.9. In the absence of a national legal legislation applicable, this guarantee shall prevail and may be
construed as the buyer’s only protection. ROINTE, its offices, distributors and installers may not be
held responsible for any accidental damage that emerges due to infringement of any rules implicitly
related to this product.
6.10. Check the EULA conditions in the enclosed document for information about the legal agreement
you accept when installing our D-SERIES with DELTA Ultimate technology system.
For help about the product or guarantee, please contact ROINTE by telephoning 0203 321 5929
for Technical Support or by email to [e-mail].
7. European Directive (WEEE) 2012/19/UE
Under the European Directive 2012/19/UE on Waste Electrical and Electronic Equipment
(WEEE), the product cannot be disposed in the usual council bins and containers. They
must be separated to optimize the recovery and recycling of all of the components and
materials and reducing the impact to human health and the environment. The symbol of
the container crossed out over a horizontal line is marked on all of ROINTE products to
remind the consumer of the obligation to separate them on disposal. The consumer should
contact the local authority or original point of sale to learn more about the correct disposal
of this product.
