Ropeflex RX2500T Installation guide

TRIPULL –RX2500T
Assembly Instructions & Manual
DOC: 32-1005T
Configuration subject to change

R X 2 5 0 0 T A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32-100 5 T R E V . A
1
WARNING DECAL PLACEMENT
The decals shown here have been placed on
the equipment in indicated locations. If anyof
the decals are missing or illegible, call us toll-
free at 650.549.5888, Monday through Friday,
9 a.m.until 5 p.m. Pacific Time, to order
replacement decals. Applyreplacement decals
in the locations shown.
Adjustable Pulley

R X 2 5 0 0 T A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32-100 5 T R E V . A
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions
before using this equipment.
1. Read all instructions in this manual and
assemble as described before using this
equipment.
2. It is the responsibility of the owner to ensure
that all users of this equipment are
adequately informed of all precautions.
3. Use this equipment only on a level surface.
Cover the floor beneath to protect the
surface.
4. Keep children under 12 and pets away from
the equipment at all times.
5. Make sure all parts are properly tightened
each time you use this machine. Replace
any worn parts immediately.
6. Make sure the adjustment knobs are fully
engaged / disengaged before using the
equipment.
7. Always wear athletic shoes for foot
protection while exercising.
8. This equipment is designed to support a
maximum user weight of 300 pounds.
9. Pull on one the rope only and never grab a
rope in a way that prevents the drum from
rotating. Never attempt to hang on the rope.
Pull rope with hands only.
10. If you feel pain or dizziness at any time
while exercising, stop immediately and
begin cooling down.
WARNING: Before beginning this or any exercise program, consult your physician. This is
especially important for persons over the age of 35 or persons with pre-
existing health problems. Read all instructions before using. HIPEQ assumes
no responsibility for personal injury or property damage sustained by or
through the use of this product.

R X 2 5 0 0 T A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32-100 5 T R E V . A
3
Contents / Parts List
ITEM
QUANTITY
DESCRIPTION
1
3
RX2500 Drum with Rope
2
3
RX2500T Main Mast
3
3
RX2500T Base
4
1
RX2500T Base Plate
5
3
RX2500 Seat
6
3
RX2500 Seat stand
7
3
Adjustable Pulley Assembly
8
18
Socket Head Screw 5/16”-18 x 1 ½”
9
42
Socket Head Screw 5/16”-18 x 1”
10
12
Socket Head Screw 5/16”-18 x 5/8”
11
12
Nut 5/16
12
78
Washer 5/16”
13
3
Mast Stiffening Plate
14
3
Binding Mid Bracket
15
6
Socket Screw 3/8”-16 x ¾”
16
3
Display bracket
17
3
LCD Display
18
3
LCD Display screw

R X 2 5 0 0 T A S S E M B L Y I N S T R U C T I O N S & M A N U A L 32- 1 0 0 5 T R E V . A
4
Tools Required for Assembly
3/16 or 1/4 Hex Key for 5/16” Button
5/16 Hex Key for 3/8” Socket Head Screws
Philips #2 Screw Driver
9/16 Hex Socket Ratchet Wrench
