Ropeflex IBEX-RX2300 Installation guide

IBEX –RX2300
Assembly Instructions & Manual
DOC: 32-1017
Configuration subject to change

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
1
WARNING DECAL PLACEMENT
The decals shown here have been placed on
the equipment in indicated locations. If anyof
the decals are missing or illegible, call us toll-
free at 650.549.5888, Mondaythrough Friday,
9 a.m.until 5 p.m. Pacific Time, to order
replacement decals. Applyreplacement decals
in the locations shown.

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions before
using this equipment.
1. Read all instructions in this manual and
assemble as described before using this
equipment.
2. It is the responsibility of the owner to ensure
that all users of this equipment are
adequately informed of all precautions.
3. Use this equipment only on a level surface.
Cover the floor beneath to protect the
surface.
4. Keep children under 12 and pets away from
the equipment at all times.
5. Make sure all parts are properly tightened
each time you use this machine. Replace
any worn parts immediately.
6. Make sure the adjustment knobs are fully
engaged / disengaged before using the
equipment.
7. Always wear athletic shoes for foot
protection while exercising.
8. This equipment is designed to support a
maximum user weight of 300 pounds.
9. Pull on one the rope only and never grab a
rope in a way that prevents the drum from
rotating. Never attempt to hang on the rope
or frame. Pull rope with hands only.
10. If you feel pain or dizziness at any time
while exercising, stop immediately and
begin cooling down.
WARNING: Before beginning this or any exercise program, consult your physician. This is
especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. HiPEQ assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
3
Box Contents / Parts List
TOP MAST ASSEMBLY
ITEM
QUANTITY
DESCRIPTION
1
1
IBEX Drum with Rope (Display)
2
1
IBEX Seat (not installed)
3
6
Button Head Screw 5/16” x 1”
4
6
Washer 5/16”
Qty.1
IBEX Mast Assembly
Qty.6
Button Head Screw
5/16" x 1”
Qty.6
Washer 5/16"

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
4
Box Contents / Parts List
BOTTOM ASSEMBLY
ITEM
QUANTITY
DESCRIPTION
1
1
IBEX Base
2
8
Socket Head Screw 5/16” x 1”
3
8
Washer 5/16”
Qty.8
Button Head Screw
5/16" x 1”
Qty.8
Washer 5/16"
Qty.1
IBEX Base

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
5
Tools Required for Assembly
3/16 or 1/4 Hex Key for 5/16” Button Head Screws

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
6
Product Assembly
STEP 1
Parts:
IBEX Main Mast
IBEX Base
Hardware:
Button Head Screw 5/16” x 1”
Washer 5/16”
Tools:
3/16 or 1/4 Hex Key for 5/16” Button Head Screws
1-1 Attach IBEX Main Mast to IBEX Base as shown.
Install and completely tighten the hardware (use washer & screw).
Note: Do not attempt assembly alone. Recommended assembly position shown below.
IBEX Mast Assembly
IBEX Base
Hardware
(washer & screw)
Qty.8
Install seat after Mast Assembly
and Base are fastened together
(8 screws & washers)
Attach seat using 6 screws (with
washers)

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
7
Equipment Maintenance
WARNING: Routine inspection and maintenance is of critical importance to ensure maximum
safety and performance. We use the highest quality materials available, but wear is
inevitable. Be advised that dangerous conditions can arise even during a warranty period. A
warranty does not negate the owner’s responsibility to thoroughly, carefully and daily inspect
the machine. Consult your physician before starting your exercise program. For your own
safety, do not begin any exercise program without proper instruction.
1. Check Rope
While the machine is not in use carefully inspect the rope for damage and tears.
Carefully inspect connection of rope ends and make sure that stitching (threads) are
not torn or damaged. Do not use equipment until damaged rope has been replaced.
2. Upholstery
Wipe down after every workout.
Periodically take the time to use a mild soap or mild vinyl upholstery cleaner. Avoid
using any abrasive cleaner not intended for use on vinyl.
Keep sharp or pointed objects out of your pockets and clear of all upholstery.
3. Nuts/Bolts/Fasteners
Periodically inspect all nuts and bolts. Tighten if needed. If bolts seem to loosen
periodically, use Loctite 242 for a long-term cure.
Go through a re-tightening sequence periodically to ensure that all hardware is
properly tensioned.
4. Adjustments / Locking Pins / Tightening Knobs
Check all pieces for signs of visible wear or damage.
Check springs in Snap Links and Pop Pins for proper tension and alignment.
If the spring sticks or has lost its rigidity, replace it immediately.
5. Anti-Skid Surfaces
Replace if they appear worn or become slippery.
7. Warning Instruction Labels
Inspect and familiarize yourself with all safety warnings and other user information on
decals. Replace decals if damaged, illegible, or removed.

R X 2 3 0 0 A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 1 7 R E V . D
8
WARRANTY
We strive to offer the simplest and fastest resolution to all product related concerns.
Our warranty service program gives its customers the option to return the product for
repair, exchange or refund if the product is determined to be defective.
All products are warranted to the original purchaser.
Warranties apply and cover all defects in material and
workmanship.
Frame (excluding coating): Lifetime
Rope, Sheaves, Bearings and Labor: One-Year
Upholstery and Stitching: 90-Days
Electronics: One-Year
Customer is responsible for the cost of shipment to HiPEQ.
Company “ship to” address for product returns and service will be
provided once the RMA has been issued. It will be at HiPEQ’s
discretion to determine the party responsible for cost of shipment
back to customer.
Out-of-Warranty Products are repaired only with the customer’s
prior approval.
15 Day 100% Satisfaction Guarantee includes full refund of
purchase price, less shipping, handling and restocking fee equaling
15% of price during purchase. Email for more details. If you decide
to return a HiPEQ product, simply email us within 15 days to ask for
a return authorization number (RMA). Items must be returned in
original condition and packaging and postmarked no later than 2
weeks after the date of return authorization.

9
If you have any questions regarding HiPEQ
equipment or any instruction found in this document
please call 650.549.5888 for assistance.
HIPEQ LLC.
