ROSE DISPLAYS ANOFRAME VERSAMOUNT CLAMP BASE SQ User manual

Parts
35 Congress Street, Salem MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
AnoFrame VersaMount
TM
Clamp Base
split rails
solid rail
solid rail
solid rail
split rails
Incept-9.6.02
Figure 1
Figure 5
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountClampBaseSQ
Figure 3
Corner
Brackets
AnoFrame
Rails
AnoFrame
Split Rails
Figure 2
Figure 4
Screw Tab Transitional
Collar
Vertical
Post
Clamp Base
Instruction Sheet (page 1 of 2)
#97-0421SQ
Step 1
Locate the two split rails and the solid
rail that is the same length as the split
rails.
Insert corner brackets into side
AnoFrame rails. Insert two corner
brackets into each end of the solid side
Ano rail. Insert one corner bracket
into each end of each split side Ano
rail. Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.
Step 2
Slide screw tab into channel of bottom
Ano rail. Fig. 3.
Step 3
Place transitional collar over screw tab
and push onto frame. Fig. 4.
Step 4
Finish assembling frame following the
sequence in Fig. 5.
Note: Placement of split rails will
depend on type of frame. Split rails
will be on the top for top-loading
frames and on the side for side-
loading frames.
Instructions For Assembly

Parts
Step 5
Screw vertical post onto screw tab on
frame and tighten. Fig. 6
Note: Use the end of the post with
the smaller opening.
Step 6
Screw the clamp base onto the end of
the vertical post and tighten. Fig 7
Step 7
Slide your graphic into the AnoFrame.
Fig. 8
Instructions For Assembly
Incept-9.6.02
Figure 6
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountClampBaseSQ
Figure 8
Figure 7
AnoFrame VersaMount
TM
Clamp Base
Finished Look
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
#97-0421SQ
Instruction Sheet (page 2 of 2)
