Ropeflex ORYX2 Installation guide

–
Assembly Instructions & Manual
Configuration subject to change

O R Y X II A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M R E V . A
1
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions
before using this equipment.
1. Read all instructions in this manual and
assemble as described before using this
equipment.
2. It is the responsibility of the owner to ensure
that all users of this equipment are
adequately informed of all precautions.
3. Use this equipment only on a level surface.
Cover the floor beneath to protect the
surface.
4. Keep children under 12 and pets away from
the equipment at all times.
5. Make sure all parts are properly tightened
each time you use this machine. Replace
any worn parts immediately.
6. Make sure the adjustment knobs are fully
engaged / disengaged before using the
equipment.
7. Always wear athletic shoes for foot
protection while exercising.
8. This equipment is designed to support a
maximum user weight of 300 pounds.
9. Pull on one the rope only and never grab a
rope in a way that prevents the drum from
rotating. Never attempt to hang on the rope.
Pull rope with hands only.
10. If you feel pain or dizziness at any time
while exercising, stop immediately and
begin cooling down.
WARNING: Before beginning this or any exercise program, consult your physician. This is
especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. HiPEQ assumes no responsibility for personal injury or
property damage sustained by or through the use of this product.

O R Y X II A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M R E V . A
2
Contents / Parts List
ITEM
QUANTITY
DESCRIPTION
1
1
ORYX II Main mast
2
1
ORYX II Resistance drum (assembled)
3
1
ORYX II Rope (assembled)
4
1
ORYX II Rope U-Bolt (assembled)
5
1
ORYX II Seat assembly
6
1
ORYX II Drum cover (assembled)
7
4
Washer ½” SS (assembled)
8
4
Locknut ½” SS (assembled)
9
6
Washer 5/16”SS (assembled)
10
6
Socket Screw 5/16”-18 SS (assembled)
11
4
Socket Screw #10-32 SS (assembled)
12
10
Washer 1” Galvanized (un-assembled)
13
10
Nut 1”-8 Grade DH Galvanized (un-assembled)

O R Y X A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M R E V . A
3
Installation and Usage
WARNING: Follow installation and usage guidelines
1. Use only supplied hardware.
2. Contact HiPEQ if hardware is missing.
3. Contact HiPEQ to order additional or replacement parts.
4. All individual assemblies of the equipment shall be mounted on concrete
footing.
5. Concrete footing shall comply with all state and federal regulations.
6. Use Structural Hot-Dipped Galvanized J-Hook Anchors 1”-8 to secure
equipment (quantity 6 for main post and quantity 4 for seat assembly).
Minimum length shall be 36 inches. Anchors shall comply with ASTM F1554
Grade 105
7. 1”-8 Structural fasteners shall be properly torqued.
8. Do not hang on the rope or apply load in such a way where the rope is not
able move in endless circular motion. Doing so will void warranty.
9. Do not swing on the rope or pull the rope sideways. Doing so will void
warranty.
10.Avoid installation of the machine in dusty and sandy areas.

O R Y X A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M R E V . A
4
Installation and Usage
ROPE PULL
DIRECTION
MAIN MAST FLANGE
SEAT FLANGE

O R Y X A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M R E V . A
5
Equipment Maintenance
WARNING: Routine inspection and maintenance is of critical importance to ensure
maximum safety and performance. We use the highest quality materials available, but
wear is inevitable. Be advised that dangerous conditions can arise even during a
warranty period. A warranty does not negate the owner’s responsibility to thoroughly,
carefully and daily inspect the machine. Consult your physician before starting your
exercise program. For your own safety, do not begin any exercise program without
proper instruction.
1. Check Rope
While the machine is not in use carefully inspect the rope for damage and tears.
Carefully inspect connection of rope ends and make sure that stitching (threads) are
not torn or damaged. Do not use equipment until damaged rope has been replaced.
2. Nuts/Bolts/Fasteners
Periodically inspect all nuts and bolts. Tighten if needed. If bolts seem to loosen
periodically, use Loctite 242 for a long-term cure.
Go through a re-tightening sequence periodically to ensure that all hardware is
properly tensioned.
3. Adjustments / Locking Pins / Tightening Knobs
Check all pieces for signs of visible wear or damage.
Check springs in Snap Links and Pop Pins for proper tension and alignment.
If the spring sticks or has lost its rigidity, replace it immediately.
4. Warning Instruction Labels
Inspect and familiarize yourself with all safety warnings and other user information on
decals. Replace decals if damaged, illegible, or removed.

O R Y X A S S E M B L Y I N S T R U C T I O N S & M A N U A L O R Y X 2 - M - R E V . A
6
WARRANTY
We strive to offer the simplest and fastest resolution to all product related
concerns. Our warranty service program gives its customers the option to
return the product for repair, exchange or refund if the product is
determined to be defective.
All products are warranted to the original purchaser.
Warranties apply and cover all defects in material and
workmanship.
Frame (excluding coating): Lifetime
Rope, Sheaves, Bearings and Labor: One-Year
The customer is responsible for the cost of shipment to HiPEQ and
we will be responsible for the cost of shipment back to the
customer. Ship to:
HiPEQ LLC.
80 Glenn Way STE 8
San Carlos, CA 94070 USA
Out-of-Warranty Products are repaired only with the customers
prior approval.
15 Day 100% Satisfaction Guarantee includes full refund of
purchase price, less shipping, handling and restocking fee equaling
15% of price during purchase. Email for more details. If you decide
to return a HiPEQ product, simply email us within 15 days to ask for
a return authorization number (RMA). Items must be returned in
original condition and packaging and postmarked no later than 2
weeks after the date of return authorization.

7
If you have any questions regarding HiPEQ
equipment or any instruction found in this document
please call 650.549.5888 for assistance.
HIPEQ LLC.
80 Glenn Way STE 8
San Carlos, CA 94070
U.S.A
