ROSE DISPLAYS SIDE-LOADING ANOSKYBOX User manual

Parts
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Note: You will be assembling four frames.
Below instructions are for one frame only.
Repeat steps 1 & 2 for each frame.
Step 1
Locate two split rails and a solid rail that is
the same length as the split rails.
Insert two corner brackets in each end of
the solid side AnoFrame rail. Insert one
corner bracket into each end of each split
side AnoFrame rails. Fig. 1.
Note: Tension tabs on corner brackets face
towards outside of frame rails.
Step 2
Assemble frame following steps in Fig. 2
sliding sides together in the order shown.
Side-Loading AnoSkyBoxTM
Instructions for assembly
Incept-1.24.03
The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #03INSSideLoadingAnoSkyBox
Instruction Sheet
Figure 1
32 Corner
Brackets
12 AnoFrame Rails
12AF-100
8 AnoFrame
split rails
Figure 2
split rails
solid rail
solid rail
solid rail
split rails
12
34

Parts
split
rails
solid rail
solid rail
split rails
8 Corner
Braces 4 Spine Rails
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Step 3
Attach one corner brace onto one end of
each corner spine. Fig. 3.
Step 4
Screw into place and tighten. Fig. 4.
Step 5
Lay out AnoSkyBox parts as shown.
Be sure to lay out frames so each corner
contains matching frame sides — two
corners should contain only split rails and
two corners should contain only solid rails.
Fig. 5.
Note: Once side of each frame contains
split rails. When laying out your
AnoSkybox, make sure you match the
split rail sides of both frames to the same
corner spine. You should have only 2
corners containing split rails.
Instructions for assembly
Incept-1.24.03
The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #03INSSideLoadingAnoSkyBox
Figure 5
Figure 3 Figure 4
1 Ball Head
Screwdriver 8 Screws 4 Hanger Tabs
Side-Loading AnoSkyBoxTM Instruction Sheet

Parts
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Step 6
Attach frames to corner spines. Be sure
to insert bottom rib of corner brace into
bottom channel of the AnoFrame rail,
as shown in Fig. 6.
Repeat for all frames. Fig. 7.
Step 7
Attach one corner brace onto the top
of each corner spine rail. Fig. 8.
Step 8
If using the cable and loop for hanging,
insert loop into hanger tab. If using the
cable and saucer for hanging, insert saucer
into hanger tab. Fig. 9.
Step 9
Insert one screw into each hanger tab
and align with hole in top corner brace.
Fig. 10.
Step 10
Screw hanger tab into place. Fig. 11.
Instructions for assembly
Incept-1.24.03
The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #03INSSideLoadingAnoSkyBox
Figure 8
Figure 6 Figure 7
Figure 11Figure 10
8 Corner
Braces 4 Spine Rails
1 Ball Head
Screwdriver 8 Screws 4 Hanger Tabs
Figure 9
Side-Loading AnoSkyBoxTM Instruction Sheet

Parts
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Step 11
Insert one Velcro strap through each
corner containing split rails. Slide the
strap through the split rails. Fig. 12.
Step 12
Tighten and secure in place on the inside
of the AnoSkyBox. Fig. 13.
Step 13
Suspend AnoSkyBox through hanger
tabs with appropriate Rose Displays
hanging accessories.
Step 14
Insert graphics. Fig. 14.
Instructions for assembly
Incept-1.24.03
The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSSideLoadingAnoSkyBox
Figure 14
2 Velcro Straps
Figure 12 Figure 13
Side-Loading AnoSkyBoxTM Instruction Sheet
