ROSE DISPLAYS ANOFRAME VERSAMOUNT SCREW BASE User manual

Parts
35 Congress Street, Salem MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
AnoFrame VersaMountTM Screw Base
Step 1
Locate the two split rails and the solid
rail that is the same length as the split
rails.
Insert two corner brackets into each
end of the solid side Ano rail. Insert
one corner bracket into each end of
each split side Ano rail. Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame. Fig. 1
Step 2
For ceiling application, slide screw
tabs into channel of top Ano rail. For
wall applications, slide into side Ano
rail. Fig. 3
Step 3
Place one transitional collar over each
screw tab and push onto frame. Fig. 4.
Step 4
Finish assembling frame following the
sequence in Fig. 5.
Note: Placement of split rails will
depend on type of frame. Split rails
will be on the top for top-loading
frames and on the side for side-
loading frames.
split rails
solid rail
Instructions For Assembly
Incept-9.6.02
Figure 1
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountScrewBase
Figure 3
Corner
Brackets
AnoFrame
Rails
AnoFrame
Split Rails
Figure 2
Figure 4
Screw Tabs
Transitional
Collars Posts
Screw
Bases
Instruction Sheet (page 1 of 2)
solid rail
solid rail
split rails
Figure 5
Wood Screws
or Togglebolts
Screws
#97-0451R

Parts
Step 5
Screw posts onto screw tabs and
tighten. Fig. 6
Note: Use the end of the post with
the smaller opening.
Step 6
Insert one screw through the middle
opening on each screw base and into
the posts. Fig. 7
Tighten with screwdriver. Fig 8
Step 7
Install screw bases using wood screws
and screwdriver. Fig. 9
Note: Togglebolts are recommended
for drywall installations (predrilling
3/8” holes is necessary)
Step 8
Slide your graphic into the AnoFrame.
Fig. 10
Instructions For Assembly
Incept-9.6.02
Figure 6
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountScrewBase
Figure 7
Finished Look
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Instruction Sheet (page 2 of 2)
AnoFrame VersaMountTM Screw Base
Figure 8 Figure 9
#97-0451R
Figure
10

Parts
AnoFrame VersaMountTM Screw Base
Step 1
Locate the two split rails and the solid
rail that is the same length as the split
rails.
Insert two corner brackets into each
end of the solid side Ano rail. Insert
one corner bracket into each end of
each split side Ano rail. Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame. Fig. 1
Step 2
For ceiling application, slide screw
tabs into channel of top Ano rail. For
wall applications, slide into side Ano
rail. Fig. 3
Step 3
Place one transitional collar over each
screw tab and push onto frame. Fig. 4.
Step 4
Finish assembling frame following the
sequence in Fig. 5.
Note: Placement of split rails will
depend on type of frame. Split rails
will be on the top for top-loading
frames and on the side for side-
loading frames.
split rails
solid rail
Instructions For Assembly
Incept-9.6.02
Figure 1
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountScrewBase
Figure 3
Corner
Brackets
AnoFrame
Rails
AnoFrame
Split Rails
Figure 2
Figure 4
Screw Tabs
Transitional
Collars Posts
Screw
Bases
Instruction Sheet (page 1 of 2)
solid rail
solid rail
split rails
Figure 5
Wood Screws
or Togglebolts
Screws
#97-0451R

Parts
Step 5
Screw posts onto screw tabs and
tighten. Fig. 6
Note: Use the end of the post with
the smaller opening.
Step 6
Insert one screw through the middle
opening on each screw base and into
the posts. Fig. 7
Tighten with screwdriver. Fig 8
Step 7
Install screw bases using wood screws
and screwdriver. Fig. 9
Note: Togglebolts are recommended
for drywall installations (predrilling
3/8” holes is necessary)
Step 8
Slide your graphic into the AnoFrame.
Fig. 10
Instructions For Assembly
Incept-9.6.02
Figure 6
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountScrewBase
Figure 7
Finished Look
Instruction Sheet (page 2 of 2)
AnoFrame VersaMountTM Screw Base
Figure 8 Figure 9
#97-0451R
Figure
10
